Kramer SID-X2N Installation and operation manual

SID - X2N
4−Input Multi−Format Video over HDBaseT Transmitter & Step− IN Commander
The SID−X2N is an HDBaseT twisted pair
transmitter and step−in commander for
computer graphics video, HDMI, DVI,
DisplayPort and unbalanced stereo audio
signals.
Max. Data Rate - 6.75Gbps (up to 1080p @60Hz 36bpp) in normal mode; up to 4.95Gbps (up to 1080p @60Hz
24bpp) in ultra mode.
HDTV Compatible.
HDCP Compliant. - Works with sources that support HDCP repeater mode.
HDMI Support - Deep Color, x.v.Color™ and 3D.
I -EDIDPro™ Kramer Intelligent EDID Processing™ - Intelligent EDID handling & processing algorithm ensures Plug
and Play operation for HDMI systems.
Data Equalization and Reclocking.
Input Signal Detection - Based on video clock presence.
Automatic Input Selection - Based on manual selection or last connected input.
Automatic Analog Audio Detection and Embedding.
Local Balanced Audio De-Embedding.
Support for Digital Audio Formats.
Lockable EDID.
System Range - Up to 130m (430ft) normal mode; up to 180m (590ft) ultra mode (1080p @60Hz @24bpp) when
using BC−HDKat6a cables.
Local Step-In Switching - Button & contact closure.
Power Supply - Requires independent power supply.
FEATURES

SID - X2N
TECHNICAL SPECIFICATIONS
INPUTS:
1 HDMI, 1 DVI on a Molex 24−pin connector, 1 DisplayPort, 1 UXGA on a 15−pin HD connector, 1
unbalanced stereo audio on a 3.5mm mini jack.
OUTPUT:
1 DGKat on an RJ−45 connector, 1 unbalanced stereo audio on a 3.5mm mini jack.
STANDARDS:
HDMI with x.v.Color™ and 3D; HDCP: works with sources that support HDCP repeater mode.
MAXIMUM STEP - IN
DISTANCE:
50m (164ft) up to 1080p @60Hz.
POWER
CONSUMPTION:
12V DC, 820mA.
OPERATING
TEMPERATURE:
0° to +40°C (32° to 104°F).
STORAGE
TEMPERATURE:
−40° to +70°C (−40° to 158°F).
HUMIDITY:
10% to 90%, RHL non−condensing.
DIMENSIONS:
18.8cm x 11.3cm x 2.5cm (7.4" x 4.5" x 1") W, D, H.
WEIGHT:
0.48 kg (1.1lbs) approx.
INCLUDED
ACCESSORIES:
Power supply.
OPTIONS:
RK−T2B 19" rack adapter, RTBUS−12, RTBUS−22, SID−X1BP Kit (substitute black top plate for
the SID−X1N that blends with the color of the modular TBUS−10xl), RC−10TB remote contact
closure switch.
