Kubota TE8511C User manual

TE8511C
Operator‘s manual
Original operator‘s manual
Edition 09.2013
Date of print 09.2014
Language EN-EU
Machine number VF69120680 –
Model VF6912
Document number VF16661369.EN-EU

TE8511C
Machine identification
In order for your dealer to assist you as efficiently as possible, you will need to provide some information about
your machine. Please enter the details here.
Designation
Working width
Weight
Machine
number
Accessories
Supplier's 
address
Manufacturer's 
address Kverneland Group Kerteminde AS
Taarupstrandvej 25
DK-5300 Kerteminde
Denmark
Tel: [phone]
11.00 m (36 ft)
1795 kg (3892 lb)
VF6912_ _ _ _
Copyright by Kverneland Group Gottmadingen N. V., Germany. Reproduction, transfer to other media, translation or the use of extracts or parts
of this manual without the explicit permission of Kverneland, is not permitted. All rights reserved. The contents of this operating manual are subject
to change without notice. The right to technical revision is reserved.

Table of contents
3
Table of contents
Preface ....................................................... 4
Target group for
this operating manual 4
Symbols used 5
Safety ......................................................... 6
For your safety 6
Who is allowed to operate the machine? 10
General safety information 10
Coupling 14
Road transport 15
Operation 16
Uncoupling 17
Care and maintenance 18
Further regulations 19
Familiarising yourself with the machine 20
Range of application of the machine 20
Features of the machine 20
Designation of components 21
Technical specifications 22
Delivery and assembly ............................. 25
Checking the scope of delivery 25
Length of PTO shaft 26
Coupling the machine .............................. 28
Safety 28
General 28
Coupling the lower link 28
Swivelling in the parking stand 29
Coupling the PTO shaft 30
Wheel wedges 31
Connections 31
Preparing for operation ............................ 34
Safety 34
Road transport .......................................... 39
Safety 39
Prior to road transport 41
Road transport 43
Preparations on the field ......................... 44
Safety 44
General 45
Folding the machine into the
work position 45
Operation ................................................... 47
Safety 47
Crop processing 48
Using the machine 49
Driving on headlands 51
Cleaning and care ..................................... 54
Safety 54
Cleaning 55
Care 55
Parking and storage .................................. 56
Setting down the
machine in a secure position 56
Uncouple and secure the machine 57
After the end of the season 57
Maintenance ............................................... 58
Safety 58
General 60
Screwed connections 63
Lubrication points for grease 65
Lubricating the PTO shafts 66
Slip clutch 66
Lubrication points for oil lubrication 67
Filling quantities 68
Tine position 69
Tyres 70
Hydraulics 71
Additional equipment ................................ 72
Tine saver 72
Night swath gear box 72
Anti-wrapping plate 72
Spare wheel 73
Fault elimination ........................................ 74
Circuit diagrams ........................................ 75
Hydraulic circuit diagram 75
Lighting equipment circuit diagram 76
Decommissioning ..................................... 77
Disposal 77
EC Declaration of Conformity .................. 78
Conforms to
EC Directive
2006/42/EC 78
Index ........................................................... 79

Preface
4
Preface
Target group for
this operating
manual
This operating manual is intended for trained agriculturists and
persons who are otherwise qualified for agricultural activities and have
received instruction in working with this machine.
For your safety
You must familiarise yourself with the contents of this operating
manual before assembly or initial operation of the machine. In this
way, you will achieve optimum work results and operational safety.
The operating manual forms an integral part of the machine and must
always be kept to hand. This will ensure that you:
•avoid accidents.
•comply with warranty conditions.
•have a fully functional machine in good working order at all times.
Training
Your will receive training from your dealer concerning using the
controls and care of the machine.
Information for the employer
All personnel are to be regularly, but at least once a year, instructed
on the use of the machine, in accordance with the regulations of the
national organisation for Health and Safety at Work. Untrained or
unauthorised persons are not permitted to use the machine.
You are responsible for ensuring that the machine is operated and
maintained safely. Make sure that you and all other persons that
operate, maintain or work in close proximity with the machine are
familiar with the operating and maintenance regulations, as well as the
corresponding safety instructions in this operating manual.
Simplified illustrations for better understanding
Illustrations of the machine in the operating manual are shown
without protective equipment – or with the protective equipment
open – for better understanding. Be sure to observe the safety
information and follow the handling instructions in the operating
manual. Otherwise, serious or fatal injury may be caused as a
result.

Preface
5
Symbols used
In this operating manual, the following symbols and terms have been
used:
•A bullet point accompanies each item in a list.
A triangle indicates operating functions which must be performed.
→An arrow indicates a cross-reference to other sections of this
manual.
[+] A plus sign indicates additional equipment which is not included in
the standard version.
We have also used pictograms to help you find instructions more
quickly:
The "Information" pictogram indicates tips and additional information.
The “Examples” pictogram indicates examples that assist under-
standing of the instructions.
The spanner indicates tips for assembly or adjustment work.
The grease gun indicates the points that must be lubricated using the
grease gun.
The brush indicates the points that must be lubricated using the brush.
Switch on the tractor.
Secure the tractor against rolling away, shut off the engine and
remove the ignition key.
Open the ball valve.
Close the ball valve.
This arrow in the diagram shows the direction of travel.
The warning triangle indicates important safety information and
danger. Failure to observe this safety information can result in:
•Serious faults in the correct operation of the machine,
•Damage to the machine,
•Personal injury or accidents.

