LDR Alba 8/22 250 CM User manual

01204220
01204230
01204240
istruzioniperl'uso
operatinginstructions
Bedienungsanleitung
instruccionesdemanejo
moded'emploi
gebruiksaanwijzing
Alba8/22250CM
Alba18/36250CM
Alba30/55250CM
380WLED,RGBW
100/260V,DMX512
LucidellaRibaltasrl,ViaBerna14,46042CastelGoffredomnItaly.tel+390376771777‐fax+390376772140‐email[email protected]

ALBAprofiles250WRGBWLEDUser’sManual–2.0
LucidellaRibaltasrl,ViaBerna14,46042CastelGoffredo(MN)Italy
Tel.+390376771777–fax+390376772140–email[email protected]–webwww.ldr.it
1
ENGLISH–TABLEOFCONTENTS
INTRODUCTION
1.Importantsafetynorms.......................................................................................2
2.Boxcontents………………………………………………………………….……………………............ 3
3.Weightanddimensions.......................................................................................4
4.Mounting/replacingtheirisdiaphragm–notsupplied……………………….............4
5.Mounting/replacingthegobo‐holder–notsupplied………………………............…..4
6.Importantnoticebeforetheinstallation/installation………………………............…5
7.Wiring………………………………………………………………………………………………...........….5
8.Voltage………………………………………………………………………………………….........…….6
9.Frequency.............................................................................................................6
10.Mechanicaloperation…………………………………………………………………...........……..6
11.Connecttothepowersupply……………………………………………………............……….7
12.Localcontrolpanelandoperation………………………………………………............….....7
CONTROLANDOPERATION
13.Menu…………………................................................................................................7
13.1DMXormanual................................................................................................7
13.2DMXaddress....................................................................................................8
13.3Dimmerresolution...........................................................................................8
13.4LostDMXsignal................................................................................................8
13.5Strobe..............................................................................................................8
13.6Strobespeed....................................................................................................8
13.7Dimmingcurve.................................................................................................9
13.8Cutoffdimmingresponse................................................................................9
13.9Dimmingbehaviour........................................................................................9
13.10FanSetting....................................................................................................9
13.11LCDscreenillumination...............................................................................10
13.12RedColourIntensity.....................................................................................10
13.13GreenColourIntensity.................................................................................10
13.14BlueColourIntensity....................................................................................10
13.15WhiteColourIntensity.................................................................................10
13.16WhiteColourtemperatureselections(Col.T)………...................................…11
13.17Temperaturecontrol....................................................................................11
13.18Softwareversion..........................................................................................11
13.19PRO–BASICcontrol....................................................................................11
13.20Factorysettings............................................................................................11
13.21IDforREMOTO............................................................................................11
13.22Calibration...................................................................................................12
13.23Exithiddenmenu........................................................................................12
14.Sofwareupgrade‐Remotocontroldevice......................................................12
15.Cleaningandmaintenance...............................................................................12
16.Spareparts.......................................................................................................13
17.Warranty..........................................................................................................13
SUMMARYOFCONTROLSANDOPERATION
18.SummaryoftheALBAfunctions......................................................................14
19.DMXCharts......................................................................................................15
19.1DMXChart1...................................................................................................15
19.2DMXChart2...................................................................................................16
19.3DMXChart3...................................................................................................16
19.4DMXChart4...................................................................................................17


LDRConformityCertificate–CertificatodiConformità–Konformitätserklärung 19
Complaintform–Modulodireclamo–Reklamationsformular………………………….20
WEEEDirective–DirettivaRAEE–WEEERichtlinie……………………………………………21

ALBAprofiles250WRGBWLEDUser’sManual–2.0
LucidellaRibaltasrl,ViaBerna14,46042CastelGoffredo(MN)Italy
Tel.+390376771777–fax+390376772140–email[email protected]–webwww.ldr.it
2
ENGLISH

ThankyouforchoosingaqualityproductfromLucidellaRibaltasrl.Wetrustourproductsandservices
meetyourrequirements,butifnotpleasecontactusdirectlyusingtheattachedfeedbackformtohelp
usimproveourservicequality.
Thisproducthasbeenmanufacturedwithgreatcareandleftourfactoryinperfectconditions,butifit
hasbeendamagedintransportpleasecontactyourdealerinthefirstinstance.Afeedbackformis
appended.Ourwarrantycoversallmanufacturingandcomponentdefectsforoneyearfromthedate
youpurchasedtheproduct.
Ourproductsaredesignedfortheuseofprofessionaltechniciansandoperatorsonly,andthe
instructionsprovidedhereensureasafeandcorrectoperationofthisproduct.LucidellaRibaltasrlwill
notacceptanyresponsibilitywheredamagehasbeencausedtotheproductorpersonsthrough
improperuseoftheproductand/ornon‐compliancewiththeregulationsdescribedherein.

IMPORTANT:Readtheseuserinstructionsbeforeusingthislightingunit

Theinstructionsgivenhereensureasafeandcorrectusageofthisproduct.Auser’sfailuretocomply
withtheinstallation,operating,maintenanceandsafetyproceduresmentionedinthismanual,aswell
asthosegenerallyapplicabletothislightingequipment,maycausetheunitnottoperformasexpected.
LucidellaRibaltaacceptsnoliabilityfordirect,indirect,incidental,special,orconsequentialdamages
resultingfromthecustomer’sfailuretofollowtheinstallation,operating,maintenanceandsafety
proceduresinthismanualorthosegenerallyapplicabletolightingequipment.
Thelimitationextendstodamagesforpersonalinjury,propertydamage,lossofoperations,lossof
profits,lossofproductorlossoftime,whetherincurredinbythecustomer,thecustomer’semployees
orathirdparty.
Apartfromtheinstructionsgivenonthismanual,allrelevantsafetyandhealthstandardsofthe
appropriateDirectivesofthecountrywheretheunitwillbeinstalledmustbecompliedwith.


