HDMI-TP-TX50
Quick Start Guide
Introduction
The HDMI-TP-TX50 is a CAT5, CAT6 and CAT7 Twisted Pair cable transmitter supporting
HDCP encryption and HDMI 1.3a compliant signals.
Typical application
HDMI-TP-TX50 and RX extender pair
Installation
1. Connect the source (e.g. computer) to the HDMI INPUT connector,
2. Connect the receiver or a compatible Lightware device
1
to the
a. VIDEO OUT with a Twisted Pair cable
b. DDC OUT with another Twisted Pair cable
3. Supply the unit with +12V 1A DC. The available power supply settings:
TX jumper configuration
RX jumper or Matrix Input Board configuration
only local adaptor
only local adaptor
local adaptor + remote send to RX
only remote receive from TX
only remote receive from RX
local adaptor + remote send to TX
only local adaptor
12V DC IN not connected to Input Board
only remote receive from Input Board
12V DC IN connected to Input Board
Status LED
Connected power source is indicated by the front panel LED.
1
Please check the TP Extension System Cross Compatibility Table in the www.lightware.eu website
HDMI-TP-TX50 front view
HDMI-TP-TX50 back view
Locking DC plug: Twist 90° clockwise to lock
Maximum cable length
Resolution
TMDS Freq
CAT5e UTP
CAT6 UTP
CAT6 S/FTP
CAT7 S/FTP
640 x 480
25,2 MHz
65 m
75 m
80 m
80 m
800 x 600
40,0 MHz
65 m
70 m
75 m
75 m
1024 x 768
65,0 MHz
60 m
65 m
75 m
75 m
1280 x 720p
74,4 MHz
60 m
65 m
75 m
75 m
1920 x 1080i
74,4 MHz
60 m
65 m
75 m
75 m
1280 x 1024
108,2 MHz
50 m
65 m
70 m
70 m
1920 x1080p
149,1 MHz
30 m
55 m
65 m
65 m
1920 x 1200
153,4 MHz
20 m
50 m
65 m
65 m
1600 x 1200
162,4 MHz
NR
45 m
65 m
65 m
1920 x 1080p 30 bit
186,3 MHz
NR
NR
40 m
60 m
1920 x 1080p 36 bit
223,6 MHz
NR
NR
10 m
20 m
NR: Not Recommended

Typical application diagram with Lightware Matrix IO boards
Power managment of HDMI-TP-TX50 and RX50 devices
