Life Span NOVA User manual

NOTE: This manual may be subject to updates or changes. Up to date manuals are available through our website at www.lifespanfitness.com.au
Product may vary slightly from the item pictured due to model upgrades
Read all instructions carefully before using this product. Retain this owner’s manual for
future reference.
NOVA OWNER’S MANUAL

2
NOVA
TABLE OF CONTENTS
1. IMPORTANT SAFETY INSTRUCTIONS 3
2. IMPORTANT ELECTRICAL INFORMATION 4
3. IMPORTANT OPERATING INSTRUCTIONS 5
4. ASSEMBLY INSTRUCTIONS 6
5. FOLDING INSTRUCTIONS 10
6. OPERATION GUIDE 11
7. EXERCISE GUIDE 15
8. MAINTENANCE INSTRUCTIONS 17
9. EXPLODED DIAGRAM 25
10. PARTS LIST 26
11. TROUBLE SHOOTING GUIDE 27
12. WARRANTY 30

3
NOVA
1. IMPORTANT SAFETY INSTRUCTIONS
WARNING - Read all instructions before using this treadmill.
It is important your treadmill receives regular maintenance to prolong its useful life. Failing to
regularly maintain your treadmill may void your warranty.
Danger –To reduce the risk of electric shock disconnect your treadmill from the electrical outlet prior to
cleaning and/or service work.
DO NOT USE AN EXTENSION CORD: DO NOT ATTEMPT TO DISABLE THE GROUNDED PLUG BY
USING IMPROPER ADAPTERS OR IN ANY WAY MODIFY THE CORD SET.
Install the treadmill on a flat level surface with access to a 220-240 volt (50/60Hz), grounded outlet.
Do not operate treadmill on deeply padded, plush or shag carpet. Damage to both carpet and
treadmill may result.
Do not block the rear of the treadmill. Provide a minimum of 1 metre clearance between the rear of
the treadmill and any fixed object.
Place your unit on a solid, level surface when in use
When running, make sure the plastic clip is fastened on your clothing. It is for your safety, should
you fall or move too far back on the treadmill.
Keep hands away from all moving parts.
Never operate the treadmill if it has a damaged power cord or plug. When damaged, these must be
replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a
hazard.
Keep the cord away from heated surfaces.
Do not operate where aerosol spray products are being used or where oxygen is being
administered. Sparks from the motor may ignite a highly gaseous environment.
Never drop or insert any object into any openings.

4
NOVA
The treadmill is intended for in-home use only and not suitable for long term running.
To disconnect, turn all controls to the off position, remove the safety key, and then remove the plug
from the outlet.
The pulse sensors are not medical devices. Various factors, including the user’s movement, may
affect the accuracy of heart rate readings. The pulse sensors are intended only as exercise aids in
determining heart rate trends in general.
Use the handrails provided; they are for your safety.
Wear proper shoes. High heels, dress shoes, sandals or bare feet are not suitable for use on your
treadmill. Quality athletic shoes are recommended to avoid leg fatigue.
Before undertaking any type of exercise program, it is recommended that you consult a doctor.
Injuries to health may result from incorrect or excessive training.
This appliance is not intended for use by persons (including children) with reduced physical, sensory
or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a person responsible for their safety.
WARNING heat rate monitoring systems may be inaccurate. If you feel faint stop exercising
immediately.
Children should not be allowed on or around the equipment, even when not in use.
Children should be supervised to ensure that they do not play with this machine
Loose-fitting clothing or jewellery that could become an entanglement hazard should not be worn.
Training shoes should be worn when using the equipment.
Equipment must be used on a level and stable surface.
All fixings should be checked before the equipment is used.
All literature relating to the use of the equipment should be retained for future reference.
Allowed operating temperature: 5-40°C
Remove the safety key after use to prevent unauthorized treadmill operation.

