Kohler SKYLINE K-705876T-FM-SHP User manual

INSTALLATION INSTRUCTIONS
SLIDING, SCREEN, 1D1P, 8mm
8mm
K-705876T-FM-SHP
SLIDING, SCREEN, 1D1P, 10mm
10mm
K-81512T-FM-SHP
SKYLINE
-1-
BEFORE YOU BEGINBEFORE YOU BEGIN
·
·
·
·
·
·
3
(
) 80mm
3mm/m
·QB 2584-2007
·
·
·
·
·
·
Before you install your shower door, please read
these instructions carefully to familiarize yourself
with the required tools, materials, and installation
sequences. Follow the sections that pertain to your
particular installation. This will help you avoid costly
mistakes. In addition to proper installation, read all
operating and safety instructions.
All information is based on the latest product
information available at the time of publication.
Kohler China Ltd. reserves the right to make
changes in product characteristics, packaging, or
availability at any time without notice.
These instructions contain important care, cleaning,
and warranty information-
Make sure that the bath and the finished wall
material are completely and correctly installed prior
to installing your shower door. Prepare waterproof
layer to wall and floor of the showering area. It is not
allowed for any presence of electric switches and
sockets. Make sure the floor drain runs smoothly.
Before starting the door installation, lay out and
identify all the parts. Use the exploded view
illustrated on page 3 for reference.
For the installation method of customized shower
with different dimensions, please refer to this
instructions.
Tempered glass cannot be cut, drilled or
knocked by hard object. Make sure corner area
of the glass refraining from knocking so as to
cause personal injury due to broken glass.
Please install this door on Kohler
receptors or curbs(Not included). If the curb is not
Kohler-branded, please note its top width should be
more than 80mm.
The shower door requires a flat vertical
finished wall. The squareness of the wall is
recommended no more than 3 mm/m. KOHLER
Company won't take responsibility of the installation
quality.
please leave these
instructions for the consumer.
CAUTION: Risk of injury or product damage.
ATTENTION:
IMPORTANT:
·The product complies with QB 2584-2007.
ZHONGSHAN KOHLER SHOWER CO., LTD. NO13-1, XINYE ROAD, ZHONGSHAN TORCH
DEVELOPMENT ZONE, ZHONGSHAN, GUANGDONG, CHINA POST CODE: 528437
13-1 528437
©
©
Copyright Kohler China Investment Co., Ltd. 2016
2016
1278975-T01-A

-2-
ROUGHING-IN
Unit: mm
BH
SKU
K-81512T
K-705876T 1200-1600 1850-2000
800-820-2628
IMPORTANT
800-820-2628
Before installation check that all components are
correctly supplied.
If any parts are missing please ring the helpline.
PARTS IDENTIFICATIONPARTS IDENTIFICATION
B
H
H
B
1278975-T01-A

-3-
X2 X2
X2
X2
X2
X6
X5
X2
X8
X16
X1
X2
X5
X1
X1
X2
X1
X1
X2
X1
X2
X1
Side Waterproof Seal,
Skyline Sliding
Cover Extrusion,
Skyline Sliding Top Rail, 1D1P,
Skyline Sliding
Wall, Skyline Sliding
Wall Jamb, Skyline Sliding
Panel Glass, Skyline Sliding
Insert Seal
U Seal, Skyline Sliding
U
L Metal Handle,
Skyline Sliding
Bottom Rail, 1D1P,
Skyline Sliding
Bottom Roller Assy,
Skyline Sliding
Straight Magnetic Seal,
Stance
Wall Jamb, 1D1P,
Skyline Sliding
1D1P
Insert Magnetic Seal,
Stance
Straight Magnetic Seal,
Stance
Top Roller Assy,
Skyline Sliding
Door Glass, Skyline Sliding
Csk Screw ST3.5X6 ST3.5X6
Top Roller Assy, Skyline Sliding
Bottom Roller Assy, Skyline Sliding
Top Cover-B, Skyline Sliding
Top Cover-A, Skyline Slidin
Twist Lock Jamb Moulding, Assy, Skyline Sliding
Screw Cap, Bar
Pressing Block, Skyline Slidin
Hollow Wall Anchor, Nylon
Pan Screw ST3.5X40 ST3.5X40
Csk Screw ST3.5X20.5 ST3.5X20.5
Csk Screw ST3.5X12 ST3.5X12
Wall, Skyline Sliding
Wall Jamb, 1D1P, Skyline Sliding 1D1P
Wall Jamb, Skyline Sliding
Rail, L Shape, Skyline Sliding
Insert Magnetic Seal, Stance
Straight Magnetic Seal, Stance
Side Waterproof Seal, Skyline Sliding
Insert Seal
U Seal, Skyline Sliding U
L Metal Handle, Skyline Sliding
1278975-T01-A

·
·
·
·
·
·
·
·
·
·
·
·
·
Phillips Screwdriver
Pencil
Caulk Gun
Measuring Tape
Safety Glasses
Center Punch
Hammer
Knife
Masonry Drill & 6mm Drilll Bit
Level
Drop Cloth
Materials Required
Tape
Silicone Sealant
Tools Required
·
·
·
·
·
·
·
·
·
·
·
·
·
6mm
INSTALLATION REQUIREMENTSINSTALLATION REQUIREMENTS
INSTALLATION
Mark the wall 20mm in from the
front edge of the tray on both
sides.
20mm
STEP
1
IMPORTANT:
MUSTTray be level
along front edge.
Mark the wall 20mm in from the front edge of the tray.
20mm
IMPORTANT
Tray must be level in all planes
or door will not install properly.
0mm
-4-
1278975-T01-A

-5-
STEP
2
Fix the top and bottom frames on the wall jamb.
0mm
The wall jamb
be kept vertical.
must
The wall jamb
be kept vertical.
must
0mm
Fix wall jambs. One is fixed on the wall. The other is not fixed on the wall after the holes are drilled.
20mm
Note: There is only holes
on the top frame.
Section of frame
Inside
Outside
A
A
6mm
STEP
3
Note: Before fixing top and
bottom frames, make sure wall
and wall jamb is properly
connected.
1278975-T01-A

-6-
STEP
6
Insert fixed glass into top and bottom rails and
then into wall jambs. Install anti-bounce
assembly.
STEP
5
Adjust the top and bottom frames vertical. The length shall be
the same on two sides. Then rotate the lock to fix wall jamb.
,
Insert the unfixed wall jamb into the frame. Then insert the whole wall jamb and fix the unfixed wall jamb.
STEP
4
The wall jamb
be kept vertical.
must
0mm
Insert the unfixed wall jamb.
XX
Rotate
clockwise to
lock.
IMPORTANT:
MUSTTray be level
along front edge.
0mm
Use U-shaped protective seals on
top and bottom of the fixed glass.
U
1278975-T01-A

-7-
Install and adjust door glass.
STEP
7
STEP
8
Insert side seal into the inside of the fix glass. Install blocks on top and bottom frames to make the fixed glass
firm.
Insert side seal.
Install blocks.
Install top roller.
Install bottom roller.
1278975-T01-A

-8-
STEP
11
Apply silicone sealant to bottom of the fixed glass and
both sides of the bottom threshold.
STEP
10
Install cover extrusion and top cover.
STEP
9
Install seals and handle.
Note: Cut the seals to proper
length to prevent scrunching
the wall jamb and glass.
Install decorative seal.
1278975-T01-A

Do not use the enclosure for at least 24 hours.
24
24hrs
STEP
12
-9-
1278975-T01-A
