LAUNCH TECH X-631 User manual

LAUNCH X-631 Wheel Aligner Product Service Manual
i
X-631 Wheel Aligner
Product Service Manual
No.: 11 LSDC 3111 0003 A
Translated by Checked by Approved by
Name Alex. Mr. Li Frank
Date 20120620 20120628 20120631

LAUNCH X-631 Wheel Aligner Product Service Manual
ii
LAUNCH TECH CO., LTD.
ADD: Launch Industrial Park, North of Wuhe Rd,
Banxuegang, Longgang, Shenzhen, P. R. China
TEL: [phone]
Internet: http://www. cnlaunch.com

LAUNCH X-631 Wheel Aligner Product Service Manual Table of contents
iii
Table of Contents
Preface..........................................................................................................................................................................................1
Target Reader...........................................................................................................................................................................1
Purpose ....................................................................................................................................................................................1
Required Knowledge ................................................................................................................................................................1
Summary.......................................................................................................................................................................................1
Function....................................................................................................................................................................................1
Specifications ...........................................................................................................................................................................1
Hardware ......................................................................................................................................................................................1
Computer ......................................................................................................................................................................................1
Hardware Configuration............................................................................................................................................................1
Operating System.....................................................................................................................................................................1
Computer (HP) Backboard Diagram.........................................................................................................................................1
Wireless Emitter/Receiver Box .....................................................................................................................................................2
Function Explanation Diagram .................................................................................................................................................5
Function Description.................................................................................................................................................................5
Power supply............................................................................................................................................................................5
RF Connecting Cable ...............................................................................................................................................................5
Working Frequency ..................................................................................................................................................................6
Switch Power Supply ....................................................................................................................................................................6
Function Explanation................................................................................................................................................................6
Function Description.................................................................................................................................................................7
Connecting Cable.....................................................................................................................................................................7
Connection Explanation............................................................................................................................................................7
Charging Connector......................................................................................................................................................................8
Function Explanation................................................................................................................................................................8
Function Description.................................................................................................................................................................8
Measurement Probe rod ...............................................................................................................................................................8
Assembly..................................................................................................................................................................................8
Function Explanation................................................................................................................................................................9
Assembly Description...............................................................................................................................................................9
Main-board of probe rod.........................................................................................................................................................10
Function Explanation..............................................................................................................................................................11
Function Description...............................................................................................................................................................12
Connecting Sockets................................................................................................................................................................13
Frequency Setting ..................................................................................................................................................................13
Communication Module..........................................................................................................................................................14
Charging Control ....................................................................................................................................................................14

LAUNCH X-631 Wheel Aligner Product Service Manual Table of contents
iv
Main chip (ATMEGA128L) Address Code ..............................................................................................................................14
Testing for Main-board Circuit.................................................................................................................................................14
CCD Camera Box...................................................................................................................................................................16
Function Explanation..............................................................................................................................................................17
Function Description...............................................................................................................................................................17
Specification ...........................................................................................................................................................................17
Camera Assembly ..................................................................................................................................................................18
Electrical Connection..............................................................................................................................................................19
LCD Display Screen ...............................................................................................................................................................19
Main-board Charging Cable ...................................................................................................................................................20
Filter........................................................................................................................................................................................20
Power Supply Battery.............................................................................................................................................................21
Specification ...........................................................................................................................................................................21
Electrical Connection..............................................................................................................................................................22
Connection Explanation..........................................................................................................................................................22
Assembly................................................................................................................................................................................24
Software........................................................................................................................................................................................1
Operating System .........................................................................................................................................................................1
Description for Operating System.............................................................................................................................................1
System Disc..............................................................................................................................................................................1
Hard Disc Assignment ..............................................................................................................................................................1
Hard disc partition information..................................................................................................................................................1
Installation for Commonly Used Software.................................................................................................................................1
Information Back-up Path.........................................................................................................................................................1
System Restoring .....................................................................................................................................................................2
User Software ...............................................................................................................................................................................2
Description for Function Module...............................................................................................................................................2
Software Installation .................................................................................................................................................................2
Path for Software Installation....................................................................................................................................................3
Introduction for the corresponding files ....................................................................................................................................4
CHECK.INI ...............................................................................................................................................................................4
Main Interface...........................................................................................................................................................................5
Function Module.......................................................................................................................................................................5
Check Software Version ...........................................................................................................................................................5
Introduction for Each Function Module.....................................................................................................................................6
System Management................................................................................................................................................................6
Function Description.................................................................................................................................................................6
Select Language.......................................................................................................................................................................6
System Setting .........................................................................................................................................................................6
Probe Rod Status .....................................................................................................................................................................7
Probe Rod Status .....................................................................................................................................................................7
Probe Rod Detailed Information ...............................................................................................................................................7
Probe Rod Calibration ..............................................................................................................................................................8

