Kramer TP-780T User manual

USER MANUAL
MODELS:
TP-780T
HDMI Line Transmitter + POE
TP-780R
HDMI Line Receiver + POE
P/N: 2900-300575 Rev 2 www.kramerAV.com

TP-780T/R – Contents i
Contents
1Introduction 1
2Getting Started 2
2.1 Achieving the Best Performance 2
2.2 Safety Instructions 2
2.3 Recycling Kramer Products 3
3Overview 4
3.1 About HDBaseT™ Technology 5
3.2 About Power over Ethernet (PoE) 5
3.3 Using Twisted Pair Cable 6
3.4 Defining the TP-780T HDMI Line Transmitter + POE 7
3.5 Defining the TP-780R HDMI Line Receiver + POE 8
4Connecting the TP-780T/R 9
4.1 Controlling AV Equipment via an IR Transmitter 11
4.2 Connecting to a PC 14
5Wiring the RJ-45 Connectors 15
6Technical Specifications 16
Figures
Figure 1: TP-780T HDMI Line Transmitter + POE 7
Figure 2: TP-780R HDMI Line Receiver + POE 8
Figure 3: Connecting the TP-780T/ TP-780R Transmitter/Receiver Pair 10
Figure 4: Controlling a DVD Player via the TP-780T/R 12
Figure 5: Controlling an LCD Display via the TP-780T/R 13
Figure 6: RS-232 Control via the TP-780T/R 14
Figure 7: TP PINOUT 15

TP-780T/R - Introduction 1
1 Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been
providing a world of unique, creative, and affordable solutions to the vast range of
problems that confront video, audio, presentation, and broadcasting professionals
on a daily basis. In recent years, we have redesigned and upgraded most of our
line, making the best even better!
Our 1,000-plus different models now appear in 14 groups that are clearly defined by
function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers;
GROUP 3: Control Systems; GROUP 4: Format/Standards Converters; GROUP 5:
Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:
Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9:
Room Connectivity; GROUP 10: Accessories and Rack Adapters; GROUP 11:
Sierra Video Products; GROUP 12: Digital Signage; GROUP 13: Audio; and
GROUP 14: Collaboration.
Congratulations on purchasing your Kramer TP-780T/R transmitter/receiver pair,
which is ideal for the following typical applications:
•Projection systems in conference rooms, boardrooms, auditoriums, hotels
and churches, production studios
•Rental and staging
Note that TP-780T and TP-780R are purchased separately, and can
be connected to other HDBaseT certified transmitters and receivers,
respectively.

2 TP-780T/R - Getting Started
2 Getting Started
We recommend that you:
•Unpack the equipment carefully and save the original box and packaging
materials for possible future shipment
•Review the contents of this user manual
Go to www.kramerav.com/downloads/TP-780T to check for up-to-date
user manuals, application programs, and to check if firmware upgrades
are available (where appropriate).
2.1 Achieving the Best Performance
To achieve the best performance:
•Use only good quality connection cables (we recommend Kramer high-
performance, high-resolution cables) to avoid interference, deterioration in
signal quality due to poor matching, and elevated noise levels (often
associated with low quality cables)
•Do not secure the cables in tight bundles or roll the slack into tight coils
•Avoid interference from neighbouring electrical appliances that may
adversely influence signal quality
•Position your TP-780T/R away from moisture, excessive sunlight and dust
This equipment is to be used only inside a building. It may only be
connected to other equipment that is installed inside a building.
2.2 Safety Instructions
Caution:
There are no operator serviceable parts inside the unit
Warning: Use only the Kramer Electronics power supply that is
provided with the unit
Warning: Disconnect the power and unplug the unit from the
wall before installing

TP-780T/R - Getting Started 3
2.3 Recycling Kramer Products
The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC aims
to reduce the amount of WEEE sent for disposal to landfill or incineration by
requiring it to be collected and recycled. To comply with the WEEE Directive,
Kramer Electronics has made arrangements with the European Advanced
Recycling Network (EARN) and will cover any costs of treatment, recycling and
recovery of waste Kramer Electronics branded equipment on arrival at the EARN
facility. For details of Kramer’s recycling arrangements in your particular country go
to our recycling pages at http://www.kramerelectronics.com/support/recycling/.

