Konami Kx43 User manual

P/N 810440 Rev A

Date of Publication: 11/5/18

Konami Gaming, Inc.

585 Konami Circle

Las Vegas, NV 89119-3720

Phone: (866) KGI-SLOT

Fax: (702) 361-9020

Operators Manual

KX43

1-1

HISTORY

DOCUMENT REVISION HISTORY

EC REVISION DESCRIPTION OF CHANGE DATE APPROVED

7881 A RELEASE TO PRODUCTION 11-5-18 EM

KX43

(Original Instructions)

SECTION 1

INTRODUCTION

CUSTOMER SUPPORT�� 1-1

Shipping ChargeS �� 1-1

WARRANTY AND RETURN MERCHANDISE (RMA) PRO-

CESS�� 1-1

Warranty poliCy�� 1-1

rMa proCeSS �� 1-1

RMA Tag �� 1-1

RADIO INTERFERENCE �� 1-2

FEATURES: �� 1-2

hardWare FeatureS �� 1-2

hardWare optionS�� 1-2

OVERVIEW �� 1-2

SeCtion 1 - introduCtion �� 1-2

SeCtion 2 - Set up�� 1-2

SeCtion 3 - partS, aSSeMblieS & hardWare�� 1-2

SeCtion 4 - troubleShooting �� 1-3

SeCtion 5 - preventive MaintenanCe �� 1-3

SeCtion 6 - Wiring diagraMS & eleCtriCal CoMponentS

�� 1-3

TERMINOLOGY�� 1-3

NOTICES�� 1-3

SECTION 2

SET-UP

OVERVIEW �� 2-1

PHYSICAL SPECIFICATIONS �� 2-1

Cabinet SpeCiFiCationS �� 2-1

ENVIRONMENTAL SPECIFICATIONS �� 2-1

UNPACKING AND INSPECTING �� 2-2

INSTALLING THE CANDLE �� 2-2

Candle pin aSSignMent �� 2-2

DROP BOX SWITCH CONNECTION �� 2-2

CheCk drop box SWitCh operationS�� 2-2

SLOT ACCOUNTING SYSTEM CONNECTIONS�� 2-2

overvieW�� 2-2

ConneCtionS�� 2-3

player traCking panel �� 2-3

Removal�� 2-3

Installation�� 2-3

Fiber optiC interFaCe �� 2-4

CABINET INSTALLATION�� 2-4

OPENING AND CLOSING THE DOORS�� 2-4

Main deCk door�� 2-4

logiC unit door�� 2-4

CASHBOX DOOR AND SUB DOOR�� 2-5

CaShbox door�� 2-5

Sub door �� 2-5

bill validator door �� 2-5

DISPLAY REMOVAL �� 2-5

DISPLAY INSTALLATION�� 2-6

TOPPER REMOVAL (OPTIONAL) �� 2-6

TOPPER INSTALLATION (OPTIONAL) �� 2-6

CHANGING LOCKS��2-6

loCk diMenSionS �� 2-6

loCk hardWare �� 2-7

loCk CaMS�� 2-7

general loCk replaCeMent �� 2-7

logiC unit door loCk replaCeMent�� 2-7

Main deCk door loCk replaCeMent�� 2-7

bill validator door loCk replaCeMent �� 2-8

option the bill aCCeptor (FaCtory preSet) �� 2-8

ColleCting billS�� 2-9

CaShbox door loCk �� 2-9

PLAYER/OPERATOR INTERFACE��2-9

Spin buttonS�� 2-9

bill entry ��2-9

43" lCd unit �� 2-10

ServiCe button �� 2-10

CaShout button�� 2-10

SeleCt nuMber oF lineS buttonS �� 2-10

SeleCt bet x per line buttonS�� 2-10

bet Max button �� 2-10

STARTUP ��2-10

inSpeCt Cabinet �� 2-10

inSpeCt uSe environMent�� 2-10

inSpeCt aFter ConneCting the aC plug to the reCep-

taCle �� 2-10

turning onthe poWer SWitCh �� 2-10

kp3�5 Setup �� 2-10

SECTION 3

PARTS, ASSEMBLIES & HARDWARE

MAINTENANCE OVERVIEW ��3-1

required toolS �� 3-1

FunCtional overvieW �� 3-1

CoMMonly-uSed hardWare �� 3-2

SWITCH WIRING��3-2

SUB DOOR SWITCH ��3-3

opening��3-3

inStallation �� 3-3

MAIN DECK DOOR SWITCH��3-3

reMoval �� 3-3

inStallation �� 3-3

KEY SWITCH ��3-4

reMoval �� 3-4

inStallation �� 3-4

BILL VALIDATOR SWITCH ASSEMBLY �� 3-4

reMoval �� 3-4

inStallation �� 3-4

CASHBOX DOOR SWITCH��3-5

reMoval �� 3-5

inStallation �� 3-5

LOGIC UNIT SWITCH�� 3-5

reMoval �� 3-5

inStallation �� 3-5

TABLE OF CONTENTS

KX43

(Original Instructions)