5
NOVA
2. IMPORTANT ELECTRICAL INFORMATION
WARNING!
Route the power cord away from any moving part of the treadmill including the elevation mechanism
and transport wheels.
NEVER remove any cover without first disconnecting AC power.
NEVER expose this treadmill to rain or moisture. This treadmill is not designed for use outdoors,
near a pool, or in any other high humidity environment.
This is a high-power item; please do not share the same outlet with other high power machines such
as, fridges, air conditioning etc. Please choose an outlet exclusively for the machine and make sure
the fuse is 10A.
3. IMPORTANT OPERATING INSTRUCTIONS
Understand that changes in speed and incline do not occur immediately. Set your desired speed on
the computer console and release the adjustment key. The computer will obey the command
gradually.
Use caution while participating in other activities while walking on your treadmill, such as watching
television, reading, etc. These distractions may cause you to lose balance or stray from walking in
the centre of the belt; which may result in serious injury.
In order to prevent losing balance and suffering unexpected injury, never mount or dismount the
treadmill while the belt is moving. This unit starts with at a very low speed. Simply standing on the
belt during slow acceleration is proper after you have learned to operate this machine.
Always hold on to handrail while making control changes.
A safety key is provided with this machine. Remove the safety key will stop the walking belt
immediately; the treadmill will shut off automatically. Inserting the safety key will reset the display.
Do not use excessive pressure on console control keys. They are precision set to function properly
with little finger pressure.

6
NOVA
Replace any defective components immediately. The machine must be kept out of use until
repaired.
4. ASSEMBLY INSTRUCTIONS
PARTS LIST
NO.
Description
Specification
Nos.
NO.
Description
Specification
Nos.
1
Main Frame
1
64
Lock Washer
8
6
12
5#Allen Wrench
5mm
1
72
Oil bottle
1
70
Bolt
M8*45
2
71
Safety Key
1
51
Bolt
M8*16
4
75
Mp3
1
ASSEMBLY TOOLS:
5# Allen Wrench 5mm: 1pcs
Wrench with screw driver S=13,14,15: 1pcs

7
NOVA
STEP 1:
STEP 2:
1. Open the carton. Place the Main
Frame onto level ground.
1. Hold the console frame.
2. Using the 5#Allen Wrench, attach the
console frame onto the left and right
upright tube with bolt (51) & lock
washer (64)

8
NOVA
STEP 3:
STEP 4:
1. Erect the Upright
1. Using the 5# Allen wrench (12),
insert the Bolt M8*45 (70) through
the Lock Washer (64). Use this to
lock the left and right uprights to the
main frame.
2. Use the 5# Allen wrench (12) to
insert the M8*16 Bolt (51) through
the Lock Washer (64) and then into
the assembly to further secures the
upright/main frame assembly.
Reference the picture left.
Attention: Hold the upright tubes when
attaching them to the main frame.

9
NOVA
STEP 5:
1. Attach the Safety Key (71) onto the
console

10
NOVA
5. FOLDING INSTRUCTIONS
Folding:
Unfolding:
Place your hand on position (A), then pull
up the base frame until you hear the click
sound emitted when the air pressure bar
(B) is locked into the round tube.
Whilst supporting position A with our
hand, gently push the marked area on the
air pressure bar with your foot.
The base frame will descend
automatically. (Please keep people and
any pets away the machine during
descent)
Video Tutorial Available at:
http://youtu.be/cP9NtFHfWlc
Lifespan Fitness Channel:
http://www.youtube.com/user/treadmillsvideos

11
NOVA
6. OPERATION GUIDE
1. OVERVIEW
2. LCD WINDOW DISPLAY
1. Speed window: Shows speed and programs
2. Time window: Shows time
3. DIS window: shows distance
4. CALO window: shows calories
5. Pulse: shows the heart rate. When you hold the hand pulse sensor the window will show your heart
rate. Heart rate data is for reference ONLY.
3. BUTTON FUNCTIONS
“PROGRAM” button: Press this button to choose a program. Choose from manual mode, preset programs
(P1 - P12) and body fat tester (FAT).
“MODE” button: Press this button to choose a mode, Choose form time count down, distance count down
and calories count down;
“START” button: Press this button to start the machine. The machine will start at the lowest speed or at the

