Cat. No(s): 0 698 76L/96L
Technical data sheet: F03477EN/00 Updated: Created: 20/09/2023
1/2
PlexoTM with Netatmo
Weatherproof connected 150 W LED switch with neutral with
dimmer option
128, av. du Maréchal-de-Lattre-de-Tassigny - 87045 LIMOGES Cedex - France
Tel: +33(0)5 55 06 87 87 - Fax: +33(0)5 55 06 88 88
www.legrandgroup.com
1. USE
150 W LED connected switch with neutral with dimmer option,
configured by default as ON/OFF (dimmer mode can be activated from
the Home + Control app).
Can be used in conjunction with one or more wireless light switches and/
or one or more mechanical push-buttons.
For local or remote control of your lighting.
With its IP55 weatherproong, this product can be used to control a light
or electrical appliance in places where damp and dust can be an issue
(garage, cellar, workshop, kitchen, etc) as well as outdoors (terrace, etc).
To be fitted with a surface-mounting box or plate support for surface-
mounted or flush-mounted installation.
Easy to install in place of a standard switch.
3. DIMENSIONS (mm)
2. RANGE
Product for use in conjunction with the “with Netatmo” starter pack.
Equipped with an LED indicator (conguration) and a RESET button
(concealed) used to return to factory settings
Grey Anthracite
0 698 76L 0 698 96L
A
BC
D
A B C D
85.5 85.5 50 5
4. CONNECTION
Terminal type: screw
Terminal capacity: 2 x 1.5 mm2 - 1 x 2.5 mm2
Stripping length: 7 mm
Flat screwdriver: 3 mm
5. OPERATION
RESET button
used to return to factory settings
LED indicator:
- useful during installation
- blue LED illumination function which can
be activated from the Home + Control app
ON/OFF when pressed at the bottom
and dimming down when held down
until released.
ON/OFF when pressed at the top and
dimming up when held down until released
2/2
Cat. No(s): 0 698 76L/96L
PlexoTM with Netatmo
Weatherproof connected 150 W LED switch with neutral with
dimmer option
Technical data sheet: F03477EN/00 Updated: Created: 20/09/2023
5. TECHNICAL CHARACTERISTICS
5.1 Mechanical characteristics
Protection against impacts: IK 08
Protection against solid bodies and/or liquids: IP 55
5.2 Material characteristics
Base: ABS
Plate: ABS
Cover plate: PP + SEBS
Rocker plate: Painted ABS
Transparent membrane: SEBS
Halogen-free
UV resistant
Self-extinguishing:
850°C/30 s for insulating components holding live parts in
place
650°C/30 s for the other insulating components
5.3 Electrical characteristics
Voltage: 110-240 V~
Power: 150 W
Frequency: 50/60 Hz
Standby consumption: 0.7 W
The connected switch (with dimmer option) works with conventional
or dimmer bulbs, including LED bulbs. Dimmable LEDs must be used to
ensure optimal installation operation in dimming mode.
Zigbee technology: 2.4 GHz to 2.4835 GHz
Power level: < 100 mW
Range: 200 m in unobstructed space
10 m between products indoors
5.4 Climate characteristics
Usage temperature: +5°C to +45°C
Storage temperature: 0°C to +45°C
6. CARE
Clean the surface with a cloth.
Do not use acetone, tar-removing cleaning agents or trichloroethylene.
Resistant to the following products: Hexane, methylated spirit, soapy water,
diluted ammonia, bleach diluted to 10%, window-cleaning products,
pre-impregnated wipes.
The product must not be painted.
7. STANDARDS AND APPROVALS
Compliant with installation and manufacturing standards.
See e-catalogue.
LEGRAND declares that the radio-electric equipment type (0 698 76L/ 96L)
complies with directive 2014/53/EU.
The full text of the EU declaration of conformity is available on the following
website: www.legrandoc.com
Caution: Always test before using other special cleaning products.
