Konami KXP User guide

P/N 810497 Rev A
Date of Publication: 11-22-19
Konami Gaming, Inc.
585 Konami Circle
Las Vegas, NV 89119-3720
Phone: (866) KGI-SLOT
Fax: [phone]
SETUP MANUAL
KXP

1-1
History-1 © 2019 Konami Gaming IncP/N 810497
DOCUMENT REVISION HISTORY
EC REVISION DESCRIPTION OF CHANGE DATE APPROVED
8259 A RELEASE FOR PRODUCTION 11-22-19 EM

THIS PAGE LEFT BLANK

1© 2019 Konami Gaming Inc.P/N 810497 KXP Setup Manual
Table of Contents
Overview.............................................................. 4
Main Unit ............................................................. 4
System Start Up (Normal) ................................... 4
KMS Mode........................................................... 5
Returning from KMS Mode ............................. 5
KMS Navigation................................................... 6
User Interface Button Panel Operations......... 6
Game Initialization Procedure (RAM Clear)..............7
RAM Clear Procedure .................................... 8
Operation............................................................. 9
Game Screen ................................................. 9
Help and Pay Table......................................... 9
KMS Overview..................................................... 10
Audit .................................................................... 11
Audit Meters ................................................... 12
General Meters 1............................................ 13
General Meters 2............................................ 14
Bill/Tickets....................................................... 16
Cashless/Bonusing 1...................................... 17
Cashless/Bonusing 2...................................... 18
Game Meters.................................................. 19
Game Play...................................................... 19
Progressive Jackpots ..................................... 20
Par Game ....................................................... 21
Par Denomination........................................... 22
Double Feature............................................... 23
Logs................................................................ 24
Bill In............................................................... 24
Ticket In .......................................................... 25
Ticket Out ....................................................... 25
Jackpot ........................................................... 26
Progressives................................................... 27
Cancelled Credit Handpay.............................. 28
AFT Transaction ............................................. 29
EFT Transaction ............................................. 29
System Bonus ................................................ 30
Cashout .......................................................... 30
Game Events.................................................. 31
Meters............................................................. 32
Logs................................................................ 32
Extended Game Meters.................................. 33
Game Recall........................................................ 34
Setup ................................................................... 35
Machine Number Setup.................................. 37
Locale Setup................................................... 40
Credit Setup.................................................... 41
Cash Device Setup......................................... 43
Bill Validator.................................................... 44
Noncashable Print Title................................... 45
Security Setup ................................................ 46
International Setup, Page 1 ............................ 47
Absolute Credit Limit, Bet Range and Limit Range Setup
48
International Setup, Page 2 ............................ 49
Minimum Game Time ..................................... 49
Game License Setup ...................................... 50
License Tampering Prevention ....................... 51
License Expiration .......................................... 51
Importing Licenses ......................................... 51
Communications Setup .................................. 52
Communication Channel Setup...................... 53
Controller Setup.............................................. 54
SAS Protocol Setup........................................ 55
G2S Setup ...................................................... 56
Validation Setup.............................................. 57
Cashless Transfer Setup ................................ 59
Progressive Setup .......................................... 60
Network Setup ................................................ 61
Sound Setup................................................... 62
Game Common Setup.................................... 63
Settings........................................................... 64
LED................................................................. 65
E-Art ............................................................... 66
Localization..................................................... 67
Game Custom Setup ...................................... 68
Topper............................................................. 69
Pay Table Setup.............................................. 70
Denomination Setup ....................................... 72
Extend Game Setup ....................................... 73
Extended Game Options Setup...................... 74
Dual Progressive Setup.................................. 75
Summary ........................................................ 76
Game Summary ............................................. 77
Machine Summary.......................................... 78
Diagnostic............................................................ 79
Touch Panel.................................................... 80
Touch Test....................................................... 80
Touch Panel Calibration Test .......................... 81
Bottom Screen Touch Panel (Stepper) Calibration
82
Button ............................................................. 83
Door................................................................ 84
Out Port .......................................................... 85
Coin Acceptor ................................................. 86
Coin Hopper ................................................... 87
Hardware Monitor ........................................... 88
Button and Door Frame LED .......................... 89
Table of Contents

