Korenix JetNet 6710G User manual

JetNet 6710G/ JetNet 6810G User Manual
1
Korenix JetNet 6710G /JetNet 6810G Series
Industrial 8-Port PoE + 2 Gigabit TX
Managed Ethernet Switch
User Manual
Ver. 1.1, 17-Feb-2014
Firmware v1.1/v1.1b (HVDC)
www.korenix.com

JetNet 6710G/ JetNet 6810G User Manual
2
Korenix JetNet 6710G / JetNet 6810G Series
Industrial 8 Port PoE + 2 Gigabit TX Managed
Ethernet Switch
User’s Manual
Copyright Notice
Copyright 2012 Korenix Technology Co., Ltd.
All rights reserved.
Reproduction in any form or by any means without permission is prohibited.

Federal Communications Commission (FCC) Statement
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in
a commercial environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the
user will be required to correct the interference at his expense.
The user is cautioned that changes and modifications made to the equipment without
approval of the manufacturer could void the user's authority to operate this equipment.

JetNet 6710G/ JetNet 6810G User Manual
1
Index
1 Introduction........................................................................................................................3
1.1 Overview...............................................................................................................................3
1.2 Major Features .....................................................................................................................7
1.3 Package List .........................................................................................................................8
2 Hardware Installation.......................................................................................................10
2.1 Hardware Introduction ........................................................................................................ 11
2.2 Wiring Power Inputs............................................................................................................ 16
2.3 Wiring RS-232 console and Relay Output .......................................................................... 17
2.4 Wiring Earth Ground & Lighting /Surge Ground..................................................................19
2.5 Wiring Fast Ethernet Ports..................................................................................................20
2.6 Wall-Mounting Installation...................................................................................................25
3 Preparation for Management ...........................................................................................26
3.1 Preparation for Serial Console............................................................................................26
3.2 Preparation for Web Interface.............................................................................................27
3.3 Preparation for Telnet Console ...........................................................................................30
4 Feature Configuration......................................................................................................33
4.1 Command Line Interface Introduction.................................................................................34
4.2 Basic Setting....................................................................................................................... 41
4.3 Port Configuration...............................................................................................................61
4.4 Power over Ethernet........................................................................................................... 69
4.5 Network Redundancy .........................................................................................................78
4.6 VLAN .................................................................................................................................. 98
4.7 Private VLAN .................................................................................................................... 107
4.8 Traffic Prioritization ........................................................................................................... 113
4.9 Multicast Filtering.............................................................................................................. 119
4.10 SNMP ...............................................................................................................................124
4.11 Security.............................................................................................................................128
4.12 Warning ............................................................................................................................135
4.13 Monitor and Diag ..............................................................................................................146
4.14 Device Front Panel ...........................................................................................................154
4.15 Save to Flash....................................................................................................................155
4.16 Logout...............................................................................................................................156
5 Appendix........................................................................................................................157
5.1 JetNet 6710G Product Specifications ...............................................................................157
5.2 JetNet 6810G Product Specifications ...............................................................................162
5.3 Korenix Private MIB for JetNet 6710G and JetNet 6810G................................................ 166
5.4 Revision History................................................................................................................ 169
5.5 About Korenix ...................................................................................................................170