LAUNCH X-631 Wheel Aligner Product Service Manual Table of contents
v
Measurement..........................................................................................................................................................................13
Function Description...............................................................................................................................................................13
Fast Test.................................................................................................................................................................................13
Function Description...............................................................................................................................................................14
Print Report ............................................................................................................................................................................14
Help ........................................................................................................................................................................................14
Exit..........................................................................................................................................................................................14
Maintenance Guide.......................................................................................................................................................................1
Summary ..................................................................................................................................................................................1
Hardware..................................................................................................................................................................................1
Probe rod cannot be switched on .............................................................................................................................................1
Related Factors ........................................................................................................................................................................1
Checking Sequence .................................................................................................................................................................1
Incorrect Display after Switching On ........................................................................................................................................1
Incorrect Display Content .........................................................................................................................................................1
Related Factors ........................................................................................................................................................................1
Check Sequence ......................................................................................................................................................................1
Disorder Codes, Double-shadow..............................................................................................................................................1
Related Factors ........................................................................................................................................................................1
Check Sequence ......................................................................................................................................................................1
No Backlight .............................................................................................................................................................................1
Related Factors ........................................................................................................................................................................1
Check Sequence ......................................................................................................................................................................2
Battery cannot be Charged.......................................................................................................................................................2
Related Factors ........................................................................................................................................................................2
Check Sequence ......................................................................................................................................................................2
The Working Time of Battery is Shorted...................................................................................................................................2
Related Factors ........................................................................................................................................................................2
Check Sequence ......................................................................................................................................................................2
Abnormal CCD Light Dots ........................................................................................................................................................2
The Light Dots cannot be Seen ................................................................................................................................................2
Related Factors ........................................................................................................................................................................2
Check Sequence ......................................................................................................................................................................2
The Light Dots are Jumping .....................................................................................................................................................2
Related Factors ........................................................................................................................................................................2
Check Sequence ......................................................................................................................................................................2
Key-press is faulty ....................................................................................................................................................................3
Related Factors ........................................................................................................................................................................3
Check Sequence ......................................................................................................................................................................3
No Inclination Angle..................................................................................................................................................................3
Related Factors ........................................................................................................................................................................3
Check Sequence ......................................................................................................................................................................3
Communication Fault................................................................................................................................................................3
Communication Fault................................................................................................................................................................3

LAUNCH X-631 Wheel Aligner Product Service Manual Table of contents
vi
Related Factors ........................................................................................................................................................................3
Check Sequence ......................................................................................................................................................................3
Communication Interference ....................................................................................................................................................3
Related Factors ........................................................................................................................................................................3
Check Sequence ......................................................................................................................................................................3
Software ...................................................................................................................................................................................3
Faulty Communication..............................................................................................................................................................3
Related Factors ........................................................................................................................................................................3
Check Sequence ......................................................................................................................................................................4
System Starts Slowly after Switching on ..................................................................................................................................4
Related Factors ........................................................................................................................................................................4
Check Sequence ......................................................................................................................................................................4
Computer runs slowly...............................................................................................................................................................4
Related Factors ........................................................................................................................................................................4
Check Sequence ......................................................................................................................................................................4
Appendix 1....................................................................................................................................................................................1
Instructions for waveform testing software of X-631 wheel aligner...........................................................................................1
Appendix 2....................................................................................................................................................................................1
Circuit Board Elements.............................................................................................................................................................1
Appendix 3....................................................................................................................................................................................1
The Instructions for the Frequency Jumping of RF Modules....................................................................................................1
Appendix 4....................................................................................................................................................................................1
Service Check List for X-631 Wheel Aligner.............................................................................................................................1
Appendix 5 Parts list................................................................................................................................................................1
Appendix 6 Calibration Operation Guide.................................................................................................................................1
Assembling the Calibration frame.............................................................................................................................................1
Adjusting the Calibration Shaft Level........................................................................................................................................3
Calibration ................................................................................................................................................................................5
To Confirm ................................................................................................................................................................................8

