Calculite®HID Adjustable Accent C4T4GA-MHT4RS
Page 1 of 4 4 1/2" Aperture, T4, Ceramic Metal Halide, Glasslite, Spot
Features
1. Spot Upper Reflector: Specular faceted aluminum; provides 12° beam.
Interchangeable with 25° Narrow Flood (MHT4RNF) and 40° Flood (MHT4RF);
see spec sheets C4T4GA-MHT4RNF and C4T4GA-MHT4RF.
2. Glasslite Trim Kit: One piece borosilicate etched glass.
3. Trim Kit Adjustment Mechanism: Provides 35° vertical tilt, 360°
horizontal rotation; lockable. EZ-Aim Helical Drive System provides fast and
accurate hot aiming with Philips screwdriver.
4. Socket Housing: Galvanized steel, pre-wired with G8.5 pulse rated
socket. Snaps onto yoke for secure attachment without tools; unitized
construction assures proper alignment of lamp to optics for consistent optical
performance.
5. Frame Housing: Steel, 0.029" (22-Ga.), matte black finish. Removable cover
for top re-lamping.
6. Frame Vertical Adjustment Mechanism: Accommodates mounting to
virtually any ceiling system using pre-installed mounting bars, or 1/2" EMT
tubing (by others). Single locking feature secures all adjustments. Alignment
holes and markings allow fixture to be pre-set prior to installation. Final
adjustment can be made from below from inside fixture.
7. Mounting Bars: Galvanized steel, 0.048" (18-ga.), pre-installed telescoping
bars extend to 30" long and lock securely into position. Built-in locking tabs
provide positive attachment to common T-bar systems. Self-centering feature
simplifies installation in 24" O.C. grid systems. Attaches to steel or wood
joists without accessories.
8. Retention Springs: Rust resistant springs secure trim for quick, tool-less
installation.
9. Ballast / Cover Assembly: Accessible from below and removable without
tools for inspection and ballast replacement .
10.Junction Box: 0.059" (16-ga.) galvanized steel. UL listed for 8 No. 12 AWG,
90° C through branch circuit conductors. Allows inspection from below.
11. Accessory Holder: Sold separately catalog # CAH4; die-formed steel,
matte black finish, slide-in installation. Accepts up to two 3 3/4" dia. media.
Features (continued)
12.Thermal Protector: (Not Shown) Meets NEC and UL requirements. Do not
install insulation above nor within 3" (76mm) of any part of the luminaire.
Electrical
Electronic Ballast: 120 or 277V, 50/60 Hz., encased, high power factor, T.H.D.
<15%, thermally and transient protected, RMI/RFI complies with FCC Part 18
non-consumer limits, shut-down circuit at end of lamp life, sound rating “A”, -5°F
minimum starting temperature, Type 1 Outdoor rating.
Ballast ANSI Code Voltage Max. Amps Input Watts
20W MH M156 120/277 0.21/0.10 23
39W MH M130 120/277 0.39/0.17 44
70W MH M139 120/277 0.67/0.29 78
Options and Accessories
Chicago Plenum: Consult Factory
Labels
UL (Suitable for Wet Locations), CSA, I.B.E.W.
Spot
Upper Reflector
For Complete Fixture Order: Glasslite Trim Kit + Spot Upper Reflector (MHT4RS) + Frame-In Kit. Each Sold Separately.
Glasslite Trim Kit + Spot Upper Reflector Frame-In Kit Lamping (Ceramic Metal Halide)
C4T4GA +MHT4RS (Spot Upper Reflector)
Etched glass, with matching flange.
C4A20BT5PGJ5E1
C4A20T4GU65EU
C4A20T4EU
C4A39T4GU65EU
C4A39T4E1
C4A39T4E2
C4A70T4E1
C4A70T4E2
Electronic 120V
Electronic 120V/277V
Electronic 120V/277V
Electronic 120V/277V
Electronic 120V
Electronic 277V
Electronic 120V
Electronic 277V
22W Philips MiniMasterColor
20W GE ConstantColor
20W T4.5
39W Philips MiniMasterColor
39W T4.5
39W T4.5
70W T4.5
70W T4.5
Ceiling Cutout: 5 1/8” (130mm) Dia.

Job Information Type:
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2011 Philips Group • C0711
Calculite®HID Adjustable Accent C4T4GA-MHT4RS
Page 2 of 4 4 1/2" Aperture, T4.5, Ceramic Metal Halide, Glasslite, Spot
(FC) is initial footcandles at center of
beam. Beam length (L) and beam width
(W) are to where the candlepower is
reduced to 50% of the center beam can-
dlepower. (C) is the distance to the center
of the beam.