2© 2019 Konami Gaming Inc.P/N 810497 KXP Setup Manual
Seven Segment .............................................. 90
Reel ................................................................ 91
Monitor............................................................ 98
LED Illuminations............................................ 99
Monument Bezel Light Diagnostic Testing...... 100
Bill Acceptor.................................................... 101
Printer ............................................................. 102
Sound ............................................................. 103
Screen ............................................................ 104
Communication............................................... 105
Game.............................................................. 106
Machine ID ..................................................... 107
Locale Setup................................................... 108
Credit Meter.................................................... 109
Out of Service...................................................... 110
LP21 .................................................................... 111
Overview......................................................... 111
Platform .......................................................... 111
CRC File Format.................................................. 112
Communication and Response Times............ 112
Setup and KMS ................................................... 112
Localization and Currency .............................. 112
SAS Protocol Setup............................................. 113
LP21 CRC CALC................................................. 114
File Generation Tool ............................................ 115
Generate File.................................................. 115
Setup/Arrange Modules.................................. 115
Run CRC on File ............................................ 115
Run Old LP21 ................................................. 115
CRC Application Screenshot .......................... 115
Key-On Credit...................................................... 116
Adding Key-On Credits................................... 116
Collect Credits (Player and Attendant) ........... 118
Audit Data............................................................ 119
Fundamental Gaming Machine Audit Data..... 119
Life-to-Date Audit Data ................................... 119
Game Recall Data .......................................... 119
Casino Floor System Communication ............ 119
RAM Clear Option for Key-On Credits............ 119
Cash Device Setup......................................... 120
Audit Meters ................................................... 123
Key-On Credit Transaction Log ...................... 124
Game Recall................................................... 125
E-Art ............................................................... 66
Localization..................................................... 67
Game Custom Setup ...................................... 68
Topper............................................................. 69
Pay Table Setup.............................................. 70
Denomination Setup ....................................... 72
Extend Game Setup ....................................... 73
Extended Game Options Setup...................... 74
Dual Progressive Setup.................................. 75
Table of Contents
Summary ........................................................ 76
Game Summary ............................................. 77
Machine Summary.......................................... 78
Diagnostic............................................................ 79
Touch Panel.................................................... 80
Touch Test....................................................... 80
Touch Panel Calibration Test .......................... 81
Bottom Screen Touch Panel (Stepper) Calibration
82
Button ............................................................. 83
Door................................................................ 84
Out Port .......................................................... 85
Coin Acceptor ................................................. 86
Coin Hopper ................................................... 87
Hardware Monitor ........................................... 88
Button and Door Frame LED .......................... 89
Seven Segment .............................................. 90
Reel ................................................................ 91
Monitor............................................................ 98
LED Illuminations............................................ 99
Monument Bezel Light Diagnostic Testing...... 100
Bill Acceptor.................................................... 101
Printer ............................................................. 102
Sound ............................................................. 103
Screen ............................................................ 104
Communication............................................... 105
Game.............................................................. 106
Machine ID ..................................................... 107
Locale Setup................................................... 108
Credit Meter.................................................... 109
Out of Service...................................................... 110
LP21 .................................................................... 111
Overview......................................................... 111
Platform .......................................................... 111
CRC File Format.................................................. 112
Communication and Response Times............ 112
Setup and KMS ................................................... 112
Localization and Currency .............................. 112
SAS Protocol Setup............................................. 113
LP21 CRC CALC................................................. 114
File Generation Tool ............................................ 115
Generate File.................................................. 115
Setup/Arrange Modules.................................. 115
Run CRC on File ............................................ 115
Run Old LP21 ................................................. 115
CRC Application Screenshot .......................... 115
Key-On Credit...................................................... 116
Adding Key-On Credits................................... 116
Collect Credits (Player and Attendant) ........... 118
Audit Data............................................................ 119
Fundamental Gaming Machine Audit Data..... 119
Life-to-Date Audit Data ................................... 119