Safety
6
Safety
For your safety
This chapter contains general safety instructions. Each chapter of the
operating manual contains additional specific safety information which
is not described here. Observe the safety information:
•in the interest of your own safety,
•in the interest of the safety of others, and
•to ensure the safety of the machine.
Numerous risks can result from handling agricultural machinery in the
wrong way. Therefore, always work with particular care and never
under time pressure.
The employer should:
Inform all persons who work with the machine about this safety
information at regular intervals and in accordance with statutory regu-
lations.

Safety
7
Warning signs (ISO)
Warning signs in the ISO standard. Safety-related stickers attached to
the machine indicate potential hazards. The stickers must not be
removed. Illegible or missing stickers should be replaced. You can
obtain new stickers as replacement parts from your dealer.
Warning signs on the
machine

Safety
8
Meaning of warning
signs
Read the operating manual
Read and follow the operating and safety instructions before using the
machine for the first time. The machine must not be used for the first
time until the operating manual has been read and understood. This
applies in particular to the safety information. Otherwise, serious or
fatal injury may be caused as a result.
Switch off the engine
Only perform maintenance, repair and adjustment work when the
machine is shut down. Otherwise, serious or fatal injury may be
caused as a result.
Distance from the rotor
Maintain a safe distance from the rotor when it is rotating. Nobody may
remain in close proximity to the machine when tedders and rakes are
running. Otherwise, serious or fatal injury may be caused as a result.
Distance from the tractor
When the machine is being coupled, uncoupled or operated, there
should be no-one between the tractor and the machine. Otherwise,
serious or fatal injury may be caused as a result.
Risk of crushing
Never reach into an area where there is a risk of crushing if parts in
that area are still likely to move. Otherwise, serious or fatal injury may
be caused as a result.
Caution, parts ejected at speed
Hazard caused by parts which may become detached when the drive
is in operation, and ejected at speed. Maintain a safe distance.
Otherwise, serious or fatal injury may be caused as a result.
PTO shaft speed 540 rpm
The specified maximum PTO shaft speed of 540 rpm must not be
exceeded. Otherwise, damage to the machine may be caused as a
result.

Safety
9
PTO shaft speed 540 rpm
The specified maximum PTO shaft speed of 540 rpm must not be
exceeded. Otherwise, damage to the machine may be caused as a
result.
Do not exceed the maximum hydraulic pressure
The tractor's hydraulic pressure on the machine's hydraulic system
must not exceed 210 bar. Otherwise, damage to the machine may be
caused as a result.
Close the ball valve for road transport
Always close the ball valve for road travel and transportation. The
machine may swing out if the ball valve is open. This can result in
traffic accidents and accidents causing serious or fatal injuries.
Observe the direction of rotation of the rotors
Observe the direction of rotation of the rotors and the tine position. If
the direction of rotation of the rotors is incorrect and/or the tine position
is incorrect, the machine does not work correctly.
Lubrication points
Lubrication points are marked with an information label. Lubricate the
machine in accordance with the instructions in the "Maintenance"
chapter.

Safety
10
Who is allowed to
operate the
machine?
Only qualified personnel
Only qualified persons who have been informed of the dangers
associated with handling the machine are permitted to operate,
service or repair the machine. This knowledge can be gained via agri-
cultural training, technical training or intensive instruction.
General safety
information
The general safety information and warning signs apply to every
phase of the life cycle of the machine and to every application.
Switch off the tractor and secure it
Before you dismount:
Switch off the tractor.
Remove the ignition key.
Secure the tractor against rolling away.
An unsecured tractor can run you over or trap you. Otherwise, serious
or fatal injury may be caused as a result.
Operate for the first time only after proper training
The machine may only be put into operation after proper training has
been provided by an employee from a dealership or the manufacturer,
or by a factory representative. Operation without proper training can
lead to damage to the machine due to incorrect operation, or may
cause accidents.
Safety is your responsibility
Follow the safety instructions. Ensure that all operators comply with
the safety instructions. Prevent serious or fatal accidents by following
the safety instructions.
Instructions in the event of malfunctions
In the event of a malfunction, shut down, stop and secure the machine
immediately. Rectify the malfunction immediately yourself or seek the
assistance of a workshop. Operating a faulty machine can cause
accidents or damage.
No persons in the working area
Ensure that no persons are present in the slewing and working area
of the machine. Persons could be caught by the machine within this
area. Fatal injury may be caused as a result.
Perfect working condition
Ensure that the tractor and the machine are always in perfect working
condition. Make sure that the tractor brakes work in synchronisation
with the machine. Also follow the instructions in your tractor's
operating manual.
