LEGRAND 7" Video Touch Screen User manual

672 85
Multimedia Touch Screen
User Manual
12/10-01 PC

2

3
Contents
User Manual
Multimedia Touch Screen
1 Introduction and basic functions 6
1.1 Your Multimedia Touch Screen: use it immediately! 7
1.2 Connections 8
1.3 How to navigate through the menus? 9
1.4 How to answer a call on the video door entry system? 10
2 Control your My Home Legrand system 14
2.1 Automation 15
2.2 Lighting 18
2.3 Scenarios 20
2.4 Advanced and programmed scenarios 22
2.5 Sound system 25
2.6 Multi-channel sound system 28
2.7 Multimedia contents 30
2.7.1 USB / SD 31
2.7.2 Web radio 38
2.7.3 Rss 40
2.7.4 Webcam 42
2.8 Burglar alarm 44
2.9 Temperature control 46
2.10 Energy management 54
2.11 Video Door Entry System 64
3 Change your Multimedia Touch Screen settings 70
3.1 Screen 71
3.2 Date and Hour 74
3.3 Volume adjustment 74
3.4 Bell Settings 75
3.5 Password Settings 76
3.6 View your Multimedia Touch Screen version information 77
3.7 Network 77
3.8 Alarm clock 78
3.9 Video door entry system 79

4
Notes

User Manual
Multimedia Touch Screen
5
Introduction and basic Functions
1.1 Your Multimedia Touch Screen: use it immediately! 7
1.2 Connections 8
1.3 How to navigate through the menus? 9
1.4 How to answer a call on the video door entry system? 10

6
1 Introduction and basic functions
Legrand’s brand-new and innovative Multimedia Touch Screen enables you to
control all the highly-advanced functions of your My Home Legrand system
through a simple and attractive icon-based graphical interface and 10” 16:9
LCD touch screen.
As well as manage your entire home automation system, you will be able to
answer calls on the video door entry system and view high-definition images
from your external CCTV cameras.
Thanks to its USB and SD card ports, you will also be able to listen to your favourite
music on your sound system, as well as to view videos and photographs.
Plus, if your system is part of a LAN network with flat-rate broadband connection,
you will be able (through simple icons located on the home page) to receive
RSS services, such as news and weather forecasts, to view webcam images and
to listen to the radio via the Web.
WARNINGS
●Improper use of the Multimedia Touch Screen or of any devices con-
nected to it invalidates the warranty!
●Clean only with the cloth supplied. Do not use solvents, thinners,
etc. or abrasive products.
LCD screen note
The LCD screen has been manufactured using advanced high precision technology. It is
however possible that sometimes up to 5 small black or coloured dots (red, blue, green) may
appear on the LCD screen. This is an absolutely normal result of the manufacturing process
and is not indicative of a malfunction and/or fault.

User Manual
7
Multimedia Touch Screen
1.1 Your Multimedia Touch Screen: use it immediately!
1 - Status bar: logo, date/hour, temperature, access to settings menu.
2 - Web bar: access to contents from broadband-connected LAN network.
3 - Favourites: your Multimedia Touch Screen contains 4 favourite controls
which are always at your disposal regardless of what menu page you are
currently in (ask your installer if you wish to change your favourites).
3
1
2
4
12:0531/07/09 23°C
webcam Weather Web radio Web radio info
Dimmer
Individual Light
Group of Lights
StaircaseLight
Favourites
4 - Applications

8
1.2 Connections
1
2
1 Introduction and basic functions
1 - USB pen drive USB ports
2 - Secur Digital memory card port* (max. 2 GB, do not use HC-SD)
Do not insert two USB pen drives at once.
*The product is sold by Legrand fitted with a 2 GB card.

User Manual
9
Multimedia Touch Screen
1.3 How to navigate through the menus?
1
2
FOLDER
Magnificient
No Line On The Horizon
Images
.mp4 Video
Get On Your Boots
No Line On The Horizon
Dimmer
Individual Light
Group of Lights
StaircaseLight
Favourites
1/2
1 - Navigation bar: no matter what menu or sub-menu you are currently in, the
navigation bar will always be displayed, so that you may switch applications
with a simple touch, without having to go back to the main page. Touch the
and arrows to scroll through available applications or touch the
icon to return to the main page. The application highlighted in white is the
application you are currently in.
2 - Navigation: touch the and arrows to move through pages in an appli-
cation; if the application contains only one page, only the icon is shown,
enabling you to go back. The icon is shown only when a USB device or SD
card is inserted in the Multimedia Touch Screen. Touch the icon to disable
the device (to re-enable the device, remove it and re-insert it into the Mul-
timedia Touch Screen).
02/07/1017:06 22°C

