Kohler SEQUOIA User manual

Kohler Co. 1 1142938-X2-B
BEFORE YOU BEGIN 
PARTS IDENTIFICATION 
• Please read these instructions carefully to familiarize yourself
with the required tools, materials, and installation sequences.
Follow the sections that pertain to your particular installation.
This will help you avoid costly mistakes. In addition to proper
installation, read all operating and safety instructions.
• All information in these instructions is based upon the latest
product information available at the time of publication.
Kohler China. reserves the right to make changes in product
characteristics, packaging, or availability at anytime without
notice.
• These instructions contain important care, cleaning and warranty
information - please leave instructions for the consumer.
• Beforeinstallationcarefullyinspectthenewxtureforany
signs of damage.
Parts supplied with your cabinet. (For cabinet body and door
replacement, call customer service with model number.)
Be sure to check the cardboard supports in the carton, glass
parts are packed in them.
• 
 

 
 
• 
 
 
• 
 
• 




Wall Anchors

#8 x 1-1/2" Philips Head
Screws

Top Clips
 Hole Plugs W

280 mm Mounting Bar

2 Glass Shelves

Snap-in Pins

#8 x 2" Hex Head Slotted
Screws

INSTALLATION AND CARE GUIDE
ขอแนะนําการติดตั้งและการดูแลรักษา
SEQUOIA MIRRORED CABINET
ตู้กระจก รุ่นเซควาญา
K-12098X

1142938-X2-B 2 Kohler Co.
INSTALLATION 
Fig.1/ 
Install Mirror Cabinet
Remove the grey decorative lid on top of the mirrored cabinet
andtheblackjunctionboxinside.
NOTE: Installing the cabinet on a wall without the door attached
can make installing easier for one person. Do not mount the doors
untiltheboxesisinoronthewall.





ROUGHING-IN 
UNIT:mm

Finished Wall/
ผนัง
800
700
125

Kohler Co. 3 1142938-X2-B
A. Install Mounting Bar
1. Drill two 5 mm holes in bottom mounting bar at
indent location.
2. Drill 6 mm hole in wall for mounting bar anchors at
locations shown in Fig.2. (If you do not use the anchor,
drill a 2 mm pilot hole.) After the holes are drilled,
  tthemountingbarontothewall,refertoFig.2for
measurements, and Fig.5 for information on anchor
cinching.
 
 

 
 
 
Fig.2/ 
260 mm From Edge Side of Cabinet
จากด้านข้างของตู้กระจก 260 มม.
20 mm Bottom of Cabinet
จากขอบด้านล่างของตู้กระจก 20 มม.
Position and drill two holes
in mounting bar.
จัดตําแหนงและเจาะรูผานรูบนฐานยึดกระจก
ตามตําแหนงที่กําหนดไว
B. Install Top Clips
 Takeoutthetopmountclip,wallanchorandhexhead
screw ready for installation See Fig.3.


Wall Anchor (If Required)

Top Mount Clip

8 x 2" Hex Head Screw (Use 6 mm Driver)

Fig.3/ 

1142938-X2-B 4 Kohler Co.
1. Fit cabinet into position on mounting bar (Fig.4.1)
2. Place clip in position as shown in Fig.4.2 and mark with
a pencil. Remove clip and cabinet and drill the pilot or
anchor holes where marked.


 
 
#8 x 2" Hex Head Screw & Wall Anchor
(Use x 6 mm Driver)
สกรู #8 x 2" และพุก (ใช้ดอกสว่าน 6 มม.)
4.3
4.4
Once Screw is bottomed out on
mount clip, turn screw and additional
5 to 7 turns to fully expand the anchor.
เมื่อขันสกรูเขากับคลิปดานบน
ใหขันสกรู 5 ถึง 7 รอบเพื่อขยายพุก
Side view at top of cabinet.
มุมด้านข้างของตู้กระจก
Cabinet bottom sits in lip
on bottom mounting bar.
ตูกระจกดานลางจะชิดกับดานลาง
ของฐานรองขอแขวน
4.2
4.1
 3.Fixboththeclipsintopositionwithascrew,andslidetheclip
into the up position. Sit the cabinet on the mountingbar,
then lower and tighten the screws into place, as shown in
Fig.4.3
4. See Fig.4.4 for anchor cinching.

