Lenze EVF9321 Series User manual

EDKVF93−01
.MUW
Ä.MUWä
Information for the operator of the machine
9300 vector 0.37 ... 11 kW

EVF9321−xV ... EVF9326−xV
Frequency inverter
Global Drive

9300vec154

Key for overview
Position Description
Controller
Fixing rails for standard mounting
Cover for the motor connection
Shield connection support with fixing screws (2 items)
1 support for the shield sheet for the supply connections
1 support for the shield sheet for the motor cable
EMC shield sheet with fixing screws (2 items)
1 shield sheet for the supply connections
1 shield sheet for the motor cable and the feed cable for the motor temperature monitoring with PTC ther-
mistor or thermal contact (NC contact)
EMC shield sheet with fixing screws for shielded control cables
Cover for the supply connections
Connections and interfaces
Position Description
L1, L2, L3, PE Mains connection
+UG, −UG DC supply
U, V, W, PE Motor connection
T1, T2 Connection of PTC thermistor or thermal contact (NC contact) of the motor
X1 AIF interface (automation interface)
Slot for communication module (e. g. XT EMZ9371BC keypad)
X3 Jumper for setting analog input signal at X6/1, X6/2
X4 System bus (CAN) connection
X5 Connection of digital inputs and outputs
X6 Connection of analog inputs and outputs
X8 Connection of incremental encoder with TTL level or SinCos encoder and KTY temperature sensor of the motor
X9 Connection of digital frequency input signal
X10 Connection of digital frequency output signal
X11 Connection of KSR relay output for "safe standstill" (for variants V004 and V024 only)
Status displays
Position LED red LED green Operating status
Off On Controller is enabled
On On Mains is switched on and automatic start is inhibited
Off Blinking slowly Controller is inhibited
Off On Motor data identification is active
Blinking quickly Off Undervoltage or overvoltage
Blinking slowly Off Active fault
0Fig. 0Tab. 0

Contentsi
4 EDKVF93−01 EN 3.0
1 About this documentation 5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.1 Document history 5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.2 Target group 5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.3 Validity information 6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.4 Conventions used 7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.5 Notes used 8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2 Safety instructions 9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.1 General safety and application notes for Lenze controllers 9. . . . . . . . . . . . . . . . . .
2.2 Thermal motor monitoring 12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.2.1 Forced ventilated or naturally ventilated motors 13. . . . . . . . . . . . . . . . . . .
2.2.2 Self−ventilated motors 14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.3 Residual hazards 16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.4 Safety instructions for the installation according to UL 18. . . . . . . . . . . . . . . . . . . . .
3 Parameter setting 20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.1 Parameter setting with the XT EMZ9371BC keypad 20. . . . . . . . . . . . . . . . . . . . . . . .
3.1.1 General data and operating conditions 20. . . . . . . . . . . . . . . . . . . . . . . . . .
3.1.2 Installation and commissioning 21. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.1.3 Display elements and function keys 21. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.1.4 Changing and saving parameters 23. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.1.5 Loading a parameter set 25. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.1.6 Transferring parameters to other standard devices 26. . . . . . . . . . . . . . . . .
3.1.7 Activating password protection 28. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.1.8 Diagnostics 29. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.1.9 Menu structure 30. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4 Troubleshooting and fault elimination 32. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.1 Display of operating data, diagnostics 32. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.1.1 Display of operating data 32. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.1.2 Diagnostics 33. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.2 Troubleshooting 34. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.2.1 Status display via controller LEDs 34. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.2.2 Fault analysis with the history buffer 35. . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.3 Drive behaviour in the event of faults 36. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.4 Fault elimination 37. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.4.1 Drive errors 37. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.4.2 Controller in clamp operation 38. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.4.3 Behaviour in case of overvoltage in the DC bus (OU message) 39. . . . . . . .
4.5 System error messages 40. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.5.1 General error messages 40. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.5.2 Resetting system error messages 45. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