POWER SUPPLY �� 3-6

reMoval �� 3-6

inStallation �� 3-6

BILL VALIDATOR �� 3-6

reMoval �� 3-6

inStallation �� 3-6

logiC unit �� 3-7

reMoval �� 3-7

inStallation �� 3-7

MAIN PROCESSING UNIT �� 3-7

reMoval �� 3-7

inStallation �� 3-7

BACKPLANE BOARD �� 3-8

reMoval �� 3-8

inStallation �� 3-8

PRINTER ASSEMBLY�� 3-8

reMoval �� 3-8

inStallation �� 3-8

SPEAKERS �� 3-9

reMoval �� 3-9

inStallation �� 3-9

POWER DISTRIBUTION ASSEMBLY�� 3-9

reMoval �� 3-9

inStallation �� 3-9

METER ASSEMBLY �� 3-10

reMoval �� 3-10

inStallation �� 3-10

P/N 331532 ASSY, MAIN MACHINE�� 3-10

P/N 331533 ASSY, CAB, MAIN (FIG� 1 OF 3)��3-11

P/N 331533 ASSY, CAB, MAIN (FIG� 2 OF 3)�� 3-12

P/N 331533 ASSY, CAB, MAIN (FIG� 3 OF 3)�� 3-14

P/N 331539 ASSY, LCD �� 3-15

P/N 331553 ASSY, TOPPER, 23�8IN �� 3-16

P/N 331534 ASSY, DECK�� 3-17

P/N 310610 ASSY, PS�� 3-18

P/N 331375 ASSY, SW, BV DR �� 3-19

P/N 331374 ASSY, HSG, BV�� 3-19

P/N 310612 ASSY, PNL, PWR CONT�� 3-20

P/N 310613 ASSY, PWR CONT PNL, INTL �� 3-21

P/N 331522 ASSY, HSG, CPU �� 3-22

P/N 311017 ASSY, KP 3�5 MAIN BOARD (4K)�� 3-22

P/N 331526 ASSY, BZL, SENTRY (OPTIONAL)�� 3-23

P/N 331517 ASSY, BZL, BV �� 3-23

P/N 331554 ASSY, BZL, PRINTER �� 3-23

P/N 331536 ASSY, METER�� 3-24

P/N 331328 ASSY, SW, JCM CASHBOX �� 3-24

P/N 310992 ASSY, TOUCH PNL BTN PNL�� 3-25

P/N 310375 ASSY, BV, JCM IVIZION, 1000 NOTE, 72MM

�� 3-26

P/N 310821 PRT, FUTURE LOGIC, GEN5, UNIVERSAL

�� 3-26

GAME POWER CORD OPTIONS�� 3-26

CANDLE TOWER PART NUMBERS �� 3-26

SIGNAL TOWER FILTERS PART NUMBERS �� 3-26

SECTION 4

TROUBLESHOOTING

SECTION 5

PREVENTIVE MAINTENANCE

SECTION 6

WIRING DIAGRAMS

SHEET 1�� 6-2

SHEET 2�� 6-3

SHEET 3�� 6-4

ELECTRICAL COMPONENTS�� 6-5

FuSeS �� 6-5

pCbS�� 6-5

board CoMponentS�� 6-5

TABLE OF CONTENTS

KX43

(Original Instructions)

SECTION 1 - INTRODUCTION

1-1-1

KX43

(Original Instructions)

SECTION 1

Introduction

Document Part Number: 810440

Operators Manual

KX43

This manual is subject to revision�

Konami Gaming, Inc� distributes all revisions�

Reproduction in whole or part of this manual by photographic,

electronic or any other form of recording is prohibited by law�

This manual may not be transmitted or copied for public or

private use without the express consent of Konami Gaming, Inc�

For permission write:

Konami Gaming, Inc�

585 Konami Circle

Las Vegas, NV 89119-3270

Customer Service & RMA Information

Installation & Field Service, call:

Phone: 866�KGI�SLOT

Fax: 702�361�9020

Domestic Sales, call:

Phone: 866�KGI�INFO

Fax: 702�952�1596

CUSTOMER SUPPORT

Konami Gaming, Inc is committed to offering high-quality

technical support, 24-hours a day, seven days a week� For

service, contact us by:

Phone: 1�866�KGI�SLOT

E-Mail: customerservice@konamigaming�com

All calls are logged into a database to track response times,

the nature of the calls, and developing trends�

Shipping ChargeS

• Konami Gaming, Inc� pays for standard ground shipping

on warranty items only�

• The Operator is responsible for shipping charges on

expedited delivery or non-warranty items�

WARRANTY AND RETURN MERCHANDISE

(RMA) PROCESS

Warranty poliCy

Warranty: 90 days parts and labor from date of sale�

rMa proCeSS

• RMA tags are included in the spare parts kit�

• RMA numbers are issued by calling the Customer Support

Hotline at 1�866�KGI�SLOT�

• Parts returned to Konami Gaming, Inc� will only be

accepted with an RMA number� Please do NOT send

any parts back without an RMA number�

• Once a replacement part is issued, the Operator has 30

days to return the old part without being charged� If the

old part is not returned within 30 days, the Operator will

be charged the full retail price for the item�

RMA Tag

(RMA) CASE #

MACHINE SERIAL #

CASINO

PART #

PART SERIAL #

PART DESCRIPTION

PROBLEM

JURISDICTION

WHITE - FIELD ENG. YELLOW - SHIPPING MANILA - PART

TECHNICIAN NAME

SERVICE

PARTICIPATION WARRANTY CUSTOMER CAUSED

TRIAL CONTRACT MAINTENANCE

SECTION 1 - INTRODUCTION

1-1-2

KX43

(Original Instructions)

FEATURES:

hardWare FeatureS

• 43” LCD portrait (4K)

• 24” Topper (Optional)

