LAUNCH TECH Premium CRP 12 Series User manual

CRP 12X Premium
Manual
LAUNCH TECH USA

1-877-528-6249
www.launchtechusa.com
1820 S. Milliken Ave
Ontario, CA 91761
I
.
CRP 12X
Premium
V1.00.000
2015-04-15

1-877-528-6249
www.launchtechusa.com
1820 S. Milliken Ave
Ontario, CA 91761
II
.
CRP 12X
Premium
Trademark Information
LAUNCH is a registered trademark of LAUNCH TECH CO., LTD. (LAUNCH) in China and other countries. All other LAUNCH trademarks,
service marks, domain names, logos and company names referred to in this manual are either trademarks, registered trademarks, service
marks, domain names, logos and company names of or are otherwise the property of LAUNCH or its afliates. In countries where any of the
LAUNCH trademarks, service marks, domain names, logos and company names are not registered, LAUNCH claims other rights associated with
unregistered trademarks, service marks, domain names, logos and company names. Other products or company names referred to in this manual
may be trademarks of their respective owners. You may not use any trademark, service mark, domain name, logo, or company name of LAUNCH
or any third party without permission from the owner of the applicable trademark, service mark, domain name, logo, or company name. You may
contact LAUNCH at www.cnlaunch.com, or write to LAUNCH TECH. CO., LTD., Launch Industrial Park, North of Wuhe Avenue, Banxuegang,
Bantian, Longgang, Shenzhen, Guangdong, P.R. China, to request written permission to use Materials on this manual for purposes or for all other
questions relating to this manual.
Copyright Information
Copyright © 2015 by LAUNCH TECH. CO., LTD. All rights reserved. No part of this publication may be reproduced, stored in a retrieval system,
or transmitted in any form or by any means, electronic, mechanical, photocopying and recording or otherwise, without the prior written permission
of LAUNCH. The information contained herein is designed only for the use of this unit. LAUNCH is not responsible for any use of this information
as applied to other units.

1-877-528-6249
www.launchtechusa.com
1820 S. Milliken Ave
Ontario, CA 91761
III
.
CRP 12X
Premium
General Notice
Other product names used herein are for identication purposes only and may be trademarks of their respective owners. LAUNCH disclaims
any and all rights in those marks.
There is a possibility that this unit is inapplicable to some of the vehicle models or systems listed in the diagnosis section due to different
countries, areas, and/or years. Do not hesitate to contact LAUNCH if you come across such questions. We are to help you solve the problem
as soon as possible.
Disclaimer
To take full advantage of the unit, you should be familiar with the engine.
All information, illustrations, and specications contained in this manual are based on the latest information available at the time of publication.
The right is reserved to make change at any time without notice.
Neither LAUNCH nor its afliates shall be liable to the purchaser of this unit or third parties for damages, losses, costs or expenses incurred
by purchaser or third parties as a result of: accident, misuse, or abuse of this unit, or unauthorized modications, repairs, or alterations to this
unit, or failure to strictly comply with LAUNCH operating and maintenance instructions.
LAUNCH shall not be liable for any damages or problems arising from the use of any options or any consumable products other than those
designated as Original LAUNCH Products or LAUNCH Approved Products by LAUNCH.
Safety Precautions and Warnings
To prevent personal injury or damage to vehicles and/or the CRP12X Premium, please read this user’s manual rst carefully and observe the
following safety precautions at a minimum whenever working on a vehicle:
Always perform automotive testing in a safe environment.
Do not attempt to operate or observe the tool while driving a vehicle. Operating or observing the tool will cause driver distraction and could
cause a fatal accident.
Wear safety eye protection that meets ANSI standards.
Keep clothing, hair, hands, tools, test equipment, etc. away from all moving or hot engine parts.
Operate the vehicle in a well-ventilated work area: Exhaust gases are poisonous.
Put blocks in front of the drive wheels and never leave the vehicle unattended while running tests.
Use extreme caution when working around the ignition coil, distributor cap, ignition wires and spark plugs. These components create hazardous
voltages when the engine is running.
Put the transmission in P (for A/T) or N (for M/T) and make sure the parking brake is engaged.
Keep a re extinguisher suitable for gasoline/chemical/electrical res nearby.
Don’t connect or disconnect any test equipment while the ignition is on or the engine is running.
Keep the CRP12X Premium dry, clean, free from oil/water or grease. Use a mild detergent on a clean cloth to clean the outside of the CRP12X
Premium, when necessary.

