INSTALLATIONPROCEDUREFORPATHLIGHT:
1. Preparefootingasrequiredbylocalcodes,seeFig.1,Fig.2andFig.3for
recommendations.
2. Setwoodenanchortemplateinpositionoverconduit. Thearrowandthe‘F’onthe
templateindicatesthefrontoftheunit.
3. Markanchorholelocationsandremovethetemplate.
4. Drillholesaccordingtoanchorsizeanddepth,seeFig.6.Clearholesofdebris.
5. AttachanchorstobaseplatetemplateasshowninFig.5.
6. Testfittemplateassemblywithanchorsintopositionbeforeinstallingepoxy.Make
anyadjustmentsasnecessarytoallowconcreteanchorstofreelyinstall.Concrete
anchorshouldsitcenteredinholeandnotrestagainstthesideofthedrilledhole.
7. Addepoxytoanchorholesperepoxymanufacturer’srecommendations.
8. Slowlysettemplateassemblywithanchorsintoposition.Wipeawayanyexcess
epoxybeforeitcures.
9. Allowepoxytofullycure.Removehexboltsandwashers.Removewooden
template.
10. Setshimandbaseplatewithdriverassemblyoverconcreteanchorsandattachusing
hexboltsandwashersasshowninFig.6.
11. Makewiringconnectionsbetweenlightbodyanddriverplate.
12. Setlightbodyoverbaseplate,aligningfrontofbodywithfrontofbaseplate.Ensure
wiringisnotpinchedorcrimped.
13. InstallthesealingwasherandM10socketheadcapscrewasshowninFig.8.
14. Installboltcoverandtightenallthreesetscrewsevenly,seeFig.9.
PROCEDUREFORWIRINGPATHLIGHT:
TheFGPpathlightisassembledatthefactory.Thelightcartridgeismountedintothe
headofthepoleandwillnotneedtoberemovedduringinstallation.Donotremovelight
cartridgeorlightbodyarmsduringinstallation.
Thefollowingschematicistobeusedtoconnecttheunittolinevoltage.Itisthe
responsibilityoftheinstallertomakesurethatallconnectionsaremadeinaccordance
withtheNECandlocalbuildingcodes.Connectionhardwarenotincluded.
INSTALLATIONANDSERVICESHOULDONLYBEPERFORMEDBYQUALIFIEDPERSONNEL.
LandscapeFormsisnotresponsibleforsitepreparationandfootings.Footingrecommendationsareincludedintheseinstructions.
Installation Guide www.landscapeforms.com Ph: 800.521.2546
Page 2 of 2
Date: March 28, 2018
Fig.10–Pathlightwiringschematic
FGP Path Light
Fig.7–baseplatewithdriver
DRIVER
SURGE
PROTECTOR
GROUNDING
LUG
Fig.8–Installbodyoverbaseplate
(lightpolearmremovedforclarity)
Fig.9–Installboltcover
SETSCREW
LOCATION
HEXKEY
Fig.6– Anchordetail
HEXBOLT
5/16
WASHER
CONCRETE
ANCHOR
BASE
CASTING
SHIM
