Labnet AccuPlate D0410 User manual

Labnet AccuPlate™Laboratory
Stirrer/Hot Plate
Instruction Manual
Catalog Numbers:
Stirrer: Hot Plate: Stirring Hot Plate:
D0410 D0400 D0420
D0410-230V D0400-230V D0420-230V

Table of Contents
1.0 Safety Information .............................................................................1
1.1 Product Voltages............................................................................1
1.2 Symbols and Conventions ...................................................................1
1.3 Safety Precautions ..........................................................................1
2.0 Operating Conditions...........................................................................2
3.0 Product Controls and Indicators .................................................................2
4.0 Product Connections ...........................................................................2
5.0 Stirring Instructions ............................................................................3
6.0 Heating Instructions............................................................................3
7.0 Heating Operation .............................................................................4
7.1 Principles...................................................................................4
7.2 Safety ......................................................................................5
8.0 Repair .........................................................................................5
9.0 Maintenance...................................................................................5
10.0 Accessories. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
11.0 Technical Specifications.........................................................................6
12.0 Frequently Asked Questions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
13.0 Limited Warranty...............................................................................7
14.0 Equipment Disposal ............................................................................8

Instruction Manual | 1
1.0 Safety Information
This instruction manual contains important operating and maintenance instructions that must be read, understood, and followed
by the product user. Failure to use this product according to this instruction manual may degrade or defeat the protection normally
provided by this product. Read this instruction manual prior to product use and keep this instruction manual for future reference.
1.1 Product Voltages
Hot plates, stirrers, and stirring hot plates are available in different voltages. Before initial use, check that the unit you received is the
correct voltage for your location.
1.2 Symbols and Conventions
CAUTION: Risk of Danger: Cautions there is material in the instruction manual which must be read, understood, and
followed in order to preserve product safety features.
CAUTION: Hot Surface: Cautions that the top plate is too hot to touch.
Indicates that the unit is plugged into power supply.
Indicates that the accessory external temperature controller is properly plugged into the unit.
1.3 Safety Precautions
Personal Injury
If the equipment is used in a manner not specified by this manual, the equipment may become unsafe to operate,
could harm the user or the device, and may void the warranty. Changes or modifications not expressly approved by the
party responsible for compliance could void the user’s authority to operate the equipment.
This product is designed for use in laboratory environments by persons knowledgeable in safe laboratory practices.
Always wear safety glasses and other appropriate protective equipment when operating this product.
Electric Shock
This product must be connected to a grounded power outlet for safe functioning.
Use only the power cord supplied with the product.
Position the product for use so the power cord can be easily disconnected without having to move the product.
Disconnect the power cord before moving or cleaning the unit.
Product Damage
Keep the product dry and clean.
Do not immerse the product for cleaning.
The ceramic top may break if impacted.
The maximum gross weight placed on the top surface must not exceed 25 lbs. (11 kg).
These units are not explosion- or spark-proof.
Do not heat or stir volatile or flammable materials.
Do not operate this product near volatile or flammable materials.
Do not use this product with a metal vessel.
The temperature probe must always be inside the media to close the heating control loop and should not be operated
unattended.
Do not leave the product unattended while operating.
Disconnect the unit when not in use.

2| LABNET ACCUPLATE LABORATORY STIRRER/HOT PLATE
2.0 Operating Conditions
Labnet AccuPlate™ hot plates, stirrers, and stirring hot plates, are designed to be safe when used under the following conditions:
Product should be placed on a flat surface at least 12 in. (30.5 cm) from walls, 48 in. (122 cm) from ceilings, and 12 in. (30.5 cm)
from other stirrers if using multiple units.
Indoor use
Pollution Degree 2
Altitude up to 2,000 meters
Ambient temperatures of 5°C to 40°C
Ambient humidity of ≤80% at 31°C, decreasing linearly to 50% relative humidity at 40°C
Installation Category II
Protection Class IP21
3.0 Product Controls and Indicators
1
2
3 5
4
67
1. Power Indicator: Illuminates at all times when the product is properly connected to input power.
2. Stir Control Knob: Turn the knob all the way counterclockwise the Off positon, to turn Off the stirring function. Turn the knob
clockwise to set desired stirring speed.
3. Stirring Speed Display: Shows the speed set for stirring.
4. Heat Control Knob: Turn the knob all the way counterclockwise to the Off position, to turn Off the heating function. Turn the knob
clockwise to set the desired heating temperature.
5. Heating Temperature Display: Shows the temperature set for heating.
6. Hot Top Indicator: Illuminates when the temperature of the top is too hot to touch (greater than approx. 60°C).
7. Temperature Probe In-Use Indicator: Illuminates when the external temperature probe is connected to the unit.
4.0 Product Connections
1. Power Cord Input: Connect the supplied power cord into this connector.
2. External Temperature Controller Input: Connect the optional External Temperature Controller (Cat. No. D0462) into this connector.
1
2
To Connect/Disconnect the External Temperature Controller
3. Turn the Stir Control Knob and Heat Control Knob to the Off position.
4. Disconnect the power cord.
5. Insert/remove the external temperature controller connector into/from the input connector.
6. Reconnect the power cord.
7. Product is now ready for use.