• Crisper graphics, high resolution

• Ergonomically-designed Button Panel

• Logical button layout

hardWare optionS

Bill Acceptors

• Cash Code

• IVizion

• JCM UBA 10 Standard

• JCM UBA 10 ICB

• JCM UBA 11 Standard

• JCM UBA 11 ICB

• Mars SC6607

• Mars Cashow w/EZ Trax

• Mars SC8307

• Mars SCM6607YE, 1000 Note

Printers

• Future Logic Gen 5

• Ithaca Epic 950

• Paycheck 3

OVERVIEW

This manual provides information required for technicians and

Konami Gaming service personnel to properly set up, operate,

and maintain the Konami Gaming, Inc� KX43 machine� This

manual contains the following sections:

SeCtion 1 - introduCtion

Section 1 contains general machine information, contact

information, a description of manual content, and a general

list of features�

SeCtion 2 - Set up

Section 2 contains complete installation and conguring

information�

SeCtion 3 - partS, aSSeMblieS & hardWare

Section 3 describes the removal and installation of machine

components and contains an illustrated parts manual�

NOTE:RMA tags are used to repair damaged equipment to

its original state of operation. Completely filling out the RMA

is required.

RADIO INTERFERENCE

This device complies with part 15 of the FCC Rules� Operation

is subject to the following two conditions:

• This device may NOT cause harmful interference�

• This device must accept any interference received

including interference that may cause undesired

operation�

Improper installation or maintenance may result in radio

interference�

SECTION 1 - INTRODUCTION

1-1-3

KX43

(Original Instructions)

SeCtion 4 - troubleShooting

Section 4 contains the troubleshooting information necessary

to diagnose and repair errors or malfunctions�

SeCtion 5 - preventive MaintenanCe

Section 5 provides the maintenance information required to

keep the machine error-free and performing as designed�

SeCtion 6 - Wiring diagraMS & eleCtriCal CoMponentS

Section 6 contains the overall system wiring diagram and

consumable parts lists for the components in the machine�

TERMINOLOGY

The term “machine” is used throughout this manual and is

dened as a physical piece of electromechanical equipment

designed and manufactured by Konami Gaming, Inc� This

machine is for sale and use only as an amusement apparatus

in jurisdictions permitting such machines�

The term “game” is used throughout this manual and is dened

as the programmed operation of the machine after money,

tokens, coupons, or equivalent are accepted� Typical game

characteristics include player interaction with the machine

through the use of buttons, and payout of coins, tokens,

coupons, or the equivalent when reel symbol combinations

appear on the payline and match the game’s paytable�

The term “operator” is used throughout this manual and is

dened as any person, partnership, company, or corporation,

and/or their legal representatives, who own, operate, service,

maintain, and/or derive prot from their association with this

machine�

The term “player” is used throughout this manual and is

dened as any person who deposits money, tokens, coupons,

or the equivalent into the machine for the purpose of playing

the games offered by the machine as dened by the rules

and odds set by the operator�

NOTICES

This document contains the following important notices:

This symbol indicates a CAUTION or WARNING. These

indicate actions or situations that can be damaging or

dangerous to you or your equipment. Read and observe

all cautions and warnings.

This symbol indicates a NOTEor TIP. Notes and tips

are items of special interest pertaining to the section or

procedure you are reading about. They typically augment

or clarify the material.

SECTION 2 - SET-UP

-2-1

KX43

(Original Instructions)

SECTION 2

Set-Up

OVERVIEW

This section describes the installation and set-up of the

machine� This section covers the following topics:

• Physical Specications

• Environmental Specications

• Unpacking and Inspecting

• Candle (Signal Tower) Installation

• Drop Box Door Switch Connection

• Slot Accounting System Connections

• Cabinet Installation

• Opening and Closing Doors

• Changing Locks

• Bill Validator Option

• Player/Operator Interface

• Startup

HEIGHT

WIDTH

HEIGHT AT DECK

DEPTH

AT DECK

HEIGHT

WITH TOPPER

WIDTH

HEIGHT

PHYSICAL SPECIFICATIONS

Cabinet SpeCiFiCationS

Height (±0�15") 75�84" 192�6 cm

Height with optional Topper

(±0�15")

91�98 233�6 cm

Height at Deck (±0�15") 30�10" 76�5 cm

Depth at Deck (±0�15") 30�93" 78�6 cm

Width (±0�15") 27�00" 68�6 cm

Weight (±5 lb) 340 lb 154�2 kg

Weight with optional Topper

(±5 lb)

370 lb 167�8 kg

ENVIRONMENTAL SPECIFICATIONS

Line Voltage Input: 100–240 VAC, 50 or 60 Hz�

The following calculations are based on an input voltage of

120 VAC:

• Power supply input voltage: 110 VAC: 108–120 VAC

(nominal 120 VAC) at 50/60 Hz�

SECTION 2 - SET-UP

-2-2

KX43

(Original Instructions)

• Power supply output voltage: +12 VDC, +24 VDC�

• Current draw at rest: 1�6 A (192 W)�

• Current draw at rest, with topper: 1�9 A (228 W)�

• Current draw during game play: 1�7 A (204 W)�

• Current draw during game play, with topper: 2�0 A

(240 W)�

• Maximum operating ambient temperature: 104° F

(40° C)�

• Minimum operating ambient temperature: 32° F (0° C)�

• Maximum surface ambient temperature: 105° F (41�5° C)�

• Minimum surface ambient temperature: 32° F (0° C)�

• Maximum relative humidity: 95% (non-condensing)�

UNPACKING AND INSPECTING

Unpack and inspect the machine before you turn on the

power� If the machine has been damaged during shipping,

contact your Konami Distributor, or Konami Customer Service

Representative, depending on warranty and sales contract

terms�

For Return Merchandise Authorization (RMA) information,

see Section 1 of this manual�

Carefully unpack and remove all loose parts and shipping

materials� Then, do the following:

• Inspect components for damage�

• Verify the power cord is properly routed from the cabinet�

• Verify all wire connectors are rmly seated.

