Section - B5 - 40C
Form 404253
jULY - 2011
MODEL 1335
TRANSFER PUMP LEVER ACTION
OWNER/OPERATOR RESPONSIBILITY
It is the owner/operator responsibility to properly use
and maintain this equipment.
The instructions and warnings contained in this manual
shall be read and understood by the owner/operator
prior to operating this equipment.
If an owner/operator does not understand english, the
contents of this manual shall be explained in the owner/
operator native language to assure the owner/operator
comprehends.
It is the owner/operator responsibility to maintain the leg-
ibility of all warning and instruction labels.
DESCRIPTION
Suitable to pump diesel fuel, lubricating oils up to SAE
140 (@ 70°F) and other non-corrosive uids.
Supplied with 1.8m (6 ft) delivery hose and metal nozzle.
Variable handle setting for light or heavy uids.
Telescopic suction tube ts 60 liter (16 us gal) and 205
liter (55 us gal) drums. Convenient bung opener cast on
pump head.
The owner/operator shall retrain this manual for future
reference to important warnings, operating and mainte-
nance instructions.
SPECIFICATIONS
Output approximately .26 quart (250ml)\ stroke.
Not for use with gasoline or other amable liquids.
©
© Indicates change
The 1335 is a multi-uid pump that contains the following
wetted components:
1. Aluminum (Pump Head)
2. Steel (Suction tube, pump body, handle)
3. Brass (Rings in pump head)
4. Viton(O Ring in Suction Tube)
5. PTFE (Under Gland Nut)
This close tolerance pump works with non corrosive uids
such as:
•Motor oil
•Transmission uid
•Gear oil
•Engine coolant / Anti-Freeze (Alcohol Base)
•Engine coolant / Anti-Freeze (Glycol Base/
Prestone®Etc.)
•Denatured Alcohol Ethanol and denaturant
•Diesel Oil (Fuel ASTM #2) Hydrocarbons
•Fuel Oils (ASTM #1 thru #9) Hydrocarbons
•Glycols
•HexyleneGlycol (Brake Fluid)
•Hydraulic Oil (Petroleum Base) Hydrocarbons
•Lubricating Oils (Petroleum) Hydrocarbons
•Naphtha (Petroleum Spirits) (Thinner)
Petroleum fractions
•Silicone Oils
•Linseed Oil (Flaxseed Oil) Glycerides
•Mineral Oil (Petroleum) Hydrocarbons
The multi-position handle design allows easy adjustment when
moving from light to heavy viscous uids.
For a more detailed list, see chart on page 4.
©
©

Page Number - 2 Form 404253
FIG. 1
Item Part Description
1 273734 Kit, Barrel
2 273735 Kit, Plunger
3 273736 Kit, Handle
4 273737 Kit, Plunger Rod
5 273738 Kit, Packing
6 273739 Kit, Hose
PARTS REQUIRED

Page Number - 3
Form 404253
FAILURE TO HEED THE FOLLOWING WARNINGS INCLUDING MISUSE, MODIFYING PARTS, USING INCOMPATIBLE
CHEMICALS AND FLUIDS, OR USING WORN OR DAMAGED PARTS, MAY RESULT IN EQUIPMENT DAMAGE AND/OR
SERIOUS PERSONAL INJURY, FIRE, EXPLOSION, OR PROPERTY DAMAGE.
• Do not alter or modify any part of this equipment.
• Make sure the pump and all other equipment used or Located in the pumping area are grounded.
• Do not use the pump if any static sparking or electrical shock occurs. Stop pumping immediately and do not use the
pump until the problem is corrected.
• Make sure all uid connections are securely tightened before using this equipment.
• Always read and follow the uid manufacturers recommendations regarding uid compatibility, and the use of protective
clothing and equipment.
• Check all equipment regularly and repair or replace worn or damaged parts immediately.
TROUBLESHOOTING
TROUBLE CAUSE REMEDY
Hard to pump. A. Gland Nut is screwed down too tight. A. Adjust Gland Nut.