JetNet 6710G/ JetNet 6810G User Manual
2

JetNet 6710G/ JetNet 6810G User Manual
3
1 Introduction
Welcome to Korenix JetNet 6810G Series Industrial 8-Port PoE + 2G
Managed Ethernet Switch User Manual. Following topics are covered in
this chapter:
1.1 Overview
1.2 Major Features
1.3 Package Checklist
1.1 Overview
The eight 10/100 TX PoE injector ports can deliver up to 200W (JetNet 6710G)
and 120W (JetNet 6810G) power per unit and 15.4W /30W per port by IEEE
802.3af / IEEE 802.3at standards to fulfill local increasing PoE demands. The
two Gigabit Ethernet ports provide high speed uplink to connect with higher
level backbone switches with Korenix MSRTM network redundancy technology.
Korenix MSRTM can recover the network failure in less than 5ms. To work
under vibrationand shock environments, the industrial M12 connectors provide
exceptional solid Ethernet and PoE connections. Korenix JetNet 6710G-M12
/JetNet 6810G-M12 / JetNet 6710G-RJ/ JetNet 6810G-RJ series, the
revolutionary Gigabit Managed Industrial Power over Ethernet Switches with
patented 24V to 57V Power booster technology embedded in JetNet 6810G
series , are specifically designed for making the deployment of standard PoE
IP cameras feasible on buses, railcars, ships, harbors, etc. With the smart
thermal detection function, the JetNet 6810G isolated power booster becomes
an intelligent and reliable power control device for PoE vehicle applications in
harsh environments with high temperature variations.
.Driving the IP Surveillance Market
Since the ratification of the Power over Ethernet standard in 2003, the Power
over Ethernet technology becomes a trend; more devices adopt PD
technology to obtain power through Ethernet cable eliminating the need of
running separate power wirings to a remote device. The JetNet
6710G-M12/JetNet 6810G-M12 /JetNet 6710G-RJ/JetNet 6810G-RJ are
equipped with the new PSE solution, compliant with IEEE 802.3af/at standard
and forced powering mode. It supports 8 PoE ports in End-span wiring

JetNet 6710G/ JetNet 6810G User Manual
4
architecture with 120W or 200W per unit at 60°C operating temperature, to
drive the IP cameras for cross–street monitoring or WiMAX systems for
internet access at train stations, airports or Hot-spots.
Power Budget Limitation with Port plug-in priority Control
The JetNet 6710G/JetNet 6810G series provides system power budget and
port budget control to ensure that the total power consumption will not exceed
the power limit installed by user. It also provides budget control function to limit
the output power in case if the PD device is not claimed right consumption
numbers. This feature allows user to protect high priority PD devices from shut
down caused by overloading of the power supply.
Isolated 24V DC PoE Booster for Vehicle Deployment
JetNet 6810G-M12 series is designed with the Korenix patented DC 24V to
57V boost technology for vehicle PoE applications where DC 57V power
supply is not available. The DC booster supports High-pot isolation feature to
protect the device from the lighting and surge of the Ethernet cable and meets
IEEE mandate safety requirement of Power over Ethernet and UL safety
requirement of TNV-1 circuit. The isolated system design allows JetNet 6810G
series efficiently powering outdoor PD equipments, such as Wireless AP,
WiMax systems, Outdoor IP cameras and other PoE-enabled devices. With
the booster technology it provides fast, easy and cost-effective solution for
configuring PoE networks on transportation and automation applications.
Smart Thermal & Power Booster Protection
As states the rule of”The Principle of Conservation of Energy”, the energy
remains constant and cannot disappear in any isolated system, but can be
converted to another form. This rule is the same in electrical circuit, where it
can generate heat and become higher when the loading is more and therefore,
can cause a system shut-down. To avoid this situation, JetNet 6810G series
adopts thermal detector to check the temperature of DC booster and adjust the
available PoE output to ensure the DC booster is working under safety
temperature. This behavior refers to the output curve of power booster; Once
the temperature exceeds the limit, system will turn off the PSE port. This
feature makes JetNet 6810G -RJ PoE switch an intelligent power control
device that helps you to maintain the PD devices under specific temperatures.
Rugged RJ45 /m12 Connectors Against Vibration and Shock
In most occasions, PD devices installed in industrial environments are being
subjected to vibration, shock, dust and other environmental threats. Korenix
has designed JetNet 6710G / JetNet 6810G series with 8 rugged RJ45 or m12

