INSTALLATION INSTRUCTIONS
10mm
SCREEN 1D1P, SHP,10mm
K-99167T
PURIST UPGRADE
-1-
, 2014
Copyright Kohler China Ltd., 2014
BEFORE YOU BEGINBEFORE YOU BEGIN
·
·
·
·
·
·
3
(
) 80mm
3mm/m
·
·
·
·
·
·
Before you install your shower door, please read
these instructions carefully to familiarize yourself
with the required tools, materials, and installation
sequences. Follow the sections that pertain to your
particular installation. This will help you avoid costly
mistakes. In addition to proper installation, read all
operating and safety instructions.
All information is based on the latest product
information available at the time of publication.
Kohler China Ltd. reserves the right to make
changes in product characteristics, packaging, or
availability at any time without notice.
These instructions contain important care, cleaning,
and warranty information-
Make sure that the bath and the finished wall
material are completely and correctly installed prior
to installing your shower door. Prepare waterproof
layer to wall and floor of the showering area. It is not
allowed for any presence of electric switches and
sockets. Make sure the floor drain runs smoothly.
Before starting the door installation, lay out and
identify all the parts. Use the exploded view
illustrated on page 3 for reference.
For the installation method of customized shower
with different dimensions, please refer to this
instructions.
Tempered glass cannot be cut, drilled or
knocked by hard object. Make sure corner area
of the glass refraining from knocking so as to
cause personal injury due to broken glass.
Please install this door on Kohler
receptors or curbs (Not included). If the curb is not
Kohler-branded, please note its top width should be
more than 80mm.
The shower door requires a flat vertical
finished wall. The squareness of the wall is
recommended no more than 3 mm/m. KOHLER
Company won't take responsibility of the installation
quality.
please leave these
instructions for the consumer.
CAUTION: Risk of injury or product damage.
ATTENTION:
IMPORTANT:
1223345-T01-A

-2-
ROUGHING-IN
Unit: mm
Wall Channel
Glass Clamp
Side Frame
Door Glass
Bottom Frame
Hingelite Panel
Side Seal
PARTS IDENTIFICATIONPARTS IDENTIFICATION
BHSKU
K-99167T 900-1600 1850-2000
Purist Bracket Assy
X1
Purist Top Hinge Assy
Purist Bottom Hinge Assy
Purist Handle Assy
4mm Allen Key
4mm
3mm Allen Key
3mm
2.5mm Allen Key
2.5mm 2mm Allen Key
2mm
X1
X1 X8
X8
Cover
X1
B
H
1223345-T01-A

0mm
STEP
2
STEP
1
-3-
·
·
·
·
·
·
·
·
·
·
·
·
·
Phillips Screwdriver
Pencil
Caulk Gun
Measuring Tape
Safety Glasses
Center Punch
Hammer
Knife
Masonry Drill & 6mm Drilll Bit
Level
Drop Cloth
Materials Required
Tape
Silicone Sealant
Tools Required
·
·
·
·
·
·
·
·
·
·
·
·
·
6mm
INSTALLATION REQUIREMENTSINSTALLATION REQUIREMENTS
INSTALLATION
Pre-install the bottom rail with seals and then put it
onto the threshold.
Pre-install seals onto the wall channel and then fix it.
6mm
Wall jamb
be
plumb.
MUST
Align
1223345-T01-A

-4-
STEP
4
STEP
3
Fix the bottom hinge onto the side panel.
STEP
5
Fix the wall channel and glass on the other side by
following the same steps.
Pre-install seals onto the wall channel and then fix it.
Insert the hingelite panel into the wall channel.
Adjust the two side panels to make them 662mm
apart.
662mm
STEP
6
<8
662
662
1223345-T01-A

-5-
STEP
10
STEP
9
Remove the upper and bottom hinge covers and the
clamp plates.
Lift the door glass and insert into the bottom hinge.
STEP
8
Fix the upper hinge onto the door glass.
STEP
7
Tighten the screws of the wall channels and clamp the
side panels.
Ensure the door is fully
supported at all times.
IMPORTANT:
1223345-T01-A

0mm
-6-
STEP
12
Fix the upper clamp plate. Adjust the rollers to make
the door glass level. Tighten the clamp plate.
STEP
11
Fix the clamp plate into the bottom hinge to tightly clip
the glass. Pay attention to the direction of the rubber
gasket.
STEP
13
STEP
14
If 90 degree is not suitable, please turn the set screw
slightly and try again.
90
Install door handle.
1223345-T01-A

-7-
STEP
16
STEP
15
Fix door seal and side seal. Fix bottom seal.
Inward-opening door
Outward-opening door
Inside
Inside
Outside
Outside
STEP
17
STEP
18
Drill a 3.3 hole. Fix the bottom hinge and side panel
block to the bottom panel.
3.3
Adjust to a proper angle and install the handle.
X2
X2
0mm
1223345-T01-A

-8-
STEP
19
Fix upper and bottom hinge covers.
STEP
20
Tighten the upper and bottom hinge covers by
tightening the screw.
STEP
21
STEP
22
Fix other decorative covers. Apply a thin layer of silicone seal on the bottom frame.
1223345-T01-A

-9-
STEP
23
24hrs
Do not use the enclosure for at least 24 hours.
24
