LAUNCH TECH X-431 EuroPro5 User manual

Version: V1.00.000
Revised date: 06-016-2020
Statement: LAUNCH owns the complete intellectual property rights for the
software used by this product. For any reverse engineering or cracking actions
against the software, LAUNCH will block the use of this product and reserve the
right to pursue their legal liabilities.

LAUNCH X-431 EuroPro5 User Manual
i
Copyright Information
Copyright © 2020 by LAUNCH TECH CO., LTD. All rights reserved. No part of
this publication may be reproduced, stored in a retrieval system, or transmitted
in any form or by any means, electronic, mechanical, photocopying, recording or
otherwise, without the prior written permission of LAUNCH. The information
contained herein is designed only for the use of this unit. LAUNCH is not
responsible for any use of this information as applied to other units.
Neither LAUNCH nor its affiliates shall be liable to the purchaser of this unit or
third parties for damages, losses, costs, or expenses incurred by purchaser or
third parties as a result of: Accident, misuse, or abuse of this unit, or
unauthorized modifications, repairs, or alterations to this unit, or failure to strictly
comply with LAUNCH operating and maintenance instructions. LAUNCH shall
not be liable for any damages or problems arising from the use of any options or
any consumable products other than those designated as Original LAUNCH
Products or LAUNCH Approved Products by LAUNCH.
Trademark Information
LAUNCH is a registered trademark of LAUNCH TECH CO., LTD. (LAUNCH) in
China and other countries. All other LAUNCH trademarks, service marks,
domain names, logos, and company names referred to in this manual are either
trademarks, registered trademarks, service marks, domain names, logos,
company names of or are otherwise the property of LAUNCH or its affiliates. In
countries where any of the LAUNCH trademarks, service marks, domain names,
logos and company names are not registered, LAUNCH claims other rights
associated with unregistered trademarks, service marks, domain names, logos,
and company names. Other products or company names referred to in this
manual may be trademarks of their respective owners. You may not use any
trademark, service mark, domain name, logo, or company name of LAUNCH or
any third party without permission from the owner of the applicable trademark,
service mark, domain name, logo, or company name. You may contact LAUNCH
by visiting the website at www.cnlaunch.com, or writing to LAUNCH TECH CO.,
LTD., Launch Industrial Park, North of Wuhe Avenue, Banxuegang, Bantian,
Longgang, Shenzhen, Guangdong, P.R.China, to request written permission to
use Materials on this manual for purposes or for all other questions relating to
this manual.

LAUNCH X-431 EuroPro5 User Manual
ii
Important Safety Precautions
Important: To avoid personal injury, property damage, or accidental damage to
the product, read all of the information in this section before using the product.
yNever collide, throw, or puncture the tool, and avoid falling, extruding and
bending it.
yDo not insert foreign objects into or place heavy objects on your device.
Sensitive components inside might cause damage.
yDo not use the tool in exceptionally cold or hot, dusty, damp or dry
environments.
yIn places using the tool may cause interference or generate a potential risk,
please turn it off.
yThis tool is a sealed unit. There are no end-user serviceable parts inside. All
internal repairs must be done by an authorized repair facility or qualified
technician. If there is any inquiry, please contact the dealer.
yNever place the tool into apparatus with strong electromagnetic field.
yKeep the tool far away from magnetic devices because its radiations can
damage the screen and erase the data stored on the tool.
yDANGER: Do not attempt to replace the internal rechargeable lithium battery.
Contact the dealer for factory replacement.
yCAUTION: Please use the included battery and charger. Risk of explosion if
the battery is replaced with an incorrect type.
Precautions on Using this tool
Before using this tool, please read the following safety information carefully.
yAlways perform automotive testing in a safe environment.
yIf the VCI (Vehicle Communication Interface) device is not in use for a long
period of time, it is suggested to unplug the connector from vehicle’s DLC to
conserve battery power.
yWear an ANSI-approved eye shield when testing or repairing vehicles.
yThe vehicle shall be tested in a well-ventilated work area, as engines produce
various poisonous compounds (hydrocarbon, carbon monoxide, nitrogen
oxides, etc.)
yDo not connect or disconnect any test equipment while the ignition is on or

