Lennox Hearth Products Decorative Style View MPB-45 User manual

NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
LENNOX HEARTH PRODUCTS
KITS AND ACCESSORIES
750,200M
REV. B 06/2006 DECORATIVE STYLE VIEW™ ARCH PANE SCREEN DOOR KITS
CHARCOAL & SATIN PEWTER
KIT CONTENTS
ITEM QUANTITY DESCRIPTION
1 1 ea. Door, Left
2 1 ea. Door, Right
3 1 ea. Doorframe Assembly
4 1 ea. Lower Compartment Cover
5 1 ea. Firebox Bottom Cover Panel
6 1 ea. Instruction Sheet
Table 2 - Refer to Figure 1
STYLE VIEW TALL ARCH PANE SCREEN DOOR KITS
CAT# MODEL DESCRIPTION
H3525 TAPD35C 35” Arch Pane, Charcoal
H3527 TAPD35SP 35” Arch Pane, Satin Pewter
H3529 TAPD40C 40” Arch Pane, Charcoal *
H3531 TAPD40SP 40” Arch Pane, Satin Pewter *
H3533 TAPD45C 45” Arch Pane, Charcoal
H3535 TAPD45SP 45” Arch Pane, Satin Pewter
H3537 TAPD35EC 35” Arch Pane, Charcoal (SDDV-35 & EDV35 only)
H3539 TAPD35ESP 35” Arch Pane, Satin Pewter (SDDV-35 & EDV35 only)
Table 1
TOOLS REQUIRED
5/16” Nutdriver or Socket
1/4” Nutdriver or Socket (for EDVST model only)
GENERAL INFORMATION
These decorative screen doors are offered in two attractive finishes and
fit on the face of the appliance over the glass doorframe. If you encounter
any problems, need clarification of these instructions or are not qualified to
properly install this kit, contact you local distributor or dealer.
* Note: Early revisions of model EDVST and EBVST may also require a magnet
mounting kit, Cat. No. H2110. If the appliance does not have slots described
in Step 5 (to accept the hinge tabs on style view doors), the tabs on the style
view doorframe must be sawed off, then the doorframe will be secured to the
glass door assembly using 4 magnets provided in the H2110 kit.
3
4
Figure 1
WARNINGS
Hot! Do not touch! The decorative screen doors
and the glass behind the screen doors will
become hot during operation
and will retain
heat for a while after shutting off the appliance
.
Severe burns may result. Carefully supervise
children in the same room as appliance.
• These decorative screen doors are NOT heat guards
and are not intended to prevent burns.
• Operate the doors by only using the door handles.
Avoid touching the doorframe, screens, or the glass
enclosure, if the door is opened.
• The lower compartment cover will become hot during
operation of the fireplace. Use care when removing
the panel to access the controls. Handle the compart-
ment cover by grasping the two knobs mounted on the
face of the cover panel.
• Be certain to place the control compartment cover
panel on a surface that is non-combustible or will not
be damaged by high temperatures.
• Use care when opening doors. Avoid exerting any
downward pressure on the doors when they are in an
open position. Excessive force can cause the doors to
come loose or be damaged.
• INSTALL ONLY WHEN THE FIREPLACE IS OFF AND COLD!
Kit Contents
(see Table 2)
Read and understand all instructions and warnings in this docu-
ment before beginning the installation.
INSTALLATION INSTRUCTIONS FOR DECORATIVE TALL ARCH SCREEN PANEL KITS
FOR USE WITH MPB-35/40/45, MPD-35/40/45, MPB35ST, MPD35ST, EDV-35/40/45, SDDV-35/40, EDVST* & EBVST* GAS FIREPLACES
12
NOTE:DIAGRAMS& ILLUSTRATIONS ARE NOT TO SCALE.