5,500
2,750
8,250
11,000 30°
60°
10,000
5,000
15,000
20,000 30°
60°
7,500
15,000
22,500
30,000 30°
60°
30° Aiming Angle
Horizontal Surface
D C FC L W
8' 4.6' 300 2.6' 2.3'
10' 5.8' 192 3.3' 2.8'
12' 6.9' 133 3.9' 3.4'
15' 8.7' 85 4.9' 4.3'
20' 11.5' 48 6.6' 5.7'
30° Aiming Angle
Vertical Surface
D C FC L W
3' 5.2' 411 3.1' 1.5'
4' 6.9' 231 4.1' 2.0'
6' 10.4' 103 6.2' 2.9'
8' 13.9' 58 8.2' 3.9'
12' 20.8' 26 12.3' 5.9'
30° Aiming Angle
Vertical Surface
D C FC L W
2' 3.5' 338 1.9' 0.9'
3' 5.2' 150 2.8' 1.4'
4' 6.9' 85 3.8' 1.8'
6' 10.4' 38 5.7' 2.7'
8' 13.9' 21 7.6' 3.6'
ANGLE WALL
0 22
5 41
10 127
15 216
20 1007
25 5286
30 10820
35 7757
40 4435
45 1178
50 187
55 41
60 10
65 5
70 0
75 0
80 0
85 0
90 0
30° Aiming Angle
Horizontal Surface
D C FC L W
8' 4.6' 207 2.4' 2.1'
10' 5.8' 133 3.1' 2.6'
12' 6.9' 92 3.7' 3.2'
15' 8.7' 59 4.6' 3.9'
20' 11.5' 33 6.1' 5.3'
30° Aiming Angle
Vertical Surface
D C FC L W
3' 5.2' 284 2.8' 1.4'
4' 6.9' 160 3.8' 1.8'
6' 10.4' 71 5.7' 2.7'
8' 13.9' 40 7.6' 3.6'
12' 20.8' 18 11.4' 5.5'
ANGLE WALL
0 72
5 101
10 236
15 541
20 2073
25 8817
30 20419
35 18264
40 6846
45 1609
50 365
55 84
60 36
65 24
70 19
75 12
80 7
85 0
90 0
ANGLE WALL
0 127
5 216
10 619
15 1507
20 5042
25 15782
30 29566
35 24248
40 11359
45 4236
50 1253
55 231
60 67
65 30
70 15
75 15
80 0
85 0
90 0
AIMED 30 deg. TOWARD WALL
LAMP: T4.5 CERAMIC MH, PHILIPS
LUMEN RATING: 6200 LMS.
CBCP: 29566
Beam Angle: 14
AROMAT ELECTRONIC BALLAST 70W
DATE: APR 2, 2004
CERTIFIED TEST REPORT NO. 18682
COMPUTED BY LSI PROGRAM
**TEST-LITE**
AIMED 30 deg. TOWARD WALL
LAMP: T4.5 CERAMIC MH, PHILIPS
LUMEN RATING: 3400 LMS.
CBCP: 20419
Beam Angle: 13
AROMAT ELECTRONIC BALLAST 39W
DATE: APR 13, 2004
CERTIFIED TEST REPORT NO. 18681
COMPUTED BY LSI PROGRAM
**TEST-LITE**
AIMED 30 deg. TOWARD WALL
LAMP: T4.5 CERAMIC MH, GE
LUMEN RATING: 1700 LMS.