4 TP-780T/R - Overview
3 Overview
The TP−780T and TP−780R are a 4K UHD, twisted pair receiver and transmitter for
HDMI, bidirectional RS−232 and IR signals. They support resolutions up to
4K@60Hz (4:2:0) UHD. The TP−780T converts HDMI, RS−232, and IR signals into
a twisted pair signal that it transmits to a TP−780R receiver. The TP−780R converts
the twisted pair signal back into HDMI, bidirectional RS−232 and IR signals. The
TP−780T and TP−780R support PoE (Power over HDBT). The TP-780T provides
power remotely over HDBT to the TP-780Rwhere it might be difficult to connect an
external power supply. This allows a single HDBT LAN cable to provide both data
and electrical power to compatible devices.
The TP-780T and the TP-780Rcan form a transmission and reception system
either together or each device separately with another certified HDBaseT device.
The TP-780T/R transmitter and receiver feature:
•A data transfer rate of up to 10.2Gbps (3.4Gbps per graphic channel)
•Resolution support of up to 4K @60Hz (4.2.0) UHD
•A range of up to 70m (230ft) at 2K, 40m (130ft) at 4K UHD resolutions.
For optimum range and performance using HDBaseT™, use
Kramer's BC−HDKat6a cable. Note that the transmission range
depends on the signal resolution, source and display used. The
distance using non−Kramer CAT 6 cable may not reach these
ranges.
•HDBaseT™ technology
•Power over HDBT that passes electrical power along with data on Ethernet
cabling. This allows a single cable to provide both data connection and
electrical power to compatible devices
•HDTV compatibility and HDCP compliance
•HDMI support for Deep Color, x.v.Color™, Lip Sync, HDMI Uncompressed
Audio Channels, Dolby TrueHD, DTS−HD, CEC.

TP-780T/R - Overview 5
•EDID pass through, passes EDID/HDCP signals from the source to the
display
•Bidirectional RS-232 & IR interface where commands and data can flow in
both directions via the RS−232 interface, allowing status requests and
remote control of the destination unit (see Section 4.1)
•LED status indicators for input selection, output, link and power
•Compact MegaTOOLS® enclosures, and these can be rack mounted side-
by-side in a 1U rack space with the optional RK-T2B universal rack adapters
3.1 About HDBaseT™ Technology
HDBaseT™ is an advanced all-in-one connectivity technology (supported by the
HDBaseT Alliance). It is particularly suitable in the consumer home environment as
a digital home networking alternative where it enables you to replace numerous
cables and connectors by a single LAN cable used to transmit, for example,
uncompressed full high-definition video, audio, IR, as well as various control
signals.
The products described in this user manual are HDBaseT certified.
3.2 About Power over Ethernet (PoE)
Power over Ethernet (HDBaseT) passes electrical power along with data on
Ethernet cabling. This allows a single twisted pair cable to provide both a data
connection and electrical power to compatible devices. PoE is convenient, flexible
and safe requiring the use of fewer power outlets, simpler configuration and low
power connections over standard category cables. A 48V DC power supply
connects to the PoE transmitter and can power the PoE receiver up to a distance of
100 meters (320 feet). Beyond this range, a 12V DC power supply must be
connected to the PoE receiver.
The TP-780T is a PoE injector. It cannot receive power from
another PoE injector but only from a 48V DC power supply.

6 TP-780T/R - Overview
3.3 Using Twisted Pair Cable
Kramer engineers have developed special twisted pair cables to best match our
digital twisted pair products; the Kramer BC−HDKat6a (CAT 6 23 AWG cable)
significantly outperforms regular CAT 5 / CAT 6 cables.
We strongly recommend that you use shielded twisted pair cable.