1-877-528-6249
www.launchtechusa.com
1820 S. Milliken Ave
Ontario, CA 91761
1
.
CRP 12X
Premium
1. Introduction
The CRP12X Premium Series are specially developed by LAUNCH, which supports all 10 modes of OBD II test for a complete diagnosis.
Featuring the 3.5” TFT color display, it enables users to read/clear DTCs, record, save and playback data in live graphic display. The CRP12X
Premium Series are also very easy to use. With built-in help menus and code denitions, diagnosing and repairing that dreaded Check Engine
Light is now easier than ever!
Moreover, CRP12X Premium Series also feature the following bi-directional “special tests”: EVAP, O2 Sensor, I/M Readiness, MIL Status, VIN
Info, and On-board monitors testing.
It can be connected to PC through the USB cable for upgrade to keep updated with the latest software version.
Note: CRP12X Premium Series may automatically reset while being disturbed by strong static electricity. THIS IS A NORMAL REACTION.

1-877-528-6249
www.launchtechusa.com
1820 S. Milliken Ave
Ontario, CA 91761
2
.
CRP 12X
Premium
2. General Information
2.1 On-Board Diagnostics (OBD) II
The rst generation of On-Board Diagnostics (OBD I) was developed by the California Air Resources Board (ARB) and implemented in 1988 to
monitor some of the emission control components on vehicles. As technology evolved and the desire to improve the On-Board Diagnostic system
increased, a new generation of On-Board Diagnostic system was developed. This second generation of On-Board Diagnostic regulations is called
“OBD II”.
The OBD II system is designed to monitor emission control systems and key engine components by performing either continuous or periodic tests
of specic components and vehicle conditions. When a problem is detected, the OBD II system turns on a warning lamp (MIL) on the vehicle
instrument panel to alert the driver typically by the phrase of “Check Engine” or “Service Engine Soon”. The system will also store important
information about the detected malfunction so that a technician can accurately nd and x the problem. Here below follow three pieces of such
valuable information:
1) Whether the Malfunction Indicator Light (MIL) is commanded ‘on’ or ‘off’;
2) Which, if any, Diagnostic Trouble Codes (DTCs) are stored;
3) Readiness Monitor status.
2.2 Diagnostic Trouble Codes (DTCs)
OBD II Diagnostic Trouble Codes are codes that are stored by the on-board computer diagnostic system in response to a problem found in the
vehicle. These codes identify a particular problem area and are intended to provide you with a guide as to where a fault might be occurring within
a vehicle. OBD II Diagnostic Trouble Codes consist of a ve-digit alphanumeric code. The rst character, a letter, identies which control system
sets the code. The second character, a number, 0-3; other three characters, a hex character, 0-9 or A-F provide additional information on where
the DTC originated and the operating conditions that caused it to set. Here below is an example to illustrate the structure of the digits:
Figure 2-1
2.3 Location of the Data Link Connector (DLC)
The DLC (Data Link Connector or Diagnostic Link Connector) is typically a 16-pin connector where diagnostic code readers interface with the
vehicle’s on-board computer. The DLC is usually located 12 inches from the center of the instrument panel (dash), under or around the driver’s
side for most vehicles. If Data Link Connector is not located under dashboard, a label should be there telling location. For some Asian and
European vehicles, the DLC is located behind the ashtray and the ashtray must be removed to access the connector. If the DLC cannot be found,
refer to the vehicle’s service manual for the location.

