Krone Swadro 35 User manual

Operating Instructions No. 4214-0 GB
Rotary Swather
Swadro 35
Swadro 38
Swadro 42
Swadro 46 (from machine no. 582 800)

Dear customer,
You have obtained the operating instructions for your new Krone
machine.
These operating instructions contain important information
concerning proper use and safe operation of the machine.
Should these operating instructions for some reason become
completely or partially unusable, you can obtain replacement
operating instructions by specifying the number listed on the front
cover.
declareunderoursoleresponsibility,thattheproduct
ttto which this declaration refers corresponds to the relevant basic safety and health requirements of
the EC Directive 98/37/EC.
EC Declaration of Conformity
corresponding to the EC Directive 98/37/EC
Heinrich-Krone-Str.10,D-48480Spelle
KroneRotarySwather
Models: Swadro 35 Swadro 38, Swadro 42, Swadro 46
We MaschinenfabrikBernardKroneGmbH
Spelle, the 31.01.05
(Dr.-Ing. Josef Horstmann, Geschäftsführer)
(ppa. Dr.-Ing. Klaus Martensen, Leiter der Konstruktion und Entwicklung)
(Wolfgang Ungruh, Leiter der Qualitätssicherung)

Foreword
Please note:
The instruction manual is an integral part of your
machine.
Only operate this machine after you have been
trained to do so and according to these instructions.
It is essential to observe the safety instructions!
It is also necessary to observe the relevant accident
prevention regulations and other generally recognised
regulations concerning safety, occupational health
and road traffic.
All information, illustrations and technical details in
this instruction manual are the latest and most up to
date at the time of going to press.
It is within our rights to modify the design at any time
and without having to give reasons. Should you for
any reason not be able to use this instruction manual
either wholly or partially, it is possible to get a
replacement instruction manual for your machine by
quoting the number supplied overleaf.
We hope that you will be satisfied with your KRONE
machine.
Machine factory Bernard Krone GmbH
Spelle
Dear Customer!
On buying the Rotary swather you have selected a
quality product from KRONE.
We are grateful for the belief you have invested in us
as a result of buying this machine.
It is important to read the operating instructions very
carefully before you start operating the machine so
that the Rotary swather may be used to its maximum
capacity.
The contents of this manual are laid out in such a way
that you should be able to perform any task by
following the instructions step by step. It contains
extensive notes and information about maintenance,
about how to use the machine safely, about secure
working methods, special precautionary measures
and the accessories which are available. It is essen-
tial, important and useful for the operational safety,
reliability and durability of the Disc mowe that these
notes and information are adhered to.

