Kraus Oletto KPF-2633 User manual

Oletto™ Single Handle Pull Down Kitchen Faucet
KPF-2633
INSTALLATION GUIDE
www.kraususa.com I Toll Free: 1.800.775.0703 I © 2022 Kraus USA Plumbing LLC I REV. JUN 09, 2022

Congratulations on the purchase of your new
Please keep the box and packaging materials until your product is
completely installed. If you have any questions, require technical
assistance, or have any problems with your product:
Please contact our Customer Service Team
1-800-775-0703 / [e-mail]
Have the model number available, and retain a copy of your receipt
with purchase date for reference.
If for any reason this product does not meet your expectations,
please be sure to repack this product in the original box and
packaging material to avoid damage during transit.
DO NOT RETURN TO STORE
1

Prior to Installation:
•Make sure you have all necessary parts by checking the diagram and parts list. If
any part is missing or damaged, please contact Kraus Customer Service at 800-775-
0703 for a replacement
•
•
Pre-drilled countertop hole size requirement: 1-3/8”(min)
•
Max countertop thickness: 2-7/8”
Tools you will need:
13
Wrench Phillips Screwdriver Safety Goggles
Silicone Sealant
(optional)
Pipe Tape
2
to release any built-up pressure
Care & Maintenance
* To keep the product clean & shining, follow the steps below:
1. Rinse with clean water & dry with a soft cloth
2. Do not clean with soaps, acid, polish, abrasives or harsh cleaners
3. Do not use cloth with a coarse surface
4. Unscrew the aerator and clean when necessary
* This installation manual is subject to change without further notice.
ACID
Read all instructions and safety warnings and ensure you have all
and equipment necessary for a safe installation.
•
STOP

3
B. Faucet Body
D. Rubber Washer
E. Metal Washer
G.Screws
B
Diagram and Parts List
H. Weight
K
I. Weight Clip
C
C. Flange
F. Mounting Nut
D
E
F
G
H
I
J
J. Quick Connector
K.Hex Wrench
A. Spray Head
A

4
Faucet Dimension
Installer Tip:
3/8” compression
Ø2 1/4"
[57.0mm]
8 3/4"
[221.3mm]
9 1/8"
[231.0mm]
19 5/8"
[500.0mm]
2 7/8"
[75.0mm]
3 1/2"
[90.2mm]
10 3/8"
[263.9mm]

G
Step 1: Installing the faucet
Step 2: Securing the faucet assembly
and attach it to the receiving block (a). Pull
down moderately to ensure the connection
has been made.
D
E
G
B
F
a
J
(2N.m
Max)
5
C
new faucet assembly. Place faucet (B)
through the hole in countertop. Secure the
faucet (B) to the countertop using the
rubber washer (D), metal washer (E) and
mounting nut (F) provided. Tighten screws
(G). Do not overtighten.
Step 3: Securing the faucet assembly
Install the weight clip (I) at the point of
the hose marking "weight here". Insert
the weight (H) onto the weight clip (I)
by sliding it down onto the weight clip (I).
Weight
here
Weight
here
I
H

Step 5: Flush faucet
Pull the hose assembly out of the spout and
remove the spray head by unscrewing it from
the hose in a counterclockwise direction. Be
sure to hold the end of the hose down into
the sink and turn the faucet on to the warm
position where it mixes hot and cold water.
Flush the water lines for one minute. This
damage to internal parts. Check for leaks.
Re-tighten any connections if necessary, but
do not overtighten. Reinstall the spray head
by hand tightening it back onto the spray
hose.
After installation is completed, turn on the
hot and cold water supplies. Check for leaks.
Step 4: Connect waterlines to main valve
Attach waterlines to angle stops
and tighten until snug. Turn on angle
stops and check for leaks (DO NOT TURN
FAUCET ON)
NOTE:
are installed before connecting to
the main valve.
6