3© 2019 Konami Gaming Inc.P/N 810497 KXP Setup Manual
Game Recall Data .......................................... 119
Casino Floor System Communication ............ 119
RAM Clear Option for Key-On Credits............ 119
Cash Device Setup......................................... 120
Audit Meters ................................................... 123
Key-On Credit Transaction Log ...................... 124
Game Recall................................................... 125
Localization..................................................... 67
Game Custom Setup ...................................... 68
Topper............................................................. 69
Pay Table Setup.............................................. 70
Denomination Setup ....................................... 72
Extend Game Setup ....................................... 73
Extended Game Options Setup...................... 74
Dual Progressive Setup.................................. 75
Summary ........................................................ 76
Game Summary ............................................. 77
Machine Summary.......................................... 78
Diagnostic............................................................ 79
Touch Panel.................................................... 80
Touch Test....................................................... 80
Touch Panel Calibration Test .......................... 81
Bottom Screen Touch Panel (Stepper) Calibration
82
Button ............................................................. 83
Door................................................................ 84
Out Port .......................................................... 85
Coin Acceptor ................................................. 86
Coin Hopper ................................................... 87
Hardware Monitor ........................................... 88
Button and Door Frame LED .......................... 89
Seven Segment .............................................. 90
Reel ................................................................ 91
Monitor............................................................ 98
LED Illuminations............................................ 99
Monument Bezel Light Diagnostic Testing...... 100
Bill Acceptor.................................................... 101
Printer ............................................................. 102
Sound ............................................................. 103
Screen ............................................................ 104
Communication............................................... 105
Game.............................................................. 106
Machine ID ..................................................... 107
Locale Setup................................................... 108
Credit Meter.................................................... 109
Out of Service...................................................... 110
LP21 .................................................................... 111
Overview......................................................... 111
Platform .......................................................... 111
CRC File Format.................................................. 112
Communication and Response Times............ 112
Setup and KMS ................................................... 112
Localization and Currency .............................. 112
SAS Protocol Setup............................................. 113
LP21 CRC CALC................................................. 114
File Generation Tool ............................................ 115
Generate File.................................................. 115
Setup/Arrange Modules.................................. 115
Run CRC on File ............................................ 115
Run Old LP21 ................................................. 115
CRC Application Screenshot .......................... 115
Key-On Credit...................................................... 116
Adding Key-On Credits................................... 116
Collect Credits (Player and Attendant) ........... 118
Audit Data............................................................ 119
Fundamental Gaming Machine Audit Data..... 119
Life-to-Date Audit Data ................................... 119
Game Recall Data .......................................... 119
Casino Floor System Communication ............ 119
RAM Clear Option for Key-On Credits............ 119
Cash Device Setup......................................... 120
Audit Meters ................................................... 123
Key-On Credit Transaction Log ...................... 124
Game Recall................................................... 125

4© 2019 Konami Gaming Inc.P/N 810497 KXP Setup Manual
OVERVIEW
This manual describes setting up the KXP system. Be advised, different options and features are available on
different versions of the software. Verify the version and options for the installed software.
MAIN UNIT
Make sure the installed Main Unit is the proper version (KXP, shown below). KXP is composed of KXP-ITX (game
CPU board), GPU card, KXP-IOB (I/O board), and KXP-IFB (interface board).
To operate properly it must be securely installed in the logic unit and connected to the backplane.
RAM CLEAR
USB DRIVE
GAME CF CARD
UPPER SIDE
SYSTEM
SD
CARD
KXP-IOB
KXP-ITX
KXP-IFB
GPU CARD
KXP MAIN UNIT
SYSTEM START UP (NORMAL)
1. Open the Main Door.
2. Turn on the Power Switch.
3. Close the Main Door. The self-check screen is displayed.
4. When the self-check clears with no errors, the game screen is displayed.

