Lightmybricks 42111 User manual

The following page is the instructions for the
Light My Bricks LEGO Dom’s
Dodge Charger (42111) LED light kit.
If you run into any issues, please refer to the
online troubleshooting guide.
To ensure a trouble
-
free installation of your light kit, please read and follow
each step carefully.
Please note: This page lists instructions for the LED light kit only.

Package Contents:
4x Warm White 30cm Large Bit Lights
2x White 30cm Bit Lights
2x Orange 30cm Bit Lights
6x White 15cm Bit Lights
1x Warm White Strip Light
1x 12-Port Expansion Board
1x 8-Port Expansion Board
1x NC Push Board
1xFlicker Effects Board
1x 5cm Connecting Cable
2x 15cm Connecting Cables
1x 30cm Connecting Cable
1x USB Power Cable
LEGO Pieces:
2x Trans Orange Round Plate 1×1

Important things to note:
Laying cables in between and underneath bricks
Cables can fit in between and underneath LEGO® bricks, plates, and tiles
providing they are laid correctly between the LEGO® studs. Do NOT forcefully
join LEGO® together around cables; instead ensure they are laying
comfortably in between each stud.
CAUTION: Forcing LEGO® to connect over a cable can result in damaging
the cable and light.
Connecting cable connectors to Expansion Boards
Take extra care when inserting connectors to ports of Expansion Boards.
Connectors can be inserted only one way. With the expansion board facing up,
look for the soldered “=” symbol on the left side of the port. The connector side
with the wires exposed should be facing toward the soldered “=” symbol as
you insert into the port. If a plug won’t fit easily into a port connector, do not
force it.

Incorrectly inserting the connector can can result in bent pins inside the
port or possible overheating of the expansion board when connected.
Connecting cable connectors to Strip Lights
Take extra care when inserting connectors to ports on the Strip Lights.
Connectors can be inserted only one way. With the Strip Light facing up,
ensure the side of the connector with the wires exposed is facing down. If a
plug won’t fit easily into a port connector, don’t force it. Doing so will damage
the plug and the connector.

Connecting Micro Cable connectors to Micro
Expansion Board Ports
Take extra care when inserting the micro connectors to micro ports of Micro
Expansion Boards. Connecting Micro Bit Lights to Micro Expansion Boards is
similar to connecting lights and cables to Strip Lights. With the expansion
board facing up, ensure the side of the connector with the wires exposed is
facing down. If a plug won’t fit easily into a port connector, do not force it. Use
your fingernail to push the plastic part of the connector to the micro port.
Installing Bit Lights under LEGO® bricks
and plates.
When installing Bit Lights under LEGO® pieces, ensure they are placed the
correct way up (Yellow LED component exposed). You can either place them
directly on top of LEGO® studs or in between.

OK, Let’s Begin!