About this documentation
Document history
1
5
EDKVF93−01 EN 3.0
1 About this documentation
Note!
This documentation contains all the information required by the machine
operator to run the drive controllers of the 9300 vector series installed in your
machine/system.
You may make further use of the information contained in this documentation
without asking Lenze for permission if you do not change the contents.
1.1 Document history
What is new / what has changed?
Material number Version Description
.MUW 3.0 11/2013 TD06 Error corrections
13330574 2.1 03/2010 TD14 Change of the company’s address
13330574 2.0 03/2010 TD14 New edition due to reorganisation of the company
UL−warnings updated
Revision for software version 8x
13217739 1.0 07/2007 TD23 First edition
Tip!
Information and auxiliary devices related to the Lenze products can be found
in the download area at
http://www.Lenze.com
1.2 Target group
This documentation is directed at qualified skilled personnel according to IEC 60364.
Qualified skilled personnel are persons who have the required qualifications to carry out
all activities involved in installing, mounting, commissioning, and operating the product.

About this documentation
Validity information
1

6 EDKVF93−01 EN 3.0
1.3 Validity information
... 9300 vector frequency inverters as of nameplate data:
   Nameplate
EVF 93xx ˘x V Vxxx 1x 8x
Product series
9300vec112
EVF = Frequency inverter
Type no. / rated power
400 V 480 V
9321 = 0.37 kW 0.37 kW
9322 = 0.75 kW 0.75 kW
9323 = 1.5 kW 1.5 kW
9324 = 3.0 kW 3.0 kW
9325 = 5.5 kW 5.5 kW
9326 = 11 kW 11 kW
Type
E = Panel−mounted unit
C = Built−in unit in "cold plate" technique
Design
V = Vector−controlled frequency inverter
Variant
˘ Standard
V003 = In "cold plate" technique
V004 = With "safe standstill" function
V024 = With "safe standstill" function and for IT mains
V100 = For IT mains
Hardware version
Software version

About this documentation
Conventions used
1
7
EDKVF93−01 EN 3.0
1.4 Conventions used
This documentation uses the following conventions to distinguish between different
types of information:
Type of information Identification Examples/notes
Spelling of numbers
Decimal separator language−dependen
t
In each case, the signs typical for the target
language are used as decimal separators.
For example: 1234.56 or 1234,56
Warnings
UL warnings Given in English and French
UR warnings 
Text
Program name » « PC software
For example: »Engineer«, »Global Drive
Control« (GDC)
Icons
Page reference Reference to another page with additional
information
For instance: 16 = see page 16
Documentation reference Reference to another documentation with
additional information
For example: EDKxxx = see
documentation EDKxxx

About this documentation
Notes used
1

8 EDKVF93−01 EN 3.0
1.5 Notes used
The following pictographs and signal words are used in this documentation to indicate
dangers and important information:
Safety instructions
Structure of safety instructions:
Danger!
(characterises the type and severity of danger)
Note
(describes the danger and gives information about how to prevent dangerous
situations)
Pictograph and signal word Meaning
Danger!
Danger of personal injury through dangerous electrical voltage.
Reference to an imminent danger that may result in death or
serious personal injury if the corresponding measures are not
taken.
Danger!
Danger of personal injury through a general source of danger.
Reference to an imminent danger that may result in death or
serious personal injury if the corresponding measures are not
taken.
Stop!
Danger of property damage.
Reference to a possible danger that may result in property
damage if the corresponding measures are not taken.
Application notes
Pictograph and signal word Meaning
Note! Important note to ensure troublefree operation
Tip! Useful tip for simple handling
Reference to another documentation
Special safety instructions and application notes
Pictograph and signal word Meaning
Warnings! Safety note or application note for the operation according to
UL or CSA requirements.
The measures are required to meet the requirements according
to UL or CSA.
Warnings!