5© 2019 Konami Gaming Inc.P/N 810497 KXP Setup Manual
KMS MODE
1. Turn the Reset key counter-clockwise to enter KMS Mode. The KMS menu is displayed.
2. KMS will automatically return to Game Mode in 15 seconds if no operation is performed and the following
conditions exist.
• The Main Door is closed
• The Audit key-switch is not turned on
• No button is pressed
3. The following table describes the functions for each item in the KMS menu.
KMS MENU
MENU DESCRIPTION
AUDIT Displays various Software Meters.
GAME RECALL Display the game history.
SETUP Allows the setup options for the game.
LP21 Provides long pull 21 communication. Setup instructions can be found starting on page XX.
DIAGNOSTIC Diagnoses various devices installed on the game.
OUT OF SERVICE Displays “OUT OF SERVICE” message and locks the machine.
Each section will be reviewed in greater detail.
RetuRning fRom KmS mode
1. Turn the Reset key to the vertical position.
2. If no option has been changed, the Game screen is displayed.
3. If any option has been changed, the game must be restarted.

6© 2019 Konami Gaming Inc.P/N 810497 KXP Setup Manual
KMS NAVIGATION
Various screens are available when working in KMS to
assist in navigating the software. The following sections
describe how to use these features.
uSeR inteRface Button Panel oPeRationS
The displayed menus can be accessed by pressing
the buttons on the touchscreen or, in the event of a
touchscreen failure, by pressing the lit buttons on the
user interface button panel.
The Basic BuTTon Panel
The function of the basic button panel is as follows:
BASIC BUTTON PANEL
BUTTON FUNCTION
Previous Item Moves the cursor to the previous item.
Next Item Moves the cursor to the next item.
Select Item Selects the item where the cursor is
placed.
Exit Returns to the previous menu.
Pull Down Menu
Press Next Item/Previous Item
to go to the target eld. When
the target eld is selected,
press Select Item to show
the pull down menu. Press
Next Item/Previous Item as
needed to go to the new
eld. Press Select Item again
to enter the selection.
check Box
Press Next Item/Previous Item
to go to the target eld. When
the target eld is selected,
press Select Item to check or
uncheck the item.
coMBo Box
Press Next Item/Previous Item to go to the target eld.
When the target eld is selected, press Select Item to
enable or disable the selection.
DigiTal keyBoarD
• The Previous Item button moves the cursor to
the previous item
• The Next Item button moves the cursor to the
next item
• The Shift button changes the keyboard to lower/
upper case
• The Select Item button selects the item where
the cursor is placed
• The Enter button enters the current selection
• The Cancel button cancels the current operation.
Set the alphanumeric characters, move the cursor to
the Enter button, and then press Select Item to enter
the selection.
nuMeric keyPaD
Set the numeric characters,
move the cursor to the Enter
button, and then press Select
Item to enter the selection.

7© 2019 Konami Gaming Inc.P/N 810497 KXP Setup Manual
GAME INITIALIZATION PROCEDURE (RAM CLEAR)
The Game Initialization Procedure clears all game data in non-volatile memory, lling each byte with 00 (Hex). It
clears all audit meters, logs, and game information, and allows the operator to clear game option settings.
A RAM CLEAR procedure is required the rst time the game is started.
The following settings can be changed during the RAM Clear Procedure.
• Machine Number Settings
• Clock and Date Settings
• Credit Settings
• Cash Device Settings
• Security Settings
• Communications Settings
• Standalone Mystery Jackpot Settings
• Sound Settings
• Denomination Setting
• Game Common Settings
• Pay Table Settings
• Progressive Combination Settings

8© 2019 Konami Gaming Inc.P/N 810497 KXP Setup Manual
Ram cleaR PRoceduRe
Perform the RAM Clear procedures as follows:
1. Turn off power to the Machine.
2. Open the Logic Unit Door and slide out the MPU board to allow easy access to the Compact Flash
cards and connectors.
3. Install the RAM CLEAR Compact Flash Card into the lower Flash Card connector on the underside of
the MPU.
4. Return MPU board to its slot by pressing rmly on the front edge of the board, making sure that the
board is fully engaged.
5. Close the Logic Unit Door.
6. Power up the Machine. The following screen is displayed.
7. Press RESET to reset all the settings saved as their default values (This procedure is highly
recommended for game initialization.). Press CURRENT to keep previously saved settings and
continue the procedures.
8. The KMS SETUP menu is displayed. There are two different KMS SETUP menus - one for domestic
games and one for international games (See the SETUP section for screenshots and details for each
screen).
9. Press Exit to return to the KMS SETUP screen.
10. Press Exit again.
11. When the following message is displayed, power off the machine to complete game initialization.
12. Power on the machine to return to GAME mode.

