Spectroradiometer CS-2000
NEW
Highly precise spectral radiance/chromaticity measurement possible from 0.003 cd/m2
Achieving 100,000 : 1 contrast measurement
World's top level capability to detect extremely low luminance

World's top level capability to detect extremely
low luminance
* As a polychromator type spectroradiometer (As of November 2007)
100,000:1 contrast measurement is now possible!
* When the peak luminance is 300 cd/m2
Since the commencement of high-definition TV broadcasting, there is an accelerating proliferation of high-quality
display devices which support full HD for reproduction of sharp, high-resolution images. State-of-the-art technology is
now achieving tone reproduction with contrasts of 100,000 : 1, offering an almost-real feeling. This has spurred technical
competition for reproduction of "blacker blacks" in particular, resulting in the need for an instrument that can measure
extremely low luminance.
In addition, the development of various light-emitting devices, including organic electroluminescent (EL) displays as well
as conventional LCD and plasma displays, requires more accurate spectrum analysis. The CS-2000 is a polychromator-
type spectroradiometer which achieves 100,000 : 1 contrast measurement with the world's top level capability to detect
extremely low luminance levels of 0.003 cd/m2.
Highly accurate measurement of luminances as
low as 0.003 cd/m2
Konica Minolta's original optical design and signal-
processing technologies provide accurate measurement of
luminance/chromaticity down to extremely low luminances of
0.003 cd/m2.
Low-luminance measurements: From 0.003 cd/m2
Measurement accuracy: ±2% (Luminance)
Quick measurements even at low luminance
Designed to thoroughly eliminate mechanical and
electrical noise factors, the CS-2000 makes quick
measurements with good repeatability possible even at
low luminance levels.
Measurement time for 1 cd/m2:
Approx. 5 sec. (FAST mode)
* Konica Minolta's previous model CS-1000: Approx. 123 sec.
Low polarization error
The polarization error generated when using a
reflection-type diffraction grating has been minimized
to 2% (measuring angle: 1°). This ensures more stable
measurements of display devices that use polarization,
such as LCDs.
Half bandwidth of 5 nm
A half bandwidth of 5 nm, which is required for colorimetry
(JIS Z 8724-1997, CIE122-1996), is ensured for the
entire wavelength range, allowing accurate chromaticity
measurements.
Selectable measuring angle for measurement of
tiny areas
The CS-2000 enables you to select the optimum measuring
angle according to the application.
Measuring angle selection: 1°, 0.2°, 0.1°
Minimum measuring area: ø0.1 mm (when the optional close-
up lens is attached)
Practical design
• The operating temperature range of 5 to 35°C ensures
reliable operation at temperatures in actual work
environments.
• Measurement can be started after a warm-up time of only
30 seconds. (Measuring angle: 1°; Target luminance:
5 cd/m2or more; 23°C)
Stable measurement even of periodic light sources
1. Internal synchronization measurement
Measurement at numerically-input frequency
2. External synchronization measurement
Measurement with line input of vertical synchronization
signal to instrument
3. Multi-integration mode measurement
Measurement for reducing variations due to unsynchronized
measurements or synchronized measurements of sources
having irregular light-emission cycles
Measurement example:
Measurement of an organic EL illumination panel during development

LCD pixels
Measurement Exam
pl
e
s
Organic ELLCDPDP
LCD pixels
Measuring diameter
viewed through
viewfinder
Measurements of various objects are possible by selecting
the best-suited measuring angle.
Measuring distance vs. measuring area (Units: mm)
Measuring distance Measuring angle
1° 0.2° 0.1°
When a close-up lens
is attached
55.0 ø1.00 ø0.20 ø0.10
70.9 ø1.39 ø0.28 ø0.14
350 ø5.00 ø1.00 ø0.50
500 ø7.78 ø1.56 ø0.78
1,000 ø16.66 ø3.33 ø1.67
2,000 ø34.18 ø6.84 ø3.42
* The measuring distance is the distance from the objective lens or the end of the metal frame
of the close-up lens.
Close-up lens for measurement of even tinier areas
(Optional accessory)
1° is suitable for
Typical targets such as middle- and
large-size display units
• LCD, PDP, or EL display panels
• LCD panels of cellular phones and
digital cameras
• Radar and other instrument panels
used in airplane cockpits
• Large outdoor display screens
0.2° is suitable for
Small light sources such as LEDs
• Car audio systems
• Instrument panels for automobiles
• Lamps, fluorescent tube backlights,
and other light sources
0.1° is suitable for
Extremely small light sources or
distant lights
• PDP or LCD pixels
• Cold-cathode tubes
• Brake lamps of automobiles
• Traffic signals
Optional close-up lens allows measurements of areas as tiny as ø0.1 mm. Not only general display units but also small
targets can be measured.