Instruction Manual | 3
5.0 Stirring Instructions
Models D0410 and D0420
1. Fill the vessel with solution to be stirred.
2. Place the stir bar into the vessel.
3. Place the vessel in the center of the top surface.
4. Turn the Stir Control Knob until the Stirring Speed Display shows the desired speed. The speed setting can be adjusted according to the
table below.
Operating Range
(rpm) Adjustable Increment (rpm)
60 - 100 5
100 - 200 10
200 - 400 20
400 - 1,150 50
Flashing Display: The number will flash when the actual stirring speed is not at set speed.
Constant Display: The number will not flash when the actual stirring speed is at the set speed. The number will remain constantly
On when the actual stirring speed is at the set speed.
5. When desired stirring is complete, turn the Stir Control Knob to the Off position. Allow the stir bar to cease rotation before
removing the vessel from the unit.
6. Heating and stirring can be performed simultaneously with the D0420 models, which offer heating and stirring functions.
NOTE: The viscosity of the stirred material will affect the ability of the stir bar to remain coupled to the rotating ring magnet.
Materials of high viscosity must be stirred at slower speed settings.
6.0 Heating Instructions
Models D0400 and D0420 (Without the External Temperature Controller)
1. Fill the vessel with solution to be heated.
2. If using a D0420 model and the stirring function, place the stir bar into the vessel.
3. Place vessel in the center of the top surface.
4. Turn the Heat Control Knob until the Heating Temperature Display shows the desired temperature. The temperature setting can be
adjusted in 5°C increments.
Flashing Display: The number shown on the Heating Temperature Display will flash when the actual heating temperature is not
at the set temperature.
Constant Display: The number shown on the Heating Temperature Display will remain constantly On when the actual heating
temperature is at the set temperature.
Hot Top Indicator: The Hot Top Indicator will be On at all times when the temperature of the top surface is too hot to touch
(greater than approx. 60°C).
The Hot Top Indicator will flash when the Heat Control Knob is turned Off but the top surface is still too hot to touch.
The Hot Top Indicator will be Off when the temperature of the top is less than approx. 60°C.
CAUTION: The Hot Top Indicator will turn Off when the power cord is disconnected from the product even if the
temperature of the top surface is still too hot to touch.
Models D0400 and D0420 (With the External Temperature Controller (Cat. No. D0462))
1. Connect the External Temperature Controller to the connector on the back of the unit.
Temperature Probe in Use Indicator: This will illuminate when the External Temperature Controller is properly connected.
2. Fill the vessel with solution to be heated.
3. If using a D0420 model and the stirring function, place the stir bar into the vessel.
4. Place the vessel in the center of the top surface.
5. Insert the tip of the External Temperature Probe into the solution (see Section 10.0 diagram for proper usage).
The tip should be located in the center of the vessel and at approximately one-half of the depth of the solution.
6. Secure the position of the External Temperature Controller by using a ring stand/support rod and clamp.
Ensure the cable of the External Temperature Controller does not come into contact with the heating surface.