12
NOVA
speed of the default program after a 3 second time count down.
“STOP” button: Press this button to stop the machine, the machine will stop smoothly;
Pressing the STOP button once during your workout will pause the workout and data on the LCD will remain.
Press the START button to resume your workout. Instead of pressing START, you may clear the workout data
by pressing the STOP button a second time.
SPEED▲, ▼: Adjusts the speed. Press these buttons to adjust the speed when running and adjust the data
when stopped/
SPEED (2, 4, 6, 8, 10, 12): Adjust the speed quickly to the specified value
Left handle bar buttons: Start and stop button;
Right handle bar buttons: Adjusts speed;
3. MAIN FUNCTIONS
3.1. Quick Start-up (Manual):
Attach the safety key. After a 3 second countdown, the treadmill will starting and running from the lowest
speed, add and subtract to the speed using the SPEED button.
3.2. Countdown mode:
Press the MODE button to cycle options: time countdown, distance countdown, calories countdown. The
default value corresponds to the window and flashing display. At this point the SPEED buttons serve as a
plus and minus functions to adjust to the desired value. Press the START, add and subtract speed by
using SPEED buttons once again. When the countdown reaches 0, the machine will stop. You can also
directly press the STOP button or disconnect safety lock to stop.
3.3. Preset programs:
Press the program button; programs from P1 to P12 are built-in programs. The time window displays the
default value of TIME. When flashing, press the SPEED buttons to adjust to your desired time. Built-in
program are divided into 20 equal segments. After pressing the START button, the treadmill will
automatically cycle through the time segments. Speed will automatically adjust to the preset value for the
segment. Upon completion of the segments, the program will end, slowing the treadmill down to a stop.

13
NOVA
During the operation speed can be adjusted but the next segment will be automatically adjusted to the
program defaults. Built-in program data is listed on the table.
4. VALUE RANGE:
5. HEART RATE:
When holding the hand pulse with two hands, the pulse window will show your heart rate after 5 seconds.
To increase accuracy please check heart rate with the machine stopped and after keeping your hands on
the sensors for more than 30 seconds.
The heart rate data is for reference purposes ONLY.
6. PROGRAM CHART
TIME
PROGRAM
Total set time = 1/10th of the running time of each period
1
2
3
4
5
6
7
8
9
1
0
1
1
1
2
1
3
1
4
1
5
1
6
1
7
1
8
19
20
P01
SPEED
2
3
3
4
5
3
4
5
5
3
4
5
4
4
4
2
3
3
5
3
P02
SPEED
2
4
4
5
6
4
6
6
6
4
5
6
4
4
4
2
2
5
4
2
P03
SPEED
2
4
4
6
6
4
7
7
7
4
7
7
4
4
4
2
4
5
3
2
P04
SPEED
3
5
5
6
7
7
5
7
7
8
8
5
9
5
5
6
6
4
4
3
P05
SPEED
2
4
4
5
6
7
7
5
6
7
8
8
5
4
3
3
6
5
4
2
P06
SPEED
2
4
4
4
5
6
8
8
6
7
8
8
6
4
4
2
5
4
3
2
P07
SPEED
2
3
3
3
4
5
3
4
5
3
4
5
3
3
3
6
6
5
3
3
P08
SPEED
2
3
3
6
7
7
4
6
7
4
6
7
4
4
4
2
3
4
4
2
P09
SPEED
2
4
4
7
7
4
7
8
4
8
9
9
4
4
4
5
6
3
3
2
P10
SPEED
2
4
5
6
7
5
4
6
8
8
6
6
5
4
4
2
4
4
3
3
P11
SPEED
2
5
8
1
0
7
7
1
0
1
0
7
7
1
0
1
0
5
5
9
9
5
5
4
3
P12
SPEED
3
4
9
9
5
9
5
8
5
9
7
5
5
7
9
9
5
7
6
3
SET RANGE
INITIAL
DEFAULT
INITIAL DATA
DEFAULT
RANGE
RANGE
DISPLAY
TIME
0:00
15:00
5:00-99:00
0:00－99:59
SPEED（KM/H）
---
---
---
0．8-14
DISTANCE(KM)
0
1.00
0．5-99.9
0.00－99.9
HEART RATE
P
N/A
N/A
50-200
CALORIES
0
50.0
10.0-999
0－999

