LEGO® UCS AT-AT #75313 LIGHT KIT
INSTALLATION GUIDE

LEGO UCS AT-AT 75313 LIGHT KIT INSTALL GUIDE
INSTALLATION GUIDE 2
Light My Bricks
LEGO® UCS AT-AT #75313 LIGHT KIT
INSTALLATION GUIDE
Hi There!
We’re here to help you get started on the LEGO®
UCS AT-AT (75313) Light Kit.
This PDF details the instructions for the LED light kit only. If
you are wishing to purchase this product, please click here
to view the product page.
If you run into any issues, please refer to the troubleshoot-
ing section towards the end of this guide.
Have fun and enjoy!

LEGO UCS AT-AT 75313 LIGHT KIT INSTALL GUIDE
PACKAGE CONTENTS 3
PACKAGE CONTENTS: LEGO PIECES:
1 x Light My Bricks Lightsaber - Blue
2 x Rotating Bit Light 30cm
2 x Cool White 30cm Large Bit Light
1 x Flashing Red 30cm Bit Light
4 x Red 30cm Bit Light
2 x Cool White 30cm Bit Light
8 x Red 15cm Micro Bit Light *
6 x White Strip Light
1 x Red Strip Light
2 x 2-Port Expansion Board
4 x 6-Port Expansion Board*
3 x 4-Port Micro Expansion Board*
2 x Adhesive Squares
• 2 x Plate 2x4 – Black
• 3 x Plate 1x2 – Trans Red
• 2 x Round Plate 1x1 Open Stud – Light Grey
• 2 x Round Plate 1x1 Open Stud – Black
• 2 x Round Plate 1x1 – Trans Clear
• 1 x Round Plate 1x1 – Trans Red
• 2 x Round Brick 1x1 – Trans Red
• 2 x Round Tile 1x1 – Trans Red
• 2 x Bracket 1x1 – Light Grey
• 1 x Bracket 1x2-1x4 – Light Grey
• 4 x Plate 1x1 Mod Rounded w Handle – Black
• 2 x Arm Skeleton, Bent with Clips (Horizontal Grip) - Black
1 x Gun Eects Board
5 x 5cm Connecting Cable
6 x 15cm Connecting Cable
2 x 30cm Connecting Cable*
2 x 50cm Connecting Cable
1 x USB Power Cable
(Power Source not Included)
* Indicates 1 extra
component has been
included just in case!

LEGO UCS AT-AT 75313 LIGHT KIT INSTALL GUIDE
CONTENTS 4
Contents
Before You Begin 5
Blueprint 8
Instructions 9
Final Product 42
Troubleshooting 43
Contact 48

LEGO UCS AT-AT 75313 LIGHT KIT INSTALL GUIDE
BEFORE YOU BEGIN 5
Before You Begin
Laying cables in between
and underneath bricks
Cables can fit in between and underneath
LEGO® bricks, plates, and tiles providing
they are laid correctly between the
LEGO® studs. Do NOT forcefully join
LEGO® together around cables; instead
ensure they are laying comfortably in
between each stud.
CAUTION: Forcing LEGO® to connect over
a cable can result in damaging the cable
and light.
Connecting Cable
Connectors To Expansion
Boards
Take extra care when inserting connectors
to ports of Expansion Boards. Connectors
can be inserted only one way. With the
expansion board facing up, look for the
soldered “=” symbol on the left side of the
port. The connector side with the wires
exposed should be facing toward the
soldered “=” symbol as you insert into the
port. If a plug won’t fit easily into a port
connector, do not force it.
Incorrectly inserting the connector can
can result in bent pins inside the port or
possible overheating of the expansion
board when connected.

