Kohler K-706145 Assembly instructions

Installation and Care Guide
Sliding Shower Door
Mproduct numbers are for Mexico (i.e. K-12345M)
Los números de productos seguidos de Mcorresponden a México
(Ej. K-12345M)
Français, page “Français-1”
Español, página ″Español-1”
K-706145, K-706147
1280799-2-B

Tools and Materials
Before You Begin
WARNING: Risk of serious injury. Damage prior to installation can result in glass shattering.
Inspect the glass and all parts for damage before installation.
WARNING: Risk of serious injury. Improper installation can result in glass shattering. Follow all
installation instructions.
WARNING: Risk of serious injury. Do not cut tempered glass. Tempered glass will shatter if cut.
WARNING: Risk of serious injury. Shower door and side panels can shatter. Regularly inspect the
glass and all parts for damage, missing or loose parts.
WARNING: Risk of serious injury. Always wear safety glasses while cutting and drilling.
CAUTION: Risk of personal injury. Tempered glass should not contact hard surfaces or it may
shatter. Do not touch the edge of the tempered glass panel with tools or any hard objects.
IMPORTANT! Leave this manual for the end user. Read these instruction before installing or using this
product.
IMPORTANT! This door is designed to accommodate walls that are less than 3/8″(10 mm) out of plumb.
Verify the area the door will be attached to is within 3/8″(10 mm) of plumb. The door may not function
properly if the wall is more than 3/8″(10 mm) out of plumb.
Before starting the installation, lay out and identify all of the parts. Inspect them for damage.
Closely follow the manufacturer’s instructions pertaining to the sealant application on the door.
Sealing areas other than those shown may cause leaking.
Two people should perform this installation.
If your model includes a return panel, follow the return panel instructions and consult these
instructions as needed.
Included:
•6 mm Drill Bit
• 2 mm and 3 mm Hex Wrench
Caulk Gun 100% Silicone Sealant
1280799-2-B 2 Kohler Co.

Parts Identification
Track
Cover Strip
Cover Strip
Wall Jamb
Seal
Cap
Cap
Cap
Wall Jamb
Magnetic
Strip
Seal
Track
Handle
Screw
Cap
Track Seal
Track Seal
Door
Fixed Panel
Fixed Panel
Seal
Kohler Co. 3 1280799-2-B

1. Prepare for Installation
NOTE: Cover the drain hole to avoid losing parts.
Confirm the shower base is level.
Confirm the walls are within 3/8″(10 mm) of plumb.
Mark the walls 3/8″(10 mm) from the front edge of the bath or shower base.
3/8"
(10 mm)
3/8"
(10 mm)
1280799-2-B 4 Kohler Co.

2. Install the Fixed Panel Seal
Remove the wall jamb from the fixed panel.
Unroll and attach the fixed panel seal.
Install the seal to the top of the fixed panel.
Cut the seal to the correct length.
Kohler Co. 5 1280799-2-B

3. Install the Track
Insert the track seal into the track.
Spray water on the fixed panel seal for lubrication.
Position the track over the fixed panel seal.
Confirm the fixed panel seal is properly seated in the track.
Secure the track in place with the provided screws.
Track Seal
Track
Fixed Panel
Seal
1280799-2-B 6 Kohler Co.

4. Install the Second Seal
Rotate the assembly to position the track on the floor.
Unroll and attach the fixed panel seal to the fixed panel.
Cut the seal to the correct length.
Track
Kohler Co. 7 1280799-2-B

5. Install the Second Track
Insert the door seal into the track.
Align the side frame with the track.
Spray water on the fixed panel seal for lubrication.
Position the track over the seal.
Confirm the seal is correctly located.
Secure in place with the provided screws.
1280799-2-B 8 Kohler Co.

6. Mark the Wall Jamb Locations
Position a wall jamb at the mark 3/8″(10 mm) from the front ledge of the shower base.
Plumb the wall jamb using a level.
Temporarily secure the wall jamb with masking tape.
Make a pencil mark at each of the four slot locations in the wall jamb.
Remove the masking tape, then move the wall jamb to a safe area.
IMPORTANT! The supplied 6 mm drill bit is not suitable for drilling through tile. For tile installations,
usea6mmtile bit.
Slowly drilla6mmhole at each of the four marked hole locations, using the provided 6 mm drill
bit for non-tiled walls.
IMPORTANT! The provided wall anchors may not be appropriate for all wall material. Use another wall
anchor when needed.
Insert an anchor in each hole. Make sure the anchors are flush with the finished wall.
3/8"
(10 mm)
6 mm
Kohler Co. 9 1280799-2-B

