Regulatory Information v1.0
The Sentrius™ MG100 hosts the Pinnacle 100 module which holds current certifications in the following countries:
Country/Region
Regulatory ID
USA (FCC)
SQG-PINNACLE1
Canada (ISED)
3147A-PINNACLE1
EU
N/A
The following FCC and ISED regulatory information applies to the Pinnacle 100 module which is hosted by the MG100.
Note: Laird Connectivity is the manufacturer for all of the antennas listed below.
Table 1: Pinnacle 100 certified antennas
Model
Laird Connectivity
Part Number
Type
Connector
Peak Gain
2400-2500 MHz
NanoBlue
MAF94045
PCB Dipole
IPEX U.FL
2 dBi
FlexPIFA
001-0014
Patch
U.FL
2 dBi
Dipole
001-0001
RP-SMA
2 dBi
Model
Laird Connectivity
Part Number
Type
Connector
Peak Gain
698-875MHz
1710-2500 MHz
Revie Flex
EFF6925A3S-15MHF1
PCB Dipole
IPEX U.FL
1.9 dBi
3.7 dBi
Dipole Blade
DBA6927C1-FSMAM
Dipole
SMA
0.5 dBi
2.2 dBi
Pinnacle™ 100 Bent Metal
110-00665
Bent Metal
N/A
1.3 dBi
2.6 dBi
Model
Man.
PN
Type
Conn.
Peak Gain
600-
698
698-
806
806-
894
880-
960
1350-
1580
1550-
1610
1690-
1880
1850-
1990
1910-
2180
2300-
2700
3300-
4200
4900-
6000
Revie
Flex 600
EFF6060A3
S-10MHF1
PCB
Dipole
IPEX
U.FL
2.0
2.5
2.7
3.2
3.8
3.8
3.7
2.8
2.9
3.8
4.7
6.9

https://www.lairdconnect.com/
2
© Copyright 2021 Laird Connectivity, Inc.
All Rights Reserved
Americas: [phone]
Europe: [phone]
Hong Kong: [phone]
Model
Man.
PN
Type
Conn.
Peak Gain
698-
824
824-
894
880-
960
1350-
1550
1550-
1690
1690-
1880
1850-
1990
1910-
2170
2300-
2500
2500-
2700
3300-
4200
4900-
6000
Revie
Flex 700
EFF6989A3
S-19MHF1
PCB
Dipole
IPEX
U.FL
0.9
1.4
2.7
3.2
4.2
4.1
3.7
3.9
3.7
3.5
3.3
4.5
Note: The OEM is free to choose another vendor’s antenna of like type and equal or lesser gain as an antenna appearing in
the table and still maintain compliance. Reference FCC Part 15.204(c)(4) for further information on this topic.
To reduce potential radio interference to other users, the antenna type and gain should be chosen so that the
equivalent isotropic radiated power (EIRP) is not more than that permitted for successful communication.
The 453-00010 and the 453-00011 hold full modular approvals. The OEM must follow the regulatory guidelines and warnings
listed below to inherit the modem approval.
Part #
Form Factor
BLE TX Pout
BLE Antenna
LTE TX Pout
LTE Antenna
453-00010
M2 Key E
6 dBm
PCB Trace
23 dBm
Bent Metal
453-00011
M2 Key E
6 dBm
U.FL
23 dBm
U.FL
This EUT complies with SAR for general population/uncontrolled exposure limits in FCC Part 1.1307, Part. 1310 and FCC
KDB 447498 –RF Exposure Procedures and Equipment Authorization Policies for Mobile and Portable Devices.
This transceiver must not be co-located or operating in conjunction with any other antenna, transmitter, or external amplifiers.
Further testing/evaluation of the end product will be required if the OEM’s device violates any of these requirements.
The Pinnacle™ 100 is fully approved for mobile and portable applications.
WARNING: The OEM must ensure that FCC labelling requirements are met. This includes a clearly visible label on the
outside of the OEM enclosure specifying the appropriate Laird Connectivity FCC identifier for this product.
Contains FCC ID: SQG-PINNACLE1
Thee following FCC part 15.19 statement must also be available on visible on outside of device:
The enclosed device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) This device must accept any
interference received, including interference that may cause undesired operation
Label and text information should be in a size of type large enough to be readily legible, consistent with the dimensions of the
equipment and the label. However, the type size for the text is not required to be larger than eight points.
CAUTION: The OEM should have their device which incorporates the Pinnacle™ 100 tested by a
qualified test house to verify compliance with FCC Part 15 Subpart B limits for unintentional
radiators.
CAUTION: Any changes or modifications not expressly approved by Laird Connectivity could void the
user’s authority to operate the equipment.