10
1.4 How to answer a call on the video door entry system?
The Multimedia Touch Screen receives a call from the Entrance Panel while it is on
standby.
1 - Go to main page
2 - Answer current call
3 - Increase / decrease incoming volume
4 - Mute key: press to turn off the microphone on the Multimedia Touch Screen
5 - Switch staircase light on
6 - Open door lock
7 - Cycle cameras connected to the system
21 3 4 5 6 7
Video Door Entry System
Dimmer
Individual Light
Group of Lights
StaircaseLight
Favourites
1 Introduction and basic functions
22°C02/07/1017:06

User Manual
11
Multimedia Touch Screen
1 2
1 - End call
2 - Mute key ON (microphone OFF)
1 - Adjust brightness
2 - Adjust contrast
3 - Adjust colour
4 - Close video adjustment settings
Touch the icon to access video adjustment settings relating to the image shown on
the display during the call.
1
2
3
4
Video Door Entry System
Video Door Entry System
Dimmer
Individual Light
Group of Lights
StaircaseLight
Favourites
Dimmer
Individual Light
Group of Lights
StaircaseLight
Favourites
22°C02/07/1017:06
22°C02/07/1017:06

12
Video Door Entry System
Touch the icon to view the videocall image in full screen mode.
Use the 4 arrows for pan & tilt camera adjustment (if available).
When the video call image is being viewed in full screen mode, all the icons described
above will appear in vertical arrangement to the right of the image itself.
Tilt camera up
Tilt camera down
Pan camera right
Full screen view
Pan camera left
Shrink image
End video call
Dimmer
Individual Light
Group of Lights
StaircaseLight
Favourites
1 Introduction and basic functions
22°C02/07/1017:06

User Manual
Multimedia Touch Screen
13
Control your My Home Legrand system
2.1 Automation 15
2.2 Lighting 18
2.3 Scenarios 20
2.4 Advanced and programmed scenarios 22
2.5 Sound system 25
2.6 Multi-channel sound system 28
2.7 Multimedia contents 30
2.8 Burglar alarm 44
2.9 Temperature control 46
2.10 Energy management 54
2.11 Video Door Entry System 64

14
2 Control your My Home Legrand system
Multimedia: this application enables you to access the mul-
timedia contents available from the Web, such as Web Radio,
RSS etc., as well as to play music or view images from any con-
nected USB or SD devices.
Burglar alarm: this application enables you to control and ma-
nage the burglar alarm system.
Temperature control: this application enables you to control
and adjust your heating and air-conditioning systems, al-
lowing you to adjust the temperature on a zone by zone basis,
according to your current requirements.
Energy management: this application enables controlling the
status of the energy loads, display consumptions/productions
of energy, and manage the rearming of Salvavita devices.
Video door entry system: depending on the type of video door
entry system installed, you may control - for each entrance
point - the opening of the door lock and/or the lighting of the
staircase light, communicate with handset units, communicate
with an associated switchboard and use the cameras connec-
ted to your My Home Legrand system in home CCTV mode .
Automation: this application enables you to manage – throu-
gh a user-friendly interface - all the automations in your home
automation system, including rolling shutters, shutters, mo-
torised blinds, controlled electrical sockets, irrigation system,
etc.
Lighting: this application enables you to turn on, turn off or
adjust an individual light or group of lights, as well as to ma-
nage light timers.
Scenarios: this application enables you to activate or modify
the scenarios available in your My Home Legrand system.
Multimedia sound system: this application enables you to ma-
nage your My Home Legrand sound system.

User Manual
15
Multimedia Touch Screen
Dimmer
Individual Light
Group of Lights
StaircaseLight
Favourites
Dimmer
Individual Light
Group of Lights
StaircaseLight
Favourites
2.1 Automation
Blinds Garage Door
Rolling Shutter Gate
Automation Group 1 Irrigation
To enable you to quickly identify the required control, icons represent the indi-
vidual system’s actual function.
Touch the “Automation“ application icon.
The display shows the page listing the systems you can control.
Automation Systems 1/2
12:0531/07/09 23°C
webcam Weather Web radio Web radio info
22°C02/07/1017:06
Blinds Irrigation
Garage door Controlled socket
Rolling shutter Door lock
Gate Contact
Video door entry system door lock Automation group
Fan Automation group

16
Blind – Garage Door – Rolling Shutter - Gate
These controls enable you to open or close blinds, rolling shutters, etc. at the
simple touch of a finger.
Depending on the configuration set by the installer, the system is operated in
one of two modes, as indicated below.
– Safe Mode
The system opens/closes only while you are touching the corresponding
icon; the icon changes to indicate motion.
As soon as you remove your finger from the icon the system stops.
– Standard Mode
The system starts opening/closing by touching the corresponding icon; during
motion, the icon changes to indicate motion and the Stop icon appears. To
stop the system touch the icon.
Examples in Standard Mode
Stop
Stop
Touch the icon to start opening
the gate
Touch the icon to start closing
the garage door
Press the Stop icon to stop the
gate.
Press the Stop icon to stop the
garage door
Examples in Safe Mode
While you are pressing the icon
the blinds continue opening
Remove your finger to stop the
blinds
Stop
Stop
While you are pressing the icon the
rolling shutter continues rolling down
Remove your finger to stop the
rolling shutter
2 Control your My Home Legrand system
Automation group
This control can be used to activate several automations at the same time. For example,
with a single touch it would be possible to lower or rise all the rolling shutters in the
home.
To activate the movement touch the / , icon. Touch the icon to stop it.

