Life & Mobility Rollit User manual

Inspired by life
USER MANUAL
ROLLIT

EN3
Inspired by life
Preface
EN3
The Rollit is a comfortable and sturdy wheelchair for
permanent use. A solid base frame also makes the
Rollit suitable for intensive use. This practical “no
nonsense” wheelchair combines extreme durability
with superb comfort seating and riding behaviour.
The Rollit is easy to use for both user and attendant.
The wheelchair can be adjusted for a specific user by
using additional parts and accessories.
The Rollit is resistant to water splashes and is suitable
for indoor and outdoor use.
The maximum occupant weight is 160 kg.
The Rollit has not been tested in accordance with ISO
7176-19. For this reason, Life & Mobility recommends
that the wheelchair does not have an occupant when
it is transported by taxi.
Attention:
nRead this user manual carefully before using the
wheelchair.
nWhen you see this symbol in the manual, it
indicates there is an additional instruction.
Always follow these instructions. Negligence may
adversely affect the operation of the wheelchair
and may cause physical injury or damage to the
wheelchair or the environment.

EN4 EN5
Inspired by life
Safety instructions
EN5
As the user of the wheelchair, you are always
responsible for complying with the applicable safety
instructions and guidelines.
Life & Mobility accepts no liability for any loss or injury
caused by negligence or by failure to comply with the
safety instructions.
General
Warning:
nNever change the construction of the wheelchair.
nKeep the wheelchair away from open fire.
Attention:
nThis wheelchair is suitable for transporting a single
person.
nOnly use original Life & Mobility parts and
accessories.
nNever cover or remove the safety instructions and
stickers.
Personal requirements
Attention:
nYour vision must be good enough to ride the
wheelchair safely in any possible situation.
Assembly and adjustment
(see also the chapter ‘Settings and adjustments’)
Warning:
nBefore using the wheelchair, check that all its parts
are properly mounted and secured.
Table of Contents
EN4
Safety instructions 5
Checking the delivery 9
Technical specifications 10
Product description 11
Options 12
Settings and adjustments 14
Use 16
Maintenance 18
Technical problems 19
Guarantee 20
Disposal of product and packaging 21

EN6 EN7
Inspired by life
Safety instructions
EN7
nWhen transporting the wheelchair, always make
sure you are seated in a fixed seat of the motor
vehicle.
Attention:
nOnly lift the wheelchair using fixed parts of the
frame; do not use the removable accessories such
as armrests, footrests, etc.
Slopes and other obstacles
(see also page 17 for more information)
Attention:
nThe risk of the wheelchair tipping over on a slope
is greater than on a flat surface.
nAlways reverse backwards down a step so that the
wheelchair cannot tip forward and let you fall.
nNever ride the wheelchair on stairs by yourself.
nNever ride on a slope with an angle of more than
5 degrees.
nAsk for help from bystanders when you are not sure
that you can reach the highest point by yourself.
nThe attendant pushing the wheelchair must
continue to push the wheelchair to prevent it
running away.
nDo not turn around on a steep slope. If the
wheelchair is at the diagonal on a steep slope, it
will significantly increase the risk of tipping.
nWhen going down a slope, always keep your
speed under control.
nThe assistant must brake the wheelchair using the
push bars.
nWhen moving the wheelchair by yourself, only
use your hands on the handrims to brake and do
not use the tyre brake. Otherwise, you risk losing
control of the wheelchair.
Steps
Slope
Safety instructions
EN6
Sitting in the wheelchair
Warning:
nMake sure the fingers and limbs of the person in
the wheelchair do not get trapped. Always be very
careful:
- When the occupant is sitting lopsided in the
wheelchair.
- When the occupant’s arms hang limply over the
armrest.
- When both of the above occur.
nAn incorrect sitting posture can cause points
of pressure. If you are uncertain about this then
immediately contact your doctor or therapist.
Driving the wheelchair
Attention:
nWhen driving up a slope, the centre of gravity will
shift and the wheelchair can tip backwards more
easily.
nPay attention to your hands when using the
handrims if there is not much room at the side(s)
of the wheelchair.
nAssistants must never leave the wheelchair on a
slope without applying the brakes.
nNever tackle obstacles higher than 10 cm on
your own. Only practised wheelchair riders that
have sufficient strength are usually able to tackle
obstacles higher than 10 cm.
nSet the brake on the wheelchair before getting
into or out of the wheelchair.
nOnly use the brake to lock the wheels when
standing still. The brake is not suitable for braking
the wheelchair.
Transporting the wheelchair
Extremely dangerous:
nThe wheelchair is not Crash Test Safe, which means
it is not suitable transportation in a taxi when the
wheelchair is carrying an occupant.