Foreword

1
List of contents
List of contents
1 General Information ..........................................................................I -1
1.1 Proper Use ...............................................................................................................I-1
1.2 Specifications ...........................................................................................................I-1
1.2.1 General .....................................................................................................................I-1
1.2.2 Manufacturer'sAddress.............................................................................................I-1
1.2.3 Certification ..............................................................................................................I-1
1.2.4 Identification..............................................................................................................I-1
1.2.5 DataRequiredforInquiriesandOrders .....................................................................I-1
1.2.6 Proper Use ...............................................................................................................I-2
1.2.7 GeneralSpecifications ..............................................................................................I-2
2 Safety..................................................................................................II -1
2.1 IdentifyingSafetyInstructionsintheOperatingManual .............................................. II-1
2.2 SafetyInstructionsandAccidentPreventionRegulations........................................... II-1
2.2.1 PersonnelQualificationandTraining......................................................................... II-1
2.2.2 FailuretoFollowtheSafetyInstructions .................................................................... II-1
2.2.3 WorkinginaSafetyConscious Manner .................................................................... II-1
2.3 SafetyInstructionsandAccidentPreventionRegulations........................................... II-1
2.3.1 Mountedimplements ................................................................................................ II-2
2.3.2 PowerTake-OffOperation ........................................................................................ II-2
2.3.3 HydraulicSystem ..................................................................................................... II-3
2.3.4 Tyres ........................................................................................................................ II-3
2.3.5 Maintenance ............................................................................................................ II-3
2.4 Introduction............................................................................................................... II-4
2.4.1 Locationofthesafety labelsonthemachine,containing technicalsafetyinformationon
themachine ............................................................................................................. II-4
2.4.2 Positioningoftheinformationsigns .......................................................................... II-6
3 Operating preparations .................................................................. III -1
3.1 Special safetyinstructions ....................................................................................... III-1
3.2 Attachmenttothe tractor.......................................................................................... III-1
3.3 PTOshaft................................................................................................................ III-3
3.3.1 General ................................................................................................................... III-3
3.3.2 Adjustingthelength ofthePTOshaft........................................................................ III-4
3.3.3 Fittingandmaintainingthe PTO shaft ...................................................................... III-4
3.4 Detaching from thetractor ....................................................................................... III-5
4 Adjusting the swather .................................................................... IV -1
4.1 General .................................................................................................................. IV-1
4.2 Basic setting .......................................................................................................... IV-1
4.3 Foldingthetinearmsintoworkingposition ............................................................. IV-1
4.4 Setting the workingheight ...................................................................................... IV-2
4.5 Seitliche Neigungseinstellung desKreiselfahrwerks ............................................... IV-3
4.6 Swathformer.......................................................................................................... IV-3
4.7 Travelspeedanddrive r.p.m................................................................................... IV-4

2
List of contents
5 Transport.......................................................................................... V -1
5.1 Lighting ................................................................................................................... V -1
5.2 Transportpreparatin................................................................................................ V -1
5.3 Foldingthetine arms into transportposition............................................................. V -2
6 Service and maintenance.............................................................. VI -1
6.1 Specialsafetyinstruction ........................................................................................ VI-1
6.2 General .................................................................................................................. VI-1
6.3 Tyres ...................................................................................................................... VI-2
6.4 Replacingthe tinearms(incaseofrepair).............................................................. VI-2
7 Lubrication ..................................................................................... VII -1
7.1 Universal driveshaft ...............................................................................................VII-1
7.2 Bearingsonthe swather.........................................................................................VII-1
8 Winter storage...............................................................................VIII - 1
9 Start-up after winter storage ......................................................... IX -1
10 Extras/accessories ......................................................................... X -1
10.1 Supportwheelwithchain primary toplink................................................................. X -1
10.2 Tinelossprotection ................................................................................................. X -1
10.3 Fittingtheswathformer ........................................................................................... X -2

I - 1
General Information
KS300118
Maschinenfabrik Bernard Krone GmbH
Heinrich-Krone-Straße 10, D 48480 Spelle
Jahr
Année
Masch. Nr
No. de série
Type
Made in
W.-Germany
1 General Information
Theoperating manual contains basicinstructionstobe
observedwhenattaching,operatinganddoingmaintance
work.Thereforeitisimperativethattheoperatingpersonnel
haveaccesstoandreadthisoperatingmanualbefore
puttingintooperationandusingtheimplement.
Follow both the general safety instructions contained in the
section on safety and the specific safety instructions
contained in the other sections.
1.1 Proper Use
The Swadro rotary windrower is used to swath cut hay.
It is installed inside the CAT II three-point hitch at the rear.
1.2 Specifications
1.2.1 Manufacturer's Address
MaschinenfabrikBernardKroneGmbH
Heinrich-Krone-Straße10
D-48480Spelle(Germany)
Telephone:[phone]
Fax:[phone]
E-mail:[email protected]
1.2.2 Certification
ECDeclarationofConformity
correspondingtotheEC Directive
See reverse side of title page
1.2.3 Identification
Themachine data are listed onthe identificationplate.
The entire identification plate re-
presents a legal document and should
not be altered or rendered illegible!
1.2.4 Data Required for Inquiries and
Orders
Whenmakinginquiries concerning themachineor
orderingreplacementparts,besuretoprovidetype
designation,vehicleIDnumberandyearofmanu-
facture.
Genuine replacement parts and
accessories authorized by the
manufacturer help ensure safety.
Use of other parts may void liability for
damage which results.
Vehicle
IDno.
Type
Year