1. IMPORTANTSAFETYNORMS
Thisproductisaprofessionallightingfixture,namelyaprofilespot,fittedwithaLEDlightsource,
whichcanonlybeoperatedbyprofessionalstaff
Thisproductmustbefittedwithasecondaryfixingsystemsuchasasafetychainorbond.Should
thisnotbesuppliedasastandardaccessory,pleasemakesureyoubuyitseparatelyandinstallit
beforeusingtheproduct
Warning,highvoltageignition.Disconnecttheunitfrompowerbeforeservicing
Continuousmainspowerisrequiredforthisspotlightasaninternaldimmercontrolsthe
intensityviaDMXorlocalrotaryknob.
Useofaphasecontroldimmedmainssupplymaydamagetheinternalelectronics
Thisproductfeaturesfan‐assistedventilation.Makesureyoudonotcoverthefansorobstruct
theairflowatanytime
Makesureallfansareworkingcorrectlyatanyonetime.Shouldyoudetecteventheslightest
malfunction,switchtheluminaireoffandcarryoutthenecessaryservicing.Replacethefansif
necessary.
ThisproductisratedIP20andisthereforedesignedforinterioruseonly.Fordetailson
maximumambienttemperatureandtiltanglepleaserefertowhatindicatedontheproduct
labelorscreen‐printingonthesideofthelens‐tubeortherearoftheLED‐house

ALBAprofiles250WRGBWLEDUser’sManual–2.0
LucidellaRibaltasrl,ViaBerna14,46042CastelGoffredo(MN)Italy
Tel.+390376771777–fax+390376772140–email[email protected]–webwww.ldr.it
3
Repairingandreplacementofanycomponentofthisproductmustbecarriedoutexclusivelyby
professionalpersonnelinconformitywiththerelevantsafetyandhealthstandardsandonlywith
originalLucidellaRibaltasrlcomponents.
Replacementofanypartofthewiringsystemmustbecarriedoutexclusivelybyprofessional
personnelincompliancewiththeoriginalwiringdiagramandwithcomponentsidenticaltoor
compatiblewiththoseoriginallyfitted.
Installationofthisproductmustbeexclusivelycarriedoutbyprofessionalpersonnelin
compliancewiththesafetynormsinforceinthecountrywheretheproductisused




WARNING:DANGEROFELECTRICALSHOCK
DONOTOPERATEONLIVEEQUIPMENT
Disconnectpowerbeforeopeningthisfixturetoaccessitslightsourceorelectronics.
ThereplacementoftheLEDsourceoranyofitselectroniccomponentscanbecarriedout
exclusivelybyprofessionalpersonneluponLDR’swrittenauthorizationandonlywithoriginal
LucidellaRibaltasrlcomponents.Failuretoobtainthemanufacturer’sauthorizationtocarryout
thereplacement/repair,willimmediatelyinvalidatetheproduct’swarranty




WARNING:EYEDAMAGEHAZARD
Makesurethisfixtureisinstalledsoastoavoidprolongeddirectstaringatitsoperatinglightsource
(LED)fromadistanceoflessthan7m/23ft.




WARNING:FIREHAZARD
Neverlocatethisfixtureonanyflammablesurface.
Minimumdistanceofanypartofthebodyoftheluminairefromanyflammablesurfaceor
object:0,5m/20in
Minimumdistancefromlitsurface,pleaserefertoproductlabel
Makesurethemainspowersupplythefixturewillbeconnectedtoisprotectedbyasuitable
thermalmagneticcircuitbreaker



2. BOXCONTENTS
Uponopeningthepackaging,pleasemakesureitcontainsthefollowing:
lightingunitinthechosenmodel

ALBAprofiles250WRGBWLEDUser’sManual–2.0
LucidellaRibaltasrl,ViaBerna14,46042CastelGoffredo(MN)Italy
Tel.+390376771777–fax+390376772140–email[email protected]–webwww.ldr.it
4
metalcolourframe185x185mm,fitted
4metalshutter‐blades
2m/6.5ftmainspowercablefittedNeutrikPower‐Conblueconnector

Shouldoneormoreitemsmiss,wekindlyaskyoutocontactyourdealerimmediately.


3.WEIGHTANDDIMENSIONS

Alba8/22RGBW  Alba18/36LEDRGBW Alba30/55LEDRGBW
netweight:17,3kg  netweight:17,1kg  netweight:16,9kg
grossweight:19,7kg  grossweight:19kg  grossweight:18,3kg
packingdim.:110x41x41hcmpackingdim:100x41x41hcm packingdim.83x41x41hcm


4. MOUNTING/REPLACINGTHEIRISDIAPHRAGM–A20100707notsupplied
Anirisdiaphragm,availableasseparateaccessoryunderpart#A20100707,andfeaturing20leaves,
allowstosizethebeamfromamaximumapertureof68mm/2.67intoaminimumof5mm/0.19in.

Inordertofitorreplacetheirisdiaphragmplease:

UsingaPhillipsscrew‐driverremovethetwocross‐headscrewsfromthesidesoftheirisplate.
Slidethediaphragminthegatearea.
Tightenthescrews.


5. MOUNTING/REPLACINGTHEGOBO‐HOLDER–notsupplied
Albaprofilespotscanbefittedwithagoboholder–notsuppliedinstandarddeliverybutobtainableas
aseparateaccessory,fortheprojectionof:

A‐orB‐sizemetalgobospart#A20100807
A‐sizeglassgobo part#A20100807/A
B‐sizeglassgobo part#A20100807/B

Thegoboholdermustbeinsertedinthegateareainsteadoftheirisdiaphragm.Usageofboth
accessoriesatthesametimeisnotpossible.

Inordertofitorreplaceagoboholder,please:

Removetheirisdiaphragmiffitted(seeabove)
Slidethegobo‐holderinthegatearea–bentmetalwingsmustlooktotheLED‐house
Makesureitiscorrectlypositionedandapplypressuretotheplasticholderifneeded

CAUTION:themetalsurfaceofthegoboholderreachesveryhightemperaturesduring
operation.Makesuretheunitistotallycoldbeforeattemptingtoremoveit,protectyouhands
withglovesandavoidskindirectcontactwithitsmetalsurface




ALBAprofiles250WRGBWLEDUser’sManual–2.0
LucidellaRibaltasrl,ViaBerna14,46042CastelGoffredo(MN)Italy
Tel.+390376771777–fax+390376772140–email[email protected]–webwww.ldr.it
5
6. IMPORTANTNOTICEBEFORETHEINSTALLATION/INSTALLATION
Beforeinstallingthisfixturecheckitsweightontheproductlabelandtheweightofeachaccessoryyou
areaddingandmakesurethestructureyouareinstallingittowithstandsthetotalweight.

Themountingstirrupismountedontherearupperprofilesofthelens‐tubeandisdesignedtoallowthe
spotlighttobesuspendedfromaboveusingaC‐clampwithM12screworaDINplate

CAUTION
DONOTTURNTHELUMINAIREUPSIDE‐DOWNBUTALWAYSTURNTHESTIRRUP
IFYOUNEEDTOMOUNTITONASTANDORBRACKET

AsthestirrupdoesnotrotatearoundtheLED‐house,incaseyouneedtomounttheluminaireona
standorbracketyouwillhavetoremovethestirrupfromitsoriginalpositionandre‐mountitonthe
setsofholes(2xoneachside)positionedontherearlowerprofilesofthelenstube,asfollows.
PositiontheAlbaonasolidandstablework‐bench
WiththeaidofaM5cross‐headscrew‐driverslackenandremoveallthe4screwsholdingthe
stirruptothelens‐tube
Liftthestirrupandre‐positionthescrews
Removethe4xM5screwsfromthelowersetsofholes
Positionthestirruponthe4xholes,makingsureitsbendlookstothefrontoftheluminaire
Stronglytightenthe4screws

Ifnotsuppliedchooseasuitableclamporspigotandmakesureitiscorrectlyfixedandstrongly
tightenedtothestirrupaccordingtotheclamp’s/spigotmanufacturer’sinstructions
Ifnotsuppliedchooseasuitablesafetycableorbond.Clampittotheeyeletprovidedontheupper
rearpartoftheluminaire(seepictureherebelow),runittwicearoundthestirrupandthestructure
theluminaireishungtosoastobondthemtogetherandclosetheloop.