1-877-528-6249
www.launchtechusa.com
1820 S. Milliken Ave
Ontario, CA 91761
3
.
CRP 12X
Premium
Figure 2-2
2.4 OBD II Readiness Monitors
An important part of a vehicle’s OBD II system is the Readiness Monitors, which are indicators used to nd out if all of the emissions components
have been evaluated by the OBD II system. They are running periodic tests on specic systems and components to ensure that they are
performing within allowable limits.
Currently, there are eleven OBD II Readiness Monitors (or I/M Monitors) dened by the U.S. Environmental Protection Agency (EPA). Not all
monitors are supported in every vehicles and the exact number of monitors in any vehicle depends on the motor vehicle manufacturer’s emissions
control strategy.
Continuous Monitors — Some of the vehicle components or systems are continuously tested by the vehicle’s OBD II system, while others are
tested only under specic vehicle operating conditions. The continuously monitored components listed below are always ready:
1. Misre
2. Fuel System
3. Comprehensive Components (CCM)
Once the vehicle is running, the OBD II system is continuously checking the above components, monitoring key engine sensors, watching for
engine misre, and monitoring fuel demands.
Non-Continuous Monitors — Unlike the continuous monitors, many emissions and engine system components require the vehicle to be operated
under specic conditions before the monitor is ready. These monitors are termed non-continuous monitors and are listed below:
1) EGR System
2) O2 Sensors
3) Catalyst
4) Evaporative System
5) O2 Sensor Heater
6) Secondary air Injection
7) Heated Catalyst
8) A/C system
2.5 OBD II Monitor Readiness Status
OBD II systems must indicate whether or not the vehicle’s PCM’s monitor system has completed testing on each component. Components that
have been tested will be reported as “Ready”, or “Complete”, meaning they have been tested by the OBD II system. The purpose of recording
readiness status is to allow inspectors to determine if the vehicle’s OBD II system has tested all the components and/or systems.
The Powertrain Control Module (PCM) sets a monitor to “Ready” or “Complete” after an appropriate drive cycle has been performed. The
drive cycle that enables a monitor and sets readiness codes to “Ready” varies for each individual monitor. Once a monitor is set as “Ready”
or “Complete”, it will remain in this state. A number of factors, including erasing of Diagnostic Trouble Codes (DTCs) with a code reader or a
disconnected battery, can result in Readiness Monitors being set to “Not Ready”. Since the three continuous monitors are constantly evaluating,
they will be reported as “Ready” all of the time. If testing of a particular supported non-continuous monitor has not been completed, the monitor
status will be reported as “Not Complete” or “Not Ready.”
In order for the OBD monitor system to become ready, the vehicle should be driven under a variety of normal operating conditions. These
operating conditions may include a mix of highway driving and stop and go, city type driving, and at least one overnight-off period. For specic
information on getting your vehicle’s OBD monitor system ready, please consult your vehicle owner’s manual.

1-877-528-6249
www.launchtechusa.com
1820 S. Milliken Ave
Ontario, CA 91761
4
.
CRP 12X
Premium
2.6 OBD II Denitions
Powertrain Control Module (PCM) — OBD II terminology for the on-board computer that controls engine and drive train.
Malfunction Indicator Light (MIL) — Malfunction Indicator Light (Service Engine Soon, Check Engine) is a term used for the light on the instrument
panel. It is to alert the driver and/or the repair technician that there is a problem with one or more of vehicle’s systems and may cause emissions
to exceed federal standards. If the MIL illuminates with a steady light, it indicates that a problem has been detected and the vehicle should be
serviced as soon as possible. Under certain conditions, the dashboard light will blink or ash. This indicates a severe problem and ashing is
intended to discourage vehicle operation. The vehicle onboard diagnostic system cannot turn the MIL off until the necessary repairs are completed
or the condition no longer exists.
DTC — Diagnostic Trouble Codes (DTC) that identies which section of the emission control system has malfunctioned.
Enabling Criteria — Also termed Enabling Conditions. They are the vehicle-specic events or conditions that must occur within the engine before
the various monitors will set, or run. Some monitors require the vehicle to follow a prescribed “drive cycle” routine as part of the enabling criteria.
Drive cycles vary among vehicles and for each monitor in any particular vehicle. Please refer to the vehicle’s factory service manual for specic
enabling procedures.
OBD II Drive Cycle — A specic mode of vehicle operation that provides conditions required to set all the readiness monitors applicable to the
vehicle to the “ready” condition. The purpose of completing an OBD II drive cycle is to force the vehicle to run its onboard diagnostics. Some form
of a drive cycle needs to be performed after DTCs have been erased from the PCM’s memory or after the battery has been disconnected. Running
through a vehicle’s complete drive cycle will “set” the readiness monitors so that future faults can be detected. Drive cycles vary depending on the
vehicle and the monitor that needs to be reset. For vehicle specic drive cycle, consult the service manual.
Freeze Frame Data — When an emissions related fault occurs, the OBD II system not only sets a code but also records a snapshot of the vehicle
operating parameters to help in identifying the problem. This set of values is referred to as Freeze Frame Data and may include important engine
parameters such as engine RPM, vehicle speed, air ow, engine load, fuel pressure, fuel trim value, engine coolant temperature, ignition timing
advance, or closed loop status.
Fuel Trim (FT) — Feedback adjustments to the base fuel schedule. Short-term fuel trim refers to dynamic or instantaneous adjustments. Long-
term fuel trim refers to much more gradual adjustments to the fuel calibration schedule than short-term trim adjustments. These long-term
adjustments compensate for vehicle differences and gradual changes that occur over time.