LEGO UCS AT-AT 75313 LIGHT KIT INSTALL GUIDE
BEFORE YOU BEGIN 6
Before You Begin
Connecting Cable
Connectors To Strip Lights
Take extra care when inserting connectors
to ports on the Strip Lights. Connectors
can be inserted only one way. With the
Strip Light facing up, ensure the side of
the connector with the wires exposed is
facing down. If a plug won’t fit easily into
a port connector, don’t force it. Doing so
will damage the plug and the connector.
Connecting Micro Cable
Connectors To Micro
Expansion Board Ports
Take extra care when inserting the
micro connectors to micro ports of Micro
Expansion Boards. Connecting Micro Bit
Lights to Micro Expansion Boards is similar
to connecting lights and cables to Strip
Lights. With the expansion board facing
up, ensure the side of the connector with
the wires exposed is facing down. If a plug
won’t fit easily into a port connector, do
not force it. Use your fingernail to push the
plastic part of the connector to the micro
port.

LEGO UCS AT-AT 75313 LIGHT KIT INSTALL GUIDE
BEFORE YOU BEGIN 7
Before You Begin
Installing Bit Lights Under
Lego® Bricks And Plates
When installing Bit Lights under LEGO®
pieces, ensure they are placed the correct
way up (Yellow LED component exposed).
You can either place them directly on top of
LEGO® studs or in between.

LEGO UCS AT-AT 75313 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 8
BLUEPRINT

LEGO UCS AT-AT 75313 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 9
INSTRUCTIONS
To ensure a smooth installation of
your light kit, please read and follow
each step carefully. If you run into
any issues, please refer to the online
troubleshooting guide.

LEGO UCS AT-AT 75313 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 10
1
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
Make sure to
support the head
with your hand
when removing the
red axle.

LEGO UCS AT-AT 75313 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 11
2
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON

LEGO UCS AT-AT 75313 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 12
3
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON

LEGO UCS AT-AT 75313 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 13
4
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
Black Round Plate 1x1
w/ Open Stud
Cool White 30cm Large Bit Light
2 x Plate 2x4 - Black
Black 1x1 Plate Modified Plate
Rounded w/ Handle
Black Arm Skeleton, Bent w
Clips (Horizontal Grips)

LEGO UCS AT-AT 75313 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 14
5
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
If you experience any issues with the lights not working and suspect an issue with a component, please try a dierent port on the expansion board to verify where the fault lies (with the light or
expansion board). To correct any issues with expansion board ports, please view the section addressing expansion board issues in our troubleshooting section.
6-Port Expansion Board
Black 1x1 Plate Modified Plate
Rounded w/ Handle
USB Power Cable
2x Adhesive Squares
x2
Connect the
other end to a USB
Power Bank, USB
Wall Adaptor, or USB
to AA Battery Pack
(sold separately)

LEGO UCS AT-AT 75313 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 15
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
50cm Connecting Cable
50cm Connecting Cable
2-Port Expansion Board
Please twist the
two Large Bit Light
cables.
When pulling the
50cm Connecting
Cable up the leg,
ensure the 2-Port
Expansion Board
remains located at
the ankle.

LEGO UCS AT-AT 75313 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 16
6
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
6-Port Expansion Board

LEGO UCS AT-AT 75313 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 17
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
Red 15cm Micro Bit Light

LEGO UCS AT-AT 75313 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 18
7
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
Connect the two
Micro Bit Lights from
this step and step 6
to the Micro 4-Port
Expansion Board.
Red 15cm Micro Bit Light
Micro 4-Port Expansion Board

LEGO UCS AT-AT 75313 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 19
8 9
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
Connect one
end of the 15cm
Connecting Cable
to the Micro 4-Port
Expansion Board
from step 7 and the
other end to the
6-Port Expansion
Board from step 5.
15cm Connecting Cable
LMB Blue Lightsaber

LEGO UCS AT-AT 75313 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 20
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
Place the Light
Grey Bars on top of
the 15cm Connecting
Cable, allowing at
least 5cm from the
middle of the ladder.
15cm Connecting Cable
2-Port Expansion Board
