LEGRAND ecotap Wallcharger Duo User manual

Wallcharger Duo
Manual

2. www.ecotap.nl 13-07-23
TABLE OF CONTENTS
1 Introduction 3
2 General 3
2.1 Warranty 3
2.2 Symbols used in this manual and charging system 3
3 Device description 4
3.1 Application 4
3.2 Accessories 4
3.3 Safety device 4
4 Safety 4
4.1 Safety regulations 4
5 Mandatory checks before initial use 5
6 User / installation manual 5
6.1 Required power cable 5
6.2 Wall mounting 5
6.3 Overview of the charging station 8
7 Maintenance 8
8 Transportation and storage 9
9 Malfunction explanation 9
10 Operation and functioning of the charging station 9
11 Technical specifications 9
12 Contact details supplier 11
13 EG conformity statement 12

3. www.ecotap.nl 13-07-23
1. INTRODUCTION
Thank you very much for selecting the Ecotap® wall-mounted charging station. This manual describes the Wall Charging
Station equipped with two type 2 sockets of 22kW each.
This manual contains important information for the proper and safe installation and use of this charging station.
The charging station is designed to supply power to vehicles equipped with a modus 3 charging system in accordance with
DIN EN 50556, IEC 61851-1 (edition2.0), VDE- AR-N 4102 appendix: 2012-04. Together with the vehicle and system, the
charging station will select the best option for charging the vehicle quickly and safely.
The entire charging station complies with the 2014/35/EU directive concerning harmonization of legislation concerning
electric material within certain voltage limits (rearrangement of all previously published versions).
This manual provides insight into how the charging station can be safely installed and used. This manual has been compiled
to ensure maximum functionality and lifespan of the charging station.
This manual has been drawn up with great care. However, if anything remains unclear, please contact your supplier before
installing the charging station.
Proper functioning of the charging station can only be guaranteed if the installation is performed by an authorized or certified
installer/technician. If the charging station is not installed by a certified installer, this may have consequences for the device’s
warranty.
Please read this manual carefully before installing and using the charging station.
Store this manual with the charging station to ensure the instructions and safety regulations are always available.
© Copyright
No part of this publication may be copied, reproduced or saved in a retrieval system without Ecotap® B.V.’s prior written
consent.
This is an English translation of the original manual, which was written in Dutch.
2. GENERAL
2.1 Warranty
The Ecotap® B.V. General Delivery Conditions apply.
Ecotap® B.V. cannot be held responsible for injury or damages as a result of the charging station being changed, damaged,
converted, or expanded with other components, or if it is not being used in accordance with the specified instructions and
conditions.
2.2 Symbols used in this manual and on the charging system
Symbol Meaning
Pay attention! Important instruction
Electrical hazard
For maintenance: first disconnect the installation from its power supply and test it to make sure there is
no voltage left, before engaging in any maintenance activities
Wear special gloves.

4. www.ecotap.nl 13-07-23
Disconnect the electrical installation from its power supply
Reading this manual is mandatory
3. DEVICE DESCRIPTION
3.1 Application
The Wallcharger DUO has been specially designed for wall-mounting.
3.2 Accessories
The following accessories are not included in the scope of delivery:
• Tools
3.3 Safety device
• Fuse holder
• 12 Volt control voltage
• Components at least IP2
• Strain relief
• 3,7 mm steel casing
• IP54 lowest waterproof category of the type 2 sockets
4. SAFETY
Read the following safety regulations carefully before you install and use the charging station.
4.1 Safety regulations
Before you install the charging station, you must make sure the location is safe for all bystanders. NEVER allow children onto
this worksite. Never allow ANYONE who has nothing to do with the work onto the worksite.
- Never be distracted while you are performing the work.
- Make sure you maintain a healthy posture at all times while doing the work.
- Do not leave any tools or charging station components unattended.
- Make sure any tools you are using are clean and dry.
- Make sure that the charging station, tools and components will stay dry
when it is raining.
Make sure that there is no danger of anyone tripping over objects or paving while you are digging the
hole for the foundation.
Make sure to wear good, suitable gloves for any special actions throughout the entire installation and
connection process.

