Light progress Uv-stick e2/75h-st-nx-nt User manual

LIGHT PROGRESS STICK-ST [Eng.]

Rev. 2 Oct 2020 Page 1of 15

UV-STICK E2/75H-ST-NX-NT

Germicidal UV-C Device for Disinfection by Direct

Irradiation Portable on wheels

MODELS:

UV-STICK E2/75H-ST-NX-NT

UV-STICK E2/75H-P-ST-NX -NT

LIGHT PROGRESS STICK-ST [Eng.]

Rev. 2 Oct 2020 Page 2of 15

SECURITY WARNING

Our Company has ensured that every care is taken in the design and production of its machinery. In order to

guarantee as far as possible, that it is safe when used correctly. However, the laws on accident prevention require all

users of the machinery to ensure that, whoever is responsible for installation, maintenance, use and sale of these

products is shown the instruction provided by our company and is made aware of the precautions to be taken.

According to the circumstances, the appropriate recommendations made in these instructions must be made

available, together with any other relative information, to any company or person involved in the installation of LIGHT

PROGRESS products.

Only use this appliance for its intended purpose as described in this booklet.

If the appliance is wrongly operated for a purpose other than that for which it is intended, no liability can be accepted

for any possible damage. The manufacturer and / or distributor cannot be responsible for any damage to people,

animals and objects caused by use or operation of the appliance contrary to these instructions.

As with all electrical appliances the safety information and precautions contained in this booklet must be carefully

observed, including following:

Before maintenance or cleaning ensure that the appliance is switched off and unplugged from the main supply.

Should the appliance become faulty please contact our authorized Service Centre direct and in case of repairs ask for

genuine parts.

Improper repairs may damage the appliance and place the user at serious risk.

WARNING

Avoid exposure to UV-C rays emitted by germicidal lamps, even

for few seconds, as it may cause severe conjunctivitis and

erythema.

Plastic or painted surfaces exposed to direct UV-C rays may

progressively yellow, similar to a long exposure to sunlight.

The intended use is as a germicidal lamp for sterilization, any

other use is improper and dangerous.

The lamp, as supplied, cannot be modified or designed for use

with accessories or tools.

Disclaimer: All responsibilities and warranty will be void due to

tampering or lack of maintenance.

• Carefully read the following instruction before use

• Before opening of the UV section, ensure the UVC device is OFF and unplugged in

order to avoid exposure to UVC light emitted by the germicidal lamp; It may cause

severe conjunctivitis and erythema.

• Remove the protection film from the device before turning on the UV-C lamp.

• This device cannot be operated by persons with reduced physical, sensory or metal

capacities.

• Ensure all users have the required knowledge and the related instructions about the safe

use of the device and the related risks.

Refer to ARPANSA Radiation Standard: Occupational Exposure to Ultraviolet Radiation for

additional requirements: https://www.arpansa.gov.au/sites/default/files/legacy/pubs/rps/rps12.pdf

LIGHT PROGRESS STICK-ST [Eng.]

Rev. 2 Oct 2020 Page 3of 15

CONVENTIONAL SYMBOLS

SUBSTITUTED ITEMS MUST BE PERFORMED RESPECTING THE LOCAL LAWS.

RECYCLE THE STUFFS THAT COMPOSES THIS PRODUCT.

OBLIGATION TO CONSULT THESE INSTRUCTIONS BEFORE USE THIS PRODUCT

DANGER OF ELECTRICAL SHOCK; REMOVE TENSION TO THE SYSTEM BEFORE

PERFORMING ANY OPERATION.

GENERIC DANGER.

DANGER OF EXPOSITION TO ULTRAVIOLET UV-C RAYS.

THIS DEVICE RESPECTS THE ROHS NORMS.

USE PROTECTIVE GLOVES

WEAR PROTECTIVE GLASSES

MANUAL

ATTENTION!

This instruction manual must be preserved and must always be kept available for consultation; it must follow

the device in case of transfer of ownership and accompany the device until its disposal.