Whentiltingtheunitmakesuretheknobblockingthestirrupisstronglytightenedatanytimeand
thattheluminairecanholdthedesiredtiltangle


7. WIRING
Beforebeingconnectedtothemainspower,thisunitmayneedtobewiredwithasuitableplugifnot
alreadyinstalled.Makesuretheplugyouareusingisratedfortheproduct’spowerloadandit
conformstotherelevantEU/ULelectricalstandards.

MakesuretheplugyouarefittingwithstandstheLEDpowerload.
Thisfixturemustbegrounded
Toperformacorrectwiring,pleasenotethatthecoresinthismainsleadarecolour‐codedas
follows:

ALBAprofiles250WRGBWLEDUser’sManual–2.0
LucidellaRibaltasrl,ViaBerna14,46042CastelGoffredo(MN)Italy
Tel.+390376771777–fax+390376772140–email[email protected]–webwww.ldr.it
6
Ground:green+yellow–Neutral:blue‐Phase:brown

Incasethecoloursofthewiresdonotcorrespondtothecolouroftheconnectionpointsonyourplug,
pleaseproceedasfollows:
Thegreenorgreenandyellowwiremustbeconnectedtotheconnectionpointmarkedwiththe
letterEorwiththesymbol orcolouredingreenoringreen‐yellow
ThebluewiremustbeconnectedtotheconnectionpointmarkedwiththeletterNorcoloured
inblack
ThebrownwiremustbeconnectedtotheconnectionpointmarkedwiththeletterLorcoloured
inred
Beforeyoufinallypositionthisproductforuse,temporarilyconnectittoaproperlyfusedpower
supplytochecktheLEDworkscorrectly.


8.VOLTAGE
Beforeoperatingthisunitpleaserefertotheproductlabelmountedatthebackoftheluminaireto
checkyouareoperatingwiththecorrectvoltage.
TheAlbaprofilecanbeoperatedbetween90Vand260VandtheelectronicPSUinsidethefixturewill
automaticallyswitchtotheavailablevoltage.


9. FREQUENCY
FrequencyonthisproductisautomaticallyselectedbytheinnerelectronicPSU(50/60Hz)


10.MECHANICALOPERATION
Installation:thisfixtureisfittedwithamountingstirrupwhichisfactory‐setfortheinstallationfrom
above(suspended)usingaC‐clamporsimilar.Incaseyouneedtoinstallthefixtureonatripodor
support,(seeaboveforreference)
Note:thespotlight’slocationmustprovidesuitableventilationfortheLEDmodule.Forminimum
distancefromflammableandlitsurfacepleaserefertotheFIREHAZARDsectioninthismanualortothe
product’slabel
Focuscontrol:theALBArangeofLEDprofilespotsisavailablein3variablebeamanglemodels,
including8°to22°,18°to36°and30°to55°.Twolarge,easy‐to‐grabcontrolknobsontheright‐hand
sideofthelens‐tubecontrolthefocus.
Thevariablebeamismodifiedbyadjustingthefrontandrearzoomlensesinrelationtoeachother.
Thefrontlensdefinesthebeamspread,therearlensdefinesthefocusdegreeof‘softness’or‘hardness’
ofthebeamedgeorshutters.
Thebeamdistribution(peak/flat)isfixed.
Gentlyturntheknobsanti‐clockwiseuntilyouhavereachedthedesiredsize/focusofthebeamin
relationtothedistanceyouareprojectingat.
Turntheknobsclockwiseandtightlyclosethemsothatthelensesareheldinpositionatanytiltangle
Beam‐shaping:4shutterbladesareprovidedwitheachfixturetoshapethebeamgeometrically
Beam‐sizing:anaccessoryirisdiaphragm,part#A20100707canbepurchasedseparatelyandusedto
sizethebeamoftheALBA
Tiltcontrol:Thestirrupisfactory‐balancedandfittedwithapositivefrictionclampcontrolledbyauser‐
friendly,effectivelever‐knob.Turntheknobanticlockwisetoreleaseit,positiontheprofileatthe
desiredtiltangleandturntheknobclockwisetoholdthedesiredposition.

ALBAprofiles250WRGBWLEDUser’sManual–2.0
LucidellaRibaltasrl,ViaBerna14,46042CastelGoffredo(MN)Italy
Tel.+390376771777–fax+390376772140–email[email protected]–webwww.ldr.it
7
Pressthebuttonatthetopoftheleverandkeepitpressedwhileturningtheleverifyouneedtochange
itsposition.
Makesuretheleverisstronglytightenedatanytimeduringoperation


11.CONNECTTOTHEPOWERSUPPLY
Connecttheunittoacontinuousmainspowersource
Makesurethepowersupplyisprotectedbyasuitablethermalmagneticcircuitbreaker
Thisfixturemustbegrounded


12.LOCALCONTROLPANELANDOPERATION
OPERATION:LCDdisplayforDMXaddress,systemsetupandstatusdetails.
POWER:powerLEDstatusindicator,redcolor.ON=power
DMX:DMXLEDstatusindicator,greencolor.LEDOFF=DMXOFFandmanualcontrolactivated,LED
LEDON=DMXMODEactivatedwithnoDMXsignal,FLASHINGLED=receivingDMX
MENU:rotaryswitchselectortoselectandmodifytheoperationalmodes.Turnleftorrighttonavigate
throughthemenuandpresstoselectortoconfirm
DMXIN:inputDMXsignal(pin1=0,pin2=DATA‐,pin3=DATA+).
DMXOUT:LoopthroughDMXsignaloutput
POWERIN:Mainspowerinput
POWEROUT:Mainspoweroutput



13.MENU
ThereareseventeendifferentmenustocontrolthesettingsoftheALBARGBWLED.Therotaryselector
isusedtoadjustthesettingsandtonavigatethroughthemenu.Turnleftorrighttoselectthemenu
andpushtoaccessortoconfirmtheselecteddataorfunctions.Toexittheselectedmenuswithout
savingthedata,presstherotaryselectorforatleast1second.