TP-780T/R - Overview 7
3.4 Defining the TP-780T HDMI Line Transmitter + POE
Figure 1: TP-780T HDMI Line Transmitter + POE
#
Feature
Function
1
IN LED
Lights green when an HDMI input device is connected
2
OUT LED
Lights green when an HDMI output device is detected
3
LINK LED
Lights green when the TP connection is active
4
ON LED
Lights green when receiving power
5 HDBT OUT RJ-45 Connector Connects to the HDBT IN RJ-45 connector on the
TP-780R
6
HDMI IN Connector
Connects to the HDMI source
7
PROG/NORMAL Switch
Slide to PROG to upgrade to the latest Kramer
firmware via RS-232, or slide to NORMAL for normal
operation
8
RS-232 9-pin D-sub
Connector
Connects to an RS-232 port for firmware upgrade and
control of the destination unit
9
IR 3.5mm Mini Jack
Connector
Connects to an external infrared transmitter / sensor
(receiver)
10
48V DC Terminal Block
+48V DC connector for powering the unit

8 TP-780T/R - Overview
3.5 Defining the TP-780R HDMI Line Receiver + POE
Figure 2: TP-780R HDMI Line Receiver + POE
# Feature Function
1
IN LED
Lights green when an HDMI input device is connected
2
OUT LED
Lights green when an HDMI output device is detected
3
LINK LED
Lights green when the TP connection is active
4 ON LED Lights green (DC power) and orange (HDBaseT PoE).
When both power sources are detected, lights orange
(HDBaseT PoE) if within range and green if exceeds
range
5 HDBT IN RJ-45 Connector Connects to the HDBT OUT RJ-45 connector on the
TP-780T
6
HDMI OUT Connector
Connects to the HDMI acceptor
7
PROG/NORMAL Button
Slide to PROG to upgrade to the latest Kramer firmware
via RS-232, or slide to NORMAL for normal operation
8
RS-232 9-pin D-sub
Connector
Connects to an RS-232 port for firmware upgrade and
control of the destination unit
9 IR 3.5mm Mini Jack
Connector Connects to an external infrared transmitter / sensor (receiver)
10
12V DC
+12V DC connector for powering the unit

TP-780T/R - Connecting the TP-780T/R 9
4 Connecting the TP-780T/R
Always switch off the power to each device before connecting it to your
Transmitter and Receiver. After connecting your Transmitter and
Receiver, connect their power and then switch on the power to each
device.
You can use the TP-780T/R HDMI Line Transmitter/Receiver + POE to configure an
HDMI transmitter/receiver system, as shown in the example in Figure 3.
To connect the TP-780T, connect the:
1. HDMI source (for example, a DVD player) to the HDMI IN connector.
2. RS-232 9-pin D-sub connector to a computer (for example, a laptop to
control the projector).
3. IR 3.5mm mini jack to an IR emitter.
4. HDBT OUT RJ-45 connector over twisted pair to the HDBT IN connector.
Alternatively, you can use any other certified HDBaseT receiver device (for example,
the Kramer WP-580R)
5. 48V DC power adapter to the power socket and connect the adapter to the
mains electricity (not shown in Figure 3).
To connect the TP-780R, connect the:
1. HDMI OUT connector to the HDMI acceptor (for example, a projector).
2. RS-232 9-pin D-sub connector to an RS-232 port (for example, a projector that is
controlled by the laptop connected to TP-780T).
3. IR 3.5mm mini jack to an IR sensor.
4. HDBT IN RJ-45 connector over twisted pair to the TP-780T HDBT OUT
connector.
Alternatively, you can use any other certified HDBaseT transmitter device (for example,
the Kramer WP-580T)
5. If the POE does not effectively power the TP-780R, connect the 12V DC
power adapter to the power socket and connect the adapter to the mains
electricity (not shown in Figure 3).
!

10 TP-780T/R - Connecting the TP-780T/R
Figure 3: Connecting the TP-780T/ TP-780R Transmitter/Receiver Pair

TP-780T/R - Connecting the TP-780T/R 11
4.1 Controlling AV Equipment via an IR Transmitter
Since the IR signal on the TP-780T/TP-780Rtransmitter/receiver pair is
bidirectional, you can use a remote control transmitter (that is used for controlling a
peripheral device, for example, a DVD player) to send commands (to the AV
equipment) from either end of the transmitter /receiver system. To do so, you must
use the Kramer external IR sensor on one end (P/N: 95-0104050) and the Kramer
IR emitter cable on the other end (P/N: C-A35/IRE-10)
Two IR emitter extension cables are also available: a 15 meter and 20 meter cable.