5. www.ecotap.nl 13-07-23
Always check any measuring instruments you will be using to disconnect the installation from its power
supply before you use them, checking them several times to make sure they are working properly.
5. MANDATORY CHECKS BEFORE INITIAL USE
The following checks are mandatory before commissioning the recharging column. NEVER use the
recharging column if one or more checks show that power supply or stability of the recharging column
does not satisfactory. Check the insulation resistance between the phases according to NEN1010
provision 61.3.3.
Always perform the checks below before applying voltage to the Wall Charger Duo.
√All work described below is in compliance with NEN 3140.
√Check whether the wires have been connected to the terminals in the right order.
√Check whether the cores have been properly tightened, 3.5 to 5 Nm.
√Check whether the grounding connector has been connected to the coded terminal and whether it has been connected
to the grounding electrode or the supplied grounding device. The entire grounding system must comply with the
NEN1010/EU/35.
√Check whether the cable thickness of the power cable matches the fused current rating.
√Check whether the charging station is tightly and properly secured.
√Check whether the station is sufficiently waterproof.
√Keep the immediate environment of the work area free from obstacles.
6. USER / INSTALLATION MANUAL
6.1 Required power cable
The power cable has to be connected to a separate power group.
When using a machine this should be C characteristic or equal, the height of the current rating depends on the length and the
available power on site.
PLEASE NOTE: the charging station requires only 1 power cable. Please take into account the cables and
groups will be under full load for several hours.
Cabling will have to be implemented in accordance with current standards, such as NEN1010.
Exceptions to the NEN1010 standard are:
• Cable thickness deviates
• Grounding spread resistor < 30 Ohm.
• Installation resistor < 1 Ohm.
• Voltage drop max. 2%.
6.2 Wall mounting
It is best to mount the charging station at a height of +/- 85 centimetres measured from the bottom
of the charging station.
We recommend mounting the charging station to the wall at a height of +/- 85 centimetres, measured from the bottom of
the charging station.

6. www.ecotap.nl 13-07-23
When mounting the charging station, you should take into account the strength of the wall. The wall should be completely
closed, without any holes or openings. If these are present, they must first be filled.
Use the right fastening screws to firmly secure the charging station to the wall and use all four fastening holes. Mounting
material is included.
First, remove the cover with a torx screw at the bottom. The charging station can now be mounted to the wall.
Insert the cable into the charging station and fasten it with a cable gland. (The cable can be inserted either through the back
or through the existing cable gland entry at the bottom of the station. If you do not use the cable gland entry, please make
sure it is properly sealed.)
Connect the cores to the relevant components as indicated.
Connect the phase wires* to the indicated L1 / L2 / L3 connecting terminals.
Connect the Null wire to the indicated Null terminal.
Connect the shield/ground wire to the indicated Ground terminal.
When fastening the cores, use the correct screwdriver and tighten to 3.5Nm to 5Nm. Do not forget to attach the loose
ground wire from the charging station to the cover.

7. www.ecotap.nl 13-07-23
734
120
12

8. www.ecotap.nl 13-07-23
6.3 Overview of the charging station
Antenna
Network meter
Controller module
12V transformer
Residual current circuit
breaker
Contactor
3-phase fuse element 32A GG
Socket type 2 IEC 61815-1VDE-
AR-E2623-2-2
Transparent plastic cover made of
Lexan to be removed only by
Ecotap B.V. or by an authorised
person
7. MAINTENANCE
Always disconnect the charging station from the power supply and read the manual before
performing maintenance or fixing a malfunction.
Only products approved by the supplier can be used to repair or replace components. Repairs and replacements should
always be carried out by a certified specialist.
Maintenance should always comply with and be carried out in accordance with NEN3140 and NEN50110 low voltage EU
regulations.
Check the charging station for leaks.
Check the connection of the main power cable and ensure a tight connection of at least 3.5 to 5 Nm.
Treat any damage to the charging station with anti-corrosion paint.