9© 2019 Konami Gaming Inc.P/N 810497 KXP Setup Manual
OPERATION
See the following descriptions to identify the game screen items listed below.
game ScReen
1. When the system is in Game Mode, the game screen is displayed. Following is a sample game screen from
the African Diamond game.
2. The game screen consists of the following areas:
A. CREDIT, BET AND WIN AREA
The credit, bet and win area displays the available credits, the amount bet, the amount won, the maximum
credits that can be wagered and the amount wagered per line.
B. GAME AREA
The game area displays image that corresponds to game type. For example, Reels and Play lines are displayed
in the Slot game. The cards and pay table is displayed in the Poker or Black Jack game. During the featured
game, the game area is changed into the feature’s image.
C. HELP BUTTON AND DENOM. BUTTON AREA
The help and paytable button displays the instructions for game play and the currently installed game’s paytable,
and the SELECT DENOM button allows the player to select the denomination of the game.
HelP and Pay taBle
The following is an example HELP (30-Line Game) and PAY TABLE setup.
• Screen 1 of 6 displays the line conguration for this game.
• Screen 2 of 6 displays the button instructions for this game.
• Screen 3 of 6 displays the scatter pay awards.
• Screen 4 of 6 displays the sofa so good bonus awards.
• Screen 5 of 6 displays the days off bonus awards.
• Screen 6 of 6 displays the days off award schedule.
NOTE:Help and Paytable screens are game specific
and will vary according to the installed game. Screens
displayed are for example only and may differ from the
currently installed game.

10 © 2019 Konami Gaming Inc.P/N 810497 KXP Setup Manual
KMS OVERVIEW
The following owchart shows an overall view of options in KMS.
KMS
Audit Game Recall Setup (id) Diagnostic Out of Service
Audit Meters
Game Meters
Logs
Game Events Machine
Number
Setup (id)
Communications
Setup
Locale Setup
Sound Setup
Credit Setup (id)
Pay Table Setup
Cash Device
Setup
Denomination
Setup
Security Setup
Game Common
Setup
Internat’l Setup
Extend Game
Setup
Touch Panel
Monitor
Sound
Coin Acceptor
Button
EBUS LED
Screen
Coin Hopper
Door
Bill Acceptor
Communication
Hardware Monitor
Out Port
Printer
Game
LED Illuminations
LP21 CRC Calc.
General
Meters 1
Bill/
Tickets
Cashless/
Bonusing 1 Game
Play
Progressive
Jackpots
Par
Game
Par
Denomination
Bill In
Cancelled
Credit
Handpay
Ticket In AFT Transaction
Ticket Out EFT Transaction
Jackpot System Bonus
Progressives Cashout
Meters
Logs
General
Meters 2
Cashless/
Bonusing 2
Theme 1 Play Theme 2 Play
Par 1 Play Par 2 Play
Par ... Play Par 10 Play
$0.01
Internat’l
Settings p.1
Internat’l
Settings p. 2 Extended Game
Options Setup
Dual Progressive
Setup
Per
Game
Communication Channel Setup (id)
Validation
Setup
Controller
Setup
Cashless Transfer
Setup
SAS Protocol
Setup
Progressive
Setup
Network
Setup
Singapore
Meters (i)
Summary (i)
Machine
Game
Legend: i = international screen id = international and domestic screens possible
KP3 Setup Screens
Seven Segment
Reel
$...
$0.02 $5.00
Settings
LED
E-ART
Locali-
zation
Key-On Credit (i)
Key-On
Credit
Trans. (i)
Machine ID
Extended
Game
Meters(id)
Game License
Setup

