Leica Sprinter 50 User manual

Sprinter_01
Sprinter 50
User Manual
Version 1.0
EN, DE, FR, ES, IT, PT,
NL, NO, SV, FI, DA

User Manual
Gebrauchsanweisung
Manuel d'utilisation
Manual del usuario
Manuale d'uso
Manual de Operação
Gebruiksaanwijzing
Brukerhåndbok
Handbok
Käyttäjän käsikirja
Brugervejledning
EN
DE
FR
ES
NO
SV
FI
DA
IT
PT
NL

1
Introduction Sprinter 50 - 1.0.0en
EN
DE
FR
ES
NO
SV
FI
DA
IT
PT
NL
User Manual (English)
1. Introduction
Purchase
Congratulations on the purchase of a new Leica
Geosystems electronic level. It is designed to make
levelling works easier and quicker on any construction
site.
Product
This manual contains important
safety directions as well as instruc-
tions for setting up the product and
operating it. Refer to "10. Safety
Directions" for further information.
Read carefully through the User Manual before you
use the product.
Product identification
The model and the serial number of your product are
indicated on the type plate.
Enter the model and serial number in your manual
and always refer to this information when you need to
contact your agency or Leica Geosystems authorized
service workshop.
Type: ____________ Serial no.: ____________
Validity of this manual
This manual is valid for Sprinter 50.
Trademarks
All trademarks are the property of their respective
owners.
Available documentation
Name Description
Sprinter 50
User Manual All instructions required in order to operate the product to a basic
level are contained in this User
Manual. Provides an overview of
the system together with tech-
nical data and safety directions.

EN
DE
FR
ES
NO
SV
FI
DA
IT
PT
NL
2
Introduction Sprinter 50 - 1.0.0en
Symbols
The symbols used in this Manual have the following
meanings:
DANGER
Indicates an imminently hazardous situation
which, if not avoided, will result in death or serious
injury.
WARNING
Indicates a potentially hazardous situation or
an unintended use which, if not avoided, could result
in death or serious injury.
CAUTION
Indicates a potentially hazardous situation or
an unintended use which, if not avoided, may result in
minor or moderate injury and / or appreciable mate-
rial, financial and environmental damage.
)Important paragraphs which must be adhered to
in practice as they enable the product to be used
in a technically correct and efficient manner.
Table of Contents
1. Introduction......................................................1
2. Instrument Components ..................................2
3. Measurement Preparations .............................3
4. User Interface..................................................4
5. Operation.........................................................6
6. Check & Adjust................................................7
7. Error Messages ...............................................9
8. Operation Messages .....................................10
9. Care and Transport .......................................11
10. Safety Directions ...........................................12
11. Technical Data ..............................................21

3
Instrument Components Sprinter 50 - 1.0.0en
EN
DE
FR
ES
NO
SV
FI
DA
IT
PT
NL
2. Instrument Components
Container Contents
Sprinter, batteries (4x), allen key, user manual, error
and operation messages leaflet, strap.
Accessories
Tripod, aluminum staff (region dependant). (Optional:
sunshade, 4 rechargeable batteries and charger.)
3. Measurement Preparations
3.1 Change battery
Insert 4 AA dry cells according to the positive and
negative signs as indicated on the holder.
)Always replace with a complete battery set!
)Do not use old and new batteries together.
)Do not use batteries from different manufac-
turers or batteries of different types.
3.2 Set-up instrument
Levelling
• Set up the tripod. Extend the legs to a suitable
length and ensure that the tripod head is approxi-
mately level. Tread the tripod shoes firmly into the
ground to ensure stability.
• Mount the instrument on the tripod by screwing the
tripod screw onto the base of the instrument.
• Use the three levelling foot screws to center the
circular bubble in order to level the instrument.
a) Horizontal fine motion
screw
b) Battery compartment
c) Circular level
d) Gunsight
e) Focusing knob
f) Handle
g) Eyepiece
h) LCD display
i) Base plate
j) Levelling footscrew
a
j
i
h
g
f
e
d
b
c
Sprinter 01

