  9. LEGRAND Arteor 5 722 69 User manual

LEGRAND Arteor 5 722 69 User manual

Cat. No(s) : 5 722 69 - 5 727 69
Fiche technique : S000099963EN/00 Mise à jour : Créée : 28/11/2017
1/2
128, av. du Maréchal-de-Lattre-de-Tassigny - 87045 LIMOGES Cedex
Tel : 0 (+33) 5 55 06 87 87 Fax : 0 (+33) 5 55 06 88 88
www.legrand.com
ArteorTM Media Hub
4. CONNECTION
Cat. Nos A B C D
5 722 69 - 5 727 69 84 79,5 22,4 9,45
x 4
5 722 69 White Arteor BS Media Hub light
5 727 69 Magnesium Arteor BS Média Hub light
HDMI cable
(not supplied)
Max: 10 m
USB Mini-A
cable (not
supplied)
Max: 2 m
HDMI cable
(not supplied)
Power supply
110/220 V line
50-60 Hz
USB Type A
cable/stick (not
supplied)
or
5. MOUNTING
Ø 68 mm
3. DIMENSIONS (mm)
The media hub light is used to:
- Watch films from a PC or camcorder on TV: HDMI socket
- Watch the content of a USB stick on TV: 1 A USB Data socket
- Charge devices: 2 A USB socket
- Listen to music on a smartphone, tablet, etc on TV: Bluetooth function
Inputs: 2 USB chargers including 1 USB Data, HDMI, Bluetooth audio
Output: HDMI and USB Data
Specially adapted for remotely locating the connections at the back
of the television or monitor when it is mounted on a wall or item of
furniture.
Product to be ush-mounted on a wooden board.
1. USE
2. RANGE
To be flush-mounted on a board with a cut-out made by a hole saw,
diameter 68 mm.
Flush-mounting depth:
- without right-angled HDMI adaptor min: 85 mm
- with right-angled HDMI adaptor min: 40 mm
- USB: 55 mm
Depending on which USB and HDMI cables are used, the minimum
flush-mounting depth can be increased in order to ensure the correct
bend radii.
HDMI output
Input power
5 VDC/3.5 A
HDMI output
A
B
CD
2/2
Fiche technique : S000099963EN/00 Mise à jour : Créée : 28/11/2017
Cat. No(s) : 5 722 69 - 5 727 69
ArteorTM Media Hub
7. COMPLIANCE - APPROVALS
Legrand
SIMPLIFIED EU DECLARATION OF CONFORMITY
Hereby
declare that the radio equipment type
5 722 69
is in compliance with Directive 2014/53/EU.
The full text of the UE declaration of conformity
is avaible at the following internet address :
www.legrand.com
Legrand
SIMPLIFIED EU DECLARATION OF CONFORMITY
Hereby
declare that the radio equipment type
5 727 69
is in compliance with Directive 2014/53/EU.
The full text of the UE declaration of conformity
is avaible at the following internet address :
www.legrand.com
CEC-compatible
If your TV set is CEC-compatible, it can be controlled by the Media Hub.
If you connect an HDMI device or press the button, the Media Hub can
switch on the TV automatically.
Refer to the TV manual to nd out how to enable/disable the CEC
function.
If your TV set is not CEC-compatible, use the remote control to select
the HDMI input.
Depending on the set manufacturer, HDMI CEC has dierent trade
names:
Samsung: AnyNet
LG: Simplink
Sony: Bravia Link
Etc
6. TECHNICAL CHARACTERISTICS
6.1 Electrical characteristics
Mains input 110 V-220 V
Power consumption in active mode 18.5 W maximum
Power consumption in sleep mode 0.2 W maximum
Bluetooth version 3 (supports A2DP Audio
Profile)
10 m
USB charger socket 2 x 1.5 A
HDMI version 1.3a 10 m
CEC-compatible One-touch play
6.2 Mechanical characteristics
Front
- 1 HDMI version 1.3 input connector
- 1 USB 2.0 - 1.5 A input connector for recharging and Data connection
with TV
- 1 USB 1.5 A dedicated charging connector
- 1 push-button for HDMI and Bluetooth selection
- 1 Bluetooth activation LED
Rear
- 1 HDMI type socket for TV connection
- 1 mini-USB type socket for TV connection
- 1 x 5 V - 3.5 A power supply socket
6.3 Compatibility:
-HDMI HDCP
- Bluetooth AD2P audio
- CEC
Supplied with external 90-230 V/5 V power supply.
Not supplied with HDMI and USB cables to connect the product to the
television.
The HDMI cable to be supplied should be a maximum of 10 m long.
0 517 32 1 m
0 517 33 2 m
0 517 34 3 m
0 517 27 5 m
0 517 20 10 m
The USB cable to be supplied should be the following type: mini-A USB
plug/type-A USB plug - Maximum length 2 m (without using a booster).
Right-angled HDMI adaptor Cat. No. 0 517 37 can be used for ease of
connecting at the rear.
6.4 Climate characteristics
Operating temperature: +5°C to +45°C