LAUNCH X-631 Wheel Aligner Product Service Manual Preface
0-1
Preface
Target Reader
zThis maintenance manual is suitable for the following people: the first, the people who has some basic knowledge on
wheel alignment or people who has some automobile service and maintenance experience and is specializing in the
work of automobile maintenance; the second, people who is familiar to the wheel aligner products of Launch Tech Co.,
Ltd. and has wealthy maintenance experience.
Purpose
zThe purpose to compile this manual is to serve the after-sales technical personnel of Launch Tech Co., Ltd., especially
for the technical personnel who have contacted the wheel aligner products for no long time, this manual provides the
corresponding knowledge on wheel alignment and technical support to them.
zThe main content of this manual is to introduce the wheel aligner of model X-631. In this manual, author describes the
wheel aligner by using a lot of practical pictures and explication to avoid unnecessary misunderstanding caused by
over-many special items. At the same time, the manual provides the detailed specifications of each key device for
servicing personnel looking up. Thus, the after-sales service personnel can rapidly grasp the wheel alignment products
of Launch Tech Co., Ltd.
Required Knowledge
zIn order to understand and grasp the content of this manual more rapidly, the related personnel should have the
following basic knowledge:
Basic computer knowledge (including the aspects of hardware and software), can assemble and operate
computer skillfully.
Basically trained on wheel alignment measurement, having the basic knowledge on wheel alignment.
Having the basic knowledge on electrical/electronic technology, can do it by him-self.

LAUNCH X-631 Wheel Aligner Product Service Manual Summary
1-1
Summary
Function
zX-631 wheel aligner is the product newly developed by Launch Tech Co., Ltd., which adopts lots of new technology and
many advanced elements and devices, and has many new functions and higher measurement precision.
zThe X-631 Wheel Aligner can be used to measure the most wheel alignment parameters, such as front wheel toe-in,
front wheel camber, caster, Kingpin inclination, maximal steering angle (if equipped with electronic turntable), toe-out on
turns, rear wheel toe-in, rear wheel camber, thrust angle, wheelbase difference, tread difference, etc.
zDiversified measurement mode: common mode, special mode and fast test mode.
zThe wheel aligner can test the most of the vehicle models in the current market, even the vehicle with low chassis can
be tested by the wheel aligner via wheel clamp position-dropping devices or the position-dropping function the software
has. The maximum measurable wheelbase shouldn’t be less than 6m.
zComplete databank: wheel alignment data of over 20,000 vehicle models is stored in the system. User can also add
new data to the databank.
zNewly developed CCD signal processing technology, uninfluenced by the strong sunlight; Electronic level and
mechanical level function.
zThe wheel aligner equips with four individual probe rods, each of them contains two CCD cameras. All eight CCD
cameras are arranged as a rectangle via infrared beams.
zWireless transmission including RF transmission and Bluetooth transmission mode.
zLarge capacity (4000mAh) Lithium battery with low power consumption and dormancy mode of design. At least 500
times for charging and discharging.
zProfuse vehicle adjustment animation and HELP information; Language operating prompt function.
Specifications
Dimension: Cabinet: w x d x h: 1120×620×600 mm; Weight: 80kg, accessory 91kg; Working voltage: AC220V±10%;
Working frequency: 50/60Hz; Rated power: 0.4KW Fuse capacity: 10 A; Probe rod dimension:
729x312x179mm; Probe rod weight: 5.12 Kg
Wireless communication frequency: 433MHz /2.4GHz (RF)
Lithium battery specification: 7.4V 4400mAH
Ambient temperature: -10～40℃
Relative humidity: ≤85%
Outer magnetic field intensity: ≤400A/m
Lifter gradient: ≤1°
Item Range
Front total toe-in ±40.0º
Front toe-in ±20.0º
Front camber ±8.0º
Caster ±20º
Kingpin inclination ±20º
Rear total toe-in ±16.0º
Rear toe-in ±20.0º
Rear camber ±8.0º
Thrust angle ±5.0º

LAUNCH X-631 Wheel Aligner Product Service Manual Hardware
2-1
Hardware
Computer
Hardware Configuration
Computer host LENOVO
Main-board 946GZ
CPU 3.0GHz
RAM 256M
Hard disc 80G
CD-ROM N/A
Video display card Integrated
Sound card Integrated
Network interface card Integrated
Operating System
Operating system Windows XP
Computer (HP) Backboard Diagram
1 Serial port 2 7 Parallel socket
2 Voltage switching shift 8 Serial port 1
3 Power socket 9 Mouse socket
4 Sound box socket 10 Keyboard socket
5 USB Socket 11 NIC Socket
6 Monitor data socket
1
2
3
4
11
5
7
6
8
9
10

LAUNCH X-631 Wheel Aligner Product Service Manual Hardware
2-2
Wireless Emitter/Receiver Box
X-631 wheel aligner is equipped with two types of Wireless Emitter/Receiver Modules, 433M and 2.4G. For the Wireless
Emitter/Receiver boxes inside the cabinet, their antennas are different. There is a Wireless Emitter/Receiver Module in each
probe rod, 433M module is equipped with the antenna of spring shape, and 2.4G module’s antenna is a wire only.
433M MODULE ASSEMBLY 2.4G MODULE ASSEMBLY
WITH SAME BACK BOARDS
The Modules are Different Only