9. www.ecotap.nl 13-07-23
8. TRANSPORTATION AND STORAGE
When transporting the wall charger, avoid damaging the paintwork. This could cause rusting. Store the wall charger preferably
in a dry, non-damp room.
9. MALFUNCTION EXPLANATION
If the charging station is not functioning properly, please contact the back office provider or contact another certified
mechanic with the right measuring and testing equipment with car simulation.
CAUTION ! All work and adjustments to the wall charger must comply with NEN10 as a minimum.
10. OPERATION AND FUNCTIONING OF THE CHARGING SYSTEM
This charge point can be operated with a charge card.
The wall-mounted charging station DUO version “Charging With Registration / LMR” still needs to be registered.
Once registration is complete, the charging station can be used with any electric transport charging card (EV charging card) or
other suitable cards, mobile and key holders.
Operation:
Start/stop procedure by holding the charging card or charging key in front of the scan point. You will hear 1 sound signal
and the lamp will flash green.For the type 2 socket, the plug inserted is locked in the charging socket. Then the charge point
communicates with the vehicle and the BackOffice system. Once all safety and payment requirements have been checked,
the maximum allowable charging current is transmitted.The charging procedure is now automatically switched on and the
lamp lights blue. (Other options possible)When stopping the charging procedure, hold the pass in front of the scan point. You
will hear 2 beeps. The lamp starts flashing green and the plug is unlocked. You can now remove it.
11. TECHNISCHE SPECIFICATIES
General characteristics
Reference number 55161800 / 55161100 / 55161600 / 55321800 /
55321100 / 55321600 / 55081800 / 55081100 /
55081600 / 55081602 / 55081102 / 55081801 /
55320014 / 55320013 / 55320012 / 55321604
Reference number (Eichrecht) 55451800 / 55451100 / 55451600
Reference number (FR) 55483702 / 55483703
Dimension H x W x D (mm) 800 x 220 x 200
Casing material Steel 2,2 mm
Standard colour Body: Ral 6018 / Cover: Ral 9016 for 55161800 /
55321800 / 55451800 / 55081800 / 55081801 /
55320014 / 55320013 / 55160012
Body: Ral 7011 / Cover: Ral 9016 for 55161100 / 55321100
/ 55451100 / 55483702 / 55081100 / 55483703 /
55081102
Body: Ral 9016 / Cover: Ral 9016 for 55161600 /
55321600 / 55451600 / 55081600 / 55081602 /
55321604
Steel treatment Anti-corrosion (KTL) and powder coating

10. www.ecotap.nl 13-07-23
Weight (kg) 21kg for 55451800 / 55451100 / 55451600 / 55483702
/ 55081800 / 55081100 / 55081600 / 55483703 /
55081602 / 55081102 / 55081801
25kg for 55161800 / 55161100 / 55161600 / 55321800
/ 55321100 / 55321600 / 55320014 / 55320013 /
55160012 / 55321604
Number of charging points 2
Socket Type 2, Type 2 + type E/F for 55483702 / 55483703
Cable Type 2
Electrical characteristics
Power output per socket 0 to 22 kW for 55483702 / 55483703 / 55451800
/ 55451100 / 55451600 / 55081800 / 55081801
/ 55081100 / 55081101 / 55081600 / 55081601
/ 55321800 / 55321801 / 55321100 / 55321101 /
55321600 / 55321601 / 55320013 / 55320014
0 to 11 kW for 55161800 / 55161801 / 55161100 / 55161101
/ 55161600 / 55161601 / 55160011 / 55160012
Operating voltage (Ue) / Current rates (In A, In C) Single-phase cabling, phase + N 230V~ from 0 to 32A
(determined at 20°C)
Three-phase cabling, 3 phases + N 400V~ from 0 to 32A
(determined at 20°C)
Impulse voltage (Uimp) 4kV
Insulation voltage (Ui) 230V single-phase, 500V three-phase
Frequency (fn) 50Hz/60Hz
Rated voltage 1 phase + N: 230V - 3 phases + N: 400V
Voltage tolerance (V) regardless of vehicle requirements 195V - 265V
Integrated protection system on charging station Fuse type gG 63A
Integrated protection system per charge point MCB 40A curve C
RCD 40A 30mA Type B
Conditional short-circuit 6000A IEC/EN 60898-1
10kA IEC/EN 60947-2
Allowable thermal stress in Short Circuit 16 000 A²s
Connection to the mains Phase/Neutral, rigid cable, 2.5 to 25 mm², screw terminals
H07 V R/U Earth, rigid cable, 2.5 to 25mm², screw terminals
H07 V R/U
Type of load Mode 3 charging terminal equipped with a locking system
for Mode 3
Vehicle connection Mode 3 connector socket
(55451800 / 55451100 / 55451600 / 55483702 /
55081800 / 55081100 / 55081600 / 55483703 /
55081602 / 55081102 / 55081801)
Type 2 3P+N (single-phase compatible) with pilots compliant
with IEC 62191-1 and IEC 62196-2.
Use only a manufacturer-approved plug with silver-plated
contacts.
Use of extension and adapter prohibited. .
Vehicle connection Mode 2 connector socket
(55483702 / 55483703)
Type E/F domestic 2P+E (16A-250V) depending on the local
regulation
Use of extension and adapter prohibited.

