Labnet Excel P3600L-10 User manual

LCD Display
Reset Button
Keypad
Tip Ejector
Bushing Connector Nut
Finger Rest
Plunger Button
DC-in Jack
Battery Cover
Lower Part
Tip Fitting
Enter Button: Confirms your choice
Count No./Prog No.
Volume (µL)
Down Button: Decreases volume
and changes parameters
Up Button: Increases volume, changes
parameters, or activates aspirating/dispensing
Back Button: Exits to
previous mode/setting
Reset Button: Piston
automatically returns to
the home position
Battery Charge
Speed
Direction
SYS System Setting
AUTO Auto Pipetting
MD Multiple Dispensing
MIX Mixing
SE Sequential Aspirating/Dispensing
Audible Signals
Blow Out
Reverse Pipetting
Labnet Excel™ Single- and Multi-channel
Electronic Pipettors
Quick Start Guide
Catalog Numbers: P3600L-10, P3608L-10, P3612L-10, P3600L-20, P3608L-20, P3612L-20, P3600L-200, P3608L-200, P3612L-200,
P3600L-1200, P3608L-1200, P3612L-1200
For the complete Labnet Excel Electronic Pipettors Instruction Manual (CLSLN-AN-1032DOC), visit www.labnetlink.com.
Single-channel Pipettor Overview
LCD Display Panel

Function Modes and Examples
The shown icons will appear on LCD display after previous action.
, , , PLUNGER: press Back, Up/Down, Enter, and Plunger button.

(Mix 100 μL)
: (Mix 100 μL) means action and setting volumes.
SYS (System Settings)
Example: Switch off audible signals
Steps: SYS
AUTO (Automatic Pipetting)
Example: Pipetting 100 μL
Steps: AUTO
(100 μL)
PLUNGER
(Aspirate)
PLUNGER
(Dispense)
MD (Multiple Dispensing)
Example: Multiple dispense 40 μL x 3 = 120 μL
Steps:
PLUNGER
(Dispense 40 μL)
PLUNGER
(Reverse)
MD 01
(03)
(40 μL)
PLUNGER
(Aspirate 120 μL) PLUNGER
(Dispense 40 μL) PLUNGER
(Dispense 40 μL)
MIX (Mixing)
Example: Mix 100 μL sample 5 times
Steps: MIX 01
(05)
(Mix 100 μL)
PLUNGER
SE (Sequential Aspirating/Dispensing)
Example: Sequential aspirate – sample A (20 μL), sample B (30 μL), sample C (40 μL), and dispense 130 μL (20 μL air gap between samples)
Steps: SE SA 01
(20 μL)
02
(30 μL)
03
(40 μL)
04
PLUNGER
(Sample A: 20 μL) PLUNGER (Air gap: 20 μL) PLUNGER (Sample B: 30 μL) PLUNGER (Air gap: 20 μL) PLUNGER (Sample C: 40 μL) PLUNGER (Dispense 130 μL)