I - 2
General Information
1.2.5 Proper Use
TheSwadrorotarywindrower isdesignedexclusivelyfor
usualapplicationsduringagriculturalwork(properuse).
Anyfurther use is consideredtobeimproper use. The
manufacturerisnotliableforanydamageresultingfrom
such use. Such use is solely at the operator's risk.
Part of the proper use is the adherence to the operating,
maintenanceandrepairinstructions specifiedbythe
manufacturer.
1.2.6 GeneralSpecifications
Driving on roads is only permissible with the swath arms in
thetransportposition.
The max. height of 4 m must not be exceeded.
Type Swadro35 Swadro38 Swadro42 Swadro46
Three-point linkage (Connection CAT I + CAT II) standard
Tandemaxle standard
Numberofarms Piece 10 10 13 13
Numberofdoubletines Piece 3 4 4
Workingwidth approx.mm 3500 3800 4200 4600
Swathdiscdiameter approx.mm 2700 2960 3300 3600
Heightin transportposition approx.mm 2210 2210 2500 2700
Heightinoperatingposition approx.mm 1550
Length approx.mm 3020 3300 3600 3900
Widthintransportposition approx.mm 1900 1900 2265 2550
Maximumwidthinoperatingposition approx.mm 3500 3800 4200 4600
Powerrequirement app. kW/PS 26/36 26/36 37/50
PTO shaft speed max. permitted drive speed 1/min. max. 540U/min
PTOshaftspeedrecommendedoperating 1/min max. 350-450U/min
drivespeed
Equivalentcontinoussoundpressurelevel below70dB(A)
Acreagecapacity ca./h 3 - 3,5 3,5 - 4 4 - 4,5 4,5 - 5
Tyres 16 x 6.50-8
Tyrepressure bar 1.5
lightingvoltage Volt 12
Weightofmachine [kg] 510 565 640 665

II - 1
Safety
2 Safety
2.1 Identifying Safety Instructions in
the Operating Manual
The safety instructions contained in this manual, which
couldresultinpersonal injury if notfollowed,areidentified
bythegeneraldangersign:
safety sign in accordance with DIN 4844 - W9
Generalfunctioninstructionsareindicatedasfollows:
Instructions which are attached to the machine need to be
followedandkeptfullylegible.
2.2 Safety Instructions and Accident
Prevention Regulations
2.2.1 Personnel Qualification and Training
The rotary swather must only be used, maintained and
repairedbypersonnelwhoareacquaintedwiththe
machineandhavebeeninformedofthedangersinvolved.
The operator must precisely define the areas of
responsibilityandcompetenceandmonitorthepersonnel.
Shouldpersonnel lacktherequiredknow-ledgetheymust
receivetherequiredtrainingandinstruction.Theoperator
must also ensure that the contents of this operating
manualhavebeenfully understood bythepersonnel.
Repairworknot describedinthisoperating manualshould
becompletedbyauthorizedservicecentersonly.
2.2.2 Failure to Follow the Safety
Instructions
Failure to follow the safety instructions could result in
personalinjuryandenvironmentalhazardsaswellas
damage to the machine. Failure to follow the safety
instructions could result in the forfeiture of any claims for
damages.
Failure to follow the safety instructions could, for
example, result in the following hazards:
– risk to persons by failure to secure the working area
– breakdownofimportantmachinefunctions
– failureofprescribedmethodsforrepairand
maintenance
– risk to persons due to mechanical and chemical
effects
– damagetotheenvironmentduetoleakinghydraulic
oil
2.2.3 Working in a Safety Conscious
Manner
Follow the safety instructions included in this operating
manual,existingaccidentpreventionrulesandany
internal work, operating and safety rules set out by the
operator.
Thesafetyandaccidentpreventionregulationsofthe
responsibleprofessionalassociationsarebinding.
Observethesafetyinstructionsprovidedbythevehicle
manufacturer.
Observetheapplicabletrafficlawswhenusingpublic
roads(forexample,inGermany,theRoadTrafficType
ApprovalLawandRoadTrafficLaw).
2.3 Safety Instructions and Accident
Prevention Regulations
1. Pleasefollowallgenerallyapplicablesafetyand
accidentpreventionregulationsinadditiontothe
safety instructions contained in this manual!
2. Theattachedwarningandsafetysignsprovide
importantinformationforsafeoperation.Pay
attentionto these for your ownsafety!
3. Whenusingpublicroads,make sure to observe
theapplicabletrafficregulations!
4. Make sure that you are familiar with all equipment
and controls as well as their functions before you
begin working with the machine. It is too late to
learnthiswhenyouareoperatingthemachine!
5. Theusershould wear tight fittingclothes.Avoid
wearinglooseorbaggyclothing.
6. Keepthemachinecleantopreventdangeroffire!
7. Beforestartingormovingthemachine,make
certain that nobody is in the vicinity of the
machine!(Watchforchildren!)Makesurethatyou
haveaclearview!