 
 


Kohler Co. 5 1142938-X2-B
C. Door Adjustments
Adjust the hinge of door in 3 directions to make sure the
door 6 level as shown in Fig.5.
D. Connect The Power Wire
1. Connect the power wire according to the marks on
  thejunctionbox,seeFig.6.
 2. Capthejunctionbox,arrangethewireandthencap
the grey decorative lid, see Fig.7.



   
   
Assemble
การประกอบ
Removal
การถอด
Height Adjustment
การปรับความสูง
Side Adjustment
การปรับด้านข้าง
Depth Adjustment
การปรับความลึก
Fig.5/ 
Fig.7/ Fig.6/ 

1142938-X2-B 6 Kohler Co.
E. Install The Shelves
1. Push/twist the pins into place, see Fig.8.
1.1 Push one side of the shelf into the left or ritht clips.
1.2 Snap the shelf down into the opposite side. If the shelf
is too tight, repeat the process from the other side.
2. Fill the remaining holes with the plugs, see 2 in Fig.9.
F. Replace The Tube
NOTE: Please ask professionals to replace the tube.
The tube for replacement can be purchased from the customer
service department (see Service Parts Page for specic part
number). You can also choose to purchase the T5 tube with the
diameter of 16 mm and length of 563 mm from the market for
replacement.
 1. Removethescrewsfromthelidofthelightbox.
2. Unscrew the tube from the socket (it is done when a click
  soundisheard).Itisthesamewhenthenewtubeisxed.
 3. Fixthelidofthelightbox.

  
   
   
   
  






 
 
  
 
Fig.10/ 
Fig.8/  Fig.9/ 
1.1
1.2
2
1
1
2

Kohler Co. 7 1142938-X2-B
CARE AND CLEANING 
1. Many cleansers contain abrasive and chemical substance
which is not suitable for cleaning stainless steel, enamel,
plating or plastic products. You may use mild cleansers or
soaps to clean the surfaces. Wipe any splashes of cleaner
solutions from the surface with clean soft cloth.
2. Maintain ventilation in the bathroom, and separate the dry
area from the damp one if conditions permit. Try to open
the door and windows of the bathroom and maintain good
ventilation.
3. Kohler mirror cabinet are dealt with strict procedures for
damp-proof, whose good damp-proof function ensures good
performance even in bathroom of huge humidity. Yet do not
splash and pour water directly on the mirror cabinet.
Make sure that the bathroom is not over damp and wipe any
splashes from surfaces immediately.
4. Maintenance of door board: Clean and wipe door board regularly,
and wipe the condensation vapor with dry and soft cloth.
5. The mirror cabinet door and interior are constructed of
mirror and aluminum. Use only a damp cloth to clean.
Spray the cloth, not the mirror when cleaning. Mirrors are
damaged by the use of ammonia or vinegar based cleaners.
Rubbing alcohol can be used for stubborn stains.
6. Use no abrasive cleansers on any part of the mirror cabinet.
7. The white frame should be cleaned with a damp cloth only.

    
 
 
 
  
 
 
  
  
 
  
 
  
 
  
 
 
 
  
 


 

E-mail: [email protected]
1142938-X2-B
KOHLER (THAILAND) PUBLIC COMPANY LIMITED
16th FL. Jasmine City Bldg., 2 Soi Sukhumvit 23, Sukhumvit Road, Wattana, Bangkok 10110 Thailand
Call Center Tel. +(66) 2204 6222 Fax. +(66) 2204 6224
ASIAN EMERGING MARKETS
Asia Customer Service Centre, Kohler Asia Pacic Limited
No.158, Jiang Chang San Road, Zhabei District, Shanghai, PRC. 200436.
Tel: +(86) 21 2606 2572 Fax: +(86) 21 6107 8900
