Leviton ZW15R User manual

Getting Started Guide
Cat. No. ZW15R
TAMPER-RESISTANT
OUTLET
WEB VERSION

WEB VERSION

3
See the complete line of Z-Wave enabled dimmers, switches,
outlets, fan speed controllers and plug-ins at
leviton.com/decorasmart.
Welcome to the
Decora Smart™family of
Z-Wave®enabled devices
WEB VERSION

4
Welcome
The Decora Smart branded Z-Wave
enabled outlet is designed for
use with modern Z-Wave hubs.
This product can be operated in
any Z-Wave network with other
Z-Wave certified devices from other
manufacturers. Your outlet will
act as a repeater in the network to
increase the reliability of the network.
Using mesh networking technology,
Z-Wave provides quick reliable, secure
communication to a wide variety of
smart products.
The aesthetic will look at home with
your matching Decora®branded
electrical products. Tamper-resistant
outlets help protect against
electrical injuries. An integrated
vanishing status light provides simple
indications of your outlet's status as
well as assistance joining the network
and setting up your outlet.
CALL
1-800-824-3005 (USA)
1-800-405-5320 (Canada)
ONLINE
decorasmartsupport.leviton.com
CHAT
www.leviton.com/contactus
EMAIL
[e-mail]
We are here to help
WEB VERSION

5
5
What you need
to make it work:
RATINGS
General Use 15A - 120VAC, 50/60Hz
Magnetic 15A - 120VAC, 50/60Hz
LED/CFL 5A - 120VAC, 50/60Hz
Incandescent 1500W - 120VAC, 50/60Hz
Motor 3/4 HP - 120VAC, 50/60Hz
Operating Temp 0°C - 40°C (32°F - 104°F)
Operating Humidity 0-90% non-condensing
NETWORK
Z-Wave Plus 908.42 MHz
To install and use your Z-Wave enabled outlet.
1. A Z-Wave compatible hub.
2. A Z-Wave mesh network to join within 30 feet of
installation location.
3. An available interior wallbox with a hot, neutral,
and ground wire.
WARNING: Do not use with aluminum wire.
To ensure proper communication do not use with
metal wallplates.
4. Compatible with outlet loads up to 15A.

GROUND
LINE
NEUTRAL
WEB VERSION

6
Features
Controlled Outlet
Press the button or use
an app command to turn
the outlet on/o.
Status Light
Illuminates when
the outlet is o.
Tamper-Resistant
Built-in shutters help prevent
the insertion of unintended
foreign objects.
Integrated Button
Provides manual control
as well as setup and
configuration.
Powered Outlet
The bottom outlet
is always on.
WEB VERSION

7
For additional support use the support
options in the My Leviton app or contact
technical services (page 4).
NOTE: Z-Wave is a mesh network. Ensure
your device is installed within 30 feet of
the hub or another Z-Wave enabled device.
Communication through exterior surfaces will
likely reduce transmission distances.
WARNING: TO AVOID FIRE, SHOCK OR DEATH, turn o power at the
circuit breaker.
1. Work on only one connection at a time.
2. Connect wires as shown.
NOTE: Wire sizes for Hot and Neutral must be #14-12 AWG. Strip length is
marked on the device. Tighten terminal screws to 14 in-lbs (1.6 N-m).
Installation
If your back box looks dierent,
consult an electrician
GROUND
From Branch Circuit
NEUTRAL
LINE
WEB VERSION

8
Test and install
1. Gently push wires into wall box. Do not overtighten
wallbox screws.
2. Install wallplate base and snap on Decora wallplate.
3. Restore power.
Congratulations!
Your Z-Wave enabled outlet
is ready to control your fixture.
WEB VERSION

9
SmartStart
Your Decora Smart branded outlet is compatible with
SmartStart
SmartStart enabled products can be added into a Z-Wave network by
scanning the Z-Wave QR Code found on the top of the outlet or the
back of the box with a controller providing SmartStart inclusion.
No further action is required and the SmartStart product will be added
automatically within 10 minutes of being switched on and in the
network vicinity.
The QR Code and DSK is found on
the side of the outlet. If required,
the pin code is underlined on
the label.
This image is an example, please
use the code found on the
product or product packaging.
WEB VERSION

10
Add your outlet to a hub
Leviton Decora Smart branded Z-Wave enabled products support two
methods of inclusion. When using a Z-Wave Plus certified controller
choose Network Wide Inclusion or SmartStart. If network wide
inclusion does not discover your device, try classic inclusion.
Network Wide Inclusion to A Z-Wave Network
Modern Z-Wave Plus hubs support network wide inclusion which allows
your device to be included into the network using devices already
paired to your home automation hub.
Start with the devices closest to the hub and work your way
outward.
1. To enter programming mode, hold the button for 7 seconds. The status
light will turn amber. Release and the status light will blink.
2. Tap the button 1 time. The status light will quickly flash green.
3. The outlet is now ready to learn into the Z-Wave network. Follow directions
for the Z-Wave controller to complete the process.
4. Upon successful addition to network the status light will turn o and then
flash green 4 times. If it was not successfully added to the network, the
status light will flash red 4 times.
Classic Inclusion To A Z-Wave Network
For older controllers Classic Inclusion is supported. Depending on the age of
the controller it will need to be 3 to 35 feet from the device when including.
1. To enter programming mode, hold the button for 7 seconds. The status
light will turn amber. Release and the status light will blink.
2. Follow the Z-Wave controller instructions to enter inclusion mode.
3. Tap the button one time. The status light will quickly flash green.
4. The Z-Wave controller will confirm successful inclusion to the network.