II - 2
Safety
8. Carryingpassengersduringoperationandtransporton
the working implement is not permitted.
9. Attach implements correctly! Attach and secure
implementstospecifieddevicesonly!
10. When attaching or removing implements, place the
supportingdevices inthecorrectpositions!
11. Use extreme caution when attaching or detaching
implementsontoor from thetractor!
12. Always attach ballast weights properly to the fixing
pointsprovided!
13. Observepermittedaxleloads,grossweightandtransport
dimensions!
14. Checkandattachtransportequipmentsuchaslighting,
warningdevicesandanyprotectiveequipment!
15. Actuating mechanisms (cables, chains, linkages etc.)
forremotecontrolleddevicesmustbepositionedinsuch
awaythatnomovementsareunintentionallytriggeredat
anytransportorworkingpositions.
16. Ensurethatimplementsareintheprescribedcondition
foron-roadtravelandlocktheminplaceaccordingtothe
manufacturer'sinstructions!
17. Neverleavethedriver'sseatwhenthevehicleismoving!
18. Always drive at the correct speed for the pre-vailing
driving conditions! Avoid sudden changes in direction
whentravellinguphillordownhilloracrossagradient!
19. Attached implements and ballast weights affect the
driving,steeringandbrakingresponse of the machine.
Make sure that you are able to brake and steer the
machineasrequired!
20. Takeintoaccounttheextensionradiusand/orinertiaof
animplementwhenturningcorners!
21. Start up implements only when all protective devices
havebeenattachedandsetintherequiredposition!
22. Keep clear of the working range of the machine at all
times!
23. Donotstandwithintheturningandslewingrangeofthe
implement!
24. Neveroperatethe hydraulic foldingframesifanyone is
insidetheslewingrange!
25. Partsoperatedby external power (e.g. hydraulics) can
causecrushingandshearinginjuries!
26. Beforeleavingthetractor,lowertheimplementonto
the ground, switch off the engine and remove the
ignitionkey!
27. No one should stand between the tractor and the
implement unless the vehicle has been secured
against rolling with the handbrake and/or wheel
chocks!
2.3.1 Mounted implements
1. Beforemountingimplementson/fromthethree-point
linkage, all controls have to be positioned in such a
way that any unintentional lifting or lowering of the
machine is impossible.
2. Incaseofthree-pointmountedimplementsitisessen-
tial that the hitch category of the implement matches
that of the tractor.
3. Thethree-pointlinkageincludesshearingandpinching
areas.
4. When operating the outer controls of the three-point
linkagedo not step between tractorandimplement.
5. Whentheimplementisintransportpositionassureat
all times a sufficient lateral limitation of the tractor
three-pointlinkage.
6. Whentravellingonpublicroadswithimplementraised
makesurethecontrolleverissecuredagainstlowering.
2.3.2 Power Take-Off Operation
1. UseonlyPTOshaftsspecifiedbythemanufacturer!
2. The guard tube and guard cone of the PTO and the
PTO guard must be attached and in good working
condition(ontheimplementside,too)!
3. Makesurethattherequiredtubecoversareinplace
forPTOshaftsintransportandworkingposition!
4. BeforeinstallingorremovingPTOshafts,disengage
thePTO,switchofftheengineandremovetheignition
key!
5. When using PTO shafts with an overload safety or
free-runningcouplingwhichare not shielded by the
guard on the tractor, mount the overload safety or
free-runningcouplingontheimplementside!
6. Always make sure that the PTO shaft is properly
installedandsecured!
7. Attach chains to prevent the PTO shaft guard from
rotatingwiththeshaft!