13.1DMXORMANUAL(Mode)

SelecttheLEDcontrolmodebetweenDMX(factorysetting)andmanual.Tochangethecontrolmode
pressoncetherotaryselectoruntilanarrow()appearsonthemenu.Turntheselectortotherightor
thelefttoselectthedesiredmodeofoperationandpresstoconfirmyourselection.




TaptherotaryselectorandtheLCDscreenwilldisplaythemodestatusandthecurrentvalue:









M: Manual
XX % XXX
M: DMX
XX %
1 Mode
DMX
1 Mode
MANUAL
TAPTHEROTARY
SELECTORTODISPLAY
THEVALUE
TAPTHEROTARY
SELECTORTODISPLAY
THEVALUE
00%=LEDOFF
100%=LEDFULL
00%(000)=LEDOFF
100%(FFF)=LEDFULL
PRESSTOACTIVATE
THEMENU,AN
ARROWSHOULD
APPEAR
1 Mode
DMX
1 Mode
DMX 
1 Mode
MANUAL 
TURNTOSELECT
MANUALORDMX
ANDPRESSTO
CONFIRM

ALBAprofiles250WRGBWLEDUser’sManual–2.0
LucidellaRibaltasrl,ViaBerna14,46042CastelGoffredo(MN)Italy
Tel.+390376771777–fax+390376772140–email[email protected]–webwww.ldr.it
8
13.2 DMXADDRESS(Addr)

ItallowstoselecttheinitialDMXstartingaddresstoremotelycontroltheLEDfunctions.Tochangethe
initialDMXaddresspresstherotaryswitchuntilanarrowappears,thenturntochangetothedesired
DMXstartingaddress.Presstoconfirmyourselection.Factorysettingis001.




13.3DIMMERRESOLUTION(8/16b)
Thedimmingresolutioncanbecontrolledat8bitsfromoneDMXchannelto16bitswith2DMX
channels.
Factorysettingis8Bit.




13.4 LOSTDMXSIGNAL(DMXMem)
IncaseofsignalfailurethisfunctionallowstostoreinmemorythelastDMXvalue.FactorysettingisON
Threeoptionsareavailable:











13.5STROBE(Strobe)
Thisfunctionenablestheactivationofthestrobefunction.FactorysettingisDISABLE.




13.6 STROBESPEED(SetStr)
Itallowstosetthestrobespeed.Thismenuisnotactivewhenthestrobefunctionisdisabledorwhenit
isremotelycontrolledthroughDMX.FactorysettingisOPEN.










2 Addr
001
2 Addr
001 
2 Addr
### 
TURNTOASSIGNTHE
DMXADDRESSAND
PRESSTOCONFIRM
3 8/16b
8 BITS
PRESSTHEROTARY
SELECTORTO
ACTIVATE
3 8/16b
8 BITS 
3 8/16b
16 BITS 
TURNTOSELECT8OR
16BITSANDPRESSTO
CONFIRM
PRESSTOACTIVATE
THEMENU,AN
ARROWSHOULD
APPEAR
PRESSTOACTIVATE
THEMENU,AN
ARROWSHOULD
APPEAR
4 DMXMem
ON
5 Strobe
DISABLE
5 Strobe
DISABLE 
5 Strobe
ENABLE 
TURNTOENABLEOR
DISABLESTROBEAND
PRESSTOCONFIRM
PRESSTOACTIVATE
THEMENU,AN
ARROWSHOULD
APPEAR
PRESSTOACTIVATE
THEMENU,AN
ARROWSHOULD
APPEAR
6 SetStr
OPEN
WITHSTROBEENABLE
THELIGHTISSETTOON
6 SetStr
OPEN 
6 SetStr
SPEED # 
CHOOSETHESTROBE
SPEEDVALUEFROM
1(SLOW)TO10(FAST)
6 SetStr
CLOSE 
WITHSTROBEENABLE
THELIGHTISSETTO
OFF
LASTSCENEHOLD
4 DMXMem
ON 
4 DMXMem
OFF=80% 
DIMTHELEDTO80%OF
ITSMAXIMUMPOWER
4 DMXMem
OFF=00% 
DIMTHELEDTO0%

ALBAprofiles250WRGBWLEDUser’sManual–2.0
LucidellaRibaltasrl,ViaBerna14,46042CastelGoffredo(MN)Italy
Tel.+390376771777–fax+390376772140–email[e-mail]–webwww.ldr.it
9


13.7 DIMMINGCURVE(Curves)
ThisfunctionallowstoselectaresponsecurvefortheAlbaLED.Achoiceoftwocurvesisavailable:
SquareandLinear.FactorysettingisSQUARE.







13.8 CUTOFFDIMMINGRESPONSE(CutOff)
ThisfunctionallowstoselecttheLEDbehavioursimulatingatungstenorhalogenlampduringthe
dimmingcutoff.
FactorysettingisSLOW.








13.9DIMMINGBEHAVIOUR(Smooth)
ThisfunctionallowstosettheLEDdimmingresponse.FactorysettingisNORMAL.










13.10FANSETTING(Fan)
Thisfunctionallowstosetthefanresponse.Achoiceofthreemodesisavailable:Automatic,Silentor
Steady.WhenthefanisinAutomode,itsspeediscontrolledbythetemperatureoftheLED.When
Silentmodeischosenthefanrunsslowlytoreducethenoise.IfSteadyisactivatedthefanrunsat
constantspeed,halfwaybetweentheminimumandmaximumspeed.Inallcases,ifthetemperatureon
theLEDexceedsthemaximumadmittedvalue,theLEDisprotectedbyade‐ratingsecuritysystem,
whichlowersthelightoutputuntilthetemperaturegoesbacktosafelevels,whenfullpoweristhen
restoredautomatically.FactorysettingisAUTO.






PRESSTOACTIVATE
THEMENU,AN
ARROWSHOULD
APPEAR
7 Curves
SQUARE
PRESSTOACTIVATE
THEMENU,AN
ARROWSHOULD
APPEAR
8 CutOff
SLOW
PRESSTOACTIVATE
THEMENU,AN
ARROWSHOULD
APPEAR
9 Smooth
NORMAL
9 Smooth
FAST 
IMMEDIATEDIMMING
RESPONSE
SQUARETOINCREASE
VOLTAGERESPONSEAT
LOWERVALUE
7 Curves
SQUARE 
7 Curves
LINEAR 
LINEARDIMMING
CONTROL
SOFTLEDDIMMINGAT
SHUTDOWN
8 CutOff
SLOW 
8 CutOff
FAST 
DIRECTDIMMING
RESPONSEATSHUT
DOWN
FASTDIMMING
RESPONSE=150ms
9 Smooth
NORMAL 
9 Smooth
SLOW 
SLOWDIMMING
RESPONSE=300ms
PRESSTOACTIVATE
THEMENU,AN
ARROWSHOULD
APPEAR
10 Fan
AUTO
FANSPEEDIS
REGULATEDBYLED
TEMPERATURE
10 Fan
AUTO 
10 Fan
SILENT 
SLOWFANSPEEDTO
REDUCETHENOISE

ALBAprofiles250WRGBWLEDUser’sManual–2.0
LucidellaRibaltasrl,ViaBerna14,46042CastelGoffredo(MN)Italy
Tel.+390376771777–fax+390376772140–email[email protected]–webwww.ldr.it
10





13.11LCDSCREENILLUMINATION(BackL)
ThisfunctionallowstoturnofftheLCDbacklight,theLEDPOWERandLEDDMXafter1’30”fromlast
setting.FactorysettingisAutoOFF.