DISPOSAL

Do not dispose of these products as unsorted municipal waste. Collect them separately as a special

waste and entrust them to specialized waste disposal companies. Disposal should be in accordance with

Legislative Decree No. 151/2005 (WEEE - Italy), or the law of the country where disposal will occur

(WEEE - EC). In case of failure to comply with laws or illegal disposal heavy penalties are provided. The

apparatus consists of plastic parts, electronic components, metal, UV lamps containing mercury (sub-

stances dangerous for the environment and human health). The dealer is available to the withdrawal of the apparatus

used.

LIGHT PROGRESS STICK-ST [Eng.]

Rev. 2 Oct 2020 Page 4of 15

DEVICE DESCRIPTION

The UV STICK E2/75H-ST-NX-NT is a dual lamp

germicidal device, placed on a stand with four wheels

for easy mobility. It works on direct radiation at 360

degrees and sterilizes irradiated air and surfaces. The

UV-C lamps, with an emission peak at 235.7 nm.

(nanometres) have a strong germicidal power against

all micro-organisms (moulds, bacteria and viruses).

Installed UV Stick (Picture 1):

A) Metal stand: painted steel base plate, with 4

swivelling wheels.

B) Control Unit: stainless steel (AISI 304), equipped

with a bipolar magneto-thermal switch, two rotary

knobs for ignition delay and treatment duration setting,

start/stop button, hour meter for UV lamps

replacement.

C) UV unit: 2 UV-lamps, protected by stainless steel

grid (AISI 304). The body is made of stainless steel

with mirror polished aluminium reflector, which

increases performance reflecting a higher percentage

of UV-C rays.

APPLICATIONS AND RESULTS

Each UV-STICK series can be installed in any type of

environment to achieve a deep disinfection of air and

surfaces, even those difficult to be reached by

traditional systems.

When turned on, there is a strong reduction of microbes

in the air and on surfaces. For example, in 8 minutes at

a distance of 3 meters, it achieves a 99% reduction of

bacteria such as: Bacillus coli, Clostridium, Legionella,

Vibrio,

Salmonella,

Pseudomonas,

Staphylococcus,

Streptococcus, etc..

Thanks to natural air circulation, even microbes located

in hidden areas are continually drawn towards the

irradiated area, so that their overall level progressively

decreases.

Usage of the UV Stick is permitted only in absence of

staff or if radiation is adequately shielded.

The device can operate during personnel break from

Pic.1

work. Timer can be used to manage the switching off

immediately before the start of work, so that workers

can have perfectly disinfected room.

Switching on and off is triggered by dedicated control unit, equipped with two timers to manage

ignition delay and treatment duration.

LIGHT PROGRESS STICK-ST [Eng.]

Rev. 2 Oct 2020 Page 5of 15

BENEFITS AND ADVANTAGES

a) DEEP AND CONTINUOUS DISINFECTION

This device can be switched on continuously without people being present (i.e. during the night for 2-3 hours).

The dis-infection of air, machinery, and everything that is contained inside the room allows beginning the work day in

ideal hygienic conditions. In this way, the level of microbial load in one site is maintained constantly low.

b) PHYSICAL ACTION AND ECOLOGICAL PROTECTION

Treatment with UV-C rays is purely physical, always allowing treatment with the same efficiency; with no danger of

overdosing. In contrast, many chemical treatment methods involve the use of products that are risky and difficult to

biodegrade, with consequent hazards to human health; besides, the use of chemical products, in contrast to UV-C

rays, could develop resistant microbial forms.

c) PRACTICALITY AND ECONOMY

Treatment is immediate and ready to use. Maintenance is minimal with low costs of both energy consumption and

maintenance.

d) IMMEDIATE EFFECT

Effective treatment (99.9% bacteria reduction) takes just a few minutes.

e) NO CHEMICAL/PHYSICAL CHANGES

Treatment is cold and dry; it causes no organoleptic or qualitative changes in the food.

f) NO DANGER OF GLASS DISPERSION

With special UVLON® protection, there is no danger of glass fragments dispersion resulting from any breakage of UV-

C lamps.

DEVICE CODES

LIGHT PROGRESS STICK-ST [Eng.]

Rev. 2 Oct 2020 Page 6of 15

ASSEMBLY

Handle with care. Verify the integrity of the packaging, and please be careful not to damage the contents when using

sharp blades or cutters to open the box.