II - 3
Safety
8. Before engaging the PTO shaft, make sure that the
selected PTO shaft speed of the tractor matches the
permissibleimplementspeed!
9. Beforeengaging thePTOshaft, makesurethat noone
isin the hazard areaaroundtheimplement!
10. NeverengagethePTOshaftiftheengineisswitchedoff!
11. NooneshouldbeinthevicinityoftherotatingPTOshaft
when it is in use.
12. AlwaysswitchoffPTOshaftwhentheangleistoolarge
or the PTO shaft is not required!
13. Cau1tion! Theflywheelwillcontinuetorotateforsome
time even after the PTO shaft has been disengaged!
Keepclear oftheimplementduringthistime.Donotdo
anyworkontheimplementuntilthemachinehascome
to a complete stand-still and the flywheel has been
securedusingthehand brake.
14. DisengagethePTOshaft,stoptheengineandremove
theignitionkeybeforecleaning,lubricatingandadjusting
the PTO shaft driven implements or the PTO shaft!
Secure the flywheel with the hand brake.
15. Place the disconnected PTO shaft onto the bracket
provided!
16. After removing the PTO shaft, attach the protective
cover to the PTO shaft end!
17. Ifdamageoccurs,correctthisimmediatelybeforeusing
theimplement!
2.3.3 Hydraulic System
1. The hydraulic system is pressurized!
2. When connecting hydraulic cylinders and
engines, make sure that the hydraulic hoses are
connectedcorrectly!
3. When connecting the hydraulic hoses to the tractor
hydraulics, make sure that the hydraulics of both the
tractorandtheimplementhavebeendepressurized!
4. Inthecaseofhydraulicconnectionsbetweentractorand
implement the coupling sleeves and plugs should be
markedtoensureaproperconnection!Iftheconnections
areswitched,thefunctionwillbereversed(e.g.raising/
lowering)-dangerof accidents!
5. Check the hydraulic hose lines at regular intervals and
replacethemifdamagedorworn!Thenewhosesmust
fulfillthetechnicalrequirementssetbythemanufacturer
of the implement!
6. Whensearchingforleaks,usesuitableaidstoavoidthe
risk of injuries!
7. Liquidsescapingunderhighpressure(hydraulicoil)can
penetrate the skin and cause serious injury! Seek
medicalhelpimmediatelyshouldinjuriesoccur!Riskof
infection!
8. Before working on the hydraulic system, lower the
implement,depressurizethesystem and switch offthe
engine!
2.3.4 Tyres
1. When working on the tyres, make sure that the
implement has been safely lowered and secured
againstrolling(wheelchocks).
2. Installing wheels and tyres requires adequate
knowledgeandsuitabletools!
3. Repairworkonthetyresandwheelsshouldbedone
by specially trained personnel using appropriate
installation tools only!
4. Checktyrepressureregularly!Inflatethetyrestothe
recommendedpressures!
2.3.5 Maintenance
1. Repair,maintenanceandcleaning work as well as
therectificationofmalfunctionsmay only ever be
carriedoutwhenthedriveisswitchedoffandthe
engine is at a standstill!
-Removetheignitionkey! Pull the parking brake
forthebalancingweight.
2. Regularly check that nuts and bolts are properly
seatedandtightenif necessary!
3. Whendoingmaintenanceworktoaraisedimplement,
always use suitable means to secure it against
falling.
4. Whenreplacingworkingtoolswithcuttingedges,use
suitabletoolsandgloves!
5. Disposeofoils,greasesand filtersaccordingto
regulations!
6. Alwaysdisconnectthepowersupplybeforeworking
on the electrical system!
7. Ifprotectivedevicesandguardsaresubjectto
wear, check them regularly and replace them in
goodtime!
8. Whendoingelectricalwelding on the tractor and
attachedimplements,disconnect thealternator
andbatterycables!
9. Replacement parts must at least comply with the
technicalrequirementssetbythemanufacturer of
theimplements!
ThisisguaranteedwhenusinggenuineKRONE
replacementparts!
10. Onlyuse nitrogenforfillingpneumatic
accumulators-Risk of explosion!

