WP-871xr Quick Start
P/N:
2900- 301061QS
Rev:
2
Scan for full manual
WP-871xr Quick Start Guide
This guide helps you install and use your WP-871xr for the first time.
Go to www.kramerav.com/downloads/WP-871xr to download the latest user manual and check if firmware
upgrades are available.
Step 1: Check what’s in the box
WP-871xr HDMI 4K Line Transmitter
1 Quick start guide
1 Power adapter (with open DC head) and cord
Frame (or frame set) and faceplate
Step 2: Get to know your WP-871xr
#
Feature
Function
1
HDMITM IN Connector
Connects to an HDMI source.
2
STATUS LED
Lights green when power is connected to the device.
Lights blue when powered and both active source and acceptor are detected.
3
Ring Tongue Terminal Grounding
Screw
Connect to grounding wire (optional).
4
Power Supply 2-pin Terminal Block
Connector
To Connect to a power supply (if required). Connect GND to GND, +12V to +12V.
5
DGKat-2.0 OUT RJ-45 Connector
Connect to the DGKat-2.0 IN connector on the using CAT 6A cable.
The terms HDMI, HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.

Front Panel –Before assembly
#
Feature
Function
SETUP DIP-switches
Do not change the default DIP-switch settings (located on the front panel)
6
DIP-switch 1
Compression
ON (right) –High compression level for additional range extension
(default).
7
DIP-switch 2
Compression Setup
OFF (left) –Enable compression (default).
ON (right) –For future use.
Step 3: Install the WP-871xr
Insert the device into the in-wall box (note that first you need to connect the DGKAT 2.0 cable and power) and connect
the parts as shown in the illustrations below:
European Version
US Version
We recommend that you use any of the following standard 1 Gang in-wall junction boxes (or their equivalent):
US: 1 Gang US electrical junction boxes.
EU: 1 Gang in-wall junction box, with a cut-hole diameter of 68mm and depth that can fit in both the device and the
connected cables (DIN 49073).
UK: 1 Gang in-wall junction box, 75x75mm (W, H) and depth that can fit in both the device and the connected cables
(BS 4662).

Step 4: Connect the inputs and outputs
Always switch OFF the power on each device before connecting it to your WP-871xr. For best results, we recommend that
you always use Kramer high-performance cables to connect AV equipment to the WP-871xr.
We highly recommend using only Kramer UNIKAT cables with these products. If using 3rd party shielded CAT 6A
cables, both ends of the shield must be soldered to the connectors for the products to function properly. Do not use
any jumpers, unshielded wall plates or mid-span cable connections. These extenders are not compatible with
HDBaseT technologies. Prior to signal extension, ensure that the extension line cable is lying straight and not coiled.
Step 5: Connect the power
Connect the 12V power adapter to the remote device (for example, PT-872xr) or to WP-871xr if needed, and plug the power
supply into the mains electricity. This device provides power to its counterpart via DGKat 2.0. Each device can provide or
accept power over cable (PoC) via DGKat 2.0.
Safety Instructions
Caution:
There are no operator serviceable parts inside the unit.
Warning:
Use only the Kramer Electronics power supply that is provided with the unit.
Warning:
Disconnect the power and unplug the unit from the wall before installing.
See www.KramerAV.com for updated safety information.

Technical Specifications
Inputs
1 HDMI
On a female HDMI connector
Outputs
1 DGKAT 2.0
On a female RJ-45 connector
Video
Transmitted Data
Bandwidth
Up to 18Gbps (6Gbps per graphic channel)
Max Resolution
3840x2160@60Hz (4:4:4) 24bpp
Compliance
HDMI 2.0, HDCP 2.2, HDR 10
Reach Extension
We recommend that you use Kramer shielded cables to achieve optimum extension ranges.
High Compression Level
Up to 60m (200ft) at 4K@60Hz (4:4:4)
Up to 70m (230ft) at 4K@60Hz (4:2:0) or full HD (1080p
@60Hz 36bpp)
Control
Behind Frame
DIP-switches
Power
Consumption
12V DC, 600mA when coupled with a compatible receiver
Source
12V DC, 2A
Environmental Conditions
Operating Temperature
0° to +40°C (32° to 104°F)
Storage Temperature
-40° to +70°C (-40° to 158°F)
Humidity
10% to 90%, RHL non-condensing
Regulatory Compliance
Safety
CE, UL
Environmental
RoHs, WEEE
Enclosure
Net Dimensions (W, D, H)
US: 7cm x 3.1cm x 11.4cm (2.8" x 1.2" x 4.5)
EU: 8cm x 3.1cm x 8cm (3.1" x 1.2" x 3.1)
UK: 8.6cm x 3.1cm x 8.6cm (3.4" x 1.2" x 3.4")
Shipping Dimensions (W,
D, H)
23.2cm x 13.6cm x 10cm (9.1" x 5.4" x 3.9")
Net Weight
0.17 kg (0.4lbs)
Shipping Weight
0.56 kg (1.2lbs) approx.
Type
Aluminum
Cooling
Convection ventilation
Accessories
Included
1 Power adapter, 1 power cord
For the US version: 2 US Frame sets and faceplates (in black
and in white)
For the European version: 1 EU white frame, 1 UK white
frame, 1 EU/UK white faceplate
Specifications are subject to change without notice at www.kramerav.com