12 TP-780T/R - Connecting the TP-780T/R
The example in Figure 4illustrates how to control the DVD player that is connected
to TP-780T using a remote control, via the TP-780R. In this example, the external
IR sensor is connected to the IR connector of the TP-780R and an IR emitter is
connected between the TP-780T and the DVD player. The DVD remote control
sends a command while pointing towards the external IR sensor. The IR signal
passes through the TP cable and the IR emitter to the DVD player, which responds
to the command sent.
Figure 4: Controlling a DVD Player via the TP-780T/R

TP-780T/R - Connecting the TP-780T/R 13
The example in Figure 5illustrates how to control the LCD display that is connected
to theTP-780R using a remote control, via theTP-780T. In this example, the
external IR sensor is connected to the IR connector of the TP-780T and an IR
emitter is connected between the TP-780R and the LCD display. The LCD display
remote control sends a command while pointing towards the external IR sensor.
The IR signal passes through the TP cable and the IR emitter to the LCD display,
which responds to the command sent.
Figure 5: Controlling an LCD Display via the TP-780T/R

14 TP-780T/R - Connecting the TP-780T/R
4.2 Connecting to a PC
You can connect to the transmitter/receiver system via an RS-232 connection
using, for example, a PC.
Note: A null-modem adapter/connection is not required.
To connect a PC via RS-232:
•Connect the RS-232 9-pin D-sub rear panel port on the transmitter/receiver
system unit via a 9-wire straight cable (only pin 2 to pin 2, pin 3 to pin 3, and
pin 5 to pin 5 need to be connected) to the RS-232 9-pin D-sub port on your
PC.
Figure 6shows RS-232 bidirectional control of the projector that is connected to
TP-780R, via a PC connected to the TP-780T:
Figure 6: RS-232 Control via the TP-780T/R

TP-780T/R - Wiring the RJ-45 Connectors 15
5 Wiring the RJ-45 Connectors
This section defines the TP pinout, using a straight pin-to-pin cable with RJ-45
connectors.
Note, that the cable ground shielding must be connected / soldered to
the connector shield.
EIA /TIA 568B
Figure 7: TP PINOUT
PIN
Wire Color
1
Orange / White
2
Orange
3
Green / White
4
Blue
5
Blue / White
6
Green
7
Brown / White
8
Brown

16 TP-780T/R - Technical Specifications
6 Technical Specifications
TP-780T
TP-780R
INPUTS:
1 HDMI connector
1 RJ-45 connector
OUTPUTS:
1 RJ-45 connector
1 HDMI connector
PORTS:
1 IR on a 3.5mm mini jack (for
emitter or sensor)
1 RS-232 on a 9-pin D-sub
connector
1 IR on a 3.5mm mini jack (for
emitter or sensor)
1 RS-232 on a 9-pin D-sub
connector
DATA TRANSFER RATE:
Up to 10.2Gbps (3.4Gbps per graphic channel), supporting 4K @60Hz
(4.2.0) resolution
RS-232 BAUD RATE:
115200
STANDARDS COMPLIANCE:
Supports HDMI 1.4 and HDCP 1.4
OPERATING TEMPERATURE:
0° to +40°C (32° to 104°F)
STORAGE TEMPERATURE:
-40° to +70°C (-40° to 158°F)
HUMIDITY:
10% to 90%, RHL non-condensing
POWER CONSUMPTION:
48V DC, 240mA
12V DC, 450mA
DIMENSIONS:
18.8cm x 11.5cm x 2.5cm (7.4" x 4.5" x 1.0") W, D, H
WEIGHT:
0.6kg (1.4lbs)
INCLUDED ACCESSORIES: Power supply 48V/1.36A
Bracket installation kit
Power supply 12V/2A
Bracket installation kit
OPTIONS: RK-T2B 19” rack mount; Kramer external IR sensor (P/N: 95-0104050),
Kramer IR emitter cable (P/N: C-A35/IRE-10); Kramer BC−HDKat6a
cable
Specifications are subject to change without notice
For the most updated resolution list, go to our Web site at http://www.kramerelectronics.com