II - 4
Safety
1
Order no. 939 471-1 (1x)
Read and observe the
operatinginstructionsand
thesafetyinstructionsbefore
startingoperation.
2
Order no. 939 100-4 (1x)
The PTO shaft speed must not exceed
540 rpm!The PTO shaft speed must not
exceed
540rpm!
939 100-4
MAX. 540/ min
MAX. 200 bar
2.4 Introduction
TheKRONErotary swatherisequippedwithall necessarysafetydevices(protectiveequipment). Notallpotentially
dangerous positions on this implement can be fully secured, as this would be incompatible with full functional
capability.Youwillfindappropriatedangernotification
(= warning signs in yellow/black), indicating these residual risks.
Thesafetyinstructionsareprovidedintheformofso-calledwarningpictograms.Importantinformationonthelocation
of these safety signs and what they mean is given below!
Familiarize yourself with the meaning of the warning signs opposite. The text beside them
and their location on the machine indicates the machine's particularly dangerous areas.
2.4.1 Location of the safety labels on the machine, containing technical safety
information on the machine
2
1
KS300100
3
4

II - 5
Safety
3
Order no. 939 574-0 (2x)
Before starting work put the
guard bar into the protective
position(folddown).
4
Never put your hand into
the danger area as long
as parts may be moving.
Order no. 942 196-1 (2x)
939 574-0
2
1
KS300100
3
4

II - 6
Safety
2.4.2 Positioning of the information signs
942118-0 (1x)
2942119-2 (1x)
3
942295-0 (2x)
4939183-1 (2x)
5924569-0 (2x)
6
1,0 bar
942519-0 (2x)Swadro 35
xxxxxx-0 (2x)Swadro 38
942520-0 (2x) Swadro42
942518-0 (2x) Swadro46
1
942119-2
350-450/ min
942339-0 (1x)
7
942 339-0
23 7
KS300101
1
46
5

III-1
Operating preparations
3 Operating preparations
3.1 Special safety instructions
• Basic rule for service, maintenance, repair and assembly work on the rotary swather -
switch off the PTO shaft. Switch off the engine and remove the ignition key. Secure the
tractor and rotary swather from rolling away!
• The maximum drive speed is 540 rpm.
• Actuating components such as ropes and cords; and hydraulic hoses and cable
connections should be laid in such a way that they cannot be activated unintentionally or
come into contact with the tractor wheels! Danger of accidents!
• No-one should be standing between the tractor and the rotary swather during raising or
lowering operations. Great risk of injury!
• Before switching on the PTO shaft, ensure that no-one is standing in the danger area of the
rotary swather. Danger of accidents!
• Make sure that the protective devices are correctly fitted during operation and when
travelling on public roads! Attach the lights and check that they are functioning correctly.
• The operator must not leave the tractor during operation!
Beforeconnectingordisconnectingimplementsto and
from the three-point linkage, position the controls in such
away that any unintentional raisingorloweringofthe
implementisimpossible!
Particular care is to be taken when connecting or
disconnectingimplementstoandfromthetractor!
There is a risk of shearing and pinching in the area
aroundthethree-pointlinkage!
• Attach and secure the lower link arms.
• Attach the top link and secure with pins.
• Raise the jack stand and secure it in the uppermost
position with pin. Do not remove the jack stand.
• No-one should be standing between
the tractor and the machine during
attachment.
• Implements that are attached on the
front and rear must not result in the
maximum weight, maximum axle loads
ortyrecarrying capacitiesofthetractor
being exceeded. The front axle of the
tractor must always be loaded with at
least 20% of the empty weight of the
tractor,evenwhentherearattachment
isfitted.
Make certain you have complied with
theserequirementsbeforestartingto
movethetractor
3.2 Attachment to the tractor
The swather is equipped with cat. I and II coupling lugs
forthethree-pointlinkage.
KS300117