13.12REDCOLOURINTENSITY(Red)
Thisfunctionallowstosettheintensityoftheredcolourformanualmode.Selectingthemanualmode,
100%isautomaticallyset.




13.13GREENCOLOURINTENSITY(Green)
Thisfunctionallowstosettheintensityofthegreencolourformanualmode.Selectingthemanual
mode,100%isautomaticallyset.




13.14BLUECOLOURINTENSITY(Blue)
Thisfunctionallowstosettheintensityofbluecolourformanualmode.Selectingthemanualmode,
100%isautomaticallyset.





13.15 WHITECOLOURINTENSITY(White)
Thisfunctionallowstosettheintensityofwhitecolorformanualmode.Selectingthemanualmode,
100%isautomaticallyset.








11 BackL
AutoOFF
11 BackL
AutoOFF 
PRESSTOACTIVATE
THEMENU,AN
ARROWSHOULD
APPEAR
LCDBACKLIGHTOFF
AFTER1MINUTEAND
30SECONDS
10 Fan
STEADY 
CONSTANTFANSPEED
11 BackL
ON 
LCDBACKLIGHT
ALWAYSON
12 Red
###%
12 Red
###% 
12 Red
###% 
TURNTOSELECTTHE
REDINTENSITYAND
PRESSTOCONFIRM
PRESSTOACTIVATE
THEMENU,AN
ARROWSHOULD
APPEAR
13 Green
###%
13 Green
###% 
13 Green
###% 
TURNTOSELECTTHE
GREENINTENSITYAND
PRESSTOCONFIRM
PRESSTOACTIVATE
THEMENU,AN
ARROWSHOULD
APPEAR
14 Blue
###%
14 Blue
###% 
14 Blue
###% 
TURNTOSELECTTHE
BLUEINTENSITYAND
PRESSTOCONFIRM
PRESSTOACTIVATE
THEMENU,AN
ARROWSHOULD
APPEAR
15 White
###%
15 White
###% 
15 White
###% 
TURNTOSELECTTHE
WHITEINTENSITY
ANDPRESSTO
CONFIRM
PRESSTOACTIVATE
THEMENU,AN
ARROWSHOULD
APPEAR

ALBAprofiles250WRGBWLEDUser’sManual–2.0
LucidellaRibaltasrl,ViaBerna14,46042CastelGoffredo(MN)Italy
Tel.+390376771777–fax+390376772140–email[email protected]–webwww.ldr.it
11
13.16 WHITECOLOURTEMPERATURESELECTION(Col.T)
Thisfunctionallowstochoosebetween10differentwhitecolourtemperaturesformanualmode.This
functionoverwritesanysettingmadeontheRGBWmenus(seechapters13.12,13.13,13.14and13.15
ofthismanual).Selectingthemanualmode,100%isautomaticallyset.
PleaserefertoDMXChart19.1toseetheavailable10shadesofwhite.




13.17TEMPERATURECONTROL(Tled)
ThisfunctionallowstovisualizetheLEDtemperature.Factorysettingis°C.




13.18SOFTWAREVERSION(SwVer)
Thisfunctionallowstovisualizethesoftwareversion.
TherearealsofourdifferenthiddenmenuswhichallowtoselecttheadvancedsettingsoftheALBA
RGBWLED.ToactivatethisfunctionturnOFFandONtheAlbabypressingtherotaryswitchatpower
on.


13.19‐APROorBASICCONTROL(ProBasic)
ThePRO‐BASICcontrolisaspecialfunctionwhichallowstolimittheaccesstothecontrolmenu.Select
ProBasicwiththerotaryswitchandpresstoaccessthemenu.
Select:
PRO,toenableaccesstoallthefunctions
BASIC,tolimitaccesstofunctions13.1DMXorMANUALMODE,13.2DMXADDRESS,13.12
TemperatureControland13.13Softwareversion.
FactorysettingisPRO.





13.20‐B FACTORYSETTINGS(Reset)
TheRESETcontrolisaspecialfunctionwhichallowstoRESETtheproducttofactorysettings.





13.21‐C IDREMOTO(IDRem)
ItallowstoselecttheIDnumbertoconnectAlbatoRemotoforuploadanddownloadfirmware.To
changetheinitialIDpresstherotaryswitchuntilanarrowappears,thenturntochangetothedesired
IDnumber.Presstoconfirmyourselection.ItispossibletoselectanIDnumberfrom0to250.IfID
number=0remotecontrolisnotactive.Factorysettingis000.



16 Tled
##°C
16 Tled
##°C 
16 Tled
###°F 
TURNTOSELECT°C
OR°FANDPRESSTO
CONFIRM
PRESSTOACTIVATE
THEMENU,AN
ARROWSHOULD
APPEAR
Choose
ProBasic
MenuType
PRO 
MenuType
BASIC 
TURNTOSELECTPRO
ORBASICMENUAND
PRESSTOCONFIRM
PRESSTOACTIVATE
THEMENU,AN
ARROWSHOULD
APPEAR
Choose
Reset
Are You
SURE?
MenuType
BASIC 
PRESSTOCONFIRM
THERESET
PRESSTOACTIVATE
THEMENU
Choose
ID Rem
ID Rem
000 
ID Rem
### 
TURNTOASSIGNTHE
IDNUMBERAND
PRESSTOCONFIRM
PRESSTOACTIVATE
THEMENU,AN
ARROWSHOULD
APPEAR
16 Col.T
###%
16 Col.T
TunWht 
16 Col.T
####°K
TURNTOSELECT
THEWHITECOLOUR
TEMPERATUREAND
PRESSTOCONFIRM
PRESSTOACTIVATE
THEMENU,AN
ARROWSHOULD
APPEAR

ALBAprofiles250WRGBWLEDUser’sManual–2.0
LucidellaRibaltasrl,ViaBerna14,46042CastelGoffredo(MN)Italy
Tel.+390376771777–fax+390376772140–email[email protected]–webwww.ldr.it
12


13.22‐DCALIBRATION(SetMin)
Itallowstocalibratetheminimumoutputlevelofeachcolor.














