USER MANUAL
Model:
F-110
XGA Line Transmitter on Dual-slot Wall-plate Insert

Contents
i
Contents
1Introduction 1
2Getting Started 1
3Overview 2
3.1About the Power Connect Feature 2
3.2Shielded Twisted Pair (STP) / Unshielded Twisted Pair (UTP) 2
3.3Achieving the Best Performance 3
4Your F-110 XGA Line Transmitter 4
5Connecting the F-110 5
5.1Wiring the 9-pin Terminal Block Line Output Connector 7
5.2Wiring the CAT 5 LINE IN / LINE OUT RJ-45 Connectors 8
6Using the F-110 8
7Technical Specifications 10
Figures
Figure 1: F-110 XGA Line Transmitter 4
Figure 2: Connecting the F-110 to the TP-120 6
Figure 3: Terminal Block Pinouts 7
Figure 4: CAT 5 PINOUT 8
Tables
Table 1: F-110 Features 4
Table 2: CAT 5 PINOUT 8
Table 3: F-110 Applications 8
Table 4: Technical Specifications of the F-110 10

Introduction
1
1 Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been
providing a world of unique, creative, and affordable solutions to the vast
range of problems that confront the video, audio, presentation, and
broadcasting professional on a daily basis. In recent years, we have
redesigned and upgraded most of our line, making the best even better! Our
1,000-plus different models now appear in 11 groups1that are clearly
defined by function.
Thank you for purchasing the Kramer F-110 XGA Line Transmitter on
dual-slot wall-plate insert which is ideal for:
•Presentation venues
•Multimedia applications
•Long range graphics distribution for schools, hospitals, security, and
stores
The F-110 can be mounted on Kramer2:
•Wall-plate insert mounting frames for Ackermann floor boxes
•TBUS table connection buses connecting surfaces
•Wall plate insert frames
The package includes the following items:
•F-110
•Power adapter (12V DC Input) and this user manual3
2 Getting Started
We recommend that you:
•Unpack the equipment carefully and save the original box and
packaging materials for possible future shipment
•Review the contents of this user manual
•Use Kramer high-performance high-resolution cables4
1 GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Matrix Switchers; GROUP 3: Control Systems;
GROUP 4: Format/Standards Converters; GROUP 5: Range Extenders and Repeaters; GROUP 6: Specialty AV Products;
GROUP 7: Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity;
GROUP 10: Accessories and Rack Adapters; GROUP 11: Sierra Products
2 The complete list of Kramer products can be found on our Web site at http://www.kramerelectronics.com
3 Download up-to-date Kramer user manuals from the Internet at http://www.kramerelectronics.com
4 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Overview
2
3 Overview
The Kramer F-110 dual-slot wall-plate insert is an XGA line transmitter
that accepts up to a UXGA video signal, encodes it to a twisted pair (TP)
signal, and transmits the TP signal to a compatible TP receiver1.
In particular, the F-110:
•Has a resolution of up to UXGA
•Includes the Kramer Power Connect™ feature
•Has a 12V DC power supply
•Fits into various insert mounting surfaces2
3.1 About the Power Connect Feature
The Power Connect feature applies as long as the cable can carry power.
This feature is available when using STP cable and the distance does not
exceed 50m on standard CAT 5 cable. For longer distances, heavy gauge
cable should be used3.For units which are connected via RJ-45 connectors,
make sure that the shield of the STP cable is connected to the metal casing
of the connectors on both ends of the cable. For units which are connected
via terminal block connectors, the shield of the STP cable must be
connected to a ground terminal on the units at both ends (use the ground
terminal of the power supply connection if necessary).
For a CAT 5 cable exceeding a distance of 50m, separate power supplies
should be connected to the transmitter and to the receiver simultaneously.
3.2 Shielded Twisted Pair (STP) / Unshielded Twisted Pair (UTP)
We recommend that you use Shielded Twisted Pair (STP) cable. There are
different levels of STP cable available, and we advise you to use the best
quality STP cable that you can afford. Our non-skew-free cable, Kramer
BC-STP is intended for analog signals where skewing is not an issue. For
cases where there is skewing, our UTP skew-free cable, Kramer BC-XTP,
may be used. Bear in mind, though, that we advise using STP cables where
possible, since the compliance to electromagnetic interference was tested
using those cables.
Although Unshielded Twisted Pair (UTP) cable might be preferred for long
range applications, the UTP cable should be installed far away from electric
1 For example, the Kramer TP-120 or PT-120
2 For example, TBUS units, wall plate frames or Ackermann insert mounting frames (see section 6 )
3 CAT 5 cable is still suitable for the video/audio transmission, but not for feeding the power at these distances

Overview
3
cables, motors and so on, which are prone to create electrical interference.
However, since the use of UTP cable might cause inconformity to
electromagnetic standards, Kramer does not commit to meeting the standard
with UTP cable.
3.3 Achieving the Best Performance
To achieve the best performance:
•Use only good quality connection cables1to avoid interference,
deterioration in signal quality due to poor matching, and elevated noise
levels (often associated with low-quality cables).
•Avoid interference from neighboring electrical appliances that may
adversely influence signal quality and position your Kramer F-110
away from moisture, excessive sunlight and dust
1 Available from Kramer Electronics on our Web site at http://www.kramerelectronics.com