11 © 2019 Konami Gaming Inc.P/N 810497 KXP Setup Manual
KMS
AUDIT
1. From the KMS menu press AUDIT. The following screen is displayed.
2. Options available in the AUDIT menu are AUDIT METERS, GAME RECALL, LOGS, GAME EVENTS,
EXTENDED GAME METERS.
The EXTENDED GAME METERS tab is only available if there are additional progressive games available.
3. Select a Tab to change options. Alternatively, use the Previous Page/Next Page buttons to move between tabs.
4. Select a button to view the options for each screen.
5. Press EXIT to return to the AUDIT menu.
AUDIT

12 © 2019 Konami Gaming Inc.P/N 810497 KXP Setup Manual
KMS AUDIT
audit meteRS
1. From the AUDIT menu, press AUDIT METERS. The following screen is displayed.
2. Tabs available in the AUDIT METERS screen are GENERAL METERS 1, GENERAL METERS 2, BILL/
TICKETS, CASHLESS BONUSING, and CASHLESS BONUSING 2.
3. Screen defaults to the GENERAL METERS 1 Tab.
AUDIT METERS

13 © 2019 Konami Gaming Inc.P/N 810497 KXP Setup Manual
KMS AUDIT
geneRal meteRS 1
1. The following table describes the functions for each item in the GENERAL METERS 1 screen.
AUDIT METERS - GENERAL METERS 1
ITEM DESCRIPTION
COIN IN
This meter accumulates the total credits wagered to game play from any source including credits
wagered from the credit meter, inserted coins directly wagered and residual credits wagered to the
Mini Game.
COIN OUT
This meter accumulates the total won credits from both regular game play and the Mini Game paid
by the machine. If the game is initialized with RAM Clear Compact Flash Cards of NV, MI, MS, ONT
and QUE, this meter does not include any win from progressive or external bonuses. Otherwise,
this meter includes any won credits paid by the machine.
COIN DROP This meter accumulates the total amount of coins or tokens dropped into the cash box.
ATTENDANT PAID JACKPOTS
This meter accumulates the total credits won from regular game play paid by attendant. If the game
is initialized with RAM Clear Compact Flash Card of NV, MI, MS, ONT and QUE, this meter does
not include any won form progressives and external bonuses. Otherwise, this meter includes any
won credits paid by attendant.
ATTENDANT PAID CANCELLED
CREDITS This meter accumulates the total credits paid by attendant in cash-out.
PHYSICAL COIN IN This meter accumulates the total amount of coins or tokens accepted including inappropriate coins
in.
PHYSICAL COIN OUT This meter accumulates the total amount of coins or tokens out from the Hopper including overpaid
coins and Hopper runaway.
BILL IN This meter accumulates the total amount of cash in from bills.
VOUCHER IN This meter accumulates the total amount of cashable tickets accepted and redeemed.
VOUCHER OUT This meter accumulates the total amount of cashable tickets printed.
MACHINE PAYOUT PERCENTAGE
FROM PAYTABLE WON
PAYOUTS Machine payout percentage form payable won payouts.
WITH PROGRESSIVE
JACKPOTS Machine payout percentage with progressive jackpots.
WITH EXTERNAL BONUS
AWARDS Machine payout percentage with external bonus awards.
WEIGHTED AVERAGE PAYBACK This meter shows Weighted Average Theoretical Payback Percentage of the payable and each bet
category.
AUDIT METERS