LENNOXHEARTH PRODUCTS
KITSAND ACCESSORIES
750,200M
REV.NC 12/2005 DECORATIVESTYLE VIEW™ ARCH PANE SCREEN DOOR KITS
CHARCOAL,TEXTURED IRON, SATIN PEWTER & ANTIQUE BRASS
KITCONTENTS
ITEM QUANTITY DESCRIPTION
1 1ea. Door,Left
2 1ea. Door,Right
3 1ea. Doorframe Assembly
4 1ea. Screen Panel, Lower
5 1ea. Instruction Sheet
Table2 - Refer to Figure 1
STYLEVIEW ARCH PANE SCREEN DOOR KITS
CAT# MODEL DESCRIPTION
H3525 TAPD35C 35”Arch Pane, Charcoal
H3526 TAPD35TI 35”ArchPane, TexturedIron
H3527 TAPD35SP 35”Arch Pane, Satin Pewter
H3528 TAPD35AB 35”Arch Pane, Antique Brass
H3529 TAPD40C 40”Arch Pane, Charcoal
H3530 TAPD40TI 40” Arch Pane, Textured Iron
H3531 TAPD40SP 40”Arch Pane, Satin Pewter
H3532 TAPD40AB 40”Arch Pane, Antique Brass
H3533 TAPD45C 45”Arch Pane, Charcoal
H3534 TAPD45TI 45” Arch Pane, Textured Iron
H3535 TAPD45SP 45”Arch Pane, Satin Pewter
H3536 TAPD45AB 45”Arch Pane Doors, Antique Brass
H3537 TAPD35EC 35”Elite Arch Pane, Charcoal
H3538 TAPD35ETI 35”EliteArch Pane, Textured Iron
H3539 TAPD35ESP 35” Elite Arch Pane, Satin Pewter
H3540 TAPD35EAB 35” Elite Arch Pane, Antique Brass
Table 1
TOOLSREQUIRED
None
GENERALINFORMATION
Thesedecorative screen doors are offered in four attractive finishes and
fiton the face of the appliance over the glass doorframe. If you encounter
anyproblems, need clarification of these instructions or are not qualified to
properlyinstall this kit, contact you local distributor or dealer.
3
4
Figure1
WARNINGS
Hot!Donot touch! Thesedecorative screen doors
areNOTheat guards.
Theceramicglass behindthe
screenswillbe hotduringoperation
andwillretain
heatfor a while after shutting off the appliance
.
Severe burns may result. Carefully supervise
childrenin the same room as appliance.
• As with any similar heating appliance, surfaces of the
frameand doors including handles can become very
hot. Avoid touchingthe glass or screen door surfaces
whenoperating the doors.
• Use care whenopening doors. Avoid exerting any
downwardpressure on the doors when they are in an
openposition. Excessive force can cause the doors to
comeloose or be damaged.
• The lower screen panel covering the controls will
becomehot during operation. Use care when remov-
ingthe panel to access the controls and make sure to
placethe screen on a surface that is non-combustible
orwill not be damaged by high temperatures.
• INSTALL ONLY WHEN THE FIREPLACE IS OFF AND COLD!
KitContents
(seeTable2)
Readand understand all instructions and warnings in this docu-
mentbefore beginning the installation.
INSTALLATIONINSTRUCTIONS FOR DECORATIVE ARCHSCREEN PANEL KIT
FORUSE WITH LMDV-35/40/45, MPD-35/40/45, MPD35ST,
EDV-35/40/45,EDVST & EBVST GAS FIREPLACES
12
NOTE:DIAGRAMS&ILLUSTRATIONSARENOTTOSCALE.