Average repeatability (logarithm)
Average repeatability (logarithm)
100
10
1
0.1
Average repeatability (logarithm)
Average repeatability (logarithm)
100
10
1
0.1
Average repeatability (logarithm)
Average repeatability (logarithm)
100
10
1
0.1
CS-2000
CS-1000
CS-2000
CS-1000
CS-2000
Luminance ( Lv ) Chromaticity ( x ) Chromaticity ( y )
CS-1000
Difference:
24.7 times
Difference:
24.7 times Difference: 34.7 times
Difference:
34.7 times Difference: 24.3 times
Difference:
24.3 times
AC Adapter
AC-A312
Eyepiece with ND filter
CS-A1
Calibration certificate
CCD Camera
Adapter
CS-A36
CS-2000 main unit
USB cable (2 m)
CS-A32
Personal computer
(commercial product)
Standard accessories
Optional accessories
ND filter
(1/10) CS-A33
(1/100) CS-A34
Lens Cap
Data Management
Software
CS-S10w
Professional
Edition
Close-up lens
CS-A35
White Calibration Plate
CS-A5 (without data)
CS-A5 (with data)
CS-A5 (with data
and calibration certificate)
Storage Case
CS-A30
Pan Head
CS-A4
Tripod
CS-A3
Projector
System Configuration
Measured luminance vs. Measurement times
(Units: sec.)
High repeatability achieved by an instrument design which thoroughly eliminated mechanical and electrical noise factors.
Comparison of
repeatability
* Comparison with Konica Minolta's previous model CS-1000 for target luminance of 0.1 cd/m2
* The y-axis indicates the logarithm when the average of the CS-2000 measured values is assumed to be 1.
Luminance (cd/m2) NORMAL mode FAST mode
0.003 243 35
0.01 243 35
0.1 155 27
1195
10 4 4
300 3.7 3.7
Measurement subject: Standard light source A
* All time indications are approximate values.
Thermal analysis diagram
of the sensor block
The optical sensor, which is the
heart of the CS-2000, was designed
through precise analysis in order to
eliminate the influence of thermal
distortion of its components on the
measurement values.
Measurement example:
A display panel with a high contrast ratio (Image)
Technology

With this software, the CS-2000 can be controlled from a personal computer to display measured data in various graphs
or lists, to transfer data to spreadsheet software, or to copy-and-paste data. CS-S10w offers various data management,
analysis and evaluation options to assist in research and development or quality control.
Display Spectral graph, spectral data list, chromaticity diagram
Color space mode Lvxy, Lvu'v', LvT∆uv, XYZ, dominant wavelength,
excitation purity
Calculation Four basic arithmetic operations and
function processing of spectral data
Mode selection Normal mode, contrast mode, RGB mode, RGB &
contrast mode, object color mode
Instrument control Averaging measurement, interval measurement, user calibration
Data management Reading/saving files; managing data by using folders;
creating, saving and reading templates with various graphs
designed and laid-out by users; displaying data with graphs
Data evaluation Observer/illuminant setting, color rendering property evaluation,
statistic value display for each folder, box tolerance setting,
multiple point setting for display evaluation, non-uniformity
(mura) display, contrast display, polygonal tolerance setting
Multiple data objects can be copied
and pasted to spreadsheet software.
Template showing xy and u'v' chromaticity diagrams
• Windows®is a trademark or registered
trademark of Microsoft Corporation in the
USA and other countries.
• Pentium®is a trademark of Intel Corporation
in the USA and other countries.
Data Management Software CS-S10w Professional (Standard accessory)
System requirements
OS Windows®2000 Professional SP4,
Windows®XP Professional SP2/×64 Edition,
Windows®Vista Business 32-bit (x86)/64-bit (x64)
CPU Pentium®III 600 MHz equivalent or faster
(recommended)
Memory 128 MB or more
(256 MB or more recommended)
Hard disk 60 MB or more of free space for installation
Display 1024 x 768, 256 colors minimum
Other CD-ROM drive for installation, USB port
for instrument connection
Color LCD screen
Color space mode
screen
Menu screen
cd
m
2
Lv 30 .79
0 . 3211
0 . 3404
x
y
cd
m
2
Lv 30 .79
6027K
+0 . 005
T
duv
Simple
operation
The desired function
can be called
intuitively.
Easy
connection
via USB
Easy operation with color LCD screen and simple operation panel
The color LCD screen and operation panel are located at the rear of the instrument.
The simply arranged operation panel enables intuitive selection of necessary
functions.
a
n
d
p