Safety instructions
General safety and application notes for Lenze controllers
2
9
EDKVF93−01 EN 3.0
2 Safety instructions
2.1 General safety and application notes for Lenze controllers
(in accordance with Low−Voltage Directive 2006/95/EC)
For your personal safety
Disregarding the following safety measures can lead to severe injury to persons and
damage to material assets:
ƒOnly use the product as directed.
ƒNever commission the product in the event of visible damage.
ƒNever commission the product before assembly has been completed.
ƒDo not carry out any technical changes on the product.
ƒOnly use the accessories approved for the product.
ƒOnly use original spare parts from Lenze.
ƒObserve all regulations for the prevention of accidents, directives and laws
applicable on site.
ƒTransport, installation, commissioning and maintenance work must only be carried
out by qualified personnel.
– Observe IEC 364 and CENELEC HD 384 or DIN VDE 0100 and IEC report 664 or
DIN VDE 0110 and all national regulations for the prevention of accidents.
– According to this basic safety information, qualified, skilled personnel are persons
who are familiar with the assembly, installation, commissioning, and operation of
the product and who have the qualifications necessary for their occupation.
ƒObserve all specifications in this documentation.
– This is the condition for safe and trouble−free operation and the achievement of
the specified product features.
– The procedural notes and circuit details described in this documentation are only
proposals. It is up to the user to check whether they can be transferred to the
particular applications. Lenze Automation GmbH does not accept any liability for
the suitability of the procedures and circuit proposals described.
ƒDepending on their degree of protection, some parts of the Lenze controllers
(frequency inverters, servo inverters, DC speed controllers) and their accessory
components can be live, moving and rotating during operation. Surfaces can be hot.
– Non−authorised removal of the required cover, inappropriate use, incorrect
installation or operation, creates the risk of severe injury to persons or damage to
material assets.
– For more information, please see the documentation.
ƒHigh amounts of energy are produced in the controller. Therefore it is required to
wear personal protective equipment (body protection, headgear, eye protection, ear
protection, hand guard).

Safety instructions
General safety and application notes for Lenze controllers
2

10 EDKVF93−01 EN 3.0
Application as directed
Controllers are components which are designed for installation in electrical systems or
machines. They are not to be used as domestic appliances, but only for industrial purposes
according to EN 61000−3−2.
When controllers are installed into machines, commissioning (i.e. starting of the operation
as directed) is prohibited until it is proven that the machine complies with the regulations
of the EC Directive 2006/42/EC (Machinery Directive); EN 60204 must be observed.
Commissioning (i.e. starting of the operation as directed) is only allowed when there is
compliance with the EMC Directive (2004/108/EC).
The controllers meet the requirements of the Low−Voltage Directive 2006/95/EC. The
harmonised standard EN 61800−5−1 applies to the controllers.
The technical data and supply conditions can be obtained from the nameplate and the
documentation. They must be strictly observed.
Warning: Controllers are products which can be installed in drive systems of category C2
according to EN 61800−3. These products can cause radio interferences in residential areas.
In this case, special measures can be necessary.
Transport, storage
Please observe the notes on transport, storage, and appropriate handling.
Observe the climatic conditions according to the technical data.
Installation
The controllers must be installed and cooled according to the instructions given in the
corresponding documentation.
The ambient air must not exceed degree of pollution 2 according to EN 61800−5−1.
Ensure proper handling and avoid excessive mechanical stress. Do not bend any
components and do not change any insulation distances during transport or handling. Do
not touch any electronic components and contacts.
Controllers contain electrostatic sensitive devices which can easily be damaged by
inappropriate handling. Do not damage or destroy any electrical components since this
might endanger your health!