4| LABNET ACCUPLATE LABORATORY STIRRER/HOT PLATE
7. Turn the Heat Control Knob until the Heating Temperature Display shows the desired heating temperature.
Flashing Display: The number shown on the Heating Temperature Display will flash when the actual heating temperature is not
at the set temperature.
Constant Display: The number shown on the Heating Temperature Display will remain constantly On when the actual heating
temperature is at the set temperature.
Hot Top Indicator: The Hot Top Indicator will be On at all times when the temperature of the top surface is too hot to touch
(greater than approx. 60°C).
The Hot Top Indicator will flash when the Heat Control Knob is turned Off but the top surface is still too hot to touch.
The Hot Top Indicator will be Off when the temperature of the top is less than approx. 60°C.
CAUTION: The Hot Top Indicator will turn Off when the power cord is disconnected from the product even if the
temperature of the top surface is still too hot to touch.
7.0 Heating Operation
7.1 Principles
The heating element and a temperature sensor are located just beneath the ceramic top surface of the product. The microprocessor-
controlled heat, generated by the heating element, is based upon the sensor temperature and the value set on the Heating
Temperature Display. When the sensor temperature is not within range of the value set on the display, the display will flash. When
the sensor temperature is within range, the value displayed will remain constantly On.
The Heating Temperature Display does not indicate the actual temperature of materials placed on top of the product or the actual
temperature of the ceramic top surface.
The following table shows a typical difference between the temperature set on the Heating Temperature Display and the actual
temperature measurement of the ceramic top surface. This information was taken using a D0420 with no top load in 20°C ambient
conditions.
Temp. Set on
Display (°C) Actual Top Surface Temp. (°C)
50 45
100 85
150 125
200 165
250 205
300 245
350 285
400 325
450 365
500 405
550 440
Using the External Temperature Controller (Cat. No. D0462) enables precision temperature control of materials placed in vessels on top of
the product.
When the External Temperature Controller is connected to the product, the closed loop control process is extended to include
temperature input from the External Temperature Controller. The microprocessor-controlled heat, generated by the heating element,
is based upon the sensor temperature located in the tip of the External Temperature Controller and the value set on the Heating
Temperature Display. When the sensor temperature is not within range of the value set on the display, the display will flash. When
the sensor temperature is within range, the value displayed will remain constantly On.
To directly control the temperature of liquid in a vessel on the top surface, place the External Temperature Controller into the liquid
and connect the Controller to the product. The Heating Temperature Display shows the temperature of the liquid and can be used to
adjust the temperature of the liquid. See Section 10.0 for ordering information.
CAUTION: The top surface and the vessel used may be at substantially higher temperatures than indicated by the setting on
the Heating Temperature Display as the controller regulates the liquid temperature inside the vessel.

Instruction Manual | 5
7.2 Safety
The microprocessor-controlled system has built-in error routines to detect product operation in some unfavorable conditions. The type
of error routines which may be active in a product varies depending upon the functionality of the model and the operating software
version.
If an error routine is engaged, the product will typically shut down. Some error routines will display an error code number in the left
digital location of the Heating Temperature Display when the product is shut down. For more information on error codes, contact
Corning Scientific Support at www.corning.com/lifesciences.
A product shut down by an error routine must be disconnected and reconnected to mains input before it can be used again. Please
contact Corning Customer Service if a product does not reset from the error routine shut down or if it continues to shut down after
resetting.
CAUTION: Error routines built into these products do not substitute the need to use these products per the specified
operating conditions and according to safe laboratory practices. There are potential failure modes in product functionality
or in the process of use that could result in uncontrolled or unexpected heating of the top surface. Reaction plans should be
developed and safety precautions put in place based on the worst case scenario that any materials placed on the top surface
could be subjected to a continuous supply of heat, raising the material temperature to levels in excess of 550°C.
8.0 Repair
There are no direct user serviceable components inside this series of products.
Please contact Corning Customer Service for repair or maintenance issues.
9.0 Maintenance
Power
CAUTION: Disconnect the power to the product by unplugging the power cord before performing any maintenance or
inspection procedures.
Inspect the power cord regularly and replace if damaged. Use only replacement power cords available from Corning or Corning
authorized product distributors.
Ceramic Top Plate
These products are supplied with a Pyroceram™ top that is easy to clean and highly resistant to scratches, corrosion, and chemical
attack.
The ceramic top may break during use if not properly maintained.
Keep the ceramic top clean. A nonabrasive cleaner may be used to clean the ceramic top.
Inspect the ceramic top for damage during cleaning.
Discontinue product use if the ceramic top is chipped, etched, or shows excessive scratching.
Contact Corning Customer Service for a top replacement.
General
It is important to keep this product dry and clean.
Remove minor exterior liquid spills promptly.
Clean exterior surfaces with a nonabrasive cleaner. Do not reconnect product to power input until all cleaned surfaces have dried.
If liquid or wet solid material gets inside the product, immediately disconnect the power to the product and discontinue use.
Contact Corning Customer Service for additional instructions regarding interior spills.