Certificate No : JQA-E-80027
Registration Date : March 12, 1997
Certificate No : YKA 0937154
Registration Date : March 3, 1995
For correct use and for your safety, be sure to read the instruction
manual before using the instrument.
lAlways connect the instrument to the specified power supply
voltage. Improper connection may cause a fire or electric shock.
SAFETY PRECAUTIONS The specifications and drawings given here are
subject to change without prior notice.
- If you have any questions about specifications,
please contact your Konica Minolta representative.
http://konicaminolta.com/instruments/about/network
2007 KONICA MINOLTA SENSING, INC.
67.4
79
70
392
253
51
50 47
Filter thread
diameter:
ø52
58.5
300
200
Reference
for measuring
distance
Optical axis
95.7 229.5
9
Mounting screw: M5,
Depth: 6.5
Mounting screw: M5,
Depth: 6.5
Tripod screw (ø3/8-inch screw)
Positioning pin hole (1):
ø5, Depth: 4
5
6
Positioning pin hole (2):
Depth: 4
90
158
190.4
170
ø15
120.5 129
Model CS-2000
Wavelength range 380 to 780 nm
Wavelength resolution 0.9 nm/pixel
Display wavelength bandwidth 1.0 nm
Wavelength precision ±0.3 nm (Median wavelength: 435.8 nm, 546.1 nm, 643.8 nm; Hg-Cd lamp)
Spectral bandwidth 5 nm or less (half bandwidth)
Measuring angle (selectable) 1° 0.2° 0.1°
Measurement luminance range
(Standard light source A) 0.003 to 5,000 cd/m20.075 to 125,000 cd/m20.3 to 500,000 cd/m2
Minimum measuring area ø5 mm
(ø1 mm when using close-up lens)
ø1 mm
(ø0.2 mm when using close-up lens)
ø0.5 mm
(ø0.1 mm when using close-up lens)
Minimum measuring distance 350 mm (55 mm when using close-up lens)
Minimum luminance display 0.00002 cd/m2
Accuracy: Luminance
(Standard light source A)*1 ±2%
Accuracy: Chromaticity
(Standard light source A)*1
x,y :±0.003 (0.003 to 0.005 cd/m2)
x,y :±0.002 (0.005 to 0.05 cd/m2)
x : ±0.0015
(0.05 cd/m2or more)
y : ±0.001
x,y : ±0.003 (0.075 to 0.125 cd/m2)
x,y : ±0.002 (0.125 to 1.25 cd/m2)
x : ±0.0015
(1.25 cd/m2or more)
y : ±0.001
x,y : ±0.003 (0.3 to 0.5 cd/m2)
x,y : ±0.002 (0.5 to 5 cd/m2)
x : ±0.0015
(5 cd/m2or more)
y : ±0.001
Repeatability: Luminance (2σ)
(Standard light source A)*2
0.4% (0.003 to 0.05 cd/m2)
0.3% (0.05 to 0.1 cd/m2)
0.15% (0.1 to 5,000 cd/m2)
0.4% (0.075 to 1.25 cd/m2)
0.3% (1.25 to 2.5 cd/m2)
0.15% (2.5 to 125,000 cd/m2)
0.4% (0.3 to 5 cd/m2)
0.3% (5 to 10 cd/m2)
0.15% (10 to 500,000 cd/m2)
Repeatability: Chromaticity (2σ)
(Standard light source A)*2
0.002 (0.003 to 0.005 cd/m2)
0.001 (0.005 to 0.1 cd/m2)
0.0006 (0.1 to 0.2 cd/m2)
0.0004 (0.2 to 5,000 cd/m2)
0.002 (0.075 to 0.125 cd/m2)
0.001 (0.125 to 2.5 cd/m2)
0.0006 (2.5 to 5 cd/m2)
0.0004 (5 to 125,000 cd/m2)
0.002 (0.3 to 0.5 cd/m2)
0.001 (0.5 to 10 cd/m2)
0.0006 (10 to 20 cd/m2)
0.0004 (20 to 500,000 cd/m2)
Polarization error 1°: 2% or less (400 to 780 nm); 0.1° and 0.2°: 3% or less (400 to 780 nm)
Integration time Fast: 0.005 to 16 sec.; Normal: 0.005 to 120 sec.
Measurement time 1 sec. minimum (Manual mode) to 243 sec. maximum (Normal mode)
Color space mode Lvxy, Lvu'v', LvT∆uv, XYZ, spectral graph, dominant wavelength, excitation purity
Interface USB 1.1
Operating temperature/
humidity range 5 to 35°C, relative humidity 80% or less with no condensation
Storage temperature/
humidity range 0 to 35°C, relative humidity 80% or less with no condensation
Power AC adapter (100 - 240 V , 50/60 Hz)
Current consumption Approx. 20 W
Size 158 (W) x 262 (H) x 392 (D) mm
Weight 6.2 kg
*1: Average of 10 measurements in Normal mode at a temperature of 23±2°C and a relative humidity of 65% or less.
*2: 10 measurements in Normal mode at a temperature of 23±2°C and a relative humidity of 65% or less.
Major specifications of CS-2000
Outer dimensions (Units: mm)
9242-4892-10 AHLAPK
1