Safety instructions
General safety and application notes for Lenze controllers
2
11
EDKVF93−01 EN 3.0
Electrical connection
When working on live controllers, observe the applicable national regulations for the
prevention of accidents (e.g. VBG 4).
The electrical installation must be carried out according to the appropriate regulations
(e.g. cable cross−sections, fuses, PE connection). Additional information can be obtained
from the documentation.
This documentation contains information on installation in compliance with EMC
(shielding, earthing, filter, and cables). These notes must also be observed for CE−marked
controllers. The manufacturer of the system is responsible for compliance with the limit
values demanded by EMC legislation. The controllers must be installed in housings (e.g.
control cabinets) to meet the limit values for radio interferences valid at the site of
installation. The housings must enable an EMC−compliant installation. Observe in
particular that e.g. the control cabinet doors have a circumferential metal connection to
the housing. Reduce housing openings and cutouts to a minimum.
Lenze controllers may cause a DC current in the PE conductor. If a residual current device
(RCD) is used for protection against direct or indirect contact for a controller with
three−phase supply, only a residual current device (RCD) of type B is permissible on the
supply side of the controller. If the controller has a single−phase supply, a residual current
device (RCD) of type A is also permissible. Apart from using a residual current device (RCD),
other protective measures can be taken as well, e.g. electrical isolation by double or
reinforced insulation or isolation from the supply system by means of a transformer.
Operation
If necessary, systems including controllers must be equipped with additional monitoring
and protection devices according to the valid safety regulations (e.g. law on technical
equipment, regulations for the prevention of accidents). The controllers can be adapted to
your application. Please observe the corresponding information given in the
documentation.
After the controller has been disconnected from the supply voltage, all live components
and power terminals must not be touched immediately because capacitors can still be
charged. Please observe the corresponding stickers on the controller.
All protection covers and doors must be shut during operation.
Safety functions
Certain controller versions support safety functions (e.g. "Safe torque off", formerly "Safe
standstill") according to the requirements of the EC Directive 2006/42/EC (Machinery
Directive). The notes on the integrated safety system provided in this documentation must
be observed.
Maintenance and servicing
The controllers do not require any maintenance if the prescribed operating conditions are
observed.
Disposal
Recycle metal and plastic materials. Ensure professional disposal of assembled PCBs.
The product−specific safety and application notes given in these instructions must be
observed!

Safety instructions
Thermal motor monitoring
2

12 EDKVF93−01 EN 3.0
2.2 Thermal motor monitoring
Note!
From software version 8.1 onwards, the 9300 vector controllers are provided
with an I2xt function for sensorless thermal monitoring of the connected
motor.
ƒI2xt monitoring is based on a mathematical model which calculates a
thermal motor utilisation from the detected motor currents.
ƒThe calculated motor utilisation is saved when the mains is switched off.
ƒThe function is UL−certified, i.e. additional protective measures for the motor
are not required in UL−approved systems.
ƒNevertheless, I2xt monitoring does not provide full motor protection
because other influences on the motor utilisation such as changes in the
cooling conditions (e.g. cooling air flow interrupted or too warm) cannot be
detected.
Die I2x t load of the motor is displayed in C0066.
The thermal loading capacity of the motor is expressed by the thermal motor time
constant (t, C0128). Find the value in the rated motor data or contact the manufacturer of
the motor.
The I2x t monitoring has been designed such that it will be activated after 179 s in the
event of a motor with a thermal motor time constant of 5 minutes (Lenze setting C0128),
a motor current of 1.5 x INand a trigger threshold of 100 %.
Two adjustable trigger thresholds provide for different responses.
ƒAdjustable response OC8 (TRIP, warning, off).
– The trigger threshold is set in C0127.
– The response is set in C0606.
– The response OC8, for instance, can be used for an advance warning.
ƒFixed response OC6−TRIP.
– The trigger threshold is set in C0120.
Behaviour of the I2x t monitoring Condition
The I2x t monitoring is deactivated.
C0066 is set = 0 % and
MCTRL−LOAD−I2XT is set = 0.00 %.
When C0120 = 0 % and C0127 = 0 %, set controller
inhibit.
I2x t monitoring is stopped.
The current value in C0066 and at the
MCTRL−LOAD−I2XT output is frozen.
When C0120 = 0 % and C0127 = 0 %, set controller
enable.
I2x t monitoring is deactivated.
The motor load is displayed in C0066.
Set C0606 = 3 (off) and C0127 > 0 %.
Note!
An error message OC6 or OC8 can only be reset if the I2x t load falls below the
set trigger threshold by 5 %.