13.23‐EEXITHIDDENMENU(Exit)
Itallowstoexitfromhiddenmenus.


14. SOFTWAREUPGRADE–REMOTOcontroldevice
Softwareupgradesareavailablefordownloadfromthereservedareaofourwebsite(password
requested).
Anaccessorygateway
REMOTO,‐GATEWAYFULLLINEDISPLAYREMOTERDMX512A‐ARTNET(part#20107072)
AllowstouploadthedesiredsoftwareversiononyourAlbas.Pleasecontactyourlocaldistributorfor
moredetailedinformation.


15.CLEANINGANDMAINTENANCE
Toensuremaximumperformanceoftheproduct,aregularmaintenanceserviceshouldbecarriedout.
Pleasemakesuretheproductiscoldanddisconnectedfrompowersupplywhendoingthis.

Generalmaintenance
*Cleanallreflectivepartssuchaslensesopeningtheproduct,ifnecessary.
*Checkthelensesandreplaceanyvisiblydamagedcomponent.
*Cleanairductsandfansinordertoallowaproperventilationactivityontheproduct.
*Checkinternalandexternalwiringandreplaceanycablewhichshouldbedamagedbyheator
mechanicalagents

Cleaningofopticalcomponents
LEDhouselenses:
OpenthelenscompartmentdoorbyremovingthetwoM4crossheadscrewsonthetopofthe
LEDhousetubeandslidethetopcoverfree
RemovethecondensorlensesassembledblockbyremovingthetwoM5crossheadscrews.
Cleanthelenseswithasoftclothandre‐position

Zoomlenses:
Choose
Set Min
Min Red
#### 
Min Red
#### 
TURNTOASSIGN
THECALIBRATION
VALUEANDPRESSTO
CONFIRM
PRESSTOACTIVATE
THEMENU.TURN
ANDPRESSTOSELECT
THECOLORTOSET
Min Blue
#### 
Min Green
#### 
Min White
#### 
Min Green
#### 
TURNTOASSIGN
THECALIBRATION
VALUEANDPRESSTO
CONFIRM
Min Blue
#### 
TURNTOASSIGN
THECALIBRATION
VALUEANDPRESSTO
CONFIRM
Min White
#### 
TURNTOASSIGN
THECALIBRATION
VALUEANDPRESSTO
CONFIRM

ALBAprofiles250WRGBWLEDUser’sManual–2.0
LucidellaRibaltasrl,ViaBerna14,46042CastelGoffredo(MN)Italy
Tel.+390376771777–fax+390376772140–email[email protected]–webwww.ldr.it
13
Slidethefrontzoompanelspositionedatthebottomofthelenstubeandcleanwithasoftcloth.

16. SPAREPARTS
Allcomponentsareavailableasspareparts.WestronglyrecommendyoualwaysuseoriginalLDR
componentsasspareparts.Pleaserefertoourtechnicalassistanceshouldyouneedtoorderand/or
replaceanypartoftheunit.

17. WARRANTY
Ourwarrantycoversallstructuralandmanufacturingdefectsforaperiodofoneyearfromthedateof
purchase.Incaseofcomplaint,westronglyrecommendthatinthefirstinstanceyoucontactthelocal
dealerwhosuppliedtheproducttoyou.Inallcases,pleaserefertotheserialnumberlocatedatthe
rearofthespotlight.







































ALBAprofiles250WRGBWLEDUser’sManual–2.0
LucidellaRibaltasrl,ViaBerna14,46042CastelGoffredo(MN)Italy
Tel.+390376771777–fax+390376772140–email[email protected]–webwww.ldr.it
14
18. SUMMARYOFCONTROLSANDFUNCTIONS

#FunctionDescriptionAvailableOptionsFactorySetting
1ModeMANUALorDMXcontrol MANUAL(controlledfromthe
rotaryswitchorslider);DMXDMX
2Addr
SelectstheDMXstarting
addressotherremotely
controlledfunctionsare
assignedinsequencetothe1st
assignedDMXaddress
From001to512001
38/16b8or16Bitsdimmingresolution8BITSon1channel;16BITSon2
channels8BITS
4DMXMemSetsthebehaviouroftheunitin
caseofDMXfailure
ON=lastdmxvalue;OFF=80%
fadeto80%after1,5Sec;
OFF=0%
ON
5StrobeActivatestheStrobefunctionENABLE;DISABLEDISABLE
6SetStr
SelectstheStrobespeed.This
menuisinactivewhenthe
Strobefunctionisdisabledor
whenisremotelycontrolled
throughDMX
OPEN=ON;SPEED=##(select
valuefrom01slowestto10
fastest);CLOSED=OFF
OPEN
7CurvesSelectsthedimmingcurveSQUARE;LINEARSQUARE
8CutOffReplicatesthehalogenlamp
dimmingbehaviouratcutoff
FAST=NOTACTIVE;
SLOW=ACTIVESLOW
#FunctionDescriptionAvailableOptionsFactorySetting
9SmoothDimmerresponse
NORMAL=150ms;SLOW=
300msFAST=Immediate
response
NORMAL
10FanFansetting
AUTO=regulatedbyTled;
SILENT=slowspeed,lownoise;
SILENT=constantspeed
AUTO
11BackLLCDscreenretro‐illumination ON;AutoOFF=LCDlightoffafter
1'30"AutoOff
12RedRedintensityformanualmodeFrom00%to100%‐‐‐
13GreenGreenintensityformanual
modeFrom00%to100%‐‐‐
14BlueBlueintensityformanualmodeFrom00%to100%‐‐‐
15WhiteWhiteintensityformanual
modeFrom00%to100%‐‐‐
16 Col.TWhitecolourtemperaturefor
manualmode
####°K=10availablecolour
temperaturepreset‐‐‐
17TledVisualizestheLEDtemperature SelecttheLEDTempin°CorF°°C
1SwVerVisualizesthesoftwareversion  ‐‐‐


ALBAprofiles250WRGBWLEDUser’sManual–2.0
LucidellaRibaltasrl,ViaBerna14,46042CastelGoffredo(MN)Italy
Tel.+390376771777–fax+390376772140–email[email protected]–webwww.ldr.it
15
SPECIALFUNCTIONS:toactivatethesefunctionspresstherotaryswitchatpoweron
#FunctionDescriptionAvailableOptionsFactorySetting
AProBasicSetstheavailablefromthe
controlmenu
PRO=Enablesaccesstoall
functions;BASIC=Limitthe
accessto:1Mode,2Addr,12
Tledand13SwVer
PRO
BRESETFactoryRESETReturntofactorysettings‐‐‐
CIDRem
SetstheIDnumbertoactivate
theRemotocontrolforupload
anddownloadfirmware
From000(noremotecontrol)to
250000
DSetMinSetstheminimumoutputlevel
ofeachcolour
Red:from000to9999‐‐‐
Green:from000to9999‐‐‐
Blue:from000to9999‐‐‐
White:from000to9999‐‐‐
EExitExitsfromhiddenmenus  ‐‐‐