User Manual
17
Multimedia Touch Screen
Fan
This control enables you to turn on or turn off the fan.
The icon changes to indicate that the fan is in operation.
Controlled Socket
This control, represented by an electrical socket, enables you to turn on or off a
household appliance or other device.
In this case too, the icon indicates whether the controlled appliance is on or off.
Irrigation
This control enables you to turn on or off the irrigation system.
The icon changes to indicate that the irrigation system is in operation.
Door lock
Touch the icon to activate an electrical door lock.
This control works like a pushbutton; the door lock is activated while you touch
the icon and deactivates as soon as you remove your finger. If this control is
connected to the video door entry system door lock, the time of activation de-
pends on the door lock configuration.
Touch to turn off Touch to turn on
ON OFF
Touch to turn off Touch to turn off
ON ON
Door lock is activated
Touch to turn on Touch to turn on
OFF OFF
Door lock is deactivated

18
Dimmer
Individual Light
Group of Lights
StaircaseLight
Favourites
Dimmer
Individual Light
Group of Lights
StaircaseLight
Favourites
2 Control your My Home Legrand system
2.2 Lighting
Individual Light
This control enables you to turn on or
off an individual light.
Kitchen Light
Group of Lights
This control enables you to turn on or
off a group of lights at once.
Garden Lights
Dimmer
This control enables you to turn on, turn
off or adjust the intensity of a dimmer-
fitted light.
Light intensity can be adjusted by
pressing the - and + icons; the level of
intensity is represented graphically.
If the light does not work or is not con-
nected a cracked bulb is shown.
Living Room Light
Dimmer at
minimum
level
Fault
Touch the “Lighting” application icon.
The display shows the page listing the lights you can control.
12:0531/07/09 23°C
webcam Weather Web radio Web radio info
Lighting 1/2
Individual Light Group of Lights
Dimmer
0:00:00
Timed light
Fixed timed light Group of Dimmers
1’
22°C02/07/1017:06

User Manual
19
Multimedia Touch Screen
Group of Dimmers
This control enables you to turn on, turn
off or adjust the intensity of a group of
dimmer-fitted lights. Bedrooms Lights
Pre-set timed light
This control enables you to turn on a
light by touching the , icon and to
set the time for which the same light is
to stay on using the icon.
Pre-set timed light function is
not activated
Fixed timed light
This control enables you to turn on a
light for a fixed period of time (pre-
set via the configuration software) by
touching the icon.
The icon shows the remaining light-
on time in the form of a percentage.
The icon shows whether the func-
tion is activated or not.
Staircase Light
This control enables you to activate the
staircase light function connected to the
video door entry system.
Fixed timed light function is not
activated
Pre-set timed light function is
activated
Fixed timed light function is acti-
vated (approximately halfway to
switching off)
Light intensity can be adjusted by pressing the - and + icons; the level of inten-
sity is not represented graphically.
The individual dimmers included in a group could be set at different inten-
sity levels; adjustment leads to increasing or decreasing the intensity level of
all dimmers starting from the level at which they were set when they were
switched on.
12:10
12:10
1’
1’

20
Dimmer
Individual Light
Group of Lights
StaircaseLight
Favourites
2.3 Scenarios
12:0531/07/09 23°C
webcam Weather Web radio Web radio info
2 Control your My Home Legrand system
Touch the “Scenarios” application icon.
The display shows the page listing the scenarios you can activate; touch the
icon to activate the chosen scenario.
Scenari 1/2
Scenario 4Scenario 1
Scenario 2 Scenario 5
Scenario 3 Scenario 6
Scenario from the scenarios control unit
This control enables you to turn on a
scenario stored on the Scenarios Con-
trol Unit. If you wish, you can change
the scenario settings on the Scenarios
Control Unit; from that moment on, the
Multimedia Touch Screen will imple-
ment the new scenario set.
If the icon is not shown, the Scenarios Module is blocked.
Scenario from the scenarios module
This control enables you to turn on one
of the scenarios stored on the Scenarios
Module. Touch the icon to bring up a
series of additional icons that will enable
you to delete or program a new scenario
according to the Scenarios Module’s op-
erating instructions.
Scenario 2
Scenario 1
Dimmer
Individual Light
Group of Lights
StaircaseLight
Favourites
22°C02/07/1017:06