https://www.lairdconnect.com/
3
© Copyright 2021 Laird Connectivity, Inc.
All Rights Reserved
Americas: [phone]
Europe: [phone]
Hong Kong: [phone]
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one of the following measures:
▪Reorient or relocate the receiving antenna.
▪Increase the separation between the equipment and receiver.
▪Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
▪Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the
user's authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must accept any interference received, including interference that may
cause undesired operation.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the
user's authority to operate this equipment.
IMPORTANT NOTE:
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should
be installed and operated with a minimum distance of 20 centimeters between the radiator and your body.
This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter.
Integration Instructions for Host Product Manufacturers
Applicable FCC rules to module –FCC Part 24/27; FCC Part 15.247
Summary of the Specific Operational Use Conditions –The module must be installed in a mobile device. This device is
intended only for OEM integrators under the following conditions:
▪The antenna must be installed such that 20 cm is maintained between the antenna and users, and
▪The transmitter module may not be co-located with any other transmitter or antenna
As long as the two conditions above are met, further transmitter testing is not be required. However, the OEM integrator is still
responsible for testing their end-product for any additional compliance requirements required with this module installed.
IMPORTANT NOTE: In the event that these conditions cannot be met (for example, certain laptop configurations or co-
location with another transmitter), then the FCC authorization is no longer considered valid and the FCC ID cannot be used on
the final product. In these circumstances, the OEM integrator is responsible for re-evaluating the end product (including the
transmitter) and obtaining a separate FCC authorization. The OEM integrator must be aware not to provide information to the
end user regarding how to install or remove this RF module in the user’s manual of the end product which integrates this
module.
The end user manual shall include all required regulatory information/warning as show in this manual.
Limited Module Procedures –Not applicable
Trace Antenna Designs –Not applicable
RF Exposure Considerations –20-centimeter separation distance and co-located issue shall be met as mentioned in
Summary of the Specific Operational Use Conditions.
Product manufacturer shall provide the following text in the end-product manual:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment
should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body.

