KVM-TEC SmartLINE SVX Operator's manual

kvm-tec
First Aid
SVX
Video error
(stripes in the
picture)
USB is not
working
No Power
(No LED)
Check the
powerplug
Is the power
supply ok? Try
another Unit.
Try reprogramming
the Unit by using a
JTAG programmer
Contact kvm-tec
support
Are the USB
Devices plugged
in correctly?
Is the USB cable
on the Local side
plugged into the
PC?
Are the USB
Devices working
directly on the
PC?
Check if local
and remote Unit
have the same
fi rmware
Replace the USB
cable from PC to
the Local
Extender
Check if the local
or the remote
Unit is causing
the problem by
swaping fi rst the
local and than the
remote Unit to
another Unit
Contact kvm-tec
support
Check if all
cables are plug-
ged in correctly
Check if the PC is
sending a Image by
plugging in a
monitor on the
local out of the
local Unit
Check if the DDC is
set correctly (in menu
under point „O“)
Check if both
Units have the
correct fi rmware
No Video
Contact kvm-tec
support
Check if all
cables are plug-
ged in correctly
Check if the PC is
sending a Image
by plugging in a
monitor on the
local out of the
local Unit
Check if local and re-
mote Unit have the
correct fi rmware
Check if the DDC
is set correctly (in
the menu under
point „o“)
Check if the
network switch
is setup correctly
and has enough
bandwidth
Contact kvm-tec
support
Check if other units
have the same
behaviour
We are here for you to answer
your questions about installation?
Manual download www.kvm-tec.com
or
kvm-tec Installationchannel on our homepage
personally [phone]
kvm-tec Support [email protected] Phone: [phone] - 30
Check out
our Installation
Channel:
www.kvm-tec.com
line
line
line
smart
smart
kvm-tec
Quick
Instruction
Smartline SVX
6501 SET
6501L CPU/LOCAL
6501R CON/REMOTE
connect collaborate communicate control
kvm-tec = C 4

power plug
12V 1A
DVI in from PC
USB to PC
DVI out to Monitor
power plug
12-24 VDC
USB from Keyboard and Mouse
Network cable CAT 5e/6/7 up to 150m/492ft
DVI to Monitor
25
6
KVM-TEC Smartline Local / PC
DC PC
In
PC
USB
KVM-Link
Monitor
Out
13 4
Quick Installation SVX1 SMARTLINE local / CPU – remote / CON
1. Connect the CON / Remote and the CPU / Local Unit to the included 12V 1A power supply.
2. Now connect the USB cable to a USB port on your PC and connect the other end of the USB cable to the CPU /
Local Unit. Connect keyboard and mouse to the CON / Remote Unit.
3. Connect the CPU / Local and the CON / Remote Unit with a network cable.
4. Now connect the DVI cable to the DVI socket of the PC and the other end to the DVI socket of the CPU / Local
Unit (PC-in). Then connect the monitor with the DVI cable to the CON / Remote Unit.
HAVE FUN - your kvm-tec Extender is now in use for many years (MTBF approx 10 years)