6| LABNET ACCUPLATE LABORATORY STIRRER/HOT PLATE
10.0 Accessories
Support rod
(D0466)
Boss head clamp
(D0464)
Holding rod
(D0465)
External
temperature
controller
(D0462)
Stir bar retriever
(included with
D0461)
Accessories (Shown with Cat. No. D0420)
Cat. No. Description
D0461 Labnet Stirrer/Hot Plate Accessory Kit
Kit includes: External temperature controller (Cat. No. D0462), vertical support rod (Cat. No D0466) and stir bar retriever
D0462 External temperature controller for digital display hot plates and stirring hot plates. Use with D0400 and D0420 models.
D0463 PTFE (polytetrafluoroethylene)-coated magnetic stir bar, 0.39 x 1 in. (1 x 2.5 cm)
D0464 Boss head clamp, aluminum. Use for connecting the holding rod (Cat. No. D0465) at a 90° angle to the support rod (Cat. No. D0466).
D0465 Holding rod, aluminum. Use for holding the external temperature controller (Cat. No. D0462) in position.
D0466 Vertical support rod, stainless steel. Supplied as two 9 in. (22.86 cm) rods which can be screwed together.
11.0 TechnicalSpecications
Power
Model No. 120V/60Hz 230V/50Hz Temp. Range1Stir Range (rpm) Weight
D0400 665W/5.5A 635W/2.7A 5°C-550°C (41°F-1,022°F) —5.5 lbs. (2.5 kg)
D0410 15W/0.625A 15W/0.625A — 60-1,150 6.2 lbs. (2.8 kg)
D0420 675W/5.6A 645W/2.8A 5°C-550°C (41°F-1,022°F) 60-1,150 6.2 lbs. (2.8 kg)
1The Temperature Range using the External Temperature Controller is 5°C to 200°C (41°F to 392°F).
Top Plate Size Dimensions
5 x 7 in. (12.7 x 17.8 cm) 10.8 x 7.8 x 4.3 in. (27.5 x 19.7 x 10.9 cm)
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate
the equipment.

Instruction Manual | 7
NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in
a commercial environment. The equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the user manual, may cause harmful interference to radio communications. Operation of equipment in a residential
area is likely to cause harmful interference in which case the user will be required to correct the interference.
CAUTION: This equipment is not intended for use in residential environments and may not provide adequate protection to radio
reception in such environments.
This ISM device complies with Canadian ICES-001.
Cet appareil ISM est conforme à la norme NMB-001 du Canada.
12.0 Frequently Asked Questions
I have a beaker of water on my hot plate and the temperature is set for 550°C. Why does the display setting blink and not remain
constant?
The display will blink at any time when the temperature sensor is not within range of the set temperature value. The temperature
measured by the sensor is a composite of the temperature of the heating element located beneath the sensor, the ceramic top
above the sensor, and the very small air space around the sensor. Water requires a substantial amount of heat in order to boil yet
remains at a constant temperature of 100°C for the duration of the boiling process. Although the heating element is producing
maximum heat at the 550°C setting, the water consumes this heat so quickly during the boiling process that the heat is unable to
raise the temperature measured by the sensor to within the range of the 550°C set value.
How long does it take to bring a beaker of water to a boil?
Using a 600 mL beaker with 400 mL of water at 25°C, it takes approximately 15 minutes to bring the water to a full, rolling boil.
Can I use a metal tray on top of my Labnet hot plate?
No. The metal will act as a heat sink, and have a high probability of creating an abnormal heating condition. If an abnormal
condition is detected, the product will shut down. A metal vessel will also scratch the ceramic top plate.
The stir bar keeps decoupling. Why and what can I do to stop this?
These units are programmed to minimize decoupling. However, liquid viscosity, stir bar magnetic strength, vessel used, and speed
changes can cause decoupling. High viscosity liquids must be stirred at slower speed settings. The magnetic strength of stir bars can
weaken over time and may need to be replaced. The vessels used need to have thin, flat bottoms to insure optimal performance.
Rapid decreases in stir speed can cause decoupling as the magnet slows down quicker than the stir bar and the liquid.
What size vessel should I use?
The vessels used on the top of a hot plate must not be larger than the top plate.
13.0 Limited Warranty
Corning Incorporated (Corning) warrants that this product will be free from defects in material and workmanship for a period of
two (2) years from date of purchase. CORNING DISCLAIMS ALL OTHER WARRANTIES WHETHER EXPRESSED OR IMPLIED, INCLUDING
ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR OF FITNESS FOR A PARTICULAR PURPOSE. Corning’s sole obligation shall be to
repair or replace, at its option, any product or part thereof that proves defective in material or workmanship within the warranty
period, provided the purchaser notifies Corning of any such defect. Corning is not liable for any incidental or consequential damages,
commercial loss or any other damages from the use of this product.
This warranty is valid only if the product is used for its intended purpose and within the guidelines specified in the supplied instruction
manual. This warranty does not cover damage caused by accident, neglect, misuse, improper service, natural forces or other causes not
arising from defects in original material or workmanship. This warranty does not cover motor brushes, fuses, light bulbs, batteries or
damage to paint or finish. Claims for transit damage should be filed with the transportation carrier.
In the event this product fails within the specified period of time because of a defect in material or workmanship, contact Corning
Customer Service at: USA/Canada 1.800.492.1110, outside the U.S. +1.978.442.2200, visit www.corning.com/lifesciences, or contact
your local support office.
Corning’s Customer Service team will help arrange local service where available or coordinate a return authorization number and
shipping instructions. Products received without proper authorization will be returned. All items returned for service should be sent
postage prepaid in the original packaging or other suitable carton, padded to avoid damage. Corning will not be responsible for
damage incurred by improper packaging. Corning may elect for onsite service for larger equipment.
Some states do not allow limitation on the length of implied warranties or the exclusion or limitation of incidental or consequential
damages. This warranty gives you specific legal rights. You may have other rights which vary from state to state.
No individual may accept for, or on behalf of Corning, any other obligation of liability, or extend the period of this warranty.