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Your F-110 XGA Line Transmitter
4
4 Your F-110 XGA Line Transmitter
Figure 1 and Table 1 define the F-110:
Figure 1: F-110 XGA Line Transmitter
Table 1: F-110 Features
# Feature Function
1 Screw holes (4) Fix the wall plate to the connecting surface
2 PC INPUT 15-pin HD F Connector Connect to the XGA source
3 ON LED Lights green when receiving power
4 12V DC + PIN1Connect (+) to the connector for powering the unit
5 - PIN Connect (-) to the Ground
6 + PIN1Connect (+) to the connector for powering the unit
7 - PIN Connect (-) to the Ground
8 Line output 8-pin terminal block
Connector2Connects to the LINE IN RJ-45 connector on the Kramer PT-120
or TP-120 XGA Line Receiver
1 One set is used to power the F-110 and the other set can be used to power an adjacent insert
2 See section 5.1

Connecting the F-110
5
5 Connecting the F-110
The Kramer F-110 together with the Kramer PT-120 or TP-120 XGA line
receivers constitute a VGA/XGA-to-twisted pair transmitter and receiver.
To connect the F-110, do the following:
1. Unscrew the two screws that fasten each of the two adjacent blank
plates to the connecting surface and remove them.
2. Place and align the F-110 dual-slot wall-plate insert over the opening.
3. Connect the cables to the rear side of the insert, that is, attach the:
Terminal block line output of the F-110 to the pre-installed UTP
wiring that connects to the TP receiver (with a range of more than
300ft (>100m)), see section 5.1
12V DC power supply to either one of the power terminal blocks
(connect the wire labeled “+” to the +12V pin, and the wire labeled
“–” to the GND pin) taking care that the polarity is correct. You can
use the second power terminal block to power an additional unit (for
example, an adjacent insert on the mounting surface)
4. Insert the four screws to fix the insert in place, and tighten them.
5. Connect the UXGA source to the PC IN connector (for example, a
computer graphics source).

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Connecting the F-110
6
Figure 2: Connecting the F-110 to the TP-120

Connecting the F-110
7
5.1 Wiring the 9-pin Terminal Block Line Output Connector
The 8-pin terminal block is an easy plug-in connector for attaching the UTP
cable. Follow the colors of the color-coded sticker on these terminals for
proper connection of the UTP cable. Figure 3 defines the pinouts for the
terminal block.
Figure 3: Terminal Block Pinouts
Notes:
•Use the connector clips only when removing wires, not when inserting
them
•Each wire should protrude 9mm (0.35") from the plastic insulation so
that it can be easily connected. To prevent the wires crossing, be sure
that each wire is fully inserted
Orange / White
Green / White
Brown / White
Brown
Green
Blue / White
Blue
Orange

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Using the F-110
8
5.2 Wiring the CAT 5 LINE IN / LINE OUT RJ-45 Connectors
Table 2 and Figure 4 define the UTP CAT 5 PINOUT, on the RJ-45
connector:
Table 2: CAT 5 PINOUT Figure 4: CAT 5 PINOUT
EIA /TIA 568A EIA /TIA 568B
PIN Wire Color PIN Wire Color
1 Green / White 1 Orange / White
2 Green 2 Orange
3 Orange / White 3 Green / White
4 Blue 4 Blue
5 Blue / White 5 Blue / White
6 Orange 6 Green
7 Brown / White 7 Brown / White
8 Brown 8 Brown
Pair 1 4 and 5 Pair 1 4 and 5
Pair 2 3 and 6 Pair 2 1 and 2
Pair 3 1 and 2 Pair 3 3 and 6
Pair 4 7 and 8 Pair 4 7 and 8
6 Using the F-110
Table 3 shows examples of how the F-110 dual-slot wall-plate insert can be
installed in various applications.
Table 3: F-110 Applications
F-110 installed in a wall plate
insert frame (for example, the
Kramer FRAME 1G/US):

Using the F-110
9
F-110 installed in an
Ackermann floor box frame (for
example, the Kramer FLA-12):
F-110 installed in a TBUS
connecting surface (for
example, a Kramer TBUS):

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Technical Specifications
10
7 Technical Specifications
Table 4 lists the technical specifications:
Table 4: Technical Specifications1of the F-110
INPUT: 1 VGA / UXGA on a 15-pin HD connector
OUTPUT: 1 CAT 5 LINE OUTPUT on an 8-pin terminal block connector
RESOLUTION: Up to UXGA
MAX. OUTPUT LEVEL: 2Vpp
DIFF. GAIN2: 6.3% (worst case)
DIFF. PHASE20.3 Deg (worst case)
K-FACTOR2: <0.05%
S/N RATIO2: 69.5dB , 5MHz
CONTROLS: ON power LED
COUPLING: DC
POWER SOURCE: 12V DC 250mA, feeding receiver
DIMENSIONS: 5cm x 2.4cm x 4.7cm (1.97" x 0.94" 1.85") W, D, H
WEIGHT: 0.14kg (0.31lbs) approx.
ACCESSORIES: Power supply
1 Specifications are subject to change without notice
2 For the transmitter/receiver pair

