LP-N24, Internet Bandwidth Control 123 Manual.
LPN24_M123_ENF01W
LP-N24
Internet Bandwidth Control 123 Manual.

www.lanpro.com
Wireless - Equipment - 2.4 GHz - LP-N24, Internet Bandwidth Control 123 Manual
2
This document´s goal is to explain how to control the WAN port Access bandwidth. Please follow the instructions in the
previous 123 conguration Manuals before using this one. Please visit www.lanpro.com for downloading the proper
manuals.
Figure 1
Figure 2
Figure 3
1
2
3
Please open your preferred browser and navigate to the LP-N24`s default IP address: 192.168.0.1, as shown in gure 1.
A window will pop-up asking you to input the User Name and
the Password defaults. User: admin and password: admin,
then, select: OK, as shown in gure 2.
Select option: Trafc Control, mark: Trafc Control, as
shown in gure 3.

www.lanpro.com
Wireless - Equipment - 2.4 GHz - LP-N24, Internet Bandwidth Control 123 Manual
3
Figure 4
Figure 5
4
5
6
Input in: WAN Upload BW the upload bandwidth in Kbyte/s you wish and in: WAN Download BW the download bandwidth
in Kbyte/s you wish, these values will depend on the ISP Internet speed available. This rst kind of control refers to Total
Trafc and is assignable per IP group and/or port. Please see paragraph 5. Then select: Apply, as shown in gure 4.
In order to setup this rule, please proceed to select this HTTP service, and input the IP range as follows: 192.168.0.100 – 120,
then, select: UP in option: UP/Down, then input the bandwidth value. Once done, select: Apply, then: Add as shown in
gure 5.
In the following example we will congure the following requirement:
a. In this installation it is required that the users having the following IP addresses: from 192.168.0.100 to
192.168.0.120 have a restriction of HTTP access speed to 512Kbytes/s.

www.lanpro.com
Wireless - Equipment - 2.4 GHz - LP-N24, Internet Bandwidth Control 123 Manual
4
Figure 6
Figure 7
Figure 8
7
8
9
10
Now, please change option: UP/Down to: Down and
select: Add, as shown in gure 6.
Once nished, please select option: Apply, you will have the
result shown in gure 7.
If you wish to modify one of the rules, select option: Edit
and modify the corresponding values accordingly as shown
in gure 8, then select option: Renew and nally: Apply.
If you wish to delete one of the options, select the option and hit: Del and then: Apply in order to activate it.