1-877-528-6249
www.launchtechusa.com
1820 S. Milliken Ave
Ontario, CA 91761
5
.
CRP 12X
Premium
3. Product Descriptions
3.1 Outline of CRP12X Premium
Figure 3-1 CRP129 Premium Front View
Note: CRP12X Premium Series feature same appearance. Here we only take CRP129 Premium for example.
No. Name Descriptions
1OBD-16
connector
To connect to vehicle’s DLC (Data Link Connector) via
diagnostic cable.
2To retrieve the DTCs in the database.
3LCD Indicates test results.
4TF card slot Insert the TF card into it to read or write the data/le
stored in TF card.
5USB port To connect on PC to upload data or print test results.
6
/Move cursor up and down for selection.
/Move cursor left or right for selection; Or turn page
up and down when more than one page is displayed.
7OK Conrms a selection (or action) from a menu list.
8ESC Exit the current program or return to the previous
screen.
3.2 Specications
Screen: 4.0” TFT LCD display
Input voltage range: 9~18V
Working temperature: 0 to 50°C (32 to 122 F°)
Storage temperature: – 20 to 70°C (-4 to 158 F°)
External Dimension: 7.7”(L) x 4.17”(W) x 1.25”(H)
Weight: <400g
3.3 Accessories Included
1. CRP12X Premium handset
2. Diagnostic cable
3. User manual
4. TF card
5. TF card reader
6. USB cable

1-877-528-6249
www.launchtechusa.com
1820 S. Milliken Ave
Ontario, CA 91761
6
.
CRP 12X
Premium
4. Connection
4.1 Install TF card
1) Take out the TF card from package box.
2) Insert the TF card into the CRP12X Premium TF card slot perpendicularly. Make sure is fully inserted in the right place with the “micro” label
facing upward.
Note: You can hear a clicking sound if you insert the TF card in the right place. Press the card slightly, it will be ejected automatically.
4.2 Connect CRP12X Premium
1. Turn the ignition off.
2. Locate vehicle’s DLC socket: It provides standard 16 pins and is generally located on driver’s side, about 12 inches away from the center of
dashboard. See Figure 2-2. If DLC is not equipped under dashboard, a label indicating its position will be given. In case no DLC is found,
please refer to Automobile Repair Manual.
3. Plug one end of the diagnostic cable into the OBD II 16 pin connector of CRP12X Premium, and connect the other end to the vehicle’s DLC.
4. Turn the ignition on. Engine can be off or running.
5. After nishing, the system will start initializing. After initialization, the system will enter the main menu interface.
CAUTION: Don’t connect or disconnect any test equipment with ignition on or engine running.
4.3 Settings
Select [Settings] in the main menu and press [OK], the system will enter the following screen:
Figure 4-2
1) Language
This option enables you to set the user interface language.
Note: Due to continuous software upgrade, language interface may differ from different software versions.
2) Unit of Measure
This option allows you to set measurement unit.
3) Beeper
It is used to set On/Off the buzzer.
4) Record Mode
It is used to turn On/Off recording function.
