Release Notes for SPA942 and SPA962 IP Phones Firmware Version 6.1.3 1
Release Notes
Release Notes for SPA942 and SPA962 IP
Phones Firmware Version 6.1.3
September 2008
These Release Notes describe the new features and enhancements in the
SPA942 and SPA962 firmware version 6.1.3.
Contents
This document includes the following topics:
•“Changes Since SPA942 and SPA962 Firmware Version 5.2.8,” on page1
•“Related Documentation,” on page 6
•“Downloading the Firmware,” on page 6
•“Technical Support,” on page 6
Changes Since SPA942 and SPA962 Firmware Version 5.2.8
New features were added, and problems were fixed.
New Features
The following new features were added.
•Secure Real Time Protocol (SRTP) enhancements for secure calling
The security methods for VoIP calls were enhanced to incorporate a standard
base SRTP Key Negotiation called Security Description (RFC 4568).

Release Notes for SPA942 and SPA962 IP Phones Firmware Version 6.1.3 2
Release Notes
•Contact header in 18X messages for Application Server features
The Contact Header is now included in all 18X messages. This enhancement
improves the interoperability of the phones with Application Server features
that use the contact header to identify the endpoint interaction.
•Busy display information for 486 Busy Here message
This feature enables the phone to display the word “Busy” when receiving a
486 Busy Here message as response to an INVITE.
•VLAN and priority tagging on phone data port (802.1p/q)
This feature facilities tagging of the VLAN ID (802.1Q) and priority bits (802.1p)
of the traffic coming from the PC port of the SPA9x2 phone. Three new
parameters are included with the feature:
Parameter Description
<Enable_PC_Port_VLAN_Tagging> Yes/No (default No). Enables or disables
the tagging algorithm.
<PC_Port_VLAN_ID> 0-4095 (default 0). Value of the VLAN ID.
The phone tags all the untagged frames
coming from the PC (it will not tag frames
with an existing tag).
<PC_Port_VLAN_Highest_Priority> 0-7 (default 0). The priority applied to all
frames, tagged and untagged. The phone
modifies the frame priority only if the
incoming frame priority is higher than this
value.

Release Notes for SPA942 and SPA962 IP Phones Firmware Version 6.1.3 3
Release Notes
•LDAP Corporate Directory Search
The SPA9x2 phones now incorporate the LDAPv3 Corporate Directory Search
Menu as in other Cisco Phones to enable the retrieval of directory information
based on LDAP, an Active Directory Technology. SPA9x2 phones support the
following parameters:
Parameter Description
<LDAP_Dir_Enable> Yes/No (default No). Enables the LDAP
functionality.
<LDAP_Corp_Dir_Name> String (default is Corporate Directory). The
name of the Service to be displayed in the
Directory menu when LDAP Corporate
directory is active.
<LDAP_Server> String (default blank). Server address or
name. Can be an IP address or FQDN.
<LDAP_Port> String (default blank). Server port. If blank,
the default LDAP port will be selected.
<LDAP_Search_Base> String (default blank). LDAP Search base
object according to LDAP specifications.
<LDAP_Username> String (default blank). Username of the
LDAP database.
<LDAP_Password> String (default blank). User Password of the
LDAP database.
<Last_Name_Filter> String (default blank). Last Name search
filter, according to LDAP specification.
<First_Name_Filter> String (default blank). First Name search
filter, according to LDAP specification.
<Search_item_3_Name> String (default blank). Name to be displayed
on the Phone-Corporate Directory-
Advanced Search menu. If blank, this option
is not displayed.
<Search_item_3_Filter> String (default blank). Item 3 search filter,
according to LDAP specification.

Release Notes for SPA942 and SPA962 IP Phones Firmware Version 6.1.3 4
Release Notes
•Attended transfer enhancements
The SPA9x2 phones now support the transfer of a call that is on hold.
•Programmable line keys
Idle line keys on the SPA942 and SPA962 can be used for Busy Lamp Field,
Speed Dial, and Call Pickup functions, as described below.
•Busy Lamp Field: The line button is used to monitor activity on another
station. The LED indicates the line status:
-Red: Busy
-Red Fast Blink: Ringing
-Amber: Failed to subscribe (received 4xx response)
-Amber Slow Blink: Undefined (may be no response to subscribe, or BLF
not specified)
•Call Pickup: The user can press the line button to answer a call that is
ringing on the other station. This feature is available only when BLF is
enabled.
<Search_Item_4_Name> String (default blank). Name to be displayed
on the Phone-Corporate Directory-
Advanced Search menu. If blank, this option
is not displayed.
<Search_Item_4_Filter> String (default blank). Item 4 search filter,
according to LDAP specification.
<Display_Name_Attributes> String (default blank). Attributes to be
returned for each record in the database.
<Number_Attributes> Comma separated list (default blank).
Attributes to be returned for each record in
the database.
<Number_mapping> Dial plan (default blank). Similar to the
incoming caller ID map option. Used for
mapping the format of the number in the
database to a telephone number that can be
processed by the phone or network.
Parameter Description

Release Notes for SPA942 and SPA962 IP Phones Firmware Version 6.1.3 5
Release Notes
•Speed Dial: The user can press the line button to place a call to the other
station.
To program a line key:
a. Start Internet Explorer, and enter the IP address of the phone. Click the
Admin Login link and then click advanced.
b. Click the Phone tab.
c. Find the Line Key that you want to configure, such as Line Key 1. Enter the
following settings:
-From the Extension drop down list, choose Disabled.
-From the Share Call Appearance drop-down list, choose shared.
-Enter the rule in the Extended Function field, as described below.
SYNTAX: fnc=type;sub=stationname@$PROXY;ext=extension#
@$PROXYvid=#
Example 1: Busy Lamp Field and Speed Dial:
fnc=blf+sd+cp;sub=Accounting@$PROXYext=103@$PROXY
In this example, the line key is programmed as a shared line with extension
103, Accounting. The button can be used for Busy Lamp Field, speed dial,
and call pickup.
•Configuration of missed call display per extension
The user can configure the missed call log function for each extension, to avoid
collecting unneeded missed call messages for shared lines. This option is
found on the Phone > User tab of the Web UI. The Log Missed Calls for EXT N
field can be set to Ye s (missed calls are displayed) or No (missed calls are not
displayed).
Other Updates
The following problems were fixed in firmware version 6.1.3:
•One-way audio between SPA phones with different firmware versions
(CSCsr86185)

Release Notes for SPA942 and SPA962 IP Phones Firmware Version 6.1.3 6
Release Notes
•Omission of user parameters from the TO and FROM headers (CSCsu42465)
•Improper decoding of early media, such as ring tone (CSCsu25715)
Known Issues
•In some instances, inband DTMF may not be recognized correctly when the
speakerphone is in use. If an interactive voice response menu is not responding
as expected to the keys that a user is pressing, the user can press the Mute
button to avoid this issue. (CSCsm85917)
Related Documentation
For more information, refer to the following documents:
•SPA9000 Voice System Administration Guide
•SPA Phone Administration Guide
•SPA Phone User Guide
For these documents and more, visit the following URL:
www.cisco.com/go/smallbiz
Downloading the Firmware
To obtain current firmware for Cisco Small Business and Small Business Pro
products, visit the following URL:
www.cisco.com/go/smallbiz
Technical Support
To obtain current support contact information for Cisco Small Business and Small
Business Pro products, visit the following URL:
www.cisco.com/go/smallbiz