JetNet 6710G/ JetNet 6810G User Manual
5
Ethernet connectors resistant to vibration and shock and ideal solutions for
outdoor networking applications, such as telecom, outdoor surveillance,
wireless AP connections etc.
Rapid Super ring (RSRTM) Technology
Rapid Super Ring is the 2nd generation of Korenix Ring Redundancy
technology. The recovery time is greatly improved from 30ms to few ms for
both copper and fiber ring. The Ring master can be auto-selected by RSR
engine. The 1st ring port of the R.M. is the primary path while the 2nd ring port
of the R.M. is the block path. Once the primary path fails, the 2nd path will be
recovered within few ms. Besides, the restore time is also shortened to zero in
the R.M. auto-selection mode.
Comprehensive Redundant Solutions –Multiple Super Ring (MSRTM)
The JetNet managed PoE Switch supports new generation ring technology -
MSRTM (Multiple Super Ring) which includes various new technologies for
different network redundancy applications and structures. The JetNet 6710G/
JetNet 6810G allows aggregating up to 5 Rapid Super Rings, including 4 Fast
Ethernet plus 1 Gigabit Ethernet Rings. With the MSRTM technology, a node
can be configured to multiple rings with the failover time in as little as 5ms and
zero-second of restoration time. In addition, users can extend the ring topology
by adding hundreds of JetNet series to meet the large-scale network needs
without compromising the network speed. The MSRTM also allows the JetNet
series to easily connect with core management switches via standard Rapid
Spanning Tree protocol or through multiple paths or nodes to increase the
reliability by RDHTM (Rapid Dual Homing) technology. By integrating MSRTM
and Link Aggregation Control Protocol (LACP) the JetNet series can enhance
the link availability and increase the overall link capacity. Two or more Fast
Ethernet connections are combined in order to increase the bandwidth and to
create a resilient and redundant link.
Seamless Ring Port Restoration TM
Seamless restoration is a new Korenix patented technology which can restore
a failed ring without causing any loop problem, topology change and packet
loss. With a 0 second restoration time, this mechanism eliminates any unstable
status and guarantees the applications running non-stop.
Rapid Dual Homing (RDHTM) Technology
Rapid Dual Homing is also the important feature of Korenix new generation
Ring technology. It supports ring coupling with other vendors and with easy
configuration and multiple redundancies, the failover time is much faster and
the restore time is zero ms. Uplinks can be auto detected and gathered into

JetNet 6710G/ JetNet 6810G User Manual
6
groups. In each group, uplinks are sorted into primary, secondary and
standbys by their link speed. The uplink with the highest speed is more likely to
be active path for data transmission. Link aggregation is also integrated into
RDHTM. An uplink connection can be a single link or several links aggregated
as a trunk, which provides better redundancy and link capacity.
TrunkRingTM
TrunkRing is a new feature in MSR which merges the two technologies of RSR
and link aggregation. It takes advantages of aggregation to enhance the link
redundancy, while increase the link speed. The ring will open only if all the
aggregated links are broken. Link aggregation can be achieved by either,
static trunk or LACP. Not all the link sections in a TrunkRing need to be the
same. Ring links can be either symmetric or asymmetric. Some are a single
path, and the others are aggregated by links where the number of links in a
trunk group can be different. Users can enhance the link redundancy at
different locations in accordance to the need. And the link with less speed is
more likely to be used as the backup path for restoring the network to full play
capacity.
Link Aggregation Control Protocol
Link Aggregation Control Protocol allows you grouping multiple Ethernet ports
in parallel to increase the link bandwidth. The aggregated ports can be viewed
as one physical port, so that the bandwidth is higher than just one single
Ethernet port. The member ports of the same trunk group can balance the
loading and backup with each other. The LACP feature is usually used when
you need higher bandwidth for the backbone network. This is a cost-effective
way for you to transfer much more data.
Multi Powering Mechanism- User Manual, Forced and IEEE 802.3at LLDP
Power over Ethernet
Some of Legacy PD devices also feature user defined manual mode and
forced powering mode to support non-standard PD devices without the PoE
signature resistor for some WiMax systems, which are non-compliant with
IEEE 802.3at LLDP Power over Ethernet.
For the new PoE standard –IEEE 802.3at, JetNet 6810G implements Link
Layer Discovery Protocol (LLDP) into the system for allowing power budget
negotiation between PD devices while providing smart power budget control
behavior.
Auto Topology Discovery & Efficient Management through LLDP and
JetView Pro i2NMS