CBCP: 10820
Beam Angle: 13
AROMAT ELECTRONIC BALLAST 20W
DATE: APR 2, 2004
CERTIFIED TEST REPORT NO. 18680
COMPUTED BY LSI PROGRAM
**TEST-LITE**
30° Aiming Angle
Horizontal Surface
D C FC L W
6' 3.5' 195 1.8' 1.6'
8' 4.6' 110 2.4' 2.1'
10' 5.8' 70 3.1' 2.6'
12' 6.9' 49 3.7' 3.2'
15' 8.7' 31 4.6' 3.9'
20W T4.5 Ceramic MH, Spot Upper Reflector
39W T4.5 Ceramic MH, Spot Upper Reflector
70W T4.5 Ceramic MH, Spot Upper Reflector

Job Information Type:
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2011 Philips Group • C0711
Calculite®HID Adjustable Accent C4T4GA-MHT4RS
Page 3 of 4 4 1/2" Aperture, PGJ5, Glasslite, 12° Spot
14000
10500
7000
3500
3500
7000
10500
14000
30°
60°
20000
15000
10000
5000
5000
10000
15000
20000
30°
60°
Angle Wall
0 29
5 88
10 150
15 475
20 2178
25 8393
30 14663
35 7790
40 1764
45 270
50 39
55 0
60 0
65 0
70 0
75 0
80 0
85 0
90 0
Angle Wall
0 70
5 158
10 338
15 920
20 3814
25 12439
30 18781
35 10694
40 3279
45 659
50 110
55 20
60 6
65 0
70 0
75 0
80 0
85 0
90 0
Certified Test Report No. 3952FR, Date: Oct 16, 2008. Computed by LSI Program **Test-Lite**
Certified Test Report No. 3943FR, Date: Oct 16, 2008. Computed by LSI Program **Test-Lite**
22W PGJ5 Philips MiniMastercolor CMH Lamp, Spot Upper Reflector, Lumen Rating = 1650 lms, Aromat Electronic Ballast
39W PGJ5 Philips MiniMastercolor CMH Lamp, Spot Upper Reflector, Lumen Rating = 3000 lms, Aromat Electronic Ballast
30° Aiming Angle
Horizontal Surface
D C FC L W
6' 3.5' 265 1.5' 1.3'
8' 4.6' 149 2.1' 1.8'
10' 5.8' 95 2.6' 2.2'
12' 6.9' 66 3.1' 2.7'
15' 8.7' 42 3.9' 3.3'
30° Aiming Angle
Vertical Surface
D C FC L W
2' 3.5' 458 1.6' 0.8'
3' 5.2' 204 2.4' 1.2'
4' 6.9' 115 3.2' 1.5'
6' 10.4' 51 4.8' 2.3'
8' 13.9' 29 6.3' 3.1'
30° Aiming Angle
Horizontal Surface
D C FC L W
6' 3.5' 339 1.8' 1.6'
8' 4.6' 191 2.4' 2.1'
10' 5.8' 122 3.1' 2.6'
12' 6.9' 85 3.7' 3.2'
15' 8.7' 54 4.6' 3.9'
30° Aiming Angle
Vertical Surface
D C FC L W
2' 3.5' 587 1.9' 0.9'
3' 5.2' 261 2.8' 1.4'
4' 6.9' 147 3.8' 1.8'
6' 10.4' 65 5.7' 2.7'
8' 13.9' 37 7.6' 3.6'

Job Information Type:
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2011 Philips Group • C0711
Calculite®HID Adjustable Accent C4T4GA-MHT4RS
Page 4 of 4 4 1/2" Aperture, GU6.5, Glasslite, 12° Spot
7500
2500
10000
5000
2500
5000
7500
10000
30°
60°
4000
8000
12000
16000
4000
8000
12000
16000
30°
60°
Angle Wall
0 35
5 92
10 140
15 366
20 1370
25 4948
30 10563
35 5981
40 1176
45 92
50 6
55 0
60 0
65 0
70 0
75 0
80 0
85 0
90 0
Angle Wall
0 99
5 202
10 395
15 1000
20 3493
25 10288
30 17013
35 9277
40 2510
45 361
50 82
55 28
60 14
65 14
70 0
75 0
80 0
85 0
90 0
Certified Test Report No. 3956FR, Date: Oct 16, 2008. Computed by LSI Program **Test-Lite**
Certified Test Report No. 3944FR, Date: Oct 16, 2008. Computed by LSI Program **Test-Lite**
20W GU6.5 GE Constantcolor CMH Lamp, Spot Upper Reflector, Lumen Rating = 1615 lms, Aromat Electronic Ballast
39W GU6.5 GE Constantcolor CMH Lamp, Spot Upper Reflector, Lumen Rating = 3400 lms, Aromat Electronic Ballast
30° Aiming Angle
Horizontal Surface
D C FC L W
6' 3.5' 191 1.4' 1.2'
8' 4.6' 107 1.9' 1.6'
10' 5.8' 69 2.3' 2.0'
12' 6.9' 48 2.8' 2.4'
15' 8.7' 30 3.5' 3.0'
30° Aiming Angle
Vertical Surface
D C FC L W
2' 3.5' 330 1.4' 0.7'
3' 5.2' 147 2.1' 1.0'
4' 6.9' 83 2.9' 1.4'
6' 10.4' 37 4.3' 2.1'
8' 13.9' 21 5.7' 2.8'
30° Aiming Angle
Horizontal Surface
D C FC L W
6' 3.5' 307 1.7' 1.5'
8' 4.6' 173 2.3' 1.9'
10' 5.8' 111 2.8' 2.4'
12' 6.9' 77 3.4' 2.9'
15' 8.7' 49 4.2' 3.6'
30° Aiming Angle
Vertical Surface
D C FC L W
2' 3.5' 532 1.7' 0.8'
3' 5.2' 236 2.6' 1.3'
4' 6.9' 133 3.5' 1.7'
6' 10.4' 59 5.2' 2.5'
8' 13.9' 33 7.0' 3.4'