• Check all display areas for signs of broken glass or bulbs�

INSTALLING THE CANDLE

1� Remove the candle cover screws (4)�

2� Remove the ground nut�

3� Mount the Candle with two UNC 8-32 screws�

4� Connect the Candle to Wiring Harness in the machine�

5� If equipped, secure Frame Ground (FG) wire of the Candle

with the M3 nut�

6� Install candle cover screw (4) (M3)�

7� Turn power on and verify that the Candle illuminates�

Candle pin aSSignMent

CANDLE PIN ASSIGNMENT

NUMBER

WIRE

COLOR

SIGNAL

ASSIGNED

LIGHT

LOCATION

1 BROWN TL0 BOTTOM

2 BLUE TL1 TOP

3 VIOLET TL2

CANDLE PIN ASSIGNMENT

NUMBER

WIRE

COLOR

SIGNAL

ASSIGNED

LIGHT

LOCATION

4 GREY TL3 RESERVED

5 N� C� N� C�

6 YELLOW +24 V

DROP BOX SWITCH CONNECTION

NOTE: The Drop Box Switch wiring is typically used

ONLY when the machine is not connected to a slot

accounting system.

1� Open the Main Deck Door�

2� Locate the connector labeled DROP (on the main cabinet

harness)�

3� Connect the optional Drop Switch Harness (P/N 110324)�

4� Connect the three spade connectors to the Drop Switch�

CheCk drop box SWitCh operationS

If any of the following problems arise after turning the power

on, check that the Drop Box Switch is installed properly�

• The 031 DROP DOOR ACCESSED error message is

not displayed even after the power is turned on again

with the drop-door closed�

• The 041 DROP DOOR PORT error message is

displayed�

• No error messages appear when the Sub Panel is

opened and closed�

A Drop Door open accessed error can be detected even with

the power turned off� Reset the error and turn the power on

to check that the switch is installed correctly�

DROP BOX SWITCH PIN ASSIGNMENT

PIN # PIN ASSIGNMENT DESCRIPTION

1 GND GND (COM)

2 SW_DROP

SECURITY

(SW DROP BOX DOOR

(N�O�))

3 BSW_DROP

SECURITY

(SW DROP BOX DOOR

(N�C�))

4 N� C� -

SLOT ACCOUNTING SYSTEM CONNECTIONS

overvieW

The Slot Accounting System (SAS) communication with the

video gaming machine takes place via interface connectors

located on the Backplane board in the Logic Unit box and

through settings in the Konami Maintenance System (KMS)�

SECTION 2 - SET-UP

-2-3

KX43

(Original Instructions)

ConneCtionS

Under typical conditions, CNB35/COM 1 on the backplane

is for interconnection to the SAS Unit, used for the ber

optic interface� CNB36 and CNB37 are used for serial

communications with conventional wiring�

CNB22

USB (SYS) CNB07 PLAY BUTTON

CNB18 TOUCH SCREEN2

CNB10 TOUCH SCREEN1

CNEX01

EXT BOARD

CNB55 VIDEO3

CNB17 VIDEO2

CNB17 VIDEO1

CNCP01

DC FAN

CNB22

CNB20 JXU (NSW)

VIDEO5

CNB72

VIDEO (SYS) TEST (SYS)

CNB21

ATU (VIC, QLD) CNB35

COM1

CNB36

COM2

CNB37

COM3

CNB26

EBUS

10B CNCP02

10B CNCP05

10B CNCP03 CNCP04

10B

CNB23 CNB22

LOGIC SW DC FAN

10B

CNB05 METER

DOOR SENSOR

DC FAN

CNB06

CNB64

CNB28

CNB13

BILL

CNB29

CNB27

CNB15

CNB08

CNB01

CNB63

CNB02

CNB78

CNB24

CNB53

CNB54TEST

+24V

+12V

+5V

CNB83

USB

CNB22

24V OUT

VIC COMM POW

LINE OUT2LINE OUT1

LED2LED3LED1

LINE IN/ OUT3

DROP

SW

DC FAN

CNB16 REEL

CNB04 ICON

CNB11 COIN

CNB82

CNB14

CNB12 PRINTER

CNB61

CNB62

LAN

CNB03 MAIN

POWER

OUT

POWER IN

EXTEND MONITOR

CNB65

EXT UART1

EXT UART2

EXT I / 01

EXT I / 02

VSW

CNB58

CNB85

CNB57

LAN (SYS)

DOOR

CNB35

(COM1)

CNB36

(COM2)

CNB37

(COM3)

player traCking panel

The SAS components are mounted on a removable bracket

installed on top of the box� Use the following illustration to

remove and install the bracket�

Removal

1� Open the Main Deck Door and turn power off�

2� Remove four 8-32 nuts holding the Player Tracking Panel�

3� Remove Player Tracking Panel from Main Deck�

Installation

1� Install Player Tracking Panel onto Main Deck�

2� Secure with four 8-32 nuts screws�

3� Power on the unit and close Main Deck Door�

PLAYER TRACKING PANEL

SECTION 2 - SET-UP

-2-4

KX43

(Original Instructions)