B. Handle is positioned in the wrong setting for heavy uid. B. Adjust Handle Position (See Fig. 2).
C. Bent Piston Rod. Replace Piston Rod and Piston Assembly.
Pump fails to prime. A. Footvalve ball is not sealing. A. Remove and clean footvalve. Reassemble the
footvalve using Pipe Sealant on Threads.
B. Piston Valve is damaged and is not seating. B. Replace Piston and Piston Rod Assembly.
C. O-Ring is not sealing. C. Replace O-Ring.

Page Number - 4 Form 404253
COMPATIBLE YES or NO
LIQUID LIQUID
ACETONE NO GLYCERINE YES
AMLY ALCOHOL NO GLYCOLS YES
BENZENE YES HYDRAULIC OIL (MINERAL) YES
BENZYL ALCOHOL YES ISOBUTYL ALCOHOL YES
BUNKER OIL YES ISO-OCTANE YES
BUTYL ALCOHOL YES ISOPROPYL ALCOHOL YES
CASTER OIL YES KEROSENE YES
CREOSOTE YES LINSEED OIL YES
CRESOL YES LUBRICATING OIL (MINERAL) YES
CYCLOHEXANE YES METHYL ALCOHOL NO
CYCLOHEXANOL YES METHYLBUTYL KETONE NO
CYCLOHEXANONE NO METHYL ETHYL KETONE
(MEK)
NO
DENATURED ALCOHOL YES METHYL ISOBUTYL KETONE NO
DETERGENT YES MINERAL OIL YES
DEVELOPING FLUID YES MONOCHLOROBENZE NE YES
DIESEL OIL YES OCTYL ALCOHOL YES
DIETHYL BENZENE YES PAINT THINNER (DUCO) YES
DIETHYLENE GLYCOL YES PETROL YES
DI-ISOBUTYLENE YES PHENOL YES
DI-ISOPROPYL BENZENE YES PROPYL ALCOHOL YES
DI-ISOPROPYL KETONE NO SILICONE OILS YES
DIOCTYL PHTHALATE YES SOAP SOLUTIONS YES
DRY CLEANING FLUID YES TERTIARY BUTYL ALCOHOL YES
ETHYL ALCOHOL YES TOLUENE YES
ETHYL BENZENE YES TRANSFORMER OIL YES
ETHYLENE GLYCOL YES TRANSMISSION FLUID YES
FLUOROBENZENE YES TRICHLOROETHANE YES
FLUOROCARBON OILS NO TRICHLOROETHYLENE YES
FLUORINATED CYCLIC
ETHERS
NO TURBINE OIL YES
FUEL OIL YES TURPENTINE YES
Note: Use of this equipment to pump other than approved
uids can and will void the manufacturer warranty.

Page Number - 5
Form 404253
Americas:
One Lincoln Way
St. Louis, MO 63120-1578
USA
Phone [phone]
Fax [phone]
Europe/Africa:
Heinrich-Hertz-Str 2-8
D-69183 Walldorf
Germany
Phone [phone]
Fax [phone]
© Copyright 2004
Printed in USA
Web site:
www.lincolnindustrial.com
Lincoln Industrial Standard Warranty
LIMITED WARRANTY
Lincoln warrants the equipment manufactured and supplied by Lincoln to be free from defects in material and workmanship for a period of
one (1) year following the date of purchase, excluding therefrom any special, extended, or limited warranty published by Lincoln. If equipment is
determined to be defective during this warranty period, it will be repaired or replaced, within Lincoln’s sole discretion, without charge.
This warranty is conditioned upon the determination of a Lincoln authorized representative that the equipment is defective. To obtain repair
or replacement, you must ship the equipment, transportation charges prepaid, with proof of purchase to a Lincoln Authorized Warranty and Service
Center within the warranty period.
This warranty is extended to the original retail purchaser only. This warranty does not apply to equipment damaged from accident, overload,
abuse, misuse, negligence, faulty installation or abrasive or corrosive material, equipment that has been altered, or equipment repaired by anyone
not authorized by Lincoln. This warranty applies only to equipment installed, operated and maintained in strict accordance with the written
specications and recommendations provided by Lincoln or its authorized eld personnel.
