LEGRAND HPM 700TM User manual

TRAILING EDGE DIMMER
Instruction Manual
Cat.No. 700TM/1000TM
1
2
Operation
Technical Characteristics
Please read carefully: Read through these instructions completely before commencing installation. Retain for future use. This product should be
installed by a licensed electrical contractor or similarly qualified person.
■ Turn the knob clockwise to increase brightness.
■ Turn the knob anticlockwise to decrease brightness.
■ Over-temperature protection: If the dimmer gets too hot (due to overloading or insufficient de-rating), the lamp brightness is
automatically reduced. After the dimmer cools down, normal operation is automatically resumed. Be sure to correct the cause of
the high temperature.
■ Nominal Input Voltage: 230-240 V a.c. 50 Hz
■ Operating Temperature: 0°C to 50°C
■ Terminal Capacity: 2 x 1.5 mm²
Notes:
1. Not compatible with all dimmable LEDs. Bench test prior to installation. Dimming range may be reduced with some models.
2. When used in ambient temperatures greater than 25°C, the dimmer must be de-rated by 10% for every increase of 5°C.
WARNING - DO NOT MEGGER THIS PRODUCT
Load Type Minimum Load
Maximum Load
700TM 1000TM
Dimmable LED Lamps
●DLI70 Downlights 1 Lamp 28 Lamps 40 Lamps
●AZA+, DLI90, DLI110, DLI125 & DLI150 Downlights
●R80 Dimmable Globe 1 Lamp 21 Lamps 30 Lamps
●DLS, Dalia, Azalea & Freesia Downlights
●Luna Panel Lights
●Calla Step Lights
●Zinnia Starlights
1 Lamp 14 Lamps 20 Lamps
●All other models (See Note1) 1 Lamp 14 Lamps or 700VA
(whichever is smaller)
20 Lamps or 1000VA
(whichever is smaller)
●Incandescent Lamps
●Halogen Lamps
●Electronic Transformers
10VA 700VA 1000VA
●Fluorescent Lamps
●Wirewound Transformers
●Fan Motors
Not suitable

■ This product must be installed and used as per these instructions.
■ This product must be installed by a licensed electrician or similarly qualified person.
■ V90-rated building wire must be used when wiring this product.
■ This product must only be used with the loads specified. Other load types should only be used when written confirmation is given by
Legrand.
■ This product has been designed to filter out interference from off-peak electricity signalling. The level of such signalling will vary
from installation to installation and interference is still possible in rare cases.
■Severe electromagnetic interference from other products may cause malfunction of this product.
■ This product should only be cleaned with a damp cloth. Cleaning agents and solvents should not be used.
■ This product contains no serviceable parts and no attempt should be made to repair this product. If the product is faulty it should be
discarded.
■ Legrand reserves the right to modify the specifications of this product at any time.
5Important Information
2
3Wiring
Setting Minimum Brightness
■ The minimum brightness can be set before the knob is put into place.
■ When the unit is wired and mounted as required, switch on the power.
■ Turn the potentiometer carefully by hand until the desired minimum
brightness is obtained.
■ Insert the knob so that the “tongue” on the knob lines up with the slot
on the dimmer.
■ Once inserted, the knob cannot be turned any further anticlockwise.
Warranty
Legrand Australia Pty Ltd will honour all statutory guarantees that you as a consumer
are entitled to rely upon under the Australian and New Zealand Consumer Laws against
a manufacturer, including a guarantee that this product is of acceptable quality.
To make a claim under any statutory guarantee you should rst contact the supplier, or
retailer from whom you purchased this product.
Customer Service
For all Customer Service and Technical Support
please call Monday to Friday during business hours.
LE12607AA 02/2021
Legrand Australia
1300 369 777
www.hpm.com.au
Legrand New Zealand
0800 476 009
www.hpm.co.nz
ABN: 31 000 102 661
One-way wiring diagram
770M
Two-way wiring diagram
770M
770M
Slot
Tongue
Paper