Safety instructions
Thermal motor monitoring
Forced ventilated or naturally ventilated motors
2
13
EDKVF93−01 EN 3.0
2.2.1 Forced ventilated or naturally ventilated motors
Parameter setting
The following codes can be set for I2x t monitoring:
Code Meaning Value range Lenze setting
C0066 Display of the I2x t load of the motor 0 ... 250 % −
C0120 Threshold: Triggering of error "OC6" 0 ... 120 % 0 %
C0127 Threshold: Triggering of error "OC8" 0 ... 120 % 0 %
C0128 Thermal motor time constant 0.1 ... 50.0 min 5.0 min
C0606 Response to error "OC8" TRIP, warning, off Warning
Calculate release time and I2xt load
Formula for release time Information
t+*(t) ln
ȧ
ȧ
ȡ
Ȣ
1*z)1
ǒIMot
INǓ2
 100
ȧ
ȧ
ȣ
Ȥ
IMot Actual motor current (C0054)
IrRated motor current (C0088)
tThermal motor time constant (C0128)
zThreshold value in C0120 (OC6) or C0127 (OC8)
Formulae for I2x t load Information
L(t) +ǒIMot
INǓ2
100% ǒ1*e*t
tǓ
L(t) Chronological sequence of the I2x t load of the motor
(Display: C0066)
IMot Actual motor current (C0054)
Ir Rated motor current (C0088)
tThermal motor time constant (C0128)
If the controller is inhibited, the I2x t load is reduced:
L(t) +LStart e*t
t

ǸLStart I2x t load before controller inhibit
If an error is triggered, the value corresponds to the
threshold value set in C0120 (OC6) or C0127 (OC8).
Read release time in the diagram
Diagram for detecting the release times for a motor with a thermal motor time constant
of 5 minutes (Lenze setting C0128):
I = 3 × I
Mot N
0
50
100
120
0 100 200 300 400 500 600 700 800 900 1000
t [s]
L [%] I = 2 × I
Mot N I = 1.5 × I Mot N I = 1 × I
Mot N
9300STD105
Fig. 2−1 I2× t−monitoring: Release times for different motor currents and trigger thresholds
IMot Actual motor current (C0054)
IrRated motor current (C0088)
LI
2x t load of the motor (display: C0066)
T Time

Safety instructions
Thermal motor monitoring
Self−ventilated motors
2

14 EDKVF93−01 EN 3.0
2.2.2 Self−ventilated motors
Due to the construction, self−ventilated standard motors are exposed to an increased heat
generation in the lower speed range compared to forced ventilated motors.
Warnings!
For complying with the UL 508C standard, you have to set the
speed−dependent evaluation of the permissible torque via code C0129/x.
Parameter setting
The following codes can be set for I2x t monitoring:
Code Meaning Value range Lenze setting
C0066 Display of the I2x t load of the motor 0 ... 250 % −
C0120 Threshold: Triggering of error "OC6" 0 ... 120 % 0 %
C0127 Threshold: Triggering of error "OC8" 0 ... 120 % 0 %
C0128 Thermal motor time constant 0.1 ... 50.0 min 5.0 min
C0606 Response to error "OC8" TRIP, warning, off Warning
C0129/1 S1 torque characteristic I1/Irated 10 ... 200 % 100 %
C0129/2 S1 torque characteristics n2/nrated 10 ... 200 % 40 %
Effect of code C0129/x
0
0.9
0 0.1
C0129/2
0.2 0.3 0.4
0.6
0.7
0.8
1.0
1.1
1
0
0.132
2
I/ IN
n/ nN
C0129/1
3
9300STD350
Fig. 2−2 Working point in the range of characteristic lowering
The lowered speed / torque characteristic (Fig. 2−2) reduces the permissible thermal load
of self−ventilated standard motors. The characteristic is a line the definition of which
requires two points:
ƒPoint : Definition with C0129/1
This value also enables an increase of the maximally permissible load.
ƒPoint : Definition with C0129/2
With increasing speeds, the maximally permissible load remains unchanged
(IMot = Irated).
In Fig. 2−2, the motor speed and the corresponding permissible motor torque () can be
read for each working point (on the characteristic () ... ). can also be calculated
using the values in C0129/1and C0129/2 (evaluation coefficient "y", 15).