14 © 2019 Konami Gaming Inc.P/N 810497 KXP Setup Manual
KMS AUDIT
geneRal meteRS 2
1. Press the GENERAL METERS 2 tab to enter the GENERAL METERS 2 screen. The following screen is displayed.
2. The following table describes the functions for each item in the GENERAL METERS 2 screen.
AUDIT METERS
AUDIT METERS - GENERAL METERS 2
ITEM DESCRIPTION
TOTAL DROP
This meter accumulates the total amount
of drop including coins dropped to the
cashbox, bill drop, ticket drop and credits
transferred to the machine.
HOPPER TEST This meter accumulates the total number
of coins paid out in hopper test mode.
HOPPER OVER-
PAY
This meter shows the total number of
occurrences of hopper overpay.
HOPPER RUN-
WAY
This meter shows the total number of
occurrences of hopper runaway.
NUMBER OF EX-
CESSIVE COIN-IN
(AFTER TILT)
This meter shows the total number of coins
accepted with inhibited from accepting
coins.
OVERFED COINS
LEFT
This meter shows the total amount of coins
inserted after game start.
RESIDUAL CREDIT PAYOFF
GAMES PLAYED
This meter shows the total number of
games played in the residual credit
removal game.
GAMES WON
This meter shows the total number of
games won in the residual credit removal
game.
COIN IN This meter shows the total amount of coins
in from the residual credit removal game.
COIN OUT This meter shows the total amount of coins
out from the residual credit removal game.
AUDIT METERS - GENERAL METERS 2
ITEM DESCRIPTION
MACHINE PAID WON JACKPOTS
MACHINE PAID
PAYTABLE WON
PAYOUTS
This meter shows the total amount of
winnings the machine paid from the
paytable.
MACHINE PAID
PROGRESSIVE
PAYOUT
This meter shows the total amount of
winnings the machine paid from the
progressives.
MACHINE PAID
EXTERNAL BO-
NUS PAYOUTS
This meter shows the total amount of win-
nings the machine paid from the external
bonus.
ATTENDANT PAID WON PAYOUT
ATTENDANT PAID
PAYTABLE WON
PAYOUT
This meter shows the total amount of
winnings the attendant paid from the
paytable.
ATTENDANT PAID
PROGRESSIVE
PAYOUTS
This meter shows the total amount of
winnings the attendant paid from the
progressive.
ATTENDANT PAID
EXTERNAL
BONUS PAYOUT
This meter shows the total amount of
winnings the attendant paid that came
from the external bonus.

15 © 2019 Konami Gaming Inc.P/N 810497 KXP Setup Manual
KMS AUDIT
singaPore MeTers (inTernaTional)
1. Press the SINGAPORE METERS tab to enter the SINGAPORE METERS screen. The following screen is displayed.
The Singapore Meters Tab is only available on International versions of the software.
2. The following table describes the functions for each item in the SINGAPORE METERS screen.
AUDIT METERS - SINGAPORE METERS
ITEM DESCRIPTION
TURNOVER/BET This meter shows the total amount of machine turnover/bet.
TOTAL WINS/WON This meter shows the amount of total wins.
MONEY IN This meter shows the total money taken in.
MONEY OUT This meter shows the total money paid out.
GAMES PLAYED This meter shows the total number of games played.
CANC CRED/HANDPAYS This meter shows the total amount for cancelled credit/handpays.
COINS IN This meter shows the total amount of coins taken in.
COINS OUT This meter shows the total amount of coins paid out.
COIN DROP/CASH BOX This meter shows the amount of coin drop/cash box.
BANKNOTES IN This meter shows the total amount in banknotes taken in.
TOTAL CASHLESS IN This meter shows the total amount in cashless transactions.
TOTAL CASHLESS OUT This meter shows the total amount paid out in cashless transactions.
JACKPOTS This meter shows total number of jackpots hit.
MAIN DOOR ACCESSES This meter shows the total number of main door accesses on the machine.
POWER UPS This meter shows the total number of power ups performed on machine.
HOPPER JAMMED This meter shows the total number of times hopper jammed.
HOPPER EMPTY This meter shows the total number of times hopper was empty.
YOYO ATTEMPTS This meter shows number of yoyo attempts.
REFILL AMOUNT This meter shows the total amount relled.
TICKET IN This meter shows the total amount in tickets.
TICKET OUT This meter shows the total paid out in tickets.
AUDIT METERS