Fiber optiC interFaCe

When ber optic communication lines are used, they are rst

routed to the SAS Unit mounted in the machine� The SAS

Unit is equipped with two input and two output ber optic

receptacles� The SAS unit is also equipped with a serial input/

output connector and attached wiring, the output of which is

connected to the CNB35 port on the Backplane board�

SERIAL

I/O

AC115V IN

Green : Communication

Blink Lit Off

Normal

Error Idling

Normal

Error Idling

Normal

Error Idling

Red : Opto IN2 Monitor

Yellow : Terminal Serial Data

SERIAL

I/O

OUT1 OUT2 IN1 IN2

SERIAL I/O

FIBER OPTIC OUT 1

FIBER OPTIC OUT 2

FIBER OPTIC IN 2

FIBER OPTIC IN 1

AC 115V IN

CABINET INSTALLATION

This section describes the procedure for installing the cabinet

and setup of the initial settings of the equipment�

• Opening and Closing Doors

• Changing Locks

OPENING AND CLOSING THE DOORS

Main deCk door

1� To open the Main Deck Door, insert Main Deck Door Key

into Key Cylinder underneath the Main Deck�

2� Turn key 90° clockwise while simultaneously applying

pressure on the surface of Main Deck Door�

3� Pull pin button with key turned�

4� Open Main Deck Door�

LATCH

LOCK

UNDERSIDE VIEW OF DECK

5� Close Main Deck Door with the key turned clockwise�

6� Turn key 90° counter-clockwise and remove from cylinder�

logiC unit door

1� To open the Logic Unit Door, insert the Logic Unit Door

key into the cylinder on the front of the Logic Unit�

2� Turn the key 90° counter-clockwise�

3� Open the Logic Unit Door by pulling the Logic Door toward

you and up to clear the mounting tabs�

4� To close the Logic Unit Door, insert the Logic Unit Door

tabs into the slots and pivot into the locking position�

5� Turn the Logic Door key 90° clockwise�

6� Remove the Logic Unit Door key from the cylinder�

SECTION 2 - SET-UP

-2-5

KX43

(Original Instructions)

CASHBOX DOOR AND SUB DOOR

CaShbox door

1� To open the Cashbox Door, turn key 90° counter-

clockwise�

2� Door will swing down�

3� Close Cashbox Door by lifting door closed and turning

key 90° clockwise�

CASHBOX DOOR

Sub door

1� Open the Main Deck�

2� Open the Sub Door�

3� Pull back the Slide Latch to the right to release the Sub

Panel door�

BELLY DOOR LATCH

PULL RIGHT TO RELEASE

BELLY DOOR

bill validator door

1� To open the Bill Validator Door, open the Cashbox Door�

2� Insert key into the cylinder on the Bill Stacker Door�

3� Turn the key 90° counter-clockwise�

4� Open the Bill Stacker Door�

5� Close the Bill Stacker Door� Turn the key 90° clockwise�

6� Remove the Bill Stacker Door key from the cylinder�

7� Close Cashbox Door�

DISPLAY REMOVAL

1� Open the Main Deck Door�

T-HANDLE

PULL TO RELEASE DISPLAY

WARNING: The display has a maximum weight of 61lb

(27.6 kg). At least 2 people, one on each side, must

handle the display when removing or installing it.

SECTION 2 - SET-UP

-2-6

KX43

(Original Instructions)

2� Pull the T-Handle to release the display�

�

3� Pull out the LCD from the bottom and lower the LCD

retaining bar�

4� Remove the HW #8-32 nuts for the Ground Straps (qty

2) behind the LCD�

5� Disconnect all cables from behind�

6� Remove the LCD by lifting upward and toward the front

of the cabinet�

DISPLAY INSTALLATION

WARNING: The display has a maximum weight of 61lb

(27.6 kg). At least 2 people, one on each side, must

handle the display when removing or installing it.

1� Hang the LCD onto the top mounting bracket�

2� Reconnect all cables�

3� Install the HW #8-32 nuts for the Ground Straps (qty 2)

on the LCD�

4� Raise the LCD retaining bar� Push back the LCD from the

bottom unit until the Rotary Latch locks in place�

5� Close the Main Deck Door�

TOPPER REMOVAL (OPTIONAL)

WARNING: The display has a maximum weight of 17 lb

(7.71 kg). You should consider employing the help of a

second person.

1� Remove Display per display removal instructions�

2� Remove Cable cover plate�

3� Remove Topper back cover�

4� Disconnect all cables�

5� Disconnect ground strap�

6� Remove HW Qty 4 – 1/4-20 Nylon nuts behind the topper�

TOPPER INSTALLATION (OPTIONAL)

1� Install HW Qty 4 –1/4-20 Nylon nuts behind the topper�

2� Connect ground strap�

3� Connect all cables�

4� Install Topper back cover�

5� Install Cable cover plate�

6� Install Display per instructions�

CHANGING LOCKS

loCk diMenSionS

The following shows the standard lock dimensions�

SECTION 2 - SET-UP

-2-7

KX43

(Original Instructions)

.87

.68 .39

.73

.62

1.28

.58

ALL DIMENSIONS ARE IN INCHES

loCk hardWare

The following shows the standard lock hardware�

loCk CaMS

The following shows the standard lock cams required for this

machine�

CAM, LOCK,

LOGIC UNIT

DOOR

CAM, DOOR,

BV

CAM, LOCK,

MAIN DECK

190020

192688

192744

LOCKING CAMS

PART # DESCRIPTION

CAM, DOOR,

BV (CASHBOX)

193613

NOTE: Locks are supplied for shipping purposes only.