LENNOXHEARTHPRODUCTS
KITSANDACCESSORIES
750,200M
REV.NC12/2005DECORATIVESTYLEVIEW™ARCHPANESCREEN DOOR KITS
CHARCOAL,TEXTUREDIRON,SATINPEWTER&ANTIQUEBRASS
KITCONTENTS
ITEMQUANTITYDESCRIPTION
11ea. Door, Left
21ea. Door, Right
31ea. Doorframe Assembly
41ea. ScreenPanel,Lower
51ea. Instruction Shee t
Table2-RefertoFigure1
STYLEVIEWARCHPANESCREENDOORKITS
CAT#MODEL DESCRIPTION
H3525TAPD35C35”ArchPane,Charcoal
H3526TAPD35TI35”ArchPane,TexturedIron
H3527TAPD35SP35”ArchPane,SatinPewter
H3528TAPD35AB35”ArchPane,AntiqueBrass
H3529TAPD40C40”ArchPane,Charcoal
H3530TAPD40TI40”ArchPane,TexturedIron
H3531TAPD40SP40”ArchPane,SatinPewter
H3532TAPD40AB40”ArchPane,AntiqueBrass
H3533TAPD45C45”ArchPane,Charcoal
H3534TAPD45TI45”ArchPane,TexturedIron
H3535TAPD45SP45”ArchPane,SatinPewter
H3536TAPD45AB45”ArchPaneDoors,AntiqueBrass
H3537TAPD35EC35”EliteArchPane,Charcoal
H3538TAPD35ETI35”EliteArchPane,TexturedIron
H3539TAPD35ESP35”EliteArchPane,SatinPewter
H3540TAPD35EAB35”EliteArchPane,AntiqueBrass
Table1
TOOLSREQUIRED
None
GENERALINFORMATION
Thesedecorativescreendoorsareofferedinfourattractivefinishesand
fitonthefaceoftheapplianceovertheglassdoorframe.Ifyouencounter
anyproblems,needclarificationoftheseinstructionsorarenotqualifiedto
properlyinstallthiskit,contactyoulocaldistributorordealer.
3
4
Figure1
WARNINGS
Hot!Donottouch!Thesedecorativescreendoors
areNOTheatguards.
Theceramicglassbehindthe
screenswillbehotduringoperation
andwillretain
heatforawhileaftershuttingofftheappliance
.
Severeburnsmayresult.Carefullysupervise
childreninthesameroomasappliance.
•Aswithanysimilarheatingappliance,surfacesofthe
frameanddoorsincludinghandlescanbecomevery
hot.Avoidtouchingtheglassorscreendoorsurfaces
whenoperatingthedoors.
•Usecarewhenopeningdoors.Avoidexertingany
downwardpressureonthedoorswhentheyareinan
openposition.Excessiveforcecancausethedoorsto
comelooseorbedamaged.
•Thelowerscreenpanelcoveringthecontrolswill
becomehotduringoperation.Usecarewhenremov-
ingthepaneltoaccessthecontrolsandmakesureto
placethescreenonasurfacethatisnon-combustible
orwillnotbedamagedbyhightemperatures.
•INSTALLONLYWHENTHEFIREPLACEISOFFANDCOLD!
KitContents
(seeTable2)
Readandunderstandallinstructionsandwarningsinthisdocu-
mentbeforebeginningtheinstallation.
INSTALLATIONINSTRUCTIONSFORDECORATIVEARCHSCREENPANELKIT
FORUSEWITHLMDV-35/40/45,MPD-35/40/45,MPD35ST,
EDV-35/40/45,EDVST&EBVSTGASFIREPLACES
12
6
4
5

2NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
Figure 2 - Remove Top Panel
INSTALLATION INSTRUCTIONS:
1. Remove Top and Bottom Panels -
a. Remove the top louvered or radiant panel/hood assembly by pulling
the assembly up and out (see Figure 2). In instances where the radiant
panel is used and it is framed in with tile or other approved material, the
hood must still be removed by firmly pulling it forward until it releases
from the receiving brackets.
b. Remove the bottom louvered or radiant panel/hood assembly (refer to
Homeowner’s Care and Operation Manual).
Remove Trim Panels
as shown. The trim
panels will be either
Louvered Panels or
Radiant Panels.
Louvered
Panels
Radiant
Panels Figure 4 - GLASS DOOR ADJUSTMENT
Top Flange on Glass Door
Bottom Vee-flange Glass Door
Glass Door Latch
Glass Door
Firebox Floor
Some models will have a
modesty panel in the control
compartment (in front of
the valve). The appearance
will vary from the example
shown below.
Bustles
Figure 3 - Remove Bustles
Lift Bustles Up
And Off
Only Some Models
Have Bustles
Modesty Panel
2. Align Glass Door (see Figure 4) - Ensure the glass door assembly on
the fireplace is properly aligned as follows:
Note: Units with Modesty Panels - Remove the modesty panel,
if necessary, as follows: Lift the modesty panel by the tab on the
panel’s right end, pull the right end of the panel away from cabinet
and then pull the panel diagonally out of the corner post slots on
the left side of the unit. Remove the modesty panel carefully, so
that none of the wires become loose or disconnected.