11. www.ecotap.nl 13-07-23
Vehicle connection Mode 3 attache cable connector
(55161800 / 55161100 / 55161600 / 55321800 /
55321100 / 55321600 / 55320014 / 55320013 /
55160012 / 55321604)
Type 2 3P+N (single-phase compatible) with pilots compliant
with IEC 62191-1 and IEC 62196-2.
Use of extension and adapter prohibited.
55161800 / 55161100 / 55161600: 4m curl 3x16A
55160012: 4m straight 3x16A
55321604: 4m straight 3x32A
55321800 / 55321100 / 55321600 / 55320014 /
55320013: 8m straight 3x32A
AC meters MID certified, Class B according to EN 50470-1, -3
Back office protocol OCPP 1.6 Json
Positioning GPS
Connectivity Ethernet RJ45 connector for 55451800 / 55451100 / 55451600
/ 55483703 / 55081602 / 55081102 / 55081801 /
55320014 / 55160012
Environment
Operating temperature -25°C / +50°C
Storage temperature -25°C / + 80°C
Relative humidity 0 to 90% without condensation
Protection rating IP 54 (IEC 60529), IK 10 (EN 62262) Plugged in or not
Noise level < 40 dBA at 1m
Product IEC 61851-1, IEC TS 61439-7 (AEVCS)
Installation Interior or exterior, limited access zone, intended for use by
ordinary persons (DBO), assembly in cabinet (wall mounted),
Pollution Degree 3, TNS, TT,compatible earthing system.
In the event of an IT earthing system, this can be changed
locally by adding an isolation transformer.
Electrical safety Class 1 IEC 61140
Electromagnetic compatibility
European standards Low Voltage Directive 2014 / 35EU / EMC Directive: 2014 /
30 / EU
Radio technology type GSM 2G/3G/4G, GPRS, RFID
Suitable charging cards Mifare, Ntag and iCODE SLI cards (more info)
Ecotap® B.V. reserves the right to change the above technical data without prior notice due to ongoing, innovative
developments of the charging station. Moreover, the technical data may vary from country to country.
12. CONTACT DETAILS SUPPLIER
Ecotap® B.V.
Kruisbroeksestraat 23
5281RV Boxtel – The Netherlands
Tel.: [phone]
E-mail: inf[email protected]

12. www.ecotap.nl 13-07-23
13. EU DECLARATION OF CONFORMITY CE 2020
Directive 2014/35 / EU, Annex II p. 96/369, EMC 2014/30 / EU
Ecotap® B.V. hereby declares.
Established:
Kruisbroeksestraat 23, 5281 RV Boxtel
The charging station mentioned below complies with the requirements of the guidelines and standards mentioned below.
Type: Ecotap® Wallcharger Duo First release: 2018
EU directives used:
- Low voltage directive 2014/35 / EU
- EMC Directive 2014/30 / EU
Boxtel, Juni 2018
Ir. P.F.A. van der Putten (Technical Director)

Ecotap B.V.
Kruisbroeksestraat 23
5281 RV Boxtel
The Netherlands
[phone]
[e-mail]
www.ecotap.nl