It is recommended that all locks be replaced with owner/

operator approved and secured locks.

general loCk replaCeMent

1� Remove 9/32-28 UNF nut and cam from shaft�

2� Remove 3/4-28 UNF nut from lock�

3� Remove Key Cylinder�

4� Install new Key Cylinder�

5� Secure with 3/4-28 UNF nut�

6� Install cam and 9/32-28 UNF nut on shaft�

logiC unit door loCk replaCeMent

1� Open Main Deck Door�

2� Open Logic Unit Door�

3� Replace lock�

4� Turn the key 90° counter-clockwise to open the Logic Unit

Door, then return the key to the original position�

5� Make sure that the lock is installed properly by locking

and unlocking the door�

If any of the following problems arise before turning on the

power, check that the key works properly for the installed lock�

• You cannot easily open or close the door�

• You cannot remove or turn the key�

If the 012 LOGIC DOOR OPEN message appears after turning

on the power, check that the above Door Lock procedure was

performed properly�

The probable causes of the error are:

• The lock is not installed properly�

• The logic door switch is not depressed completely�

If the 032 LOGIC DOOR ACCESSED message appears after

turning on the power, turn the Reset Key Switch�

For more information on the Logic Door, refer to the DOOR

section in the KP3�5 Setup Manual�

Main deCk door loCk replaCeMent

1� Open Main Deck Door�

2� Replace Lock�

SECTION 2 - SET-UP

-2-8

KX43

(Original Instructions)

3� Turn key 90° clockwise to open Main Deck Door, then

return it to the original position�

4� Make sure that the lock is installed properly by opening

and closing the door�

If any of the following problems arise before turning on the

power, check that the above procedure was performed

properly�

• You cannot easily release or engage the door�

• You cannot easily open or close the door�

• You cannot remove or turn the key�

If the MAIN DOOR OPEN message appears after turning the

power on, check that the above procedure was performed

properly�

The probable causes of the error are:

• The lock is not installed properly�

• The Sub Door Switch is not depressed completely�

If the MAIN DOOR ACCESSED message appears after

turning the power on, turn the Reset Key Switch�

For information on how to check the status of the Main Door

Switch, refer to the Door section in the KP3�5 Setup Manual,

part number 810239�

NOTE: Remove the spacer for a short lock. Retain the

spacer and other small parts for future use if not required

for this application.

bill validator door loCk replaCeMent

1� Open Cashbox Door�

2� Open Bill Validator Door�

3� Replace lock�

4� Turn key 90° counter-clockwise to open the Bill Validator

Door, then return it to the original position�

Make sure that the lock is installed properly by opening and

closing the door�

If any of the following problems arise before turning the power

on, check that the above procedure was performed properly:

• You cannot easily open or close the door�

• You cannot remove or turn the key�

If the 014 BILL DOOR OPEN message appears after turning

on the power, check that the above procedure was performed

properly�

The probable causes of the error are:

• The lock is not installed properly�

• The Bill Validator Door switch is not depressed

completely�

If the 034 BILL DOOR ACCESSED message appears after

turning the power on, turn the Reset Key Switch�

For more information on checking the status of the Bill Door

Switch and Sensor, refer to the DOOR section in the KP3�5

Setup Manual, part number 810239�

option the bill aCCeptor (FaCtory preSet)

The Bill Acceptor either accepts or rejects bills inserted into

the Bill Validator Module (Bill Head)�

Accepted bills are transported to the Cash Cassette, and an

appropriate number of credits registered on the Credit Meter�

For example, an accepted U�S� $1 bill shows as four credits

on a machine with a denomination of 25 cents� Rejected bills

are returned to the player�

• Remove the bill validator module (refer to Section 3 -

Assemblies, Parts & Hardware)�

SECTION 2 - SET-UP

-2-9

KX43

(Original Instructions)

ColleCting billS

When the Bill Stacker is full, the BILL STACKER FULL

message appears� This suspends the game until the bills

are collected� Please note that bills should be collected

periodically before the Bill Stacker becomes full�

1� Open the Cash Box Door�

2� Open the Bill Stacker Door�

3� Pull out the Bill Stacker�

4� Unlock the locks in two places on the back of the Bill

Stacker at the same time and remove the bills�

5� Install the Bill Stacker in the Bill Validator unit�

6� Close the Bill Stacker Door and Cash Box Door�

7� Turn the Reset Key Switch to recover from the error�

CaShbox door loCk

1� Open the Cashbox Door�

2� Replace the Lock�

3� Turn the key 90° counter-clockwise to open the Cashbox

Door then return it to the original position�

4� Open and close the Cashbox Door to ensure the lock is

properly installed�

If any of the following problems arise before turning the power

on, check that the key works properly for the installed lock�

• You cannot easily release or engage the door�

• You cannot easily open or close the door�

• You cannot remove or turn the key�

If the CASH BOX OPEN message appears after turning the

power on, make sure that the above procedure was performed

properly�

The probable causes of the error are:

• The lock is not installed properly�

• The door switch is not depressed completely�

If the SUB DOOR ACCESSED message appears after turning

the power on, turn the Reset Key Switch�

For more information on checking the status of the Sub Door

Switch and Sensor, refer to the DOOR section in the KP3�5

Setup Manual, part number 810239�

PLAYER/OPERATOR INTERFACE

The following illustration identifies the Player/Operator

interface items used to play the game�

SPEAKERS

LCD BUTTON PANEL

(TOUCHDASH PANEL)

43” LCD SCREEN

PRINTER

BILL ENTRY

SERVICE & CASHOUT

BUTTON

SPIN BUTTONS

SPIN buttonS

Each SPIN button can act as a REPEAT BET button� After

the player selects the number of lines, the credits wagered

per line activates the game� Pressing either SPIN button then

activates the next game�

bill entry

Accepts paper currency and converts it into credits according

to the denomination of the machine� If a player inserts a $20

bill, and the denomination of the machine is 5 cents, the

machine displays 400 credits on the credit meter�

SECTION 2 - SET-UP

-2-10

KX43

(Original Instructions)