https://www.lairdconnect.com/
4
© Copyright 2021 Laird Connectivity, Inc.
All Rights Reserved
Americas: [phone]
Europe: [phone]
Hong Kong: [phone]
Label and Compliance Information
Product manufacturers must provide a physical or e-label with the finished product that states the following:
Contains FCC ID: SQG-PINNACLE1
Information on Test Modes and Additional Testing Requirements
LTE –Simulator is required to link up and set the module to transmit at specific frequency, output power level under operation
mode.
BT –Test tool is UwTerminal, version 7.94
Additional Testing –Part 15 Subpart B Disclaimer
The module is only FCC authorized for the specific rule parts listed on the grant, and that the host product manufacturer is
responsible for compliance to any other FCC rules that apply to the host not covered by the modular transmitter grant of
certification. The final host product still requires Part 15 Subpart B compliance testing with the modular transmitter installed.
This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic
Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions:
▪This device may not cause interference
▪(Ths device must accept any interference, including interference that may cause undesired operation of the device
Cet appareil contient des émetteurs / récepteurs exempts de licence qui sont conformes au (x) RSS (s) exemptés de licence
d'Innovation, Sciences et Développement économique Canada. L'opération est soumise aux deux conditions suivantes:
▪Cet appareil ne doit pas causer d'interférences
▪Cet appareil doit accepter toute interférence, y compris les interférences pouvant provoquer un fonctionnement
indésirable de l'appareil
Radiation Exposure Statement
This equipment complies with Canada radiation exposure limits set forth for an uncontrolled environment. This equipment
should be installed and operated with minimum distance 20cm between the radiator & your body.
Déclaration d'exposition aux radiations:
Cet équipement est conforme Canada limites d'exposition aux radiations dans un environnement non contrôlé. Cet
équipement doit être installé et utilisé à distance minimum de 20cm entre le radiateur et votre corps.
This device is intended only for OEM integrators under the following condition:
▪The transmitter module may not be co-located with any other transmitter or antenna.
As long as 1 condition above are met, further transmitter test will not be required. However, the OEM integrator is still
responsible for testing their end-product for any additional compliance requirements required with this module installed.
Cet appareil est conçu uniquement pour les intégrateurs OEM dans les conditions suivantes:
▪Le module émetteur peut ne pas être coïmplanté avec un autre émetteur ou antenne.
Tant que les 1 condition ci-dessus sont remplies, des essais supplémentaires sur l'émetteur ne seront pas nécessaires.
Toutefois, l'intégrateur OEM est toujours responsable des essais sur son produit final pour toutes exigences de conformité
supplémentaires requis pour ce module installé.
IMPORTANT NOTE:
In the event that these conditions can not be met (for example certain laptop configurations or co-location with another
transmitter), then the Canada authorization is no longer considered valid and the IC ID can not be used on the final product. In
these circumstances, the OEM integrator will be responsible for re-evaluating the end product (including the transmitter) and
obtaining a separate Canada authorization.
NOTE IMPORTANTE:
Dans le cas où ces conditions ne peuvent être satisfaites (par exemple pour certaines configurations d'ordinateur portable ou
de certaines co-localisation avec un autre émetteur), l'autorisation du Canada n'est plus considéré comme valide et l'ID IC ne
peut pas être utilisé sur le produit final. Dans ces circonstances, l'intégrateur OEM sera chargé de réévaluer le produit final (y
compris l'émetteur) et l'obtention d'une autorisation distincte au Canada.

https://www.lairdconnect.com/
5
© Copyright 2021 Laird Connectivity, Inc.
All Rights Reserved
Americas: [phone]
Europe: [phone]
Hong Kong: [phone]
End Product Labeling
The final end product must be labeled in a visible area with the following: “Contains IC: 3147A-PINNACLE1”
Plaque signalétique du produit final
Le produit final doit être étiqueté dans un endroit visible avec l'inscription suivante: "Contient des IC: 3147A-PINNACLE1".
Manual Information to the End User
The OEM integrator has to be aware not to provide information to the end user regarding how to install or remove this RF
module in the user’s manual of the end product which integrates this module.
The end user manual shall include all required regulatory information/warning as show in this manual.
Manuel d'information à l'utilisateur final
L'intégrateur OEM doit être conscient de ne pas fournir des informations à l'utilisateur final quant à la façon d'installer ou de
supprimer ce module RF dans le manuel de l'utilisateur du produit final qui intègre ce module.
Le manuel de l'utilisateur final doit inclure toutes les informations réglementaires requises et avertissements comme indiqué
dans ce manuel.
This radio transmitter (IC: 3147A-PINNACLE1) has been approved by Industry Canada to operate with the antenna types
listed below with the maximum permissible gain indicated. Antenna types not included in this list, having a gain greater than
the maximum gain indicated for that type, are strictly prohibited for use with this device.
Le présent émetteur radio (IC: 3147A-PINNACLE1) a été approuvé par Industrie Canada pour fonctionner avec les types
d'antenne énumérés ci-dessous et ayant un gain admissible maximal. Les types d'antenne non inclus dans cette liste, et dont
le gain est supérieur au gain maximal indiqué, sont strictement interdits pour l'exploitation de l'émetteur.
Table 2: Pinnacle 100 certified antennas
Model
Laird Connectivity
Part Number
Type
Connector
Peak Gain
2400-2500 MHz
NanoBlue
MAF94045
PCB Dipole
IPEX U.FL
2 dBi
FlexPIFA
001-0014
Patch
U.FL
2 dBi
Dipole
001-0001
RP-SMA
2 dBi
Model
Laird Connectivity
Part Number
Type
Connector
Peak Gain
698-875MHz
1710-2500 MHz
Revie Flex
EFF6925A3S-15MHF1
PCB Dipole
IPEX U.FL
1.9 dBi
3.7 dBi
Dipole Blade
DBA6927C1-FSMAM
Dipole
SMA
0.5 dBi
2.2 dBi
Pinnacle™ 100 Bent Metal
110-00665
Bent Metal
N/A
1.3 dBi
2.6 dBi
Model
Man.
PN
Type
Conn.
Peak Gain
600-
698
698-
806
806-
894
880-
960
1350-
1580
1550-
1610
1690-
1880
1850-
1990
1910-
2180
2300-
2700
3300-
4200
4900-
6000
Revie
Flex 600
EFF6060A3
S-10MHF1
PCB
Dipole
IPEX
U.FL
2.0
2.5
2.7
3.2
3.8
3.8
3.7
2.8
2.9
3.8
4.7
6.9
Model
Man.
PN
Type
Conn.
Peak Gain
698-
824
824-
894
880-
960
1350-
1550
1550-
1690
1690-
1880
1850-
1990
1910-
2170
2300-
2500
2500-
2700
3300-
4200
4900-
6000
Revie
Flex 700
EFF6989A3
S-19MHF1
PCB
Dipole
IPEX
U.FL
0.9
1.4
2.7
3.2
4.2
4.1
3.7
3.9
3.7
3.5
3.3
4.5