16 © 2019 Konami Gaming Inc.P/N 810497 KXP Setup Manual
KMS AUDIT
Bill/ticKetS
1. Press the BILL/TICKETS tab to enter the BILL/TICKETS screen. The following screen is displayed.
2. The following table describes the functions for each item in the BILL/TICKETS screen.
AUDIT METERS - BILL/TICKETS
ITEM DESCRIPTION
BILLS
$1 This meter shows the total number of $1 bills accepted.
$5 This meter shows the total number of $5 bills accepted.
$10 This meter shows the total number of $10 bills accepted.
$20 This meter shows the total number of $20 bills accepted.
$50 This meter shows the total number of $50 bills accepted.
$100 This meter shows the total number of $100 bills accepted.
$500 This meter shows the total number of $500 bills accepted.
BILLS IN This meter shows the total number and the amount of bills accepted.
BILLS IN STACKER This meter shows the total number and amount of bills accepted.
BILLS REJECTED This meter shows the total number and amount of bills rejected.
VOUCHER IN
CASHABLE/VOUCHER IN This meter shows the total number and amount of voucher in.
COUPON PROMOTION This meter shows the total number and amount of coupon promotion in.
CASHABLE PROMOTION IN This meter shows the total number and amount of cashable promotion in.
TOTAL VOUCHER/COUPON/TICKET IN This meter shows the total number and amount of voucher/coupon/ticket in.
TOTAL BILL VALIDATOR This meter shows the total number and amount of bill validator.
VOUCHER OUT
VOUCHER OUT This meter shows the total number and amount of voucher out.
COUPON PROMOTION OUT This meter shows the total number and amount of coupon promotion out.
HANDPAY RECEIPTS
JACKPOTS This meter shows the total number and amount of handpay receipts for jackpots.
CANCEL CREDITS This meter shows the total number and amount of handpay receipts for cancelled credits.
AUDIT METERS

17 © 2019 Konami Gaming Inc.P/N 810497 KXP Setup Manual
KMS AUDIT
caSHleSS/BonuSing 1
1. Press the CASHLESS/BONUSING 1 tab to enter the CASHLESS/BONUSING 1 screen. The following screen
is displayed.
2. The following table describes the functions for each item in the CASHLESS/BONUSING 1 screen.
AUDIT METERS - CASHLESS/BONUSING 1
ITEM DESCRIPTION
CREDITS TRANSFERRED IN
ELECTRONIC FUNDS TRANSFER IN This meter accumulates the total amount of cashable credits transferred in from a nancial institution.
WAGERING ACCOUNT TRANSFER IN This meter accumulates the total amount of cashable credits transferred in from a wagering account.
CASHABLE ELECTRONIC PROMOTION IN This meter accumulates the total amount of cashable promotional credits transferred in from a
wagering account.
NON-CASHABLE ELECTRONIC PROMOTION
IN
This meter accumulates the total amount of non-cashable promotional credits transferred in from a
wagering account.
CREDITS TRANSFERRED OUT
CASHABLE ELECTRONIC PROMOTION OUT This meter accumulates the total amount of cashable promotional credits transferred out to a
wagering account.
NON-CASHABLE ELECTRONIC PROMOTION
OUT
This meter accumulates the total amount of non-cashable promotional credits transferred out to a
wagering account.
WON CREDITS This meter accumulates that total won credits transferred out to a wagering account.
CREDITS TO TICKET OUT
ELECTRONIC FUNDS TRANSFER This meter accumulates the EFT transferred out to a ticket.
WAGERING ACCOUNT TRANSFER This meter accumulates the total amount of cashable credits transferred out to a ticket.
NON-CASHABLE ELECTRONIC PROMOTION This meter accumulates the total amount of non-cashable promotional credits transferred out to a
ticket.
AFT BONUS AWARD
BONUS COIN OUT WIN This meter accumulates the total bonus coin out won.
BONUS JACKPOT WIN This meter accumulates the total bonus jackpot won.
SAS SYSTEM BONUS
DEDUCTIVE BONUS This meter accumulates the total SAS deductive system bonus awards.
NON-DEDUCTIVE BONUS This meter accumulates the total SAS non-deductive system bonus awards.
WAGER MATCH This meter accumulates that total SAS wager match system bonus awards.
AUDIT METERS