43" lCd unit

The LCD displays animations, bonus games, and bonus pays

to the player� It is also accesses the KMS to display game

information, audit information, log les, game recall les, event

info les, and system info les. It is also displays diagnostic

screens and game test screens� All touch-based controls are

on the Touch Dash Panel�

ServiCe button

The SERVICE Button is used to illuminate the upper Signal

Tower light with a steady ash, indicating to the operator that

service is required at the machine�

CaShout button

The Cashout Button is used by the player to retrieve unused

credits from the machine� When pressed, the Hopper activates

the sound of dropping coins into the coin bowl, triggering an

attendant pay, printing a ticket or a combination of events�

SeleCt nuMber oF lineS buttonS

The SELECT LINE(s) Button allows the player to choose the

number of lines played�

SeleCt bet x per line buttonS

The Bet X Per Line Buttons allow the player to select the

number of credits played for each of the selected lines�

bet Max button

The BET MAX button wagers the maximum number of

credits for each time it is pressed� A credit equals the current

denomination times the maximum amount of coins that can

be bet (if the machine is optioned with a denomination of

50 cents, and the maximum number of coins is 45, the bet

max value would be $22�50)� When the BET MAX button is

pressed, the reels spin automatically�

STARTUP

Before plugging in the machine, check the following items�

inSpeCt Cabinet

• Check that all the units are plugged in rmly.

• Check that all the connectors are connected�

• Check that the AC cord is not damaged�

• Check that the Power Switch is in the OFF position�

• Check that fuses are not opened�

inSpeCt uSe environMent

• Check that the power supply meets the specication

for the cabinet�

• Check that the AC cord is not strained (do not bend

the AC cord at a sharp angle, coil it, or weigh it down)�

• Make sure that no water is near the power supply�

inSpeCt aFter ConneCting the aC plug to the

reCeptaCle

• Check that the smell of smoke is not present�

• Check that no sparks, smoke, or ame are produced.

• Check that the AC cord does not get too hot�

turning onthe poWer SWitCh

The rst time you power on the game, you must complete a

RAM CLEAR procedure� Refer to the KP3�5 Setup Manual,

part number 810239�

kp3.5 Setup

To properly set up the game, refer to the KP3�5 Setup Manual,

part number 810239�

SECTION 3 - PARTS, ASSEMBLIES & HARDWARE

1-3-1

KX43

(Original Instructions)

SPEAKERS

CASHOUT

BUTTON

SERVICE

BUTTON

LCD BUTTON PANEL

(TOUCHDASH PANEL)

LED EDGE LIGHT

PANELS (LCD)

LED EDGE LIGHT

(CABINET SIDES)

LED EDGE LIGHT

(DECK CORNERS)

L

ED EDGE LIGHT

(DECK)

HARD METERS

SUB PANEL

CASHBOX DOOR

SERIAL PLATE

BILL ENTRY

USB CHARGER

TICKET CHUTE

MAIN DOOR LOCK

SPIN BUTTONS

LCD LED LIGHT

PANEL

LCD

SPEAKERS (LOCATED

IN CABINET)

LED LIGHT PANEL

(DECK CORNERS)

BILL VALIDATOR

LED LIGHT PANEL

(CABINET SIDE)

SUBWOOFER (LOCATED

BEHIND PANEL)

CASHBOX DOOR (TO ACCESS

BILL VALIDATOR)

LOGIC UNIT

HOUSING

MAIN POWER SWITCH

(LOCATED ON POWER SUPPLY)

POWER SUPPLY

PRINTER

LED LIGHT

PANEL DECK

MAINTENANCE OVERVIEW

This chapter describes part removal, installation, assembly,

and disasembly� It also includes a parts list� This manual is

intended for experienced maintenance personnel working on

gaming machines�

• Removal: Describes how to remove components from the

cabinet� Note that you may need special tools depending

on the type of component removed�

• Disassembly: Describes how to disassemble the

components removed from the cabinet into parts on which

maintenance can be performed�

• Assembly: Describes how to assemble the parts� Use

caution when reconnecting harnesses to ensure proper

operation� Incorrect assembly may cause malfunctions

or failures�

• Installation: Describes how to install the components

in the cabinet�

required toolS

• Phillips Screwdriver (No� 1 and No� 2)

• Small Phillips Screwdrivers (No� 0 and No� 1)

• 4 to 13 mm Nut Driver or Ratchet Wrench

• 4 to 13 mm Wrench Set

• 22 to 24 mm Double-end Wrench

• Hand Riveter

• Needle Nose Pliers

• Pliers

• Voltage and Amperage Tester

• Crimping Tool for Connectors

• Plastic Ties

• Wire Stripper

• Pin Extractor

• IC Extractor

• Wire Cutters

FunCtional overvieW

The following illustrations identify major components of the

machine�

SECTION 3

Parts, Assemblies & Hardware

SECTION 3 - PARTS, ASSEMBLIES & HARDWARE

1-3-2

KX43

(Original Instructions)