Safety instructions
Thermal motor monitoring
Self−ventilated motors
2
15
EDKVF93−01 EN 3.0
Calculate release time and I2xt load
Calculate the release time and the I2x t load of the motor considering the values in
C0129/1 and C0129/2(evaluation coefficient "y").
Formulae for release time Information
y+100% *C0129ń1
C0129ń2 n
nN)C0129ń1
T+*(t) ln
ȧ
ȧ
ȡ
Ȣ
1*z)1
ǒIMot
y INǓ2
 100
ȧ
ȧ
ȣ
Ȥ
TRelease time of the I2x t monitoring
tThermal motor time constant (C0128)
In Function: Natural logarithm
IMot Actual motor current (C0054)
IrRated motor current (C0088)
zThreshold value in C0120 (OC6) or C0127 (OC8)
yEvaluation coefficient
nrated Rated speed (C0087)
Formulae for I2x t load Information
L(t) +ǒIMot
y INǓ2
100% ǒ1*e*t
tǓ
L(t) Chronological sequence of the I2x t load of the motor
(Display: C0066)
yEvaluation coefficient
IMot Actual motor current (C0054)
Ir Rated motor current (C0088)
tThermal motor time constant (C0128)
If the controller is inhibited, the I2x t load is reduced:
L(t) +LStart e*t
t

ǸLStart I2x t load before controller inhibit
If an error is triggered, the value corresponds to the
threshold value set in C0120 (OC6) or C0127 (OC8).

Safety instructions
Residual hazards
2

16 EDKVF93−01 EN 3.0
2.3 Residual hazards
Protection of persons
ƒBefore working on the controller, check that no voltage is applied to the power
terminals:
– Because the power terminals V, W, +UGand −UGremain live for at least 3 minutes
after disconnecting from mains.
– Because the power terminals L1, L2, L3; U, V, W, +UGand −UGremain live when the
motor is stopped.
ƒThe leakage current to earth (PE) is >3.5 mA. According to EN 61800−5−1
– a fixed installation is required,
– a double PE connection is required, or, if there is only a single PE connection, the PE
conductor must have a cross−section of at least 10 mm2.
ƒThe heat sink of the controller has an operating temperature of > 80 °C:
– Contact with the heatsink results in burns.
ƒIf you use the "flying−restart circuit" function (C0142 = 2, 3) for machines with a low
moment of inertia and minimum friction:
– After controller enable in standstill, the motor may start or change its direction of
rotation for a short time, because the flying restart process also is carried out at a
speed of 0.
ƒDuring parameter set transfer, the control terminals of the controller can have
undefined states!
– Therefore the plugs X5 and X6 must be unplugged, before the transfer is executed.
This ensures that the controller is inhibited and all control terminals have the
defined "LOW" state.
Device protection
ƒFrequent mains switching (e.g. inching mode via mains contactor) can overload and
destroy the input current limitation of the drive controller:
– At least 3 minutes must pass between switching off and restarting the devices
EVS9321−xS and EVS9322−xS.
– At least 3 minutes must pass between two starting procedures of the devices
EVS9323−xS ... EVS9332−xS.
– Use the "safe torque off" safety function (STO) if safety−related mains
disconnections occur frequently. The drive variants Vxx4 are equipped with this
function.
Motor protection
ƒCertain drive controller settings can overheat the connected motor:
– E. g. long−time operation of the DC injection brake.
– Long−time operation of self−ventilated motors at low speeds.

Safety instructions
Residual hazards
2
17
EDKVF93−01 EN 3.0
Protection of the machine/system
ƒDrives can reach dangerous overspeeds (e. g. setting of high output frequencies in
connection with motors and machines not suitable for this purpose):
– The drive controllers do not provide protection against such operating conditions.
For this purpose, use additional components.

