Kohler RAIN DUET 15344T User manual

1242170-2A-A 1
INSTALLATION INSTRUCTIONS
15344T Multi-Function Handspray
45973T Traditional Handspray
RAIN DUET
BEFORE YOU BEGIN
ROUGH-IN DIMENSIONS
All information is based on the latest product information available at the time of publication. Kohler Co. reserves
the right to make changes in product characteristics, packaging, or availability at any time without notice.
Please leave these instructions for the consumer. They contain important information.
NOTES:
1. Flush the water supply pipes throughly to remove debris.
2. The highest working pressure for handspray is 0.5MPa(5 bar). If it exceeds 0.5MPa(5 bar), a pressure reducer
is needed. The highest water and environment temperature is 60°C. Please keep handspray, showerhead and the
shower arm away from heater, or it may become damaged and cause injury to the user.
STANDARD APPLICABLE
Special model meets or exceeds the following at date of manufacture: TIS
244
G1/2˝ G1/2˝
50.7
Ø122
Ø122
79
255
15344T 45973T

1242170-2A-A 2
CLEANING INSTRUCTIONS
All Finishes: Clean the finish with mild soap and warm water. Wipe entire surface completely dry with clean soft
cloth. Many cleaners may contain chemicals, such as ammonia, chlorine, toilet cleaner etc. which could adversely
affect the finish and are not recommended for cleaning.
Do not use abrasive cleaners or solvents on Kohler faucets and fittings.
SERVICE PARTS
OPERATING INSTRUCTIONS
INSTALLATION
**Color code must be specified when ordering
How to Clean the Nozzles
Any debris or mineral build-up may cause the flow stream to become distorted
or reduce the flowrate. To remove the debris or mineral build-up, run water
through the handspray, firmly press or rub your finger back and forth across
the rubber nozzles.
Flush both water supply for about one minute before the handspray is
installed.
Place the check valve(2) into the handspray(1) according to the drawing.
Note: Keep the O-ring of the check valve downward.
Install flow regulator(3) into the shower inlet if needed.
Note: If working pressure is too low, regulator is not needed.
Put the screen washer(4) into the shower hose(5, not provided) connector.
Attach the handspray to shower hose. Note: Don’t over tighten.
Connect another end of shower hose to the water supply.
3
5
2
1
4
1030624
77420
1240266
