LEGRAND Valena Life User manual

Cat. Nos: 7 521 84 - 7 522 84 - 7 523 84
Technical data sheet: F02601EN/00 Updated: 04/09/2018 Created: 27/02/2018
1/2
ValenaTM Life
Connected switch without neutral
with dimmer option
128, av. du Maréchal-de-Lattre-de-Tassigny - 87045 LIMOGES Cedex
Tél.: 0 ([phone] - Fax: 0 ([phone]
www.legrand.com
5. OPERATION
6. TECHNICAL CHARACTERISTICS
6.1 Mechanical characteristics
Protection against impacts: IK 04
Protection against solid bodies/liquids: IP 41 assembled product
 6.2 Material characteristics
Plate: ABS
Sub-plate: PC
Rocker plate: ABS
Colours: White RAL 9003
Ivory RAL 1013
Mechanism casing: PC
Support: PC grey RAL 7016 + metal
Halogen-free
UV resistant
Self-extinguishing:
+ 850° C / 30 s for insulating parts holding live parts in place.
+ 650° C / 30 s for the other insulating components.
1. USE
Connected switch without neutral with dimmer option, configured by
default as ON/OFF.
Can be combined with one or more wireless lighting controls (dimmer
mode can be activated from the Home + Control app).
For local or remote control of your lighting.
Supplied with an active power compensator (Cat. No. 0 401 49), mandatory
to ensure optimum operation with commercially-available lamps. One
compensator per lighting circuit is sufficient.
Easy to install in place of a standard switch in a box 40 mm deep
(minimum).
Claw and/or screw fixing.
3. DIMENSIONS (mm)
4. CONNEXION
Type de bornes : à vis
Capacité des bornes : 2 x 1,5 mm2ou 1 x 2,5 mm2
Longueur de dénudage : 8 mm
Tournevis plat : 3 mm
2. RANGE
A B C D
86 86 45 11.5
A
B C D
Description White Ivory Aluminium
Product for use in conjunction with the starter pack.
With LED indicator (conguration) and RESET button
(hidden) used to return to factory settings.
Supplied complete with claws and site protection
cover.
7 521 84 7 522 84 7 523 84
LED indicator:
- useful during installation
- blue LED illumination function can be activated from the
Home + Control app.
ON when pressed at the bottom and dimming when held
down until released.
OFF when pressed at the top and dimming when held
down until released.
0 401 49
7 521 84
ON
OFF
RESET button
used to return to factory settings.

2/2
Cat. Nos: 7 521 84 - 7 522 84 - 7 523 84
ValenaTM Life
Connected switch without neutral
with dimmer option
Technical data sheet: F02601EN/00 Updated: 04/09/2018 Created: 27/02/2018
Caution: Always test before using special cleaning products.
6. TECHNICAL CHARACTERISTICS (continued)
6.3 Electrical characteristics
Voltage: 110/230 V~
Power: 300 W
Frequency: 50/60 Hz
Standby consumption: 0.2 W
(*)
Or 10 lamps max. For comfortable lighting, we recommend using bulbs of the
same type and make.
(**)The ferromagnetic transformers must be charged to more than 60% of their
power. When calculating the permissible power, the ferromagnetic transformer
efficiency must be taken into account. A load must be connected before
programming and using the product.
Zigbee technology 2.4 GHz to 2.4835 GHz
Power level: < 100 mW
Range: 200 m of unobstructed space
10 m between products indoors
 6.4 Climate characteristics
Usage temperature: + 5°C to + 45°C
Storage temperature: 0°C to + 45°C
7. CARE
Clean the surface with a cloth.
Do not use acetone, tar-removing cleaning agents or trichloroethylene.
Resistant to the following products: Hexane (EN 60669-1), methylated
spirit, soapy water, diluted ammonia, bleach diluted to 10%, window-
cleaning products, pre-impregnated wipes.
The plates must not be painted.
8. STANDARDS AND APPROVALS
Compliant with installation and manufacturing standards.
See e-catalogue.
The undersigned, LEGRAND, declares that the radio-electric equipment
type
(7 521 84 - 7 522 84 - 7 523 84) complies with directive 2014/53/EU.
The full text of the EU declaration of conformity is available on the
following website: www.legrandoc.com
R L
LED **
240 V~
Max. 300 W (*)60 W 60 W 300 VA 300 VA
Min. 7 W 5 W 9 W 10 VA 35 VA
100 V~
Max. 150 W (*)30 W 30 W 150 VA 150 VA
Min. 7 W 5 W 9 W 10 VA 35 VA