Remove the unit from the box. Inspect it immediately to ensure that no damage has occurred during transport. Before

installation and use of the device please READ CAREFULLY THE SECURITY WARNINGS and all instructions that

follow.

For packaging and transport reasons, the entire unit

comes in two parts:

(1) metal stand with wheels, and

(2) UV unit.

It is necessary to assemble the UV unit to the base with

the supplied screw kit (Picture 2).

We recommend the following assembly procedure:

- Place the base plate vertically, like shown on

Picture 3, with semicircular side upwards. Align

the top hole with the corresponding hole on the

unit, insert the hex head screw then tighten by

hand or with the aid of a key. Repeat with the

bottom hole (Picture 4).

Pic. 2

Pic.3

Pic.4

- On the other side of the plate, insert the two hexagonal socket head cap screws into the holes at the bottom of

the control unit (Picture 5), then tighten it with the self-locking nuts (Picture. 6).

Pic.5

Pic.6

- Firmly tighten the four screws. It is now possible to place the device on its wheels in vertical position, and to

connect the power cable to the dedicated socket on the back of the control unit.

LIGHT PROGRESS STICK-ST [Eng.]

Rev. 2 Oct 2020 Page 7of 15

INSTALLATION

Take the device to the room to be disinfected, and place it in a position. In case of more than one device, you should

place them so that UV irradiation is uniformly distributed avoiding creating shaded areas.

The area/space covered by the UV-STICK devices are shown in Table 1. Final disinfection results are case

dependent on the amount of germs coming in from the external environment.

WARNING!!!

Remember to switch on the device ONLY IF there is adequate shielding and no accidental

exposure to rays by the personnel.

To avoid exposure to UV-C rays please provide a total shielding of the modules or enable the automatic OFF devices

at the entry doors in the environment treated. There must be no direct irradiation of the personnel.

To shield the devices, materials with opaque surfaces such as stainless steel or aluminium can be used, but also

transparent materials such as glass or Lexan®; to have further information please contact us.

To improve safety, we suggest you to add light signs or signboards to report the potential danger.

SCHEDULING

UV-STICK -E2/75H-ST-NX-NT

With timer for ignition delay and treatment duration setting.

Ensure Safety Glasses are worn before continuing:

Insert the plug into the wall socket and turn the device on using the switch on the back of the control unit. The green

control light of the switch will confirm the activation of main power source.

It is possible to set treatment duration and ignition delay, enabling time to comfortably step back from the device and

avoid accidental expositions to UV-C rays.

The ranges of both adjustments can vary from a minimum of a second to a maximum of 50 hours.

Two settings must be made:

A. IGNITION DELAY DURATION

(before sterilization starts)

B. TREATMENT DURATION

Proceed with the following steps: (see picture 7)

1) The desired range (scale) of the two

chronometers must be set. To set the range of the

chronometers, turn the Phillips screws located at

the bottom left on the chronometer. For ignition

delay, turn screw 1 (Delay).

For treatment duration, turn screw 2 (Timer).

2) The desired durations can now be set acting

on the setting head of each chronometer. To set

ignition delay duration, turn left setting head

(Delay).

To set treatment duration, turn right setting head

(Timer). We recommend a value between 20 min.

and 2-3 hours.

3) Once setting is completed, push the

START/STOP button to begin the program. The

button will light up and the program will start.

Fig 7

4) After the end of the cycle press START/STOP

again (the light will turn off) to finish the

operation.

12

LIGHT PROGRESS STICK-ST [Eng.]

Rev. 2 Oct 2020 Page 8of 15

ELECTRICAL CONNECTIONS

We suggest you to let a qualified electrician install this device, following these instructions and the electrical scheme, as

well as CEI norms.

Before connecting the device to the electrical line, make sure that the labelled data on the device is the same as the

ones of the electrical line; we remind you that the electrical supply power of this device is 220-240V, 50/60Hz.

Make sure that the electrical system is capable of providing the supply current required by the device (please read the

label).

The connection to the electrical line needs a multipolar switch.

The connection to the electrical line must be made by the supplied cable.

The use of junction devices in which connection is made via screws, nuts, or other means, is necessary to connect the

device to the electrical line.

Protect the power supply cable from high temperature, sharp corners, water, oils.