EN8 EN9
Inspired by life
Checking the delivery
Before using the wheelchair, check that the delivery
matches the product description on page 11. If you
find any transport damage on delivery, please inform
your dealer. Life & Mobility trusts that the wheelchair
meets your expectations and hopes it brings you
much convenience.
Checking the deliverySafety instructions
Miscellaneous
Warning:
nDo not put the wheelchair in direct sunlight: the
upholstery can overheat and may cause burns or
irritation to the skin.
Be careful:
nDo not allow the wheelchair to come in contact
with seawater as it is corrosive and will rust the
wheelchair.
nDo not allow the wheelchair to come in contact
with sand, as it may penetrate into the moving
parts of the wheelchair, causing unnecessarily fast
wear and tear.

EN10 EN11
Inspired by life
Product description
EN11
Product description
1. Push bar
2. Padded backrest
3. Handrim (semi-solid rear wheel)
4. Foldable side with padded armrest
5. Padded seat
6. Extended handbrake
7. Tipping lever
8. Front wheel (semi-solid)
9. Foot support + heel strap
1
3
7
5
2
4
6
8 9
Technical specifications
nSeat width (SW): 47 - 52 cm
nSeat height (SH): 51 - 56 cm
nSeat depth (SD) 46 cm
nBack height (BH): 47 cm
nArmrest height (AH): 24 cm
nWheelchair width (WW): 72 cm
nPush handle height (PH): 92 - 97 cm
nLower leg length (LL): 45 - 55 cm
nTotal weight: 39 kg
nMaximum occupant weight: 160 kg
Life & Mobility recommends using the wheelchair at
an ambient temperature between -5˚C and +40˚C.
SD
SH
PH
AH
LL
WW
SW
BH

EN12 EN13
Inspired by life
Options
nAccessories (not illustrated)
- Catheter hook
- Oxygen bottle holder 12.5 cm
- Crutch holder
- Anti-tipping supports
- Spoke protectors with printed logo
- Infusion pole, height adjustable
- Anti-theft pole
Options
Options (not illustrated)
In addition to the standard parts, the following options
are available for the wheelchair:
nSides
- Foldable sides with height adjustable armrests
- Fastening set for sides
nWorktop
- Perspex worktop
- Wooden worktop
- College worktop
- Elbow padding
nSeat
- Plank seat (with lip)
- Contour+ seat
nBackrest
- Anatomical backrest
nLeg rests
- Comfort legrest (with heel strap)
- Knee cushion
- Plaster cast legrest
- Amputation support
nHeadrest
- Standard headrest small

EN14 EN15
Inspired by life
Settings and adjustments
EN15
Lower leg length adjustment
1. Unscrew the socket screw or star grip (A)
by one turn.
2. Set the desired lower leg length.
Attention:
nAllow for a distance of at least 5 cm to
the floor.
3. Tighten the socket screw or star grip (A).
Lower leg length
A
Settings and adjustments
EN14
The wheelchair can be adjusted in various way
to meet your particular needs. The adjustments
are easy to carry out by yourself.
Attention:
nCheck whether the sides are secured in the
holders and not to the sides. Otherwise, it
may damage the sides and wheels.
Fold up the sides
Grasp and lift the front of the armrest and fold
the entire side to the back.
Removing the leg rests
The leg rests are easy to remove from the frame.
Grasp the section it is hung on and remove with
an upwards motion.
Swinging the leg rests out
1. Lift the leg rest up a little.
2. Swing the leg rest to the side.
3. Lower the leg rest again.
Attention:
nMake sure the foot plates are folded up
before you get out of the wheelchair. Never
stand on the foot plates. Otherwise, you risk
toppling forward in the wheelchair.
nNever use the foot plates to step into the
wheelchair. Swinging the leg rests out
Fold up the sides
Removing the leg rests

EN16 EN17
Inspired by life
Negotiating obstacles with an attendant
1. Push the step tube down with your foot and push
the handles down with your hands.
2. Push the wheelchair onto the elevation (obstacle)
and take your foot off the step tube.
3. Push the wheelchair further and lift the rear wheels
over the obstacle with the push handles.
Go up steps forward and down steps backward.
Attention:
nKeep speed under control when going down a
gentle slope.
Brakes
The wheelchair brakes are adjusted to the proper set-
ting at the factory as standard. Life & Mobility recom-
mends that you always use both brakes when getting
in or out of the wheelchair.
Steps
Slope
UseUse
Headrest
Removing and fitting the headrest*
The headrest can be removed easily:
1. Unscrew the star grip until loose.
2. Remove the headrest.
Putting it back in place:
3. Place the headrest in the holder.
4. Screw fast the star grip.
* If present
Making transfers
The Rollit is a wheelchair for users with various limi-
tations. Transfers from the wheelchair to the bed,
toilet or shower, and so on, and vice versa, can be
carried out in different ways.
The lifting method depends on the degree to
which the wheelchair user can cooperate. The
wheelchair enables both active and passive trans-
fers with or without the help of an assistant or a lift.
Attention:
nAlways set the brake on the wheelchair before
making a transfer.
Transfer from the front
1. Fold up the foot plates. Or, if necessary, swing
out the foot rests.
2. Engage the wheelchair brake.
Transfer from the side
If necessary, fold the sides fitted with arm rests up
and backwards.