Safety instructions
Safety instructions for the installation according to UL
2

18 EDKVF93−01 EN 3.0
2.4 Safety instructions for the installation according to UL
Original − English
Warnings!
ƒMotor Overload Protection
– For information on the protection level of the internal overload protection
for a motor load, see the corresponding manuals or software helps.
– If the integral solid state motor overload protection is not used, external or
remote overload protection must be provided.
ƒBranch Circuit Protection
– The integral solid state protection does not provide branch circuit
protection.
– Branch circuit protection has to be provided externally in accordance with
corresponding instructions, the National Electrical Code and any
additional codes.
ƒPlease observe the specifications for fuses and screw−tightening torques in
these instructions.
ƒEVS9321  EVS9326:
– Suitable for use on a circuit capable of delivering not more than 5000 rms
symmetrical amperes, 480 V maximum, when protected by fuses.
– Suitable for use on a circuit capable of delivering not more than 50000 rms
symmetrical amperes, 480 V maximum, when protected by CC, J, T or R
class fuses.
– Maximum surrounding air temperature: 0 ... +55 °C
– > +40 °C: reduce the rated output current by 2.5 %/°C
– Use 75 °C copper wire only.

Safety instructions
Safety instructions for the installation according to UL
2
19
EDKVF93−01 EN 3.0
Original − French
Warnings!
ƒProtection du moteur contre les surcharges
– Pour obtenir des informations sur le niveau de protection offert par la
protection intégrée contre les surcharges du moteur, se reporter aux
manuels correspondants ou aux systèmes d’aide logiciels.
– Si la protection statique intégrée contre les surcharges du moteur n’est
pas utilisée, prévoir impérativement un dispositif de protection externe ou
séparé contre les surcharges.
ƒProtection par disjoncteur
– La protection statique intégrée n’offre pas la même protection qu’un
disjoncteur.
– Une protection par disjoncteur externe doit être fournie, conformément
aux indications fournies, au National Electrical Code et aux autres
dispositions applicables.
ƒSe conformer aux spécifications relatives aux fusibles et aux couples de
serrage contenues dans le présent document.
ƒEVS9321  EVS9326 :
– Convient aux circuits non susceptibles de délivrer plus de 5000 ampères
symétriques eff., maximum 480 V, avec protection par fusibles.
– Convient aux circuits non susceptibles de délivrer plus de 50000 ampères
symétriques eff., maximum 480 V, avec protection par des fusibles CC de
calibre J, T ou R.
– Température ambiante maximale : 0 ... +55 °C
– > +40 °C: ramener le courant assigné de sortie à 2,5 %/°C
– Utiliser exclusivement des conducteurs en cuivre 75 °C.

Parameter setting
Parameter setting with the XT EMZ9371BC keypad
General data and operating conditions
3
20 EDKVF93−01 EN 3.0
3 Parameter setting
3.1 Parameter setting with the XT EMZ9371BC keypad
Description
The keypad is available as an accessory. A full description of the keypad can be obtained
from the Instructions included in the keypad delivery.
Plugging in the keypad
It is possible to plug the keypad into the AIF interface or remove it during operation.
As soon as the keypad is supplied with voltage, it carries out a self−test. The keypad is ready
for operation if it is in display mode.
3.1.1 General data and operating conditions
YZ
y
z
T V
S U
dABbc
p
SHPRG
Para
Code
Menu
0050
00
50.00_Hz
MCTRL-NOUT
0
b
ca
9371BC011
Feature Values
Dimensions
Width a 60 mm
Height b 73.5 mm
Depth c 15 mm
Environmentalconditions
Climate
Storage IEC/EN 60721−3−1 1K3 (−25 ... +60 °C)
Transport IEC/EN 60721−3−2 2K3 (−25 ... +70 °C)
Operation IEC/EN 60721−3−3 3K3 (−10 ... +60 °C)
Enclosure IP 20