Replacement Parts
1. Spray Head
Replacement Parts List Part #
2. Sprayer Washer
3. Sprayer Hose
5. Spring Assembly
6. Sprayer Holder Assembly
7. Inverter
9. Index
10. Screw
11. Cartridge
Finish / Color
KP27250
KP27251
8. Wearable Ring &
O-ring Assembly
4. Quick Connector Assembly
15. Set Screw
16. Cover Button
*Denotes faucet component color options:
SFS - Spot Free Stainless Steel ; MB - Matte Black; SFACB - Spot Free Antique Champagne Bronze;
SFSB - Spot Free Black Stainless; BB - Brushed Brass; GR - Grey; BL - Black;
MBSFSB - Matte Black+Spot Free Black Stainless; BBMB - Brushed Brass+Matte Black;
Grey hose with Spot Free Stainless Steel connector (GRSFS); Black hose with Matte Black connector (BLMB);
Black hose with Brushed Brass connector (BLBB); Black hose with Spot Free Black Stainless connector (BLSFSB);
Black hose with Spot-Free Antique Champagne Bronze connector (BLSFACB)
SFS, MB, SFACB*
17. Hex Wrench
18. Flange & Washer
19. Rubber & Metal Washer
20. Mounting Nut & Screw
21. 1.8GPM Flow Restrictor
22. Weight & Clip Assembly
WHITE
17
23. Block KP27073
25. Filter Washer KP27167
01
02
03
04
05
06
09
10
14
12
11
07
08
13
15
16
18
19
20
21
22
23
24
25
13. Cap & O-Ring
12. Bonnet Nut
14. Handle
24. O-RING
KP27252
KP27090
KP27322
KP27389
KP27390
KP27391
KP27222
KP27223
KP27069
KP27202
KP27203
KP27001
KP27204
KP27002
KP27020
KP27205
KP27028
KP27079
KP27074
KP27236
GR, BL*
GR, BL*
KP27092
GRSFS, BLMB,
BLSFACB*
SFS, MB, SFACB*
SFS, MB, SFACB*
SFS, MB, SFACB*
SFS, MB, SFACB*
SFS, MB, SFACB*
7

Troubleshooting
If you have followed the instructions carefully and your faucet still does not work
properly, take the following coorective steps:
P R O B L E M C A U S E A C T I O N
Leakage under the
handle
Bonnet nut (12) has
come loose
Remove the coverbutton (16).
Lossen screw (15) with hex
wrench (17). Remove the
handle (14). Unscrew cap (13)
(by hand only). Tighten bonnet
nut (12) with an adjustable
wrench
The aerator has an
irregular or reduced
The aerator is dirty or Remove the aerator and
check for debris.
Ensure that the rubber
washer is properly installed.
completely
Cartridge may need to
be adjusted or replaced
Rem
Lossen screw (15) with hex
wrench (17). Remove the
handle (14). Unscrew cap (13)
(by hand only). Tighten bonnet
nut (12) with an adjustable
wrench. Remove the cartridge
(11). Check for cracks
ove the coverbutton (16).
There is leaking from the
sink drain at the base of
the sink.
The sink has a rough or
irregular surface.
Apply additional silicone
sealant to the beveled side of
and test for leaks
water. hose connectors is dirty. water valve and unscrew the
hose connectors from water
supply lines. Clean the
washer in the water lines with
hot water, removing any debris
or calcium build up
8