https://www.lairdconnect.com/
6
© Copyright 2021 Laird Connectivity, Inc.
All Rights Reserved
Americas: [phone]
Europe: [phone]
Hong Kong: [phone]
Manufacturer:
Laird Connectivity
Product(s):
SentriusTM MG100
Product Description
SentriusTM MG100 - Micro-Gateway
Internal Antenna
External Antenna
Notified Body (where applicable)
Name of notify body
Telefication
4 digit notified body number:
0560
Conformity assessment Module
Module B
Reference number of the certificate of notified body
202140374/AA/00
EU Directives:
2014/53/EU –Radio Equipment Directive (RED)
Reference standards used for presumption of conformity:
Article Number
Requirement
Reference standard(s)
3.1a
Low voltage equipment safety
EN 62368-1: 2014+A11:2017
RF Exposure
EN 62311:2008
EN 50665:2017
EN 50385:2017
3.1b
Protection requirements with
respect to electromagnetic
compatibility
EN 301 489-1 V2.2.3 (2019-11)
EN 301 489-3 V2.1.1
Draft EN 301 489-17 V3.2.2 (2019-12)
Draft EN 301 489-52 V1.1.0 (2016-11)
3.2
Means of the efficient use of the
radio frequency spectrum
EN 300 328 V2.2.2 (2019-07)
EN 300 330 V2.1.1.(2017-02)
EN 301 908-1 V11.1.1 (2016-07)
EN 301 908-13 V11.1.2 (2017-07)

https://www.lairdconnect.com/
7
© Copyright 2021 Laird Connectivity, Inc.
All Rights Reserved
Americas: [phone]
Europe: [phone]
Hong Kong: [phone]
Declaration:
We, Laird Connectivity, declare under our sole responsibility that the essential radio test suites have been carried out and that
the above product to which this declaration relates is in conformity with all the applicable essential requirements of Article 3 of
the Radio Equipment Directive 2014/53/EU, when used for its intended purpose.
Place of Issue:
Laird Connectivity
W66N220 Commerce Court, Cedarburg, WI 53012 USA
tel: [phone] fax: [phone]
Date of Issue:
2021/2/21
Name of Authorized Person:
Bill Steinike
Signature of Authorized Person:
Max. power information:
Frequency
EIRP Power (Max) –dBm
BT LE
2402~2480 MHz
10
LTE Band
Conducted Power (Max) –dBm
Cat-M1
LTE B1
22
LTE B3
23
LTE B8
22.5
LTE B20
23
LTE B28
23.5
NB-IoT
LTE B1
22
LTE B3
23
LTE B8
22.5
LTE B20
23
LTE B28
23

https://www.lairdconnect.com/
8
© Copyright 2021 Laird Connectivity, Inc.
All Rights Reserved
Americas: [phone]
Europe: [phone]
Hong Kong: [phone]
Domain support but not currently certified for –TBD
Version
Date
Notes
Contributor(s)
Approver
1.0
15 Feb 2021
Initial version
Sue White
Jonathan Kaye