JetNet 6710G/ JetNet 6810G User Manual
7
Korenix ‘s Managed Ethernet Switches support topology discovery or LLDP
(IEEE 802.1AB Link layer Discovery Protocol) function that can help users to
discover multi-vendor’s network devices on the same segment by an NMS
system, which support LLDP function. With LLDP function, NMS can easily
maintain the topology map, display port ID, port description, system
description, VLAN ID, etc. Once a link failure happens, the topology changed
events are updated to the NMS to help users easily maintain the network
system. Besides the SNMP and LLDP protocols,JetNet 6810G series
efficiently works with the Korenix patented JetView Pro i2NMS, which in
addition to the auto-topology discovery, also delivers MSRTM group
management, group IP assignment, firmware upgrade, configuration file
backup/ restore ,SNMP MIB Browser /compile, etc. Furthermore, users can
export the topology map to diverse formats, such as JPG, BMP, PNG and PDF,
for easily managing and trouble-shooting the network. The user-friendly
software allows administrators to discover devices automatically and efficiently
manage the performance of the industrial network.
Outstanding Management and Enhanced Security
The JetNet 6710G/JetNet 6810G series provides various network control and
security features to ensure the reliable and secure network connection. To
optimize the industrial network environment, JetNet 6710G/ JetNet 6810G
series supports advanced network features, such as Tag VLAN, Private VLAN,
QinQ, IGMP Snoopinig, Qualit of Service (QoS), Link Aggregation Control
protocol (LACP), Rate Control, etc. To avoid hacker’s attach and ensure the
secure data transmission, JetNet 6710G/JetNet 6810G series features DHCP
client/Server/option 82 (DHCP relay) with IP MAC binding, IEEE 802.1x
Access control, SSH for telnet security, IP access table, port security and many
other advanced features for your industrial network communication.
1.2 Major Features
Korenix JetNet 6810G/ JetNet 6710G Series products have the following
features:
8 10/100 Base TX PoE and 2 Gigabit uplink ports
Rugged RJ45 Ethernet connectors to protect from vibration and shock
applications such as PoE in Tram, Rail or Highway
8 PoE ports support IEEE 802.3af/IEEE 802.3at standard with 120W
total power budget (JetNet 6810G series)
8 PoE ports support IEEE 802.3af/IEEE 802.3at standard with 200W
total power budge (JetNet 6710G series)
8 PoE ports support IEEE 802.3f/ IEEE802.3at sytandard with 120W

JetNet 6710G/ JetNet 6810G User Manual
8
total power budge (JetNet 6710G-HVDC series), 100W Power at 70°
C.
Built-in Isolated 24V to 57V DC PoE Booster for vehicle use ( JetNet
6810G series)
Built-in 77V ~137.5Vdc input isolated power bucker with DC 48V
output for vehicle IP surveillance use (JetNet 6710G-HVDC series)
32Gbps switch Fabric, 8K MAC address
All ports support Korenix patented RSR with 5ms recovery time, and
MSR for up to 4 x 100M Rings plus 1 Gigabit Ring
IEEE 802.1AB LLDP and optional JetView Pro i2NMS software for
auto-topology and group management
Tag VLAN for multiple VLAN traffic isolation and QinQ for private
VLAN
LACP port trunk for bandwidth aggregation in video surveillance
Auto Power Budget Control with Thermal Detection
Alarm Relay output for port event
AC 1.5KV Hi-Pot Isolation Protection for ports and power
EN 50121-4 EMC certification for railway installations
IEC 61373 Vibration and Shock certificate for railway indtallation
-40~70°C wide operating temperature
Note: The detail spec is listed in Appendix 5.1 and 5.2
1.3 Package List
Korenix JetNet 6710G/ 6810G Series products are shipped with following
items that indicated in the table:
JetNet 6710G-M12
JetNet 6710G-RJ
JetNet 6810G-M12
JetNet 6810G-RJ
JetNet 6710G-m12 HVDC
JetNet 6710G-RJ HVDC
JetNet 6710G Managed High Power IEEE 802.3at PoE Switch
(M12 / Rugged RJ)
1
1
JetNet 6710G-HVDC Managed High Power IEEE802.3at PoE
Switch (M12/Rugged RJ)
1
1
JetNet 6810 Managed Booster PoE Switch ( M12 / Rugged RJ)
1
1
M12 on DB9 Shielded Console Cable
1
1
1
1
1
1

JetNet 6710G/ JetNet 6810G User Manual
9
Rugged M12 D-coded 4-pole Field Assemble able Connecter
8
8
8
Rugged M12 A-coded 8-pole Field Assemble able Connector
2
2
2
Rugged RJ45 Field Assemble able Connecter
10
10
10
Rugged IP 67 DC power connector (4-pin)
1
1
1
1
Rugged M12 A-coded 4-pin Field Assembly able Power
Connector
1
1
2 Wall-Mount kits & 8 Screws
1
1
1
1
1
1
Quick Installation Guide
1
1
1
1
1
1
Documentation and Software CD-ROM
1
1
1
1
1
1
If any of the above items is missing or defect, please contact your local
sales representative.