LAUNCH X-431 EuroPro5 User Manual
iii
the engine is running.
yPut blocks in front of the drive wheels and never leave the vehicle unattended
while testing.
yKeep the tool dry, clean, free from oil, water or grease. Use a mild detergent
on a clean cloth to clear the outside of the equipment as necessary.
yDo not drive the vehicle and operate the tool at the same time. Any distraction
may cause an accident.
yKeep clothing, hair, hands, tools, test equipment, etc. away from all moving or
hot engine parts.
yBefore starting the engine, put the gear lever in the Neutral position (for
manual transmission) or in the Park (for automatic transmission) position to
avoid injury.
yTo avoid damaging the tool or generating false data, please make sure the
vehicle battery is fully charged and the connection to the vehicle DLC (Data
Link Connector) is clear and secure.
yAutomotive batteries contain sulfuric acid that is harmful to skin. In operation,
direct contact with the automotive batteries should be avoided. Keep the
ignition sources away from the battery at all times.
Precautions on Operating Vehicle’s ECU
yDo not disconnect battery or any wiring cables in the vehicle when the ignition
switch is on, as this could avoid damage to the sensors or the ECU.
yDo not place any magnetic objects near the ECU. Disconnect the power
supply to the ECU before performing any welding operations on the vehicle.
yUse extreme caution when performing any operations near the ECU or
sensors. Ground yourself when you disassemble PROM, otherwise ECU and
sensors can be damaged by static electricity.
yWhen reconnecting the ECU harness connector, be sure it is attached firmly,
otherwise electronic elements, such as ICs inside the ECU, can be damaged.

LAUNCH X-431 EuroPro5 User Manual
iv
TABLE OF CONTENTS
1 INTRODUCTION.............................................................................................. 1
1.1 PRODUCT PROFILE .................................................................................... 1
1.2 FEATURES ................................................................................................. 1
1.3 COMPONENTS &CONTROLS....................................................................... 2
1.3.1 Display tablet .................................................................................... 2
1.3.2 VCI.................................................................................................... 4
1.4 TECHNICAL PARAMETERS .......................................................................... 5
1.4.1 Display tablet .................................................................................... 5
1.4.2 VCI.................................................................................................... 5
1.5 PACKAGE LIST ........................................................................................... 6
2 PREPARATIONS ............................................................................................. 7
2.1 CHARGING THE TABLET.............................................................................. 7
2.2 USING BATTERY......................................................................................... 7
2.3 POWER ON/OFF.......................................................................................... 7
2.3.1 Power on........................................................................................... 7
2.3.2 Power off........................................................................................... 7
2.4 TIPS ON FINGER OPERATIONS.................................................................... 8
2.5 SCREEN LAYOUT........................................................................................ 8
2.6 ADJUST BRIGHTNESS................................................................................. 8
2.7 CHANGE SYSTEM LANGUAGE ..................................................................... 9
2.8 SET STANDBY TIME.................................................................................... 9
3 NETWORK SETUP........................................................................................ 10
3.1 CONNECT TO A WI-FI NETWORK............................................................... 10
3.2 DISCONNECT FROM A WI-FI NETWORK..................................................... 10
4 INITIAL USE .................................................................................................. 11
4.1 DIAGNOSIS FLOWCHART .......................................................................... 11
4.2 REGISTER &UPDATE ............................................................................... 11
4.2.1 User registration ..............................................................................11

LAUNCH X-431 EuroPro5 User Manual
v
4.2.2 Job menu ........................................................................................ 14
4.2.3 Diagnostics toolbar ......................................................................... 16
4.3 CONNECTIONS ......................................................................................... 17
4.3.1 Preparation ..................................................................................... 17
4.3.2 DLC location ................................................................................... 17
4.3.3 Vehicle connection.......................................................................... 18
5 DIAGNOSIS ...................................................................................................20
5.1 INTELLIGENT DIAGNOSE ........................................................................... 20
5.2 LOCAL DIAGNOSE .................................................................................... 24
5.2.1 Health Report (Quick Test) ............................................................. 30
5.2.2 System Scan................................................................................... 34
5.2.3 System Selection............................................................................ 35
5.3 REMOTE DIAGNOSE ................................................................................. 47
5.3.1 Interface Layout.............................................................................. 47
5.3.2 Add Friends..................................................................................... 48
5.3.3 Start Instant Messaging .................................................................. 49
5.3.4 Launch Remote Diagnosis (Device-To-Device) ............................. 51
5.3.5 Launch Remote Diagnosis (Device-To-PC) ................................... 53
5.4 FEEDBACK ............................................................................................... 56
5.5 DIAGNOSTIC HISTORY .............................................................................. 58
6 SPECIAL (RESET) FUNCTION .................................................................... 60
6.1 OIL RESET SERVICE................................................................................. 61
6.2 ELECTRONIC PARKING BRAKE RESET....................................................... 61
6.3 STEERING ANGLE CALIBRATION ............................................................... 62
6.4 ABS BLEEDING ........................................................................................ 62
6.5 TIRE PRESSURE MONITOR SYSTEM RESET .............................................. 62
6.6 GEAR LEARNING ...................................................................................... 62
6.7 IMMO SERVICE ....................................................................................... 63
6.8 INJECTOR CODING ................................................................................... 63
6.9 BATTERY MAINTENANCE SYSTEM RESET ................................................. 64