THIS WARRANTY IS EXCLUSIVE AND IS IN LIEU OF ANY OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT
LIMITED TO, THE WARRANTY OF MERCHANTIBILITY OR WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE. WARRANTY ON
ITEMS SOLD BY LINCOLN, BUT NOT MANUFACTURED BY LINCOLN ARE SUBJECT TO THE WARRANTY CONSIDERATION, IF ANY, OF
THEIR MANUFACTURER (SUCH AS HOSES, HYDRAULIC AND ELECTRIC MOTORS, ELECTRICAL CONTROLLERS, ETC.) ASSISTANCE
IN MAKING SUCH WARRANTY CLAIMS CAN BE OFFERED AS REQUIRED.
In no event shall Lincoln be liable for incidental or consequential damages. Lincoln’s liability for any claim for loss or damages arising out
of the sale, resale or use of any Lincoln equipment shall in no event exceed the purchase price. Some jurisdictions do not allow the exclusion or
limitation of incidental or consequential damages, therefore the above limitation or exclusion may not apply to you.
This warranty gives you specic legal rights. You may also have other rights that vary by jurisdiction.
Customers not located in the Western Hemisphere or East Asia: Please contact Lincoln GmbH & Co. KG, Walldorf, Germany, for your warranty
rights.
Lincoln Industrial Special Limited Warranties
SPECIAL LIMITED 2 YEAR WARRANTY-
SL-V Series, Single Injectors-85772, 85782, and Replacement Injectors-85771, 85781
Lincoln warrants the SL-V Injector series to be free from defects in material and workmanship for two (2) years following the date of purchase. If an
injector model (single or replacement) is determined to be defective by Lincoln, in its sole discretion, during this warranty period, it will be repaired
or replaced, at Lincoln’s discretion, without charge.
SPECIAL LIMITED 5 YEAR WARRANTY-
Series 20, 25, 40 Bare Pumps, PMV Bare Pumps, Heavy Duty and 94000 Series Bare Reels
Lincoln warrants series 20, 25, 40 bare pumps, PMV bare pumps, Heavy Duty (82206), Mini Bench (81133, 81323), and all 94000 LFR series (single
arm and dual arm) bare reels to be free from defects in material and workmanship for ve (5) years following the date of purchase. If equipment
is determined by Lincoln, in its sole discretion, to be defective during the rst year of the warranty period, it will be repaired or replaced at Lincoln’s
discretion, without charge. In years two (2) and three (3), the warranty on this equipment is limited to repair with Lincoln paying parts and labor
only. In years four (4) and ve (5), the warranty on this equipment is limited to repair with Lincoln paying for parts only.
SPECIAL LIMITED 5 YEAR WARRANTY-
LFM Series Oil Meters (Lincoln Fluid Meter), LFV (Lincoln Fluid Valves), AOD (Air-Operated Diaphragm Pumps)-
Lincoln warrants the LFM meter series (908/912 series), the Lincoln Fluid valve (708/712 series), our Universal Inline Digital Meters (812/813
series), and our AOD Pump offering to be free from defects in material and workmanship for ve (5) years following the date of purchase. If either
is determined to be defective by Lincoln, in its sole discretion, during the warranty period, they will be repaired or replaced, at Lincoln’s discretion,
without charge.
Special DEF (Diesel Exhaust Fluid) Limited Warranty-
DEF products are warranted to be free from defects in material and workmanship for a period of one (1) year following the date of purchase.
The following exceptions to the standard warranty period are in effect-
-85700-30/85700-50 DEF hose reels (bare reel only), 277251/277252 AC DEF pumps, and 277256 and 277257 DEF meters are warranted for
two (2) years from date of purchase,
-85623 DEF AOD (air operated diaphragm) pumps are covered under the standard ve (5) year AOD pump warranty.
If either is determined to be defective by Lincoln, in its sole discretion, during the warranty period, they will be repaired or replaced, at Lincoln’s
discretion, without charge.
