LEGRAND 1A User manual

Cat. No(s): 0 775 80
Technical data sheet: F02377EN/01 Updated: 16/01/2018 Created: 02/11/2016
1/2
1A wireless charger for furniture
128, av. du Maréchal-de-Lattre-de-Tassigny - 87045 LIMOGES Cedex
Tel: [phone] - Fax: [phone]
www.legrand.com
3. MOUNTING (continued)
4. DIMENSIONS (mm)
5. TECHNICAL CHARACTERISTICS
 5.1 Mechanical characteristics
Impact resistance: IK 08
Resistance to ingress of solid bodies and liquids:
• IP44 for upper part installed on furniture
 5.2 Material characteristics
ABS
Halogen free
UV resistant
Self-extinguishing:
850° C / 30 s for parts made of insulating materials holding live parts in
place
650° C / 30 s for other insulating components
1. USE
Can be used to fully charge or top up a smartphone equipped with an
induction receiver.
Designed for mounting horizontally on furniture.
Suitable for use in passageways or transit areas, oces, on kitchen
worktops.
Does not interfere with other wireless transmissions (Zigbee, TNT, GSM,
4G, etc).
Product supplied complete with accessory for xing on furniture, micro-
USB/USB type A cord (2.5 m) + 2 adhesive bases + 2 cable ties, mobile
charger.
Supplied with identication sticker for use in public spaces.
Supplied with 4 plugs: 2P Euro / BS / US / Australia-China-Argentina.
2. RANGE
3. MOUNTING
OK
Ø A
B
C
Description Cat. No.
Wireless charger equipped with an 8 cm2induction type
antenna for quick pairing with the smartphone.
Surface with non-slip coating to hold the terminal safely
in place during charging.
0 775 80
0 775 80
USB Type A x 2
x 2
22 mm min.
50 mm max.
Ø 80 mm
W
I
R
E
L
E
S
S
C
H
A
R
G
I
N
G
S
T
A
T
I
O
N
W
I
R
E
L
E
S
S
C
H
A
R
G
I
N
G
S
T
A
T
I
O
N
EURO
BS
US
Australia
China
Argentina
Ø A B C
87 18 15.3
LED
2,5 m

2/2
Cat. No(s): 0 775 80
1A wireless charger for furniture
Technical data sheet: F02377EN/01 Updated: 16/01/2018 Created: 02/11/2016
WPC QI
5. TECHNICAL CHARACTERISTICS (continued)
 5.3 Electrical characteristics
 5.4 Average charging time for a smartphone equipped with an
induction receiver
- 80 % charge < 2 hrs
- 100 0% charge < 2 hrs 45
 5.5 Climate characteristics
Storage temperature: - 20°C to + 70°C
Operating temperature: 0°C to + 45°C
6. STANDARDS AND APPROVALS
EN 62479
ICNIRP
Nominal input voltage 110 - 230 V~
Nominal output voltage 5 V
Frequency 50 - 60 Hz
Maximum input current 150 mA (ac)
Maximum output current 1000 mA (dc)
Standby consumption < 0.07 W
Energy eciency > 85 %
Protection class II - Low voltage