3. Install Firebox Bottom Cover Panel - For Models EDV-35/40/45, see
Figure 5a. For Model EDVST see Figure 5b.
Screw
Step 1 - Remove 2 fire-
box bottom screws.
Step 2 - Install the Firebox Bottom Cover Panel (#5 in Figure 1) using the
existing screws that were removed. The top two holes on the panel align to
corresponding holes on fireplace.
Figure 5a - Install Firebox Cover
c. Remove Bustles - Some models have bustles (as shown in Figure 3)
which must be removed. If applicable, remove the top and bottom bustle
by lifting them up and out.
a. Open the latch(es) at the bottom of the glass door assembly as shown
in Figure 4 (refer to Homeowners Manual).
b. Adjust glass door so that it is evenly spaced and aligned to the fireplace
chassis on both sides. See Figure 4.
c. Fasten the latch(es). Ensure that the latch(es) are engaged with the
door’s vee-flange and fully closed. See Figure 4.
For EDV-35/40/45 Models

3
NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
Figure 6 - INSTALL DOORFRAME
6. Place the doorframe bracket in the locked position as shown in Figure 7.
Hinge Pin
Doorframe
Bracket
Locate the doorframe
bracket on the lower front
of the doorframe and lock
it behind the cabinet
bottom flange as
shown here.
Figure 7
4. For EDV, EDVST & EBVST models, reinstall modesty panel, ensuring all
wires are securely connected.
5. Install Doorframe (see Figure 6) - Remove the arched doorframe
from packaging. Position the top of the doorframe above the top of the
glass doorframe (centered and approximately 1” above the top of the
glass doorframe). Slide down so that the hooks catch on the back of
the doorframe slide between the sides of the glass door and the corner
posts engaging into existing slots on fireplace.
7. Remove the screen doors from packaging. Install them by aligning
hinge pins on the doors with the hinge holes on the doorframe and
slide down (see instructions in Figure 8). Ensure the hinge pins are
fully seated onto the shoulders of the hinge holes.
Align hinge pins on the
doors with the hinge holes
on the doorframe and slide
down as shown.
Firebox
Firebox
Left
Corner
Post
Right
Corner
Post
Step 1 - Remove the
two #8 screws from
the bracket screw
cover on both sides.
Step 3 - Install the Firebox Bottom Cover Panel (#5 in Figure 1) using the
existing #10 screws. The bottom two holes on the cover panel align to cor-
responding two holes on firebox bottom.
Figure 5b - Install Firebox Cover
For EDVST Model Only
Step 2 - Remove the
two #10 screws from
the firebox bottom
on both sides (save
screws). #10 Screw
#8
Screw
Adjust Doorframe Bracket
Figure 8
Bracket
Screw
Cover
Doorframe

4NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
Printed in U.S.A. © LENNOX HEARTH PRODUCTS 2006
P/N 750,200M REV. B 06/2006
Lennox Hearth Products reserves the right to make changes at any time, without notice, in design,
materials, specifications, prices and the discontinuance of colors, styles and products. Consult your
local distributor for fireplace code information.
NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
1110 West Taft Avenue • Orange, CA 92865
10. Re-install the top louvered or radiant panel/hood assemblies.
11. Close both doors as shown in Figures 9 & 10.
Figure 11 - COMPLETED INSTALLATION
Figure 9 - INSTALL LOWER COMPARTMENT COVER
Figure 10 - CLOSE BOTH DOORS
Lower Compartment Cover
Place the lower compartment cover hook
behind the glass doorframe bottom flange.
8. Light the appliance following instrutions on lighting label in control
compartment or see lighting instructions in Homeowner’s Care and
Operation Manual provided with appliance.
Note: Ensure that the latch(es) below the door are engaged with the
door’s vee-flange and fully closed before operating the fireplace.
9. Install the lower compartment cover per instructions in Figure 9.
Knobs