III-2
Operating preparations
The lowering speed of the rear
hydrau-lics should be set using the
lowering throttle so that the rotary
swather undercarriage is lowered to
the ground slowly.
Make sure that the tractor cab rear
window is closed before raising the
rear hydraulics. The rotary swather
protective frame could otherwise
damage the rear window.
KS300102

III-3
Operating preparations
3.3 PTO shaft
3.3.1 General
Switch off the engine after coupling
the rotary swather to the tractor
linkage. Remove the ignition key.
Secure the tractor from rolling away!
The PTO shaft is fitted with an overload coupling.
Overload couplings protect the tractor and
implement from damage. The overload coupling
setting must not be altered. The guarantee will
become void if the set torque changes due to the
overload coupling being tampered with.
The torque is limited once there is overloading and
is transferred as a pulse during the slip time.
Topreventtheoverloadcouplingfromwearing
outprematurely,thePTOshaftshouldbe
disengagedimmediatelyonce
theoverloadcouplingresponds.
ComparetherelevantRMtorquevaluewith
thevaluegiveninthefollowingtable.
If these values do not tally, please consult
yourKronedealer.
Type Torque(RM)
Swadro35 550Nm
Swadro38 550Nm
Swadro42 550Nm
Swadro46 550Nm
KS-0-036
RM
KS300117

III-4
Operating preparations
Pull the PTO shaft apart so it can be adjusted. Slide the
twocorrespondinghalvesof thePTOshaftontothe
machine (1) and on to the tractor (2). The overload
coupling must be fitted on the implement side! Set
the rotary swather using the rear hydraulics to the
shortestposition for the PTOshaft.Holdboth halves next
to each other and measure the correct length. See the
PTOshaftmanufacturer'soperatinginstructionsforthe
exactmeasuringandshorteningprocedure.
3.3.2 Adjusting the length of the PTO shaft
Danger of material damage: Do not lift
before the length of the PTO shaft has
been adjusted!
• Switch off the PTO shaft when carrying out service, maintenance, repair and assembly
work on the rotary swather. Switch off the engine. Remove the ignition key. Secure the
tractor from rolling away!
• No-one should be standing between the tractor and the rotary swather while the swather
is being raised.
KS-0-01
7
4
3
Securetheguardtube (3) against rotating using the
retainingchains(4)!
Checkthat the PTO shaft hasenough swivelspace and
freemovementspace!DamagewillbecausedifthePTO
shaft is touched by the tractor or implement. (e.g. hitch,
three-pointframe)
3.3.3 Fitting and maintaining the PTO shaft
KS-0-01
6
12

III-5
Operating preparations
3.4 Detaching from the tractor
• The rotary swather should only be parked on level, solid ground!
• No-one should be standing between the tractor and the rotary swather during raising and
lowering of the swather.
• Follow all other safety instructions.
• Chosealevel,dryfloorspace with sufficient load
bearingcapacity.
• Lower the jack stand (1) and secure with pin.
• Lower the swather making completely sure that it is
standingsecurely.
• Disconnect the PTO shaft (2) and put it onto the
supportprovided.
• Disconnect the top link.
• Disconnect the lower link arm.
KS300112
1
2

III-6
Operating preparations