MAINTENANCE

USE

WEAR

UV LAMP

PROTECTIVE

GLOVES

GLASSES

Lamp maintenance is very important because the UV-C light

emitted by the source is not visible to the eye, so, although

you see the lamp ON, its germicidal effect may not be

sufficient to perform disinfection treatment.

Before reaching the lamp, ALWAYS switch off at the power supply.

If the UV-C lamp gets dirty (or dusty) clean it with a clean cloth and

alcohol. Avoid touching the glass part with hands. To check UVC

lamp life (number of hours), of the spare UV lamp please refer to

table 1(correct product code required). The lamp, once it has

reached the timing for replacement, must be replaced, this

operation is carried out as follows:

• Loosen the nuts on the lamp housing and let them slide

along the lamp; grab the lamp at the 2 ends and pull it in a

direction parallel to the lamp.

• Repeat the steps in reverse to insert the new lamp.

TROUBLESHOOTING

UV LAMP

See MAINTENANCE.

BALLAST

All UV-DIRECT models are supplied with electronic ballasts which guarantees an emission of 15% more if compared

with traditional ballasts. Furthermore, lamps are not influenced by environment temperature(<-20°C). Finally, the

switching on is immediate with no starter. For this reason, lamps last longer.

To preserve the original features of original IP protection and isolation class, and to maintain all the characteristics that

guarantee a long-lasting life of this product, the ballast replacement must be done by qualified technicians verified by

Light Progress. In case of necessity, please, send the device back to our facility for any kind of repairs.

If this is not possible, you can order the entire power supply conduit for replacement (see Table 1 for code).

LIGHT PROGRESS STICK-ST [Eng.]

Rev. 2 Oct 2020 Page 9of 15

TECHNICAL FEATURES

TABLE 1

UV-STICK

E2/75H-ST-NX-NT

AVERAGE LAMP LIFETIME (hour)*

≤ 18,000

POWER (W)

2x75

DIMENSIONS L x W x H (mm)

1420 x 404 x 336

WEIGHT (Kg)

7

TREATED AIR VOLUME (m3)

50 to 100

TREATED SURFACE (m2)

15 to 30

SPARE PARTS

UV LAMP Code

n°2

CHS-90WH

POWER SUPPLY CONDUIT Code (complete)

n°1 CE-2/75H

* continuous operation

• Selective UV-C lamp (at 253.7 nm.) with high efficiency lighting.

• Stainless steel body AISI 304.

• All materials used are tested for resistance to intense UV-C rays.

• Waterproof and dust-proof (IP 55).

• Control Console (IP 20) grounded.

• Powered with electronic ballasts specific for UV-C ray lamps.

• Reflector coated in extremely pure mirror bright aluminium.

• Direct protection of the lamp with a stainless-steel grid.

• CE mark (LVD - EMC - MD - RoHS).

• Noise: under 70 dB(A).

• Vibration: under 0.5 m/s2.

LABEL AND SYMBOLS

Warning! Check the attached

documentation

GROUND TERMINAL

(the unit must always be

connected to the ground

Device with CE certification

LIGHT PROGRESS STICK-ST [Eng.]

Rev. 2 Oct 2020 Page 10 of 15

WARRANTY

All products made by LIGHT PROGRESS are manufactured with the highest quality materials only, they are subjected

to rigorous testing, and are guaranteed to be free of factory faults according to current law and regulations.

Minimum requirements for warranty validity:

Warranty will be considered valid only in case of possession of the purchase document.

Warranty limits:

Warranty excludes:

• Damages caused by not following the instructions that accompany the product at purchase.

• Periodical controls, maintenance, repairs or replacements of parts due to normal wear.

• Consumable parts.

• Use of incompatible spare parts or consumables; Compatibility is ensured only by use of products

purchased from or recommended by Light Progress.

• Damages caused by modification of device / system without Light Progress’ previous consent.

• Improper use of the product, falling or crashes.

• Modifications or repairs made by unauthorized personnel.

For defective materials return, you must request the return merchandise authorization (RMA) sending an email to

info@lightprogress.it or calling the number +39.0575.749255.