CoMMonly-uSed hardWare

The following table shows the hardware that this electronic

gaming machine uses� Using incorrect hardware may damage

the equipment�

PART NO. DESCRIPTION

450013 NUT, HEX KEP, 10-32

450014 NUT, HEX KEP, 4-40

450015 NUT, HEX KEP, 6-32

450016 NUT, HEX KEP, 8-32

450034 NUT, HEX, FLANGE KEP, SER M6

450046 SCREW, FLAT HEAD, 4-40X3/8

450067 SCREW, PAN HEAD PHILLIPS, 6-32 x 1/2

450107 SCREW, SEMS, PAN HEAD PHILLIPS, 4-40 x 1/4

450109 SCREW, SEMS, PAN HEAD PHILLIPS, 6/32 x 1/2

450110 SCREW, SEMS, PAN HEAD PHILLIPS, 6/32 x 1/4

450114 SCREW, SEMS, PAN HEAD PHILLIPS, 8/32 x 1/2

450115 SCREW, SEMS, PAN HEAD PHILLIPS, 8/32 x 1/4

450117 SCREW, SEMS, PAN HEAD PHILLIPS, 8/32 x 3/8

450122 SCREW, SEMS, PAN HEAD PHILLIPS, M3 x 6

450127 SCREW, SEMS, PAN HEAD PHILLIPS, M4 x 6

450128 SCREW, SEMS, PAN HEAD PHILLIPS, M4 x 8

450144 NUT, NYLOK, 2-56

450146 GUIDE, PCB, 6IN, HSG, CPU

450154 NUT, HEX ACORN, 6-32

450161 SCREW, CONNECTOR MOUNTING

450163 RIVET, POP, 1/8"DIA X 3/8" LONG

450176 WASHER, #8 FLAT

450178 WASHER, 1/4" FLAT

450185 DOOR STAY, 10�5"

450222 SCREW, FLAT HEAD, M3X8

450282 NUT, HEX, NYLOCK, 8-32

450285 WASHER, FENDER, #10 OD 1"X7/32 ID X 3/64

450386 SPRING, EXT, 2�25" FL, �375 OD, �039 WD

450467 SCREW, SEMS, PAN HD, PHILLIPS, 1/4-20 x 1/2

450471 NUT, HEX, NYLON-INSERT, 1/4-20

450490 TAG, SECURITY, RED

450534 WASHER, LOCK, SPLIT, STL, 1/4

450549 BALL STUD, FEMALE

450590 SCREW, TRUSS HD PHILLIPS, 8/32 x �375, BLK

OXIDE

450631 LATCH, ROTARY, TWO STAGE, LH, IN-LINE ACT

450632 BUMPER, THREADED STUD, M6

450633 SPRING, CONICAL

450634 NUT, HEX JAM, M6

450691 SCREW, HEX HEAD PHILLIPS W/ DBL FL/LOCK

WASHER, M6 X

450757 SCREW, SHLDR, 3/8"DIA, 1 1/4"LG, 5/16-18

450761 GAS SPRING,485MM 285MM 200N

450777 SCREW, SEMS, PAN HEAD PHILLIPS W/KEP LOCK,

8-32 3/4 LG

450778 SCREW, HxHD 1/4-20 x �75 LG

450779 WASHER, FLAT 1/4, �625 OD x �281 ID

CAUTION: Distributors, Operators, and Users are

not to modify the equipment for any other use. Konami

Gaming, Inc. cannot be held liable for damages or injuries

resulting from use or modiﬁcation of this equipment.

Konami Gaming, Inc. cannot be held liable for damages or

injuries arising from improper or unsupervised installation,

modiﬁcation, or use of equipment not manufactured or

approved by Konami Gaming, Inc. This equipment is

designed as a gaming device for amusement only, for sale

and use in jurisdictions permitting such devices.

WARNING:Power to the machine must be turned off prior

to cleaning the inside of the machine or removing any

mechanical or electrical assembly. Unplug the machine.

CAUTION: PCB’s may contain a lithium battery.

Danger of explosion if the battery is incorrectly

replaced. Replace only w ith the same, o r

equivalent type recommended by the manufacturer.

WARNING: Hazardous high voltage exists within the

cabinet even with machine power off and the power

cord unplugged! Use extreme caution when removing

electrical assemblies to avoid injury. Discharge body

static BEFORE touching PCBs to avoid damaging

electrostatic sensitive components. Only qualified

personnel should attempt servicing this machine.

SWITCH WIRING

Each wire of the switch harnesses is marked to indicate

terminal position� Use the following illustration to ensure the

switch is connected correctly�

DOOR SWITCH WIRE LOCATIONS

LOCATION MARK

Terminal 2 COM

Terminal 4 N�C�

Terminal 6 N�O�

SECTION 3 - PARTS, ASSEMBLIES & HARDWARE

1-3-3

KX43

(Original Instructions)

MAIN DECK DOOR SWITCH

reMoval

1� Unlock and open the Main Deck Door and turn off

machine power�

2� Note wire locations for installation and remove all wires

from the Switch�

3� Gently grasp the Switch behind the bracket, press in on

the side tabs, and then push the Switch forward�

inStallation

1� Push the new Switch into Mounting Bracket until two tabs

on the Switch seat in place�

2� Connect wires to terminals�

3� Close and lock the Main Deck Door�

SUB DOOR SWITCH

opening

1� Unlock and open the Main Deck Door and turn off

machine power�

2� Unlock and open the Sub Door�

3� Note wire locations for installation and remove all wires

from the Switch�

4� Gently grasp the Switch behind the bracket, press in on

the side tabs, and then push the Switch forward�

inStallation

1� Insert the Switch from the front of the machine�

2� Gently push the Switch into the bracket until it seats�

3� Connect wires to the terminals� Turn on main power�

4� Close and lock the Sub Doors�

Konami KX43 User manual
