Kramer WAS-3 User manual

Congratulations on purchasing your Kramer Wall Plate Inserts (each is supplied with the
required screws)! They are ideal for the following applications: board, conference and training
rooms, presentation systems, and home theater. Each insert can be used with the Kramer
WP Frame or with one of our TBUS products.
WAS-3
The WAS-3 is a dual-insert for s-Video on a
4p connector and unbalanced stereo audio on
RCA connectors (white for L and red for R).
 
The terminal block PINOUT is as follows:
WAS-3P
The WAS-3P is a dual-insert with pass through connectors for s-Video on a 4p
connector and unbalanced stereo audio on RCA connectors (white for L and red for R):
WAS-4
The WAS-4 is a dual-insert for video (composite or SDI) on a yellow RCA connector, s-Video on
a 4p connector, and unbalanced stereo audio on RCA connectors (white for L and red for R).
The terminal block PINOUT
is as follows:
WXA-2
The WXA-2 is a dual-insert for unbalanced stereo audio on a 3.5mm mini plug connector and
UXGA computer graphics on an HD15F connector.
The terminal block PINOUT is as follows:
Right
Ground
Left
Ground
C
Ground
Y
Ground
Ground
CV
Left
Right
Ground
Y
C
All manuals and user guides at all-guides.com

WXA-2P
The WXA-2P is a dual-insert with pass through connectors for UXGA computer
graphics on an HD15F connector and unbalanced stereo audio on a 3.5mm mini plug
connector:
Wall Plate Inserts Series:  
 
WAS-3, WAS-3P, WAS-4, WXA-2, WXA-2P
 
 
For the latest information on our products and a list of Kramer distributors, visit our
Web site: www.kramerelectronics.com 
 
 
 
 
Kramer Electronics, Ltd.
Web site: www.kramerelectronics.com
E-mail: [e-mail]
P/N: 2900-000278 REV 2