Codes/Standards Applicable:
UPC
CR
APM
TM
NSF/ANSI 372
NSF/ANSI 61 ASME A112.18.1
1.8GPM 6.8L/min maximum
Faucet - Lifetime Limited Warranty
Kraus USA Plumbing, LLC (“Kraus”) extends this warranty to the original purchaser for personal household use of the
Faucet when purchased from an authorized Kraus dealer and in the location of original installation. This warranty is
non-transferable.
Kraus warrants the structure and finish of the Faucet to be free from defects in material and workmanship under normal
usage for as long as the original purchaser resides in the residence in which the Faucet was first installed.
Kraus warrants the Faucet's sprayhead assembly (including the engine, aerators, structure, restrictors, back flow
preventers, sprayer hoses, braided supply line hoses which encompasses nylon, silicon and stainless steel) of the product
to be free from defects in material and workmanship under normal usage for a period of one (1) year from the date of
purchase.
Kraus warrants the Faucet's cartridge to be free from defects in material and workmanship under normal usage for a
period of five (5) years from the date of purchase.
Any product reported to the authorized dealer or to Kraus as being defective within the warranty period will be repaired
or replaced with a product of equal value at the option of Kraus.
Commercial Warranty
Kraus USA Plumbing, LLC (“Kraus”) warrants its Products for a period of one (1) year to commercial purchasers of
Products used in industrial, commercial and business applications.
Care and Cleaning Instructions
Certain cleaning products may cause damage to a Product's finish and use of the following on the Product will void this
warranty:
Abrasive cleaners such as powders, bleach, ammonia, alcohol or chorine
Abrasive pads, steel wool or wire brushes
What is Not Covered
This warranty does not cover Products that were discontinued when purchased or display Products, whether such
Products were purchased at discount outlets, unauthorized dealers, and/or sold on clearance. This warranty does not
cover any free gifts included with purchase.
This warranty does not cover damage resulting from neglect, misuse (including use for an unintended application),
abuse, carelessness, accident, hard water or mineral deposits, exposure to corrosive materials, improper maintenance,
alteration of the Product, or failure to follow care, cleaning or installation instructions enclosed with your Product. Kraus
recommends that all Kraus Products be installed by a fully licensed and insured trade professional with experience in the
installation of bathroom and/or kitchen manufactured goods.
R
LEAD FREE
I
&
OR
T
.
.
UPC
CR
NSF/ANSI/CAN 61: Q ≤ 1
9

Download the Kraus Care & Maintenance Guide at:
http://www.kraususa.com/maintenance
How to Make a Warranty Claim
If you are a consumer purchaser, please contact a Kraus Customer Service Representative at:
Kraus USA Plumbing, LLC
12 Harbor Park Drive
Port Washington, NY 11050
Toll-free 800-775-0703
[email protected]
If you are a plumbing contractor or trade professional, please contact a Kraus Pro Representative at:
Kraus USA Plumbing, LLC
12 Harbor Park Drive
Port Washington, NY 11050
516-801-8955
[email protected]
If you are an authorized partner, please contact a Partner Support Representative at:
Kraus USA Plumbing, LLC
12 Harbor Park Drive
Port Washington, NY 11050
516-801-8954
[email protected]
In requesting warranty service, please be ready to provide your proof of purchase and a description of the problem. Shipping charges
will be covered for the first (1) year of the warranted replacement part or product (HI, AK, and Puerto Rico shipping charges may apply).
International shipping fees are not included.
Limitation on Duration of Implied Warranties
Please note that some states/provinces (including Quebec) do not allow limitations on how long an implied warranty lasts, so the
below limitations may not apply to you. TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, ANY IMPLIED WARRANTY,
INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY AND OF FITNESS FOR A PARTICULAR PURPOSE, IS LIMITED TO
THE STATUTORY PERIOD OR THE DURATION OF THIS WARRANTY, WHICHEVER IS SHORTER.
Limitation of Special, Incidental or Consequential Damages
Please note that some states/provinces (including Quebec) do not allow the exclusion or limitation of special, incidental or
consequential damages, so the below limitations and exclusions may not apply to you. TO THE MAXIMUM EXTENT PERMITTED BY
APPLICABLE LAW, THIS WARRANTY DOES NOT COVER, AND KRAUS USA PLUMBING, LLC SHALL NOT BE LIABLE FOR, ANY SPECIAL,
INCIDENTAL OR CONSEQUENTIAL DAMAGES (INCLUDING LABOR CHARGES TO REPAIR, REPLACE, INSTALL OR REMOVE THIS
PRODUCT), WHETHER ARISING OUT OF BREACH OF ANY EXPRESS OR IMPLIED WARRANTY, BREACH OF CONTRACT, TORT, OR
OTHERWISE.
This warranty gives you specific legal rights, and you may also have other rights which vary from state/province to state/province.
R
10

IMPORTANT
Register Your Kraus Product
REGISTER TODAY
http://www.kraususa.com/registration
Activate Your Warranty
Access Premium Customer Support
Get Product Information
www.kraususa.com