Once you receive the module, it has to be filled up in every part and sent via email to info@lightprogress.it or via fax to

+39.0575 789929 to obtain the RMA number that will authorize the shipments of the goods to Light Progress ware-

house. Only authorized goods will be accepted, otherwise it will be refused and sent back to the sender on ex- works

conditions. The packages must be sent on DDP (Delivery Duty Paid) with packaging suitable for transport. RMA

number is valid up to 10 working days from release date.

Europe:

Loc. San Lorenzo, 40 - 52031 ANGHIARI (AR) - ITALIA

TEL. 0575 / 74.92.55 - FAX 0575 / 78.99.29

Http: www.lightprogress.it

E-mail: info@lightprogress.it

Australia / NZ:

LAF Technologies Pty Ltd

12 Royan Place

Bayswater North VIC 3132

E: [email protected].au

T: 1300 306 002

W: www.laftech.com.au

MANUFACTURER RESPONSABILITY AND COMMITMENTS

Light Progress do not take any responsibility for any damage to persons or property, due to failure to follow these

instructions. We recommend you carefully read all the given instructions before usage.

The manufacturer agrees with the buyer to provide, upon request, schemes of circuits, component parts lists,

instructions for calibration of lamps and other information, which are useful to repair those parts that the manufacturer

considers repairable.

The company reserves itself the right to make changes without prior notification or public notice.

LIGHT PROGRESS STICK-ST [Eng.]

Rev. 2 Oct 2020 Page 11 of 15

DECLARATION OF COMPLIANCE

We, LIGHT PROGRESS s.r.l., hereby declare under our own responsibility that the following units of own production:

UV-STICK E2/75H-ST-NX-NT series

are in accordance with EEC directive 2014/30/EU (Electromagnetic Compatibility)

are in accordance with EEC Machinery Directive dispositions 2006/42/EU

are in accordance with EEC Low Voltage Directive 2014/35/EU

are in accordance with EEC (RoHS) 2011/65/EU (D.Lgs 4 Marzo 2014, n.27)

TECHNICAL STANDARDS APPLIED

UNI EN ISO 12100:2010 Safety of Machinery - Basic Concepts, General Principles for Design - Risk

assessment and risk reduction

UNI EN ISO 13857:2008 Safety of Machinery - Safety Distances to prevent danger zones being reached

by the upper and lower limbs (2008)

ISO 14120:2015 Safety of Machinery - Guards - General Requirements for the Design and

construction of fixed and movable guards

UNI EN ISO 13849-1:2016 Safety of Machinery - Parts of the Control System related to the Safety – Part 1:

General Design Principles

UNI EN ISO 14119:2013 Safety of Machinery - Interlocking devices associated with guards - Principles for

design and selection

CEI EN 60204-1/2016 Safety of Machinery - Electrical Equipment of Machines. Part 1: General Rules

(2010)

EN 61439-1:2011 Low-voltage Switchgear and Control Gear Assemblies. Part 1: General rules

FURTHER TECHNICAL STANDARDS APPLIED:

IEC EN 60335-1 "Safety of household electrical appliances and similar”

Electronic Ballasts for the control of the lamps in accordance with the standard EN 60928.

Germicidal UV-C Lamps in accordance with EN 61199.

Electrical Protective Measures in accordance with IEC 70-1, EN 60229.

Anghiari, 2.7.2019

Responsible for Standards: Dr. Aldo Santi

LIGHT PROGRESS S.r.l. Loc. San Lorenzo, 40 - 52031 ANGHIARI (AR) - ITALY - http://www.lightprogress.com

LIGHT PROGRESS STICK-ST [Eng.]

Rev. 2 Oct 2020 Page 12 of 15

Circuit scheme: UV-STICK E2/75H-ST-NX-NT

LIGHT PROGRESS STICK-ST [Eng.]

Rev. 2 Oct 2020 Page 13 of 15

Notes:

____________________________________________________

LIGHT PROGRESS STICK-ST [Eng.]

Rev. 2 Oct 2020 Page 14 of 15

____________________________________________________

LIGHT PROGRESS STICK-ST [Eng.]

Rev. 2 Oct 2020 Page 15 of 15

Light Progress UV-STICK E2/75H-ST-NX-NT User manual

Popular Steriliser manuals by other brands