EN
DE
FR
ES
NO
SV
FI
DA
IT
PT
NL
4
Measurement Preparations Sprinter 50 - 1.0.0en
Eyepiece Adjustment
Point the telescope to a uniform light surface such as
a wall or a piece of paper. Turn the eyepiece until the
cross hairs are sharp or distinct.
Target Image Focusing
Use the gunsight to aim the objective lens at the staff.
Turn the horizontal fine motion screw until the staff is
nearly centered in the field of view and then turn the
focusing knob to focus on the staff. Ensure that staff
image and reticle are sharp or distinct.
Power ON
The instrument is ready to measure.
)Technical hints:
• First check and adjust the electronic and optical
line-of-sight errors, then the circular level on the
instrument and then the staff: before starting work
in the field, after long storage periods, after long
transportation.
• Keep the optics clean. Dirt or condensation on the
optics can limit measurements.
• Before starting work, let the instrument adjust to the
ambient temperature (approx. 2 minutes per °C of
temperature difference).
• Avoid measuring through window panes.
• Staff sections have to be fully extended and prop-
erly secured.
• Touching the upper third of the tripod, can damp
vibrations at the instrument due to wind.
• Use the lens hood to cover the objective when
backlight disturbs.
• Evenly illuminate the measuring area of the staff
with a flashlight or spotlight in darkness.

5
User Interface Sprinter 50 - 1.0.0en
EN
DE
FR
ES
NO
SV
FI
DA
IT
PT
NL
4. User Interface Modes
Icons
Measurement display symbols
)Electronic collimation error can be corrected with
the on-board Adjustment program.
b
a
Measurement Mode
Adjustment Mode
Battery icon at various capacities
Measured staff height
Measured distance
MEAS
ADJ
Key Symbol 1st level functions 2nd level functions
a) On/Off Power On or Off switch NONE
b) MEAS Measuring trigger key / single
press to decline adjustment
result
Press and hold for 3 seconds to start Adjustment
program / to accept measurement and adjustment
result

EN
DE
FR
ES
NO
SV
FI
DA
IT
PT
NL
6
Operation Sprinter 50 - 1.0.0en
5. Operation
Height and Distance measurement (electronic)
Example of an electronic measurement:
)Always aim at the center of bar code staff and focus
the staff image for accurate measurement.
5.1 Height and Distance Mea-
surement
Measurement
Standby Mode Measuring in progress Measurement with height and
distance
Step Key Description
1. Press to switch on the instru-
ment, Leica logo is displayed
follow by the default measure-
ment standby mode.
2. Aim at staff and focus. Lightly
trigger the measurement key to
activate measurement.
3. Height and distance measure-
ment is displayed.
:_ _ _ _ _
:_ _ _ _ _
: >>>>
:>>>>
MEAS
:1.235m
:5.68m

7
Check & Adjust Sprinter 50 - 1.0.0en
EN
DE
FR
ES
NO
SV
FI
DA
IT
PT
NL
6. Check & Adjust
6.1 Electronic collimation ad-
justment
To activate "Adjustment" program, press and
hold measuring key for 3 seconds.
Step 1: Aim at Staff A and press MEAS key. Measure-
ment display, press and hold measuring key for 3
seconds to accept.
Step 2: Aim at Staff B and press MEAS key. Measure-
ment display, press and hold measuring key for 3
seconds to accept.
Now shift the Sprinter towards staff A and set it up at
about 3 m to staff A.
Step 3: Aim at Staff B and press MEAS key. Measure-
ment display, press and hold measuring key for 3
seconds to accept.
Step 4: Aim at Staff A and press MEAS key. Measure-
ment display, press and hold measuring key for 3
seconds to accept.
The new electronic collimation error is displayed. To
accept new correction, press and hold measuring key
for 3 seconds to accept; otherwise single press of
measuring key to decline adjustment result.
)Optical collimation error can be corrected by
adjusting the reticle.
B
A~15m ~15m
B
A
~3m ~27m