7. Install the Wall Jambs
Position the second wall jamb at the mark 3/8″(10 mm) from the front ledge of the shower base.
Plumb the wall jamb using a level.
Temporarily secure the wall jamb with masking tape.
Make a pencil mark at each of the four slot locations in the wall jamb.
Remove the masking tape, then move the wall jamb to a safe area.
IMPORTANT! The supplied 6 mm drill bit is not suitable for drilling through tile. For tile installations,
usea6mmtile bit.
Slowly drilla6mmhole at each of the four marked hole locations, using the provided 6 mm drill
bit for non-tiled walls.
IMPORTANT! The provided wall anchors may not be appropriate for all wall material. Use another wall
anchor when needed.
Insert an anchor in each hole. Make sure the anchors are flush with the finished wall.
Secure the wall jamb to the wall using the four #8 x 1-1/2″screws.
3/8"
(10 mm)
6 mm
1280799-2-B 10 Kohler Co.

8. Install the Door Assembly
Slide the second wall jamb onto the frame on the side opposite the installed wall jamb.
Angle the door frame and slide it into the installed wall jamb.
Pivot the other side of the door frame into place.
Confirm the door assembly is correctly positioned in the opening.
Open the door.
On the handle side of the frame, insert the supplied screw guide into one of the screw holes.
Insert a #8 x 1-1/2″screw into the screw guide and tighten.
Remove the screw guide.
Repeat for the other three screws.
Kohler Co. 11 1280799-2-B

9. Secure the Door Panel
Position the door inside the shower with the rollers toward the tracks.
Turn the locking screw clockwise to move and lock the rollers in the top position.
Carefully move the rollers into position on the top track.
Install the roller covers.
Position the top rollers on the top track.
Gently slide the bottom rollers into the bottom track.
Locking
Screw
1280799-2-B 12 Kohler Co.

10. Adjust the Door
If the door is out of square:
Unlock the roller assemblies by turning the screw counterclockwise with the supplied 3 mm hex
wrench.
Adjust the door until it is properly aligned.
Lock the roller assemblies by turning the locking screw clockwise.
Install the covers.
Kohler Co. 13 1280799-2-B

11. Attach the Bottom Rollers
Unlock the bottom roller assembly by turning the locking screw counterclockwise with the supplied
hex wrench.
Adjust both roller assemblies up or down until they install correctly in the bottom track.
Press the button to release the rollers from the bottom track.
Lock the rollers by turning the locking screw clockwise.
Install the covers.
1280799-2-B 14 Kohler Co.

12. Install the Seals
Install the magnetic strip to the handle side of the door panel.
Install a non-magnetic seal to the other side of the door panel.
Install a seal to the fixed glass panel.
Seal
Magnetic
Strip Seal
Kohler Co. 15 1280799-2-B

13. Install the Cover Strips
IMPORTANT! The magnetic strip must be located on the correct side or the door will not properly close.
On the wall jamb opposite the fixed panel, install the magnetic strip by inserting it at an angle and
pressing it into place .
Lubricate the rubber strip with dish soap.
Install a rubber strip to both wall jambs.
Install the cover strip.
1280799-2-B 16 Kohler Co.

14. Install the Handle
Position the handle with the inserts on the door. The inserts should go through the corresponding
holes.
Install gaskets on the inserts.
Slide the second handle onto the inserts.
Secure the handle by tightening the two setscrews in the handle.
Kohler Co. 17 1280799-2-B

15. Complete the Installation
NOTE: Thoroughly clean all dust, dirt, or grease from the bottom track and shower ledge surfaces where
sealant will be applied. Make sure the surfaces are dry.
IMPORTANT! Carefully follow the silicone sealant manufacturer’s instructions for application and curing
time.
NOTE: When applying silicone sealant, tape the area and use alcohol pads or denatured alcohol for
cleanup.
Apply silicone 100% sealant to the seams as shown.
Apply a small amount of silicone sealant to the top of the wall jamb.
Install the cover to the top of the wall jamb.
Install the bumper to the top track.
Install the bumper to the bottom track.
Care and Cleaning
For best results, keep the following in mind when caring for your KOHLER product:
•Always test your cleaning solution on an inconspicuous area before applying to the entire surface.
•Wipe surfaces clean and rinse completely with water immediately after applying cleaner. Rinse and
dry any overspray that lands on nearby surfaces.
•Do not allow cleaners to soak on surfaces.
•Use a soft, dampened sponge or cloth. Never use an abrasive material such as a brush or scouring
pad to clean surfaces.
•The ideal cleaning technique is to rinse thoroughly and wipe the product dry after each use.
Apply silicone
sealant.
1280799-2-B 18 Kohler Co.

