5. CONNECTION
5.1 Terminals
Terminal capacity: 2 ×1
2 ×1.5 mm²
1 ×2.5 mm²
1 ×4 mm²
Recommended screwdriver size: 4 mm flat blade
Recommended stripping length: 12 mm
Recommended terminal tightening torque: 0.5Nm
5.2 Circuit diagrams
mm²
2 824 17/17m
K8/H251-HK
87045 Limoges Cedex
Telephone: [phone] - Fax:[phone]
Technical data sheet:F02862EN/01 Updated: 11/11/2021 Created: 20/08/2019
GalionTM
Black touch plate push+DND/CUR sign
Cat. No(s): 2 824 17/17m
K8/H251-HK K8/H252-HK
2 824 17/17m
K8/H251-HK K8/H252-HK
1. USE
To ring and to display the messages: "Do not disturb" or "Please
clean up my room".
(Supplied with M3.5 screws for BS boxes. Flush mounting or Surface
mounting.)
3. PREPARATION
3.1 General preparation
2. RANGE
Designation
Black touch plate
push+DND/CUR
sign
Black touch plate
push+DND/CUR
+wait sign
3 A - 220VAC
3 A - 220VAC
2 824 17/17m
Cat. No. Weight
(g)
Characteristics
1/2
- flushing
mounting
box:
- surface
mounting
box:
CONTENTS
1. Use.......................................1
2. Range...................................1
3. Pr ep aration .. ....... ....... .. ....... 1
4. Overall dimensions.................1/2
5. Connection...........................2
6. Technical characteristics......2
7. Cleaning.................................2
8. Conformity - Approvals..................2
1
2
4. OVERALL DIMENSIONS
Profile Size: 86×88 mm
Distance of installation hole: 60.3 mm
Minimum depth of the box>35 mm
K8/H251-HK
K8/H252-HK
99.8
99.8
86
88
28.5
9.2

Technical data sheet:F02862EN/01 Updated: 11 Created: /11/2021 20/08/2019
2/2
6. TECHNICAL CHARACTERISTICS
6.1 Material characteristics
Plate: Poly(methyl methacrylate)
Frame: Polycarbonate
Base: Polycarbonate
Self-extinguishing:
+ 850° C / 30 s for insulating parts holding live parts in place
+ 650° C / 30 s for other parts made of insulating materials
6.2 Electrical characteristics
6.3 Climatic characteristics
Storage temperatures: -10℃ to +70℃
Operating temperatures: -5℃ to +50℃
6.4 Mechanical characteristics
Impact test: Ik04
Protection against liquids: Ip20
7. CLEANING
Surface cleaning with a soft, slightly damp cloth.
Do not use: acetone, tar remover, trichloroethylene
8. CONFORMITY - APPROVALS
Voltage: 230V~
Current: 3A
Frequency: 50/60Hz
Conform to IEC 60669-2-1.
Black touch plate push+DND/CUR sign
GalionTM
Cat. No(s): 2 824 17/17m
K8/H251-HK K8/H252-HK
K8/H252-HK