LAUNCH X-431 EuroPro5 User Manual
vi
6.10 DIESEL PARTICULATE FILTER (DPF) REGENERATION ............................. 64
6.11 ELECTRONIC THROTTLE POSITION RESET .............................................. 65
6.12 GEARBOX MATCHING ............................................................................. 65
6.13 AFS (ADAPTIVE FRONT-LIGHTING SYSTEM)RESET ................................ 65
6.14 SUNROOF INITIALIZATION ....................................................................... 65
6.15 SUSPENSION CALIBRATION .................................................................... 65
7 SOFTWARE UPDATE ...................................................................................66
7.1 UPDATE DIAGNOSTIC SOFTWARE &APP.................................................. 66
7.2 SET FREQUENTLY USED SOFTWARE......................................................... 66
7.3 RENEW SUBSCRIPTION ............................................................................ 67
8 ADAS ............................................................................................................. 69
9 USER INFO....................................................................................................72
9.1 MY REPORT ............................................................................................. 72
9.2 VCI.......................................................................................................... 75
9.3 VCI MANAGEMENT................................................................................... 75
9.4 ACTIVATE VCI.......................................................................................... 75
9.5 FIRMWARE FIX ......................................................................................... 75
9.6 DATA STREAM SAMPLE ............................................................................ 75
9.7 MY ORDER .............................................................................................. 76
9.8 SUBSCRIPTION RENEWAL CARD ............................................................... 76
9.9 PROFILE .................................................................................................. 76
9.10 CHANGE PASSWORD .............................................................................. 76
9.11 SETTINGS .............................................................................................. 76
9.11.1 Units.............................................................................................. 77
9.11.2 Shop Information........................................................................... 77
9.11.3 Printer Set ..................................................................................... 77
9.11.4 Orientation .................................................................................... 81
9.11.5 Clear Cache .................................................................................. 81
9.11.6 About ............................................................................................. 81
9.11.7 Login/Logout ................................................................................. 81

LAUNCH X-431 EuroPro5 User Manual
vii
9.12 DIAGNOSTIC SOFTWARE CLEAR ............................................................. 81
10 VIDEOSCOPE .............................................................................................82
10.1 INTRODUCTION ...................................................................................... 82
10.2 CONNECTIONS &OPERATIONS............................................................... 82
11 SYNCHRONIZATION...................................................................................84
12 FAQ ..............................................................................................................86

LAUNCH X-431 EuroPro5 User Manual
1
1 Introduction
1.1 Product Profile
X-431 EuroPro5 is a powerful Android-based diagnostic tool. It inherits from
LAUNCH’s advanced diagnosing technology and is characterized by covering a
wide range of vehicles, featuring powerful functions, and providing precise test
result.
Through Bluetooth communication between the VCI (Vehicle Communication
Interface) and the display tablet, it achieves full car model and full system
vehicle trouble diagnosis, which include Reading DTCs, Clearing DTCs,
Reading Data Stream, Actuation Test and Special Functions. Moreover, taking
advantage of the mobile Internet, it also integrates One-click Update, Remote
Diagnosis and Maintenance Data, which helps to diagnose vehicle issues more
efficiently, and greatly increase customer’s retention and boost shop revenue.
1.2 Features
yIntelligent Diagnose: This module allows you to use the VIN information of the
currently identified vehicle to access its data (including vehicle information,
historical diagnostic records) from the cloud server to perform quick test.
yLocal Diagnose: Follow the on-screen prompts to start diagnostic session
step by step. Diagnosis functions include: Read DTCs, Clear DTCs, Read
Data Stream, Special Functions etc.
yRemote Diagnose: This option aims to help repair shops or technicians
launch instant messaging and remote diagnosis, making the repair job getting
fixed faster.
yReset: All kinds of common maintenance and reset items including Oil lamp
reset, DPF regeneration, ABS bleeding etc. can be done.
yOne-click Update: Lets you update your diagnostic software online.
yDiagnostic History: This function provides a quick access to the tested
vehicles and users can choose to view the test report or resume from the last
operation, without starting from scratch.
yFeedback: Enables you to submit the vehicle issue to us for analysis and
troubleshooting.

LAUNCH X-431 EuroPro5 User Manual
2
yVehicle Coverage: Quick dial to view the vehicle models that the tool covers.
yADAS calibration: Optional. This function needs to be activated before normal
use and only works with the LAUNCH-specific ADAS calibration tool.
1.3 Components & Controls
There are two main components to the diagnostic system:
yDisplay Tablet – the central processor and monitor for the system (See
Chapter “1.3.1”).
yVCI – the device for accessing vehicle data (See Chapter “1.3.2”).
1.3.1 Display tablet
The tablet acts as the central processing system, which is used to receive and
analyze the live vehicle data from the VCI device and then output the test result.