14
NOVA
7. BODY FAT TESTER
Press "PROGRAM” until the window displays "FAT".
Press "MODE" to select parameters after entering data (F1 = "SEX", F2 = "AGE", F3 = "HEIGHT", F4
= "WEIGHT").
Use "SPEED+/-" to set data. After entering all data the window will display "F5".
Place both hands on the hand sensors for 5 seconds, and the window will display your body fat data.
Input parameter display and setting limits
8. SLEEP FUNCTION:
The treadmill automatically enters sleep mode after 10 minutes of inactivity. Press any key on the display to
wake the treadmill.
PARAMETERS
ARRANGEMENT
NOTE
F-1
SEX
01--02
01= MALE 02= FEMALE
F-2
AGE
10—99 YEARS
F-3
HEIGHT
100—200 CM
F-4
WEIGHT
20—150 KGS
FA（BMI）
RESULT
≤19
UNDER WEIGHT
20--25
NORMAL WEIGHT
25--29
OVER WEIGHT
≥30
OBESE

15
NOVA
7. EXERCISE GUIDE
PLEASE NOTE: Before beginning any exercise program, consult your physician. This is important
especially if you are over the age of 45 or individuals with pre-existing health problems.
The pulse sensors are not medical devices. Various factors, including the user’s movement, may
affect the accuracy of heart rate readings. The pulse sensors are intended only as an exercise aid in
determining heart rate trends in general.
Exercising is great way to control your weight, improving your fitness and reduce the effect of aging and
stress. The key to success is to make exercise a regular and enjoyable part of your everyday life.
The condition of your heart and lungs and how efficient they are in delivering oxygen via your blood to your
muscles is an important factor to your fitness. Your muscles use this oxygen to provide enough energy for
daily activity. This is called aerobic activity. When you are fit, your heart will not have to work so hard. It will
pump a lot fewer times per minute, reducing the wear and tear of your heart.
So as you can see, the fitter you are, the healthier and greater you will feel.
Warm-up
Start each workout with 5 to 10 minutes of stretching and some light exercises. A proper warm-up increases
your body temperature, heart rate and circulation in preparation for exercise. Ease into your exercise.

16
NOVA
Training Zone Exercise
After warming up, increase the intensity to your desired exercise program. Be sure to maintain your intensity
for maximum performance. Breathe regularly and deeply as you exercise-never hold your breath.
Cool Down
Finish each workout with a light jog or walk for at least 1 minute. Then complete 5 to 10 minutes of
stretching to cool down. This will increase the flexibility of your muscles and will help prevent post-exercise
problems.
Workout Guidelines
TARGET ZONE
THIS IS HOW YOUR PULSE SHOULD BEHAVE DURING GENERAL FITNESS EXERCISE.
REMEMBER TO WARM UP AND COOL DOWN FOR A FEW MINUTES.
The most important factor here is the amount of effort you put in. The harder and longer you work, the more
calories you will burn. Effectively this is the same as if you were training to improve your fitness, the difference
is the goal.