EN18 EN19
Inspired by life
Technical problems
EN19
Should your wheelchair be subject to unexpected
technical problems, we advise you to contact
your dealer. The dealer will assess whether he can
repair the chair or whether the wheelchair has to
be returned to the manufacturer for repairs.
You may be able to solve a number of problems
yourself.
Moving parts, such as, arm rest, foot/leg rests,
and sides will not move:
nThe above-mentioned parts may have
become stuck in the frame when excessive
force was used on these parts. Carefully
tap the components using a plastic
hammer.
The brakes do not have sufficient braking power
or the brakes on either side do not have the same
braking power:
nYou must have the brakes adjusted.
Consult your dealer for this task.
Attention:
nAll repairs other than those mentioned above
always should be carried out by a certified
dealer. Careless repairs can endanger your
health. Moreover, the warranty on the product
will be cancelled. Use common sense and
decide whether you yourself are capable of
solving technical problems of the chair. Always
consult your dealer if you have any doubt.
When fitting and replacing parts, you must
comply with this manual and your dealer’s
advice. Prevent any hazardous situation
occurring for the assistant and the occupant
of the chair!
Maintenance
EN18
Minor maintenance (every 2 weeks)
You can perform minor maintenance on the Rollit
yourself.
Cleaning
Clean your wheelchair with a damp cloth, water and
multi-purpose cleaner.
Attention:
nNever use abrasive or harsh cleaning products
or solvents, such as thinner, benzine (a.k.a. white
spirit), etc.
Check that all fastening parts are properly fastened.
Re-tighten them if necessary.
Attention:
nTightening the adjustment screw too much can
damage the wheelchair.
Disinfecting
You may use alcohol (70%) or chlorine (1,000 ppm) to
disinfect the wheelchair.
Wheeltension
Check the wheel tension on a regular basis (once
per quarter, depending on the intensity of use) to
make sure that your wheelchair continues to ride
comfortably and safely. Ask you dealer for assistance
if necessary.
Major maintenance (annual)
Your dealer would be happy to handle the major
maintenance for your wheelchair. That way you are
certain you are getting the best possible use from
your wheelchair. You can also go to your dealer for
parts replacement.

EN20 EN21
Inspired by life
Disposal of product and packaging
EN21
Disposal of product and packaging
From an environmental perspective, we recommend
that you dispose of the packaging and the wheelchair
by separating the waste as much as possible, allowing
the waste materials to be recycled efficiently.
In most cases you can hand in your used wheelchair to
your wheelchair dealer. If this is not possible, you can
hand in the wheelchair at your local waste collection
station.
Guarantee
EN20
Terms and Conditions of Warranty
The Life & Mobility products are made with care and
are carefully inspected before leaving the factory.
Should it emerge that a product does not meet
expectations please contact the party where you
purchased the product.
Life & Mobility respects the laws and regulations that
protect the consumer and that apply in the country in
which the product is purchased.
The warranty does not apply to defects caused
by: failure to observe the instructions for use and
maintenance, use other than normal use, wear and
tear, negligence, overloading, third-party accidents,
non-original parts used and defects not caused by the
product.
This warranty replaces any other warranty, either
stipulated by law or communicated verbally, except
for anything guaranteed in writing by Life & Mobility.
Warranties are only valid within the EU.

EN22
Inspired by life
This manual has been prepared with the utmost care
and is based on information known to Life & Mobility
at the time of publication. Life & Mobility accepts no
liability for any errors in the text or the consequences
thereof.
The information in this manual applies to the standard
version of the product. Life & Mobility accepts no
responsibility for any damage that may occur due to
changes or modifications to the product after it has
been sold for the first time. Neither can Life & Mobility
be held liable for any damage caused by third-party
work.
The information in this manual may not be reproduced
and/or made public by any means without prior
written permission from Life & Mobility.
Pursuant to the Dutch Trade Names Act, the trade
name and trademarks used by Life & Mobility may not
be considered free.
No rights can be derived from this text. Subject to
changes.
© Life & Mobility –All rights reserved

03/2020 - 111075AF
Life & Mobility bv
PO Box 304
NL - 7000 AH Doetinchem
Logistiekweg 7
7007 CJ Doetinchem
T [phone]
www.life-mobility.com
[e-mail]