11
LIMITED WARRANTY
WHOISPROTECTED?
WHATISCOVEREDANDWHATISNOTCOVERED
WHATWE WILLPAYFORAND WHATWEWILLNOTPAYFOR
HOW YOU CAN GET WARRANTY SERVICE
LIMITATIONOFIMPLIEDWARRANTIES
EXCLUSIONOFDAMAGES
CAUTION!
We warrantthisproductfreefromdefectsinmaterialandworkmanshipunderthefollowingterms.
HOWLONGISTHE WARRANTY
Labor and parts are warranted for seven years from the date of the first customer purchase.
Only the first purchase customer may enforce this warranty.
Wewillpaylaborandmaterialexpensesforcovereditems.We willnotpayforthefollowing:
The liability of Kramer for any effective products is limited tothe repair or replacement of the product at our option. Kramershall
notbeliablefor:
Thiswarranty gives you specific legal rights,andyou may alsohave otherrights, whichvaryfrom place toplace.
Allproducts returned to Kramer for service must have prior approval.This may be obtained from your dealer.
Thisequipmenthasbeentestedtodeterminecompliancewiththerequirementsof:
EN-50081: "Electromagneticcompatibility(EMC);
genericemissionstandard.
Residential,commercialandlightindustry"
EN-50082: "Electromagneticcompatibility(EMC)genericimmunitystandard.
Part 1: Residential, commercial and light industryenvironment".
CFR-47: FCC* Rules and Regulations:
Part 15: “Radio frequency devices
Subpart B Unintentional radiators”
Except as below, this warranty covers all defects in material or workmanship in this product. The following are not covered
bythewarranty:
1. Any product which is notdistributed by usor whichis not purchased from anauthorized Kramerdealer. Ifyou areuncertain as
towhethera dealer isauthorized,pleasecontactKramerat oneofthe agents listed intheWebsitewww.kramerelectronics.com.
2. Any product, on which the serial number has been defaced, modified or removed, or on which the WARRANTY VOID
TAMPERED sticker has been torn,
3. Damage,deteriorationormalfunctionresultingfrom:
i) Accident,misuse,abuse,neglect,fire,water,lightningorotheractsofnature
ii) Productmodification,orfailuretofollowinstructionssuppliedwiththeproduct
iii) RepairorattemptedrepairbyanyonenotauthorizedbyKramer
iv) Anyshipmentoftheproduct(claimsmustbepresentedtothecarrier)
v) Removalorinstallationoftheproduct
vi) Anyothercause,whichdoesnotrelatetoaproductdefect
vii) Cartons,equipment enclosures,cablesoraccessories usedinconjunctionwith the product
1. Removalorinstallationscharges.
2. Costs of initial technical adjustments (set-up), including adjustment of user controls or programming. These costs are the
responsibilityoftheKramerdealerfromwhomtheproductwaspurchased.
3. Shippingcharges.
1. To obtain service on you product, you must take or ship it prepaid to any authorized Kramer service center.
2. Whenever warranty service is required, the original dated invoice (or a copy) must be presented as proof of warranty
coverage, and should be included in any shipment of the product. Please also include in any mailing a contact name,
company, address, and a description of the problem(s).
3. For the name of the nearest Kramer authorized service center, consult your authorized dealer.
All implied warranties, including warranties of merchantability and fitness for a particular purpose, are limited in duration to
the length of this warranty.
1. Damage to other property caused by defects in this product, damages based upon inconvenience, loss of use of the product, loss
oftime,commercial loss;or:
2. Anyother damages, whether incidental, consequential or otherwise. Somecountriesmaynotallowlimitationsonhow long an
implied warranty lasts and/or do not allow the exclusion or limitation of incidental or consequential damages, so the above
limitationsandexclusionsmaynotapplytoyou.
Servicing the machines can only be done by an authorized Kramer technician. Any user who makes changes or
modifications to the unit without the expressed approval of the manufacturer will void user authority to operate the
equipment.
Pleaseuserecommendedinterconnection cablestoconnectthemachinetoothercomponents.
IF reattached, removed or otherwise interfered with.
* FCC and CE approvedusing STPcable (for twistedpair products)
NOTE:
Part1:

Kramer Electronics, Ltd.
Web site: www.kramerelectronics.com
E-mail: [e-mail]
P/N: 2900-000718 REV 3
For the latest information on our products and a list of Kramer
distributors, visit our Web site: www.kramerelectronics.com
where updates to this user manual may be found.
We welcome your questions, comments and feedback.
Caution
Safety Warning:
Disconnect the unit from the power supply before
opening/servicing.
