LEGRAND EW Series Guide

12:00
PROJECT
LOCATION/TYPE
www.wattstopper.com
800.879.8585
SENSORS
EW Outdoor Motion Sensor
• Sensorscanbemountedonwalls,eaves,or
ceilingsforinstallationconvenience
• 270°coverage
• Frontrotatesforeasycoverageadjustment
• Precision,double-shottoolingwithinter-
nalsilicongasketspreventswateranddust
contamination
• Notoolsneededtoaimoradjustlampholders
forspeedierinstallation
• Optionaloverride-ONtoturnlightsonremotely
forthelengthofthetimedelay
• ON/OFFcontrolbasedondaylightlevelsvia
adjustablelightlevelsetting
WattStopper’sEWoutdoormotionsensorsprovide
occupancybasedcontrolofoutdoorlighting.
Raintightandratedfor-40°Fto130°F,EWsensors
performreliablyinallweatherconditions.
Lampholders
Operation
EWsensorsoperateatlinevoltageandcanbe
mountedontoastandard,outdoorjunctionbox.
UtilizingadvancedPIRtechnology,thesensors
detectthedifferencebetweeninfraredenergy
inmotionandthebackgroundspacetoturn
lightingonwhenapersonorvehicleentersthe
coveragearea.Aftertheareaisvacatedandthe
timedelayelapses,lightingautomaticallyturns
off.TheEW’sdualPIRdetectorsandthreelevel
lensincreasethedetectiondensityaswellasthe
accuracyofmotiondetection.
Description
Product
Overview
Features • Zerocrossingcircuitryreducesstressonthe
relayandresultsinincreasedsensorlife
• ASICenhancesreliabilityandhelpstoeliminate
falsetriggers
• PulseCountProcessingeliminatesfalsetrig-
gersandprovideRFIandEMIimmunity
• PatentedVoltageDropProtection
• Solidstatedigitalmicroprocessoroffers
increasedreliability
• User-adjustabletimedelayfrom12secondsto
16minutes
Forsituationswhenacompleteoutdoorsensor
packageisdesired,theEWFmodelsinclude
durable,polycarbonatelampholdersthataccept
PAR20or38lamps.TheyareUVandimpact
resistantandareimpervioustoweathering.The
EWFfeaturesauniquedual-adjustmentaiming
systemthatallowsthelampstobeangledand
lockedintopositionwithouttheuseoftools.The
lampholders’uniquesiliconsealsallowthemto
beaimedabovehorizontalindamporwetareas.
Applications
Applicationsforcommercialsettingsinclude
walkways,parkinglots,docklightingand
warehouses.Typicalusesoutsideahomeinclude
garages,backyards,entrancewaysandporches.
Adjustable light level
and time delay settings
Optional model with
lampholders Isolated relay enables
interface with security
systems or other loads
270 degree field of view
Rated for use in
temperature range
of -40° to 130°F
Weatherproof and raintight for
reliable performance
Outdoor

12:00
www.wattstopper.com | 800.879.8585
SENSORS
Wiring,
Mounting &
Installation
Coverage
Pub.No.7206rev.10/2009
Ordering
Information
Specifications • 120VACor277VACoperation
• UL773Aratedraintight;UL1571ratedforwet
locations
• Operatingtemperature:-40°to130°F(-40to
54°C)
• Adjustablelightlevelof0.5to200footcandles
(5.4-2,152.8lux)
• IsolatedrelaywithN/OandN/Coutputs;rated
for1Amp@30VDC/VAC(EW-200)
• 1/2”threadednipplefitsstandardNEMA
weatherprooffixturefitting
• LampholdersusePAR20or38lamps,upto
150Weachlamp*
• CompatiblewithallelectronicballastsandPL
lampballastsystems
• Sensordimensions:6.7”x3.2”x2.2”
(170mmx80mmx55mm)
• ULandcULlisted
• Fiveyearwarranty
EW-200-120-W
EW-200-120-G
EW-200-277-W
EWF-205-120-W
Arcticwhite
Arch.grey
Arcticwhite
Arcticwhite
CatalogNo. Color VoltageLoadRating CoverageFeatures
*Thesensorswithlampholdersmayuseupto300wattsforlampseventhoughtheyhavea0-1000wattloadrating
120VAC;60Hz
277VAC;60Hz
120VAC;60Hz
0-1000wattballast,
tungsten
0-1000wattballast
0-1000*wattballast,
tungsten
Isolatedrelay
Isolatedrelay
Lampholders
270°
270°
270°
Wiring Diagram Mounting Diagrams
Installation & Positioning Sensor with Lampholders
Ceiling/eavemounting
Wallorpolemounting
EWF.wiring
Neutral
Red (Load)
Black Black
White White
WhiteWhite
BlackBlack
Switch
(optional)
Line
Lighting
Load
Sensor
Load
90°
9.5ft
(3m)
25ft
(8m)
52.5ft
(16m)
8ft
(2.4m)
9.5ft
(3m)
25ft
(8m)
52.5ft
(16m)
8ft
(2.4m)
EW-200Series
Coverage(270°)
Coverage Pattern
Outdoor
