Life Fitness Basic Workouts Console User manual

Basic and Advanced Workouts Consoles
for non-treadmill units
Customer Support Services
PARTS MANUALrev 11 Apr 2008

2
External Front Components
Basic Console............................................................................................................... 3
Advanced Console........................................................................................................ 4
Internal Front Components
Basic Console .............................................................................................................. 5
Advanced Console ....................................................................................................... 6
Back Components (Basic and Advanced Consoles) ............................................................... 7
Non-treadmill Basic and Advanced Workouts Consoles
Contents

3
Basic Console
Front Assembly
(includes lens and label)
8152901
Basic Button Module Assembly
8042701
Non-treadmill Basic and Advanced Workouts Consoles
External Front Components (Basic Console)

4
Advanced Console
Front Assembly
(includes lens and label)
815280
1
Advanced Button
Module Assembly
8042601
Non-treadmill Basic and Advanced Workouts Consoles
External Front Components (Advanced Console)

5
Main Console PCB
8043601 Button Module PCB 8043801
Non-treadmill Basic and Advanced Workouts Consoles
Internal Front Components (Basic Console)

6
Main Console PCB
8043501
Button Module PCB
8043701
Telemetry PCB
8046001
Non-treadmill Basic and Advanced Workouts Consoles
Internal Front Components (Advanced Console)

7
Console Back
8041501
Console Mounting Screws
322600
1
Contact Heart Rate PC
B
8045901
Non-treadmill Basic and Advanced Workouts Consoles
Back Components (Basic and Advanced Consoles)