19. DMXCHARTS

19.1DMXchart1(16bitdimmerandstrobedisabled)
ThisDMXchartreferstotheluminairesetwithdefaultparameters.
DMX
ChannelFunctionTypeof ControlEffectDecimalPercentage
1MasterDimmerProportionalAdjustsluminousoutputintensityfrom
0to100%0‐2550%‐100%
2SpareChannelStepNoeffect0‐ 2550%‐ 100%
3RedProportionalProportionalsettingoftheredcolour
from0to100%0‐2550%‐100%
4GreenProportionalProportionalsettingofthegreencolour
from0to100%0‐ 2550%‐ 100%
5BlueProportionalProportionalsettingofthebluecolour
from0to100%0‐2550%‐100%
6WhiteProportionalProportionalsettingofthewhitecolour
from0to100%0‐ 2550%‐ 100%
7TunableWhite
StepNoeffect0‐ 50%‐ 1%
StepWhite2700°K6‐302%‐11%
StepWhite3000°K31‐ 5512%‐ 21%
StepWhite3200°K56‐ 8022%‐ 31%
StepWhite3800°K81‐10532%‐ 41%
StepWhite4000°K106‐ 13042%‐ 51%
StepWhite4200°K131‐ 15552%‐ 61%
StepWhite4600°K156‐ 18062%‐ 70%
StepWhite5200°K181‐ 20571%‐ 80%
StepWhite5600°K206‐ 23081%‐ 90%
StepWhite5800°K231‐ 25591%‐100%
Luminaire:AlbaRGBWChartname:DMX512Functionschart1(Default)Revision:2.0Date:February2021

ALBAprofiles250WRGBWLEDUser’sManual–2.0
LucidellaRibaltasrl,ViaBerna14,46042CastelGoffredo(MN)Italy
Tel.+390376771777–fax+390376772140–email[email protected]–webwww.ldr.it
16
19.2DMXchart2(16bitdimmerenabled,strobedisabled)
ThisDMXchartreferstotheluminairesetwith16bitsresolution(Seechapter13.3ofthismanual).

DMX
ChannelFunctionTypeof ControlEffectDecimalPercentage
1MasterDimmerProportionalAdjustsluminousoutputintensityfrom
0to100%0‐2550%‐100%
2DimmerFineProportionalFinedimmercontrol16bit0‐ 2550%‐ 100%
3RedProportionalProportionalsettingoftheredcolour
from0to100%0‐2550%‐100%
4GreenProportionalProportionalsettingofthegreencolour
from0to100%0‐ 2550%‐ 100%
5BlueProportionalProportionalsettingofthebluecolour
from0to100%0‐2550%‐100%
6WhiteProportionalProportionalsettingofthewhitecolour
from0to100%0‐ 2550%‐ 100%
7TunableWhite
StepNoeffect0‐ 50%‐ 1%
StepWhite2700°K6‐302%‐11%
StepWhite3000°K31‐ 5512%‐ 21%
StepWhite3200°K56‐ 8022%‐ 31%
StepWhite3800°K81‐10532%‐ 41%
StepWhite4000°K106‐ 13042%‐ 51%
StepWhite4200°K131‐ 15552%‐ 61%
StepWhite4600°K156‐ 18062%‐ 70%
StepWhite5200°K181‐ 20571%‐ 80%
StepWhite5600°K206‐ 23081%‐ 90%
StepWhite5800°K231‐ 25591%‐100%
Luminaire:AlbaRGBWChartname:DMX512Functionschart2(16bits)Revision:2.0Date:February2021

19.3DMXchart3(Strobefunctionenabled,8bitdimmer)
ThisDMXchartreferstotheluminairesetwithstrobefunctionon(Seechapter13.5ofthismanual).
DMX
ChannelFunctionTypeof ControlEffectDecimalPercentage
1MasterDimmerProportionalAdjustsluminousoutputintensityfrom
0to100%0‐2550%‐100%
2SpareChannelStepNoeffect0‐ 2550%‐ 100%
3RedProportionalProportionalsettingoftheredcolour
from0to100%0‐2550%‐100%
4GreenProportionalProportionalsettingofthegreencolour
from0to100%0‐ 2550%‐ 100%
5BlueProportionalProportionalsettingofthebluecolour
from0to100%0‐2550%‐100%
6WhiteProportionalProportionalsettingofthewhitecolour
from0to100%0‐ 2550%‐ 100%
7TunableWhite
StepNoeffect0‐ 50%‐ 1%
StepWhite2700°K6‐302%‐11%
StepWhite3000°K31‐ 5512%‐ 21%
StepWhite3200°K56‐ 8022%‐ 31%
StepWhite3800°K81‐10532%‐ 41%

ALBAprofiles250WRGBWLEDUser’sManual–2.0
LucidellaRibaltasrl,ViaBerna14,46042CastelGoffredo(MN)Italy
Tel.+390376771777–fax+390376772140–email[email protected]–webwww.ldr.it
17
StepWhite4000°K106‐ 13042%‐ 51%
StepWhite4200°K131‐ 15552%‐ 61%
StepWhite4600°K156‐ 18062%‐ 70%
StepWhite5200°K181‐ 20571%‐ 80%
StepWhite5600°K206‐ 23081%‐ 90%
StepWhite5800°K231‐ 25591%‐100%
8Strobe
StepOpen0‐ 200%‐ 8%
StepStrobespeed1(minimumfrequency)21‐ 409%‐ 15%
StepStrobespeed241‐ 6016%‐ 24%
StepStrobespeed361‐ 8025%‐ 31%
StepStrobespeed481‐ 10032%‐ 39%
StepStrobespeed5101‐ 12040%‐ 47%
StepStrobespeed6121‐ 14048%‐ 55%
StepStrobespeed7141‐ 16056%‐ 63%
StepStrobespeed8161‐ 18064%‐ 71%
StepStrobespeed9181‐ 20072%‐ 78%
StepStrobespeed10(maximumfrequency)201‐ 22079%‐ 86%
StepClosed221‐ 25587%‐ 100%
Luminaire:AlbaRGBWChartname:DMX512Functionschart3(Strobe)Revision:2.0Date:February2021