8| LABNET ACCUPLATE LABORATORY STIRRER/HOT PLATE
For your reference, make a note of the serial and model number, date of purchase, and supplier here.
Serial No. __________________________________________ Date Purchased _______________________________________
Model No. _________________________________________ Supplier _____________________________________________
14.0 Equipment Disposal
According to Directive 2012/19/EU of the European Parliament and of the Council of 4 July 2012 on waste electrical and
electronic equipment (WEEE), this product is marked with the crossed-out wheeled bin and must not be disposed of with
domestic waste.
Consequently, the buyer shall follow the instructions for reuse and recycling of waste electronic and electrical equipment
(WEEE) provided with the products and available at www.corning.com/weee.

www.labnetlink.com
For a listing of trademarks, visit www.corning.com/clstrademarks. All other trademarks are the property of their respective owners.
© 2023 Corning Incorporated. All rights reserved. 12/23 CLSLN-AN-1041DOC REV1
Corning Incorporated
Life Sciences
www.corning.com/lifesciences
NORTH AMERICA
t 800.492.1110
t 978.442.2200
ASIA/PACIFIC
Australia/New Zealand
t 61 427286832
Chinese Mainland
t 86 21 3338 4338
India
t 91 124 4604000
Japan
t 81 3-3586 1996
Korea
t 82 2-796-9500
Singapore
t 65 6572-9740
Taiwan
t 886 2-2716-0338
EUROPE
[email protected]
LATIN AMERICA
[email protected]
Brazil
t 55 (11) 3089-7400
Mexico
t (52-81) 8158-8400
To request certificates, please contact us at www.labnetlink.com.
Warranty/Disclaimer: Unless otherwise specified, all products are for research use or general laboratory use only.* Not intended for
use in diagnostic or therapeutic procedures. Not for use in humans. These products are not intended to mitigate the presence of
microorganisms on surfaces or in the environment, where such organisms can be deleterious to humans or the environment. Corning
Life Sciences makes no claims regarding the performance of these products for clinical or diagnostic applications. *For a listing of US
medical devices, regulatory classifications or specific information on claims, visit www.corning.com/resources.
Corning’s products are not specifically designed and tested for diagnostic testing. Many Corning products, though not specific for
diagnostic testing, can be used in the workflow and preparation of the test at the customers discretion. Customers may use these products
to support their claims. We cannot make any claims or statements that our products are approved for diagnostic testing either directly
or indirectly. The customer is responsible for any testing, validation, and/or regulatory submissions that may be required to support the
safety and efficacy of their intended application.