Care and Cleaning (cont.)
For detailed cleaning information and products to consider, visit www.kohler.com/clean. To order Care &
Cleaning information, call 1-800-456-4537.
Warranty
ONE-YEAR LIMITED WARRANTY
KOHLER plumbing products are warranted to be free of defects in material and workmanship for one year
from date of installation.
Kohler Co. will, at its election, repair, replace or make appropriate adjustment where Kohler Co. inspection
discloses any such defects occurring in normal usage within one (1) year after installation. Kohler Co. is not
responsible for removal or installation costs. Use of in-tank toilet cleaners will void the warranty.
To obtain warranty service contact Kohler Co. either through your Dealer, Plumbing Contractor, Home
Center or E-tailer, or by writing Kohler Co., Attn.: Customer Care Center, 444 Highland Drive, Kohler, WI
53044, USA, or by calling 1-800-4-KOHLER (1-800-456-4537) from within the USA and Canada, and
001-800-456-4537 from within Mexico, or visit www.kohler.com within the USA, www.ca.kohler.com from
within Canada, or www.mx.kohler.com in Mexico.
IMPLIED WARRANTIES INCLUDING THAT OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE ARE EXPRESSLY LIMITED IN DURATION TO THE DURATION OF THIS
WARRANTY. KOHLER CO. AND/OR SELLER DISCLAIM ANY LIABILITY FOR SPECIAL,
INCIDENTAL OR CONSEQUENTIAL DAMAGES. Some states/provinces do not allow limitations on how
long an implied warranty lasts, or the exclusion or limitation of special, incidental or consequential damages,
so these limitations and exclusions may not apply to you. This warranty gives you specific legal rights. You
may also have other rights which vary from state/province to state/province.
This is Kohler Co.’s exclusive written warranty.
Kohler Co. 19 1280799-2-B

Guide d’installation et d’entretien
Porte de douche coulissante
Outils et matériel
Avant de commencer
AVERTISSEMENT: Risque de blessures graves. Des dommages avant l’installation peuvent
entraîner des éclatements de verre. Inspecter le verre et toutes les pièces pour y rechercher des
dommages avant l’installation.
AVERTISSEMENT: Risque de blessures graves. Une installation incorrecte peut entraîner des
éclatements de verre. Suivre toutes les instructions d’installation.
AVERTISSEMENT: Risque de blessures graves. Ne pas couper le verre trempé. Le verre trempé
éclate lorsqu’il est coupé.
AVERTISSEMENT: Risque de blessures graves. La porte de la douche et les panneaux latéraux
peuvent éclater. Inspecter régulièrement le verre et toutes les pièces pour y rechercher des
dommages, ou des pièces manquantes ou desserrées.
AVERTISSEMENT: Risque de blessures graves. Toujours porter des lunettes de sécurité pendant
la découpe et le perçage.
ATTENTION: Risque de blessures. Le verre trempé ne doit pas entrer en contact avec des surfaces
dures, car il risquerait de se briser. Ne pas toucher le bord du panneau de verre trempé avec des
outils ou d’autres objets durs.
IMPORTANT! Laisser ce manuel pour l’utilisateur final. Lire ces instructions avant d’installer ou d’utiliser
ce produit.
IMPORTANT! Cette porte est conçue pour s’adapter à des murs qui ont un faux aplomb de moins de
3/8″(10 mm). Vérifier que la zone sur laquelle la porte sera fixée est comprise dans un rayon de 3/8″(10
mm) de l’aplomb. La porte risque de ne pas fonctionner correctement si le faux aplomb du mur est
supérieur à 3/8″(10 mm).
Avant de commencer l’installation, étaler et identifier toutes les pièces. Vérifier qu’elles sont en bon
état.
Inclus:
• Mèche de 6 mm
• Clé hexagonale de 2 mm et 3 mm
Pistolet à mastic Mastic à la silicone à 100%
Kohler Co. Français-1 1280799-2-B