17
NOVA
8. MAINTENANCE INSTRUCTIONS
Reasonable cleaning/lubricating should be made to extend the life time of this unit. Performance is
maximized when the belt and mat are kept as clean as possible.
WARNING: THE MAT/DECK FRICTION MAY PLAY A MAJOR ROLE IN THE FUNCTION AND LIFE OF
YOUR TREADMILL AND THAT IS WHY WE RECOMMEND YOU CONSTANTLY LUBRICATE THIS
FRICTION POINT TO PROLONG THE USEFUL LIFE OF YOUR TREADMILL. FAILING TO DO THIS
MAY VOID YOUR WARRANTY.
WARNING: UNPLUG POWER CORD BEFORE MAINTENANCE
WARNING: STOP TREADMILL BEFORE FOLDING
1. General Cleaning
Use a soft, damp cloth to wipe the edge of the belt and the area between the belt edge and frame. A
mild soap and water solution along with a nylon scrub brush will clean the top of the textured belt.
This task should be done once a month. Allow to dry before using.
On a monthly basis, vacuum underneath your treadmill to prevent dust build up. Once a year, you
should remove the black motor shield and vacuum out dirt that may accumulate.
2. General Care
Check parts for wear before use.
Pay particular attention to the fixing knobs and make sure they are tight.
Always replace the mat if worn and any other defective parts.

18
NOVA
If in doubt do not use the treadmill and contact us.
TAKE CARE TO PROTECT CARPETS AND FLOOR in case of leakages. This product is a machine that
contains moving parts which have been greased / lubricated and could leak.
3. Belt/Deck/Roller Lubrication
The mat/deck friction may play a major role in the function and life of your treadmill and that is why we
recommend you constantly lubricate this friction point to prolong the useful life of your treadmill. You should
apply lubrication after approximately the first 30 hours of operation. We recommend lubrication of the deck
according to the following timetable:
oLight use (less than 3 hours per week) every 6 months
oMedium use (3-5 hours a week) every 3 months
oHeavy use (more than 5 hours per week) every 6-8 weeks
See below procedures for lubricating:
1. Use a soft, dry cloth to wipe the area between the belt and deck.
2. Spread lubricant onto the inside surface of belt and deck evenly (make sure the machine is turned
off and power is disconnected).
3. Periodically lubricate the front and rear rollers to keep them at their peak performance. If the
treadmill belt/deck/roller is kept reasonably clean it is possible to expect over 1200 hours before
relubricating is necessary.
Video Tutorial Available at:
http://youtu.be/cP9NtFHfWlc
Lifespan Fitness Channel:
http://www.youtube.com/user/treadmillsvideos

19
NOVA
4. How to check the running mat for proper lubrication:
1. Disconnect the main power supply.
2. Fold the treadmill up into the storage position.
3. Feel the underside surface of the running mat.
If the surface is slick when touched, then no further lubrication is needed.
If the surface is dry to the touch, apply a suitable silicone lubricant.
We recommend that you use a silicone based spray to lubricate your Lifespan treadmill. This can be
purchased directly from us or any hardware store.

20
NOVA
5. Adjusting the Running Belt
A
B
C
Place treadmill on a level surface. Run treadmill
at approximately 4km/h, checking the running
condition.
If the belt has drifted to the right:
Whilst the treadmill is running at 4km/h,
carefully turn the right adjusting bolt 1/4 turn
clockwise. Then monitor treadmill until the belt
centers. Repeat until the belt correctly centers.
See Picture A
If you have over adjusted the belt and it drifts to
the right, carefully turn the right adjusting bolt
anticlockwise until the belt centers.
If the belt has drifted to the left:
Whilst the treadmill is running at 4km/h,
carefully turn the left adjusting bolt 1/4 turn
clockwise. Then monitor treadmill until the belt
centers. Repeat until the belt correctly centers.
See Picture B
If you have over adjusted it, carefully turn the
left adjusting bolt anticlockwise and until the
belt centers.
To adjust the tightness of the belt:
Turn the treadmill off. Turn both the left and right
adjusting bolts 1/4 turn clockwise. Repeat until
the belt correctly tightens.
See Picture C
If the belt is over tightened, simply do the
opposite to loosen.