JetNet 6710G/ JetNet 6810G User Manual
10
2 Hardware Installation
This chapter includes hardware introduction, installation and
configuration information.
Following topics are covered in this chapter:
2.1 Hardware Introduction
Dimension
Panel Layout
Bottom View
2.2 Wiring Power Inputs
2.3 RS-232 console and relay output
2.4 Wiring Earth ground
2.5 Wiring Ethernet Ports
2.6 Wall-mounting Installation

JetNet 6710G/ JetNet 6810G User
Manual
11
2.1 Hardware Introduction
Dimension –JetNet 6810G/JetNet 6710G-HVDC series
W/o mounting kit: 198(W) x 145.2 (H)x 120(D)
W/ mounting kit: 230.6(W) x 145.2 (H)x 120(D)
JetNet 6810G-RJ
JetNet 6810G-m12

JetNet 6710G/ JetNet 6810G User Manual
12
Dimension –JetNet 6710G series
JetNet 6710G-m12/JetNet 6710G-RJ: 198(W) x145.2 (H)x75.7(D) w/o mounting kit
JetNet 6710G-m12/JetNet 6710G-RJ: 230.6(W)x145.2 (H)x75.7(D) w/ mounting kit
JetNet 6710G-m12 HVDC
JetNet 6710G-RJ HVDC

JetNet 6710G/ JetNet 6810G User Manual
13
JetNet 6710G-m12
JetNet 6710G-RJ

JetNet 6710G/ JetNet 6810G User Manual
14
Panel Layout
The front panel includes 10/100Mbps PoE ports, Gigabit Ethernet ports,
RS232 console with DO port, System / Port LED and Power input.
Note: the Jetnet 6810G’s power input conductor does not support redundant
power input function and must aggregate two V+ conductors as one input circuit
to get high current carry abilitity; as well as the V- conductors.
JetNet 6810G series
JetNet 6710G Series

JetNet 6710G/ JetNet 6810G User Manual
15
JetNet 6710G-m12 HVDC

JetNet 6710G/ JetNet 6810G User Manual
16
2.2 Wiring Power Inputs
The Power input port is located at the top of the front panel and supports
redundant input function via a proprietary assembly capable IP-67 connector
(CDG-L207SA) included in the shipment. If you cannot find this power
connector, please contact your local distributor. For the available input power
range and recommended cable size, please refer to the below table.
Power Input (DC Voltage)
Input Conductor
Cable Size
Minimum
Maximum
Recommended
Redundant Input
AWG No. / Cable Area (mm2)
JetNet 6710G-M12
48
60
48
V1, V2
AWG 14 / 2.0
JetNet 6710G-RJ
48
60
48
V1, V2
AWG 14 / 2.0
JetNet 6710G-HVDC
77
137.5
100
V1,V2
AWG 14/ 2.0
JetNet 6810G-M12
22
27
24
V1, V2 bind together
AWG 14 / 2.0
JetNet 6810G-RJ
22
27
24
V1, V2 bind together
AWG 14 / 2.0
Table 2 Power Input Voltage
The JetNet 6810G only supports single power input that binds V1 and V2
together to obtain higher current for the booster.
Use the UL listed LPS Switching power supply to powering the JetNet Switch.
For the power wiring method, please refer to the figures 2.2-1 and 2.2-2.
For system safety and the anti-immunity ability, the chassis ground screw
should be well grounded to the earth ground.
Figure 2.2-1 Power Wiring Diagram

JetNet 6710G/ JetNet 6810G User Manual
17
2.3 Wiring RS-232 console and Relay Output
The RS-232 console and the alarm relay are connected via the assembly
type of 5-pole M12 A-coding connector included in the supplied package of
JetNet switch. The following figure 3-2-1 is the disassembly diagram of M12
A-coding connector.
In the M12 connector packing, the parts 1, 2, 3 are already assembled.
Follow the steps for soldering and assembling the cable and connector
together:
Step -1: Slide component 4, 5, 6 and then 7 over the
console cable. Keep them loose. Do not tighten them
yet. 2 cable glands are provided for cable diameter from
Figure 2.2-2 Power connector assembly diagram
Figure 2.3-1 Field Assemble M12 disassembly
connector diagram