19.4DMXchart4(16bitsdimmerandStrobeenabled)
ThisDMXchartreferstotheprojectorsetwith16bitsresolutionandstrobefunctionactive(Seechapter
13.3and13.5ofthisuserguide).
DMX
ChannelFunctionTypeof ControlEffectDecimalPercentage
1MasterDimmerProportionalAdjustsluminousoutputintensityfrom
0to100%0‐2550%‐100%
2DimmerFineProportionalFinedimmercontrol16bit0‐ 2550%‐ 100%
3RedProportionalProportionalsettingoftheredcolour
from0to100%0‐2550%‐100%
4GreenProportionalProportionalsettingofthegreencolour
from0to100%0‐ 2550%‐ 100%
5BlueProportionalProportionalsettingofthebluecolour
from0to100%0‐2550%‐100%
6WhiteProportionalProportionalsettingofthewhitecolour
from0to100%0‐ 2550%‐ 100%
7TunableWhite
StepNoeffect0‐ 50%‐ 1%
StepWhite2700°K6‐302%‐11%
StepWhite3000°K31‐ 5512%‐ 21%
StepWhite3200°K56‐ 8022%‐ 31%
StepWhite3800°K81‐10532%‐ 41%
StepWhite4000°K106‐ 13042%‐ 51%
StepWhite4200°K131‐ 15552%‐ 61%
StepWhite4600°K156‐ 18062%‐ 70%
StepWhite5200°K181‐ 20571%‐ 80%
StepWhite5600°K206‐ 23081%‐ 90%
StepWhite5800°K231‐ 25591%‐100%
8StrobeStepOpen0‐ 200%‐ 8%

ALBAprofiles250WRGBWLEDUser’sManual–2.0
LucidellaRibaltasrl,ViaBerna14,46042CastelGoffredo(MN)Italy
Tel.+390376771777–fax+390376772140–email[email protected]–webwww.ldr.it
18
StepStrobespeed1(minimumfrequency)21‐ 409%‐ 15%
StepStrobespeed241‐ 6016%‐ 24%
StepStrobespeed361‐ 8025%‐ 31%
StepStrobespeed481‐ 10032%‐ 39%
StepStrobespeed5101‐ 12040%‐ 47%
StepStrobespeed6121‐ 14048%‐ 55%
StepStrobespeed7141‐ 16056%‐ 63%
StepStrobespeed8161‐ 18064%‐ 71%
StepStrobespeed9181‐ 20072%‐ 78%
StepStrobespeed10(maximumfrequency)201‐ 22079%‐ 86%
StepClosed221‐ 25587%‐ 100%
Luminaire:AlbaRGBWChartname:DMX512Functionschart4(16bits+
Strobe)Revision:2.0Date:February2021

LucidellaRibaltasrlreservestherighttomodifythepresentdocumentwithoutpriornotice.

Luci della Ribalta srl, Via Berna 14, 46042 Castel Goffredo MN Italy - tel [phone] - web www.ldr.it - email [e-mail]
VAT registration # It01815640204 - REA MN 198438 - Authorized Exporter #
IT/015/MN/11
LDR
luci ribaltadellaluci ribaltadella
INoi sottoscritti dichiariamo, sotto la nostra completa responsabilità, che i prodotti:
EN
D
F
ES
Standard models and all their variants
I
EN
D
F
ES
We hereby declare, under our own responsibility, that the products listed here below:
Wir beglaubigen, daß die nachfolgend genannten Produkte:
Nous certifions, sous notre responsabilitè, que le produits mentionnès ci-dessous:
Los que subscriben declaran, bajo su responsabilidad, que los productos aquì listados:
sono conformi alle seguenti normative:
conform to to the following standards:
entsprechen den nachfolgen angeführten Normen:
sont conformes aux normes ci-après:
cumplen de hecho con las siguientes normas:
ALBA 8/22, ALBA 18/36, ALBA 30/55, ALBA F, ALBA PC LED LUMINAIRES
EN IEC 55015:2019
EN 61547: 2020
EN 61000-3-2: 2019
EN 61000-3-3: 2013+A1: 2019
EN IEC 60598-1: 2021+A11: 2022
EN IEC 60598-2-17: 2018
EN 62493: 2015
EN 63000: 2018
LIMITS AND METHODS OF MEASUREMENTS OF RADIO DISTURBANCE CHARACTERISTICS OF ELECTRICAL
LIGHTING AND SIMILAR EQUIPMENT
EQUIPMENT FOR GENERAL LIGHTING PURPOSES. EMC IMMUNITY REQUIREMENTS
ELECTROMAGNETIC COMPATIBILITY (EMC). PARTS 3-2: LIMITS -LIMITS FOR HARMONIC CURRENT EMISSIONS
(EQUIPMENT INPUT CURRENT UP TO AND INCLUDING 16 A PER PHASE) CLASS C
ELECTROMAGNETIC COMPATIBILITY (EMC) - PART 3-3: LIMITS - LIMITATION OF VOLTAGE CHANGES,
VOLTAGE FLUCTUATIONS AND FLICKER IN PUBLIC LOW-VOLTAGE SUPPLY SYSTEMS,
FOR EQUIPMENT WITH RATED CURRENT ≤ 16 A PER PHASE AND NOT SUBJECT TO CONDITIONAL
CONNECTION
SPECIFIES GENERAL REQUIREMENTS FOR LUMINAIRES. INCORPORATING ELECTRIC LIGHT SOURCES FOR
OPERATIONS FROM SUPPLY VOLTAGES UP TO 1 000 V.
SPECIFIES REQUIREMENTS FOR STAGES, TELEVISION, FILM AND PHOTGRAPHIC STUDIO LUMINAIRES (
INCLUDING SPOT AND FLOODLIGHTING PROJECTORS) FOR USE OUTDOORS AND INDOORS, WITH ELECTRIC
LIGHT SOURCES ON SUPPLY VOLTAGES NOT EXCEEDING 1 000 V.
APPLIES TO THE ASSESSMENT OF LIGHTING EQUIPMENT RELATED TO HUMAN EXPOSURE TO
ELECTROMAGNETIC FIELD
TECHNICAL DOCUMENTATION FOR ASSESSMENT OF ELECTRICAL AND ELECTRONIC PRODUCTS WITH
RESPECT TO THE RESTRICTION OF HAZARDOUS SUBSTANCES
FOLLOWING THE EU DIRECTIVE OF THE EUROPEAN PARLAMENT AND THE COUNCIL OF THE EUROPEAN UNION:
- 2014/30/EU ELECTROMAGNETIC COMPATIBILITY (EMC)
- 2014/35/EU LOW VOLTAGE (LVD)
- 2011/65/UE
- 2009/125/CE
- 2019/2020 + 2021/341
Lisa Papi
luci ribaltadella
srl
Via berna 14, 46042 castel goffredo mn italy
tel [phone] fax [phone] email [email protected]
web www.ldr.it P.iva 01815640204 c.iso IT01815640204
In faith, Lisa Papi, President
CERTIFICATO DI CONFORMITA’ - CERTIFICATE OF CONFORMITY
KONFORMITAETSERKLAREUNG - CERTIFICAT DE CONFORMITE’
CERTIFICADO DE CONFORMIDAD
